Fluidwell F112-P User manual

F112-P
FLOWRATE INDICATOR / TOTALIZER
WITH LINEARISATION
Signal input flowmeter: pulse, Namur and coil.
Signal outputs: (0)4-20mA / 0-10V ref. flowrate and pulse ref. total.
Options: Intrinsically Safe, Modbus communication, external reset and
backlight.
F-Series - Field mounted indicators for safe and hazardous areas. More info: www.fluidwell.com/fseries

HF112PEN_v0501_04
Page 2
SAFETY INSTRUCTIONS
Any responsibility is lapsed if the instructions and procedures as described in this
manual are not followed.
LIFE SUPPORT APPLICATIONS: The F112-P is not designed for use in life support
appliances, devices, or systems where malfunction of the product can reasonably be
expected to result in a personal injury. Customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify the
manufacturer and supplier for any damages resulting from such improper use or sale.
Electro static discharge does inflict irreparable damage to electronics! Before installing
or opening the unit, the installer has to discharge himself by touching a well-grounded
object.
This unit must be installed in accordance with the EMC guidelines (Electro Magnetic
Compatibility).
Do connect a proper grounding to the aluminum casing as indicated if the F112-P has
been supplied with the 115-230V AC power-supply type PM. The green / yellow wire
between the back-casing and removable terminal-block may never be removed.
Intrinsically Safe applications: follow the instructions as mentioned in Chapter 5 and
consult “Fluidwell F1..-..-XI - Documentation for Intrinsic Safety”.
DISPOSAL
At the end of its life this product should be disposed of according to local regulations regarding
waste electronic equipment. If a battery is present in this product it should be disposed of
separately. The separate collection and recycling of your waste equipment will help to conserve
natural resources and ensure that it is recycled in a manner that protects the environment.
SAFETY RULES AND PRECAUTIONARY MEASURES
The manufacturer accepts no responsibility whatsoever if the following safety rules and
precautions instructions and the procedures as described in this manual are not followed.
Modifications of the F112-P implemented without preceding written consent from the
manufacturer, will result in the immediate termination of product liability and warranty period.
Installation, use, maintenance and servicing of this equipment must be carried out by authorized
technicians.
Check the mains voltage and information on the manufacturer's plate before installing the unit.
Check all connections, settings and technical specifications of the various peripheral devices
with the F112-P supplied.
Open the casing only if all leads are free of potential.
Never touch the electronic components (ESD sensitivity).
Never expose the system to heavier conditions than allowed according to the casing
classification (see manufacture's plate and chapter 4.2.).
If the operator detects errors or dangers, or disagrees with the safety precautions taken, then
inform the owner or principal responsible.
The local labor and safety laws and regulations must be adhered to.

HF112PEN_v0501_04
Page 3
ABOUT THE OPERATION MANUAL
This operation manual is divided into two main sections:
The daily use of the unit is described in chapter 2 "Operation". These instructions are meant for
users.
The following chapters and appendices are exclusively meant for electricians/technicians. These
provide a detailed description of all software settings and hardware installation guidance.
This operation manual describes the standard unit as well as most of the options available. For
additional information, please contact your supplier.
A hazardous situation may occur if the F112-P is not used for the purpose it was designed for
or is used incorrectly. Please carefully note the information in this operating manual
indicated by the pictograms:
A "warning" indicates actions or procedures which, if not performed correctly, may lead to
personal injury, a safety hazard or damage of the F112-P or connected instruments.
A "caution" indicates actions or procedures which, if not performed correctly, may lead to
personal injury or incorrect functioning of the F112-P or connected instruments.
A "note" indicates actions or procedures which, if not performed correctly, may indirectly
affect operation or may lead to an instrument response which is not planned.
Hardware version: 02.01.xx
Software version: 02.05.xx
Manual : HF112PEN_v0501_04
© Copyright 1997-2011 Fluidwell bv - The Netherlands.
Information in this manual is subject to change without prior notice. The
manufacturer is not responsible for mistakes in this material or for incidental
damage caused as a direct or indirect result of the delivery, performance or
use of this material.
© All rights reserved. No parts of this publication may be reproduced or used
in any form or by any means without written permission of your supplier.

HF112PEN_v0501_04
Page 4
CONTENTS MANUAL
Safety instructions ........................................................................................................................................... 2
Disposal .................................................................................................................................................... 2
Safety rules and precautionary measures ....................................................................................................... 2
About the operation manual ............................................................................................................................ 3
1. Introduction ................................................................................................................................. 5
1.1. System description of the F112-P.......................................................................................... 5
2. Operational.................................................................................................................................. 7
2.1. General .................................................................................................................................. 7
2.2. Control panel.......................................................................................................................... 7
2.3. Operator information and functions ....................................................................................... 8
3. Configuration............................................................................................................................... 9
3.1. Introduction ............................................................................................................................ 9
3.2. Programming SETUP-level.................................................................................................... 9
3.2.1. General .................................................................................................................................. 9
3.2.2. Overview functions SETUP level ......................................................................................... 12
3.2.3. Explanation OF SETUP-functions........................................................................................ 13
1 - Total........................................................................................................................... 13
2 - Flowrate ..................................................................................................................... 14
3 - Display ....................................................................................................................... 15
4 - Power management .................................................................................................. 15
5 - Flowmeter .................................................................................................................. 16
6 - linearisation................................................................................................................ 17
7 - Analog output............................................................................................................. 18
8 - Relay output............................................................................................................... 19
9 - Communication (optional).......................................................................................... 20
A - Others........................................................................................................................ 20
4. Installation ................................................................................................................................. 21
4.1. General directions................................................................................................................ 21
4.2. Installation / surrounding conditions .................................................................................... 21
4.3. Dimensions- Enclosure ........................................................................................................ 22
4.4. Installing the hardware......................................................................................................... 24
4.4.1. Introduction .......................................................................................................................... 24
4.4.2. Voltage selection sensor supply .......................................................................................... 25
4.4.3. Terminal connectors ............................................................................................................ 26
5. Intrinsically safe applications..................................................................................................... 34
5.1. General information and instructions ................................................................................... 34
5.2. Terminal connectors Intrinsically Safe applications ............................................................. 35
5.3 Configuration Examples....................................................................................................... 37
5.4 Battery replacement instructions.......................................................................................... 39
6. Maintenance.............................................................................................................................. 40
6.1. General directions................................................................................................................ 40
6.2. Repair................................................................................................................................... 40
Appendix A: Technical specification .............................................................................................................. 41
Appendix B: Problem solving......................................................................................................................... 44
Appendix C: Communication variables.......................................................................................................... 45
Notes .................................................................................................................................................. 48
Index of this manual....................................................................................................................................... 50
List of figures in this manual .......................................................................................................................... 50

HF112PEN_v0501_04
Page 5
1. INTRODUCTION
1.1. SYSTEM DESCRIPTION OF THE F112-P
Functions and features
The flowrate / totalizer model F112-P is a microprocessor driven instrument designed to linearise the
flowmeters flow curve and to display flowrate, total and accumulated total.
This product has been designed with a focus on:
ultra-low power consumption to allow long-life battery powered applications (type PB / PC),
intrinsic safety for use in hazardous applications (type XI),
several mounting possibilities with aluminum or GRP enclosures for harsh industrial
surroundings,
ability to process all types of flowmeter signals,
transmitting possibilities with analog / pulse and communication (option) outputs.
Flowmeter input
This manual describes the unit with a pulse type input from the flowmeter "-P version". Other
versions are available to process (0)4-20mA or 0-10V flowmeter signals.
One flowmeter with a passive or active pulse, Namur or sine wave (coil) signal output can be
connected to the F112-P. To power the sensor, several options are available.
Standard outputs
Configurable pulse output: a scaled pulse mirroring a certain linearized total quantity.
Maximum frequency 60Hz.; the pulse length can be set from 7,8msec up to 2 seconds.
Configurable linear (0)4-20mA or 0-10V analog output with 10-bits resolution mirroring the actual
linearised flowrate. Flowrate levels as well as the minimum and maximum signal output can be
tuned.
Fig. 1: Typical application for the F112-P.

HF112PEN_v0501_04
Page 6
Configuration of the unit
The F112-P was designed to be implemented in many types of applications. For that reason, a
SETUP-level is available to configure your F112-P according to your specific requirements.
SETUP includes several important features, such as K-factors, measurement units, signal selection
etc. All setting are stored in EEPROM memory and will not be lost in the event of power failure or a
drained battery.
To extend the battery-life time (option), please make use of the power-management functions as
described in chapter 3.2.3.
Display information
The unit has a large transflective LCD with all kinds of symbols and digits to display measuring units,
status information, trend-indication and key-word messages.
Flowrate and totals can be displayed either with the small 8mm digits or with the 17mm digits.
A backup of the total and accumulated total in EEPROM memory is made every minute.
Options
The following options are available: isolated or active 4-20mA / 0-10V / 0-20mA analog output, full
Modbus communication RS232/485/TTL (also battery powered), intrinsic safety, mechanical relay or
active output, power- and sensor-supply options, panel-mount, wall-mount and weather-proof
enclosures, flame proof enclosure and LED backlight.

HF112PEN_v0501_04
Page 7
2. OPERATIONAL
2.1. GENERAL
The F112-P may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
Take careful notice of the " Safety rules, instructions and precautionary measures " in
the front of this manual.
This chapter describes the daily use of the F112-P. This instruction is meant for users / operators.
2.2. CONTROL PANEL
The following keys are available:
Fig. 2: Control Panel.
Functions of the keys
This key is used to program and save new values or settings.
It is also used to gain access to SETUP-level; please read chapter 3.
This key is used to SELECT accumulated total.
The arrow-key is used to increase a value after PROG has been pressed
or to configure the unit; please read chapter 3.
Press this key twice to CLEAR the value for total.
The arrow-key is used to select a digit after PROG has been pressed or to
configure the unit; please read chapter 3.

HF112PEN_v0501_04
Page 8
2.3. OPERATOR INFORMATION AND FUNCTIONS
In general, the F112-P will always act at Operator level. The information displayed is dependant
upon the SETUP-settings. All pulses generated by the connected flowmeter are measured by the
F112-P in the background, whichever screen refresh rate setting is chosen. After pressing a key, the
display will be updated very quickly during a 30 second period, after which it will slow-down again.
All information displayed is corrected by using the linearization table as stored in the F112-P.
Fig. 3: Example of display information during process.
For the Operator, the following functions are available:
Display flowrate / total or flowrate
This is the main display information of the F112-P. After selecting any other information, it will
always return to this main display automatically.
Total is displayed on the upper-line of the display and flowrate on the bottom line.
It is possible to display flowrate only with the large 17mm digits; in this instance press the
SELECT-key to read the total.
When "-------" is shown, then the flowrate value is too high to be displayed. The arrows 
indicate the increase/decrease of the flowrate trend.
Clear total
The value for total can be re-initialized. To do so, press CLEAR twice. After pressing CLEAR
once, the flashing text "PUSH CLEAR" is displayed. To avoid re-initialization at this stage,
press another key than CLEAR or wait for 20 seconds.
Re-initialization of total DOES NOT influence the accumulated total.
Display accumulated total
When the SELECT-key is pressed, total and accumulated total are displayed. The
accumulated total cannot be re-initialized. The value will count up to 99,999,999,999. The unit
and number of decimals are displayed according to the configuration settings for total.
Low-battery alarm
When the battery voltage drops, it must be replaced. At first "low-battery" will flash, but as
soon as it is displayed continuously, the battery MUST be replaced shortly after!
Only original batteries supplied by the manufacturer may be used, else the guarantee and
liability will be terminated. The remaining lifetime after the first moment of indication is
generally several days up to some weeks.
Fig. 4: Example of low-battery alarm.
•Alarm 01-03
When "alarm" is displayed, please consult Appendix B: problem solving.
RUN
LOW BATTERY
RUN

HF112PEN_v0501_04
Page 9
3. CONFIGURATION
3.1. INTRODUCTION
This and the following chapters are exclusively meant for electricians and non-operators. In these,
an extensive description of all software settings and hardware connections are provided.
Mounting, electrical installation, start-up and maintenance of the instrument may only
be carried out by trained personnel authorized by the operator of the facility. Personnel
must read and understand this Operating Manual before carrying out its instructions.
The F112-P may only be operated by personnel who are authorized and trained by the
operator of the facility. All instructions in this manual are to be observed.
Ensure that the measuring system is correctly wired up according to the wiring
diagrams. The housing may only be opened by trained personnel.
Take careful notice of the " Safety rules, instructions and precautionary measures " in
the front of this manual.
3.2. PROGRAMMING SETUP-LEVEL
3.2.1. GENERAL
Configuration of the F112-P is done at SETUP-level. SETUP-level is reached by pressing the
PROG/ENTER key for 7 seconds; at which time, both arrows will be displayed. In order to return
to the operator level, PROG will have to be pressed for three seconds. Alternatively, if no keys are
pressed for 2 minutes, the unit will exit SETUP automatically.
SETUP can be reached at all times while the F112-P remains fully operational.
Note: A pass code may be required to enter SETUP. Without this pass code access to SETUP is
denied.
To enter SETUP-level:

HF112PEN_v0501_04
Page 10
Matrix structure SETUP-level:
SCROLLING THROUGH SETUP-LEVEL
Selection of function-group and function:
SETUP is divided into several function groups and functions.
Each function has a unique number, which is displayed below the word "SETUP" at the bottom of
the display. The number is a combination of two figures. The first figure indicates the function-group
and the second figure the sub-function. Additionally, each function is expressed with a keyword.
After selecting a sub-function, the next main function is selected by scrolling through all "active" sub-
functions (e.g. 1, 11, 12, 13, 14, 1, 2, 3, 31 etc.).

HF112PEN_v0501_04
Page 11
To change or select a value:
To change a value, use to select the digits and to increase that value.
To select a setting, both and can be used.
If the new value is invalid, the increase signor decrease-signwill be displayed while you are
programming.
When data is altered but ENTER is not pressed, then the alteration can still be cancelled by waiting
for 20 seconds or by pressing ENTER for three seconds: the PROG-procedure will be left
automatically and the former value reinstated.
Note: alterations will only be set after ENTER has been pressed!
To return to OPERATOR-level:
In order to return to the operator level, PROG will have to be pressed for three seconds. Also, when
no keys are pressed for 2 minutes, SETUP will be left automatically.

HF112PEN_v0501_04
Page 12
3.2.2. OVERVIEW FUNCTIONS SETUP LEVEL
SETUP FUNCTIONS AND VARIABLES
1 TOTAL
11 UNIT L - m3 - kg - lb - GAL - USGAL - bbl - no unit
12 DECIMALS 0 - 1 - 2 - 3 (Ref: displayed value)
13 K-FACTOR: 0.000010 - 9,999,999
14 DECIMALS K-FACTOR 0 - 6
2 FLOWRATE
21 UNIT mL - L - m3 - mg - g - kg - ton - GAL - bbl - lb - cf - REV -
no unit - scf - Nm3 - NL - P
22 TIME UNIT sec - min - hour - day
23 DECIMALS 0 - 1 - 2 - 3 (Ref: displayed value)
24 K-FACTOR 0.000010 - 9,999,999
25 DECIMALS K-FACTOR 0 - 6
26 CALCULATION per 1 - 255 pulses
27 CUT-OFF 0.1 - 999.9 seconds
3 DISPLAY
31 FUNCTION total - flowrate
4 POWER MANAGEMENT
41 LCD UPDATE fast - 1 sec - 3 sec - 15 sec - 30 sec - off
42 BATTERY MODE operational - shelf
5 FLOWMETER
51 SIGNAL npn - npn_lp - reed - reed_lp - pnp - pnp_lp - namur -
coil_hi - coil_lo - act_8.1 - act_12 - act_24
6 LINEARISATION
61 FREQ. / M-FACTOR 1 0.1 – 9,999.9 Hz / 0.000001 – 9.999999
62 FREQ. / M-FACTOR 2 0.1 – 9,999.9 Hz / 0.000001 – 9.999999
63 FREQ. / M-FACTOR 3 0.1 – 9,999.9 Hz / 0.000001 – 9.999999
.. .. ……..
6F FREQ. / M-FACTOR 15 0.1 – 9,999.9 Hz / 0.000001 – 9.999999
6G LINEARISATION enable / disable
6H DECIMALS FREQUENCY 00000 - 1111.1 - 222.22 - 33.333
7 ANALOG
71 OUTPUT disable - enable
72 4mA / 0V 0000.000 - 9,999,999
73 20mA / 10V 0000.000 - 9,999,999
74 CUT-OFF 0.0 - 9.9%
75 CALIBRATE LOW default - calibrate - calibrate set
76 CALIBRATE HIGH default - calibrate - calibrate set
77 FILTER 00 - 99
8 IMPULSE
81 PERIOD TIME 0 - 250
82 IMPULSE PER X,XXX,XXX quantity
9 COMMUNICATION
91 SPEED / BAUDRATE 1200 - 2400 - 4800 - 9600
92 ADDRESS 1 - 255
93 MODE rtu - off
A OTHERS
A1 TYPE / MODEL F112-P
A2 SOFTWARE VERSION -
A3 SERIAL NO. -
A4 PASS CODE 0000 - 9999
A5 TAGNUMBER 0000000 - 9999999

HF112PEN_v0501_04
Page 13
3.2.3. EXPLANATION OF SETUP-FUNCTIONS
1 - TOTAL
MEASUREMENT UNIT
11 SETUP - 11 determines the measurement unit for total, accumulated total
and pulse output. The following units can be selected:
L - m3 - kg - lb. - GAL - USGAL - bbl - _ (no unit).
Alteration of the measurement unit will have consequences for operator
and SETUP-level values.
Please note that the K-factor has to be adapted as well; the calculation is
not done automatically.
DECIMALS
12 The decimal point determines for total, accumulated total and pulse output
the number of digits following the decimal point.
The following can be selected:
0000000 - 111111.1 - 22222.22 - 3333.333
K-FACTOR
13 With the K-factor, the flowmeter pulse signals are converted to a quantity.
The K-factor is based on the number of pulses generated by the
flowmeter per selected measurement unit (SETUP 11), for example per
cubic meter. The more accurate the K-factor, the more accurate the
functioning of the system will be.
Example 1: Calculating the K-factor.
Let us assume that the flowmeter generates 2.4813 pulses per
liter and the selected unit is "cubic meters / m3". A cubic meter
consists of 1000 parts of one liter which implies 2,481.3 pulses
per m3. So, the K-factor is 2,481.3. Enter for SETUP - 13:
"2481300" and for SETUP - 14 - decimals K-factor "3".
Example 2: Calculating the K-factor.
Let us assume that the flowmeter generates 6.5231 pulses per
gallon and the selected measurement unit is gallons. So, the K-
Factor is 6.5231. Enter for SETUP - 13: "6523100" and for
SETUP - 14 decimals K-factor "6".
DECIMALS K-FACTOR
14 This setting determines the number of decimals for the K-factor entered.
(SETUP 13). The following can be selected:
0 - 1 - 2 - 3 - 4 - 5 - 6
Please note that this setting influences the accuracy of the K-factor
indirectly. (i.e. the position of the decimal point and thus the value given)
This setting has NO influence on the displayed number of digits for total
(SETUP 12)!

HF112PEN_v0501_04
Page 14
2 - FLOWRATE
The settings for total and flowrate are entirely separate. In this way, different units of measurement
can be used for each e.g. cubic meters for total and liters for flowrate.
The display update time for flowrate is one second or more.
Note: these settings also influence the analog output.
MEASUREMENT UNIT
21 SETUP - 21 determines the measurement unit for flowrate.
The following units can be selected:
mL - L - m3 - mg - g - kg - ton - GAL - bbl - lb - cf - REV -
no unit - scf - Nm3 - NL - P.
Alteration of the measurement unit will have consequences for operator
and SETUP-level values.
Please note that the K-factor has to be adapted as well; the calculation is
not done automatically.
TIME UNIT
22 The flowrate can be calculated per second (SEC), minute (MIN), hour
(HR) or day (DAY).
DECIMALS
23 This setting determines for flowrate the number of digits following the
decimal point. The following can be selected:
00000 - 1111.1 - 2222.22 - 3333.333
K-FACTOR
24 With the K-factor, the flowmeter pulse signals are converted to a flowrate.
The K-factor is based on the number of pulses generated by the
flowmeter per selected measurement unit (SETUP 21), for example per
liter. The more accurate the K-factor, the more accurate the functioning of
the system will be. For examples read SETUP 13.
DECIMALS K-FACTOR
25 This setting determines the number of decimals for the K-factor
(SETUP 24). The following can be selected:
0 - 1 - 2 - 3 - 4 - 5 - 6
Please note that this SETUP - influences the accuracy of the K-factor
indirectly.
This setting has NO influence on the displayed number of digits for
"flowrate" (SETUP 23)!
CALCULATION
26 The flowrate is calculated by measuring the time between a number of
pulses, for example 10 pulses. The more pulses the more accurate the
flowrate will be. The maximum value is 255 pulses.
Note: this setting does influence the update time for the analog output
directly (maximum update 10 times a second). If the output response is
too slow, decrease the number of pulses.
Note: the lower the number of pulses, the higher the power consumption
of the unit will be (important for battery powered applications).
Note: for low frequency applications (below 10Hz): do not program more
than 10 pulses else the update time will be very slow.
Note: for high frequency application (above 1kHz) do program a value of
50 or more pulses.
CUT-OFF TIME
27 With this setting, you determine a minimum flow requirement thresh-hold,
if during this time less than XXX-pulses (SETUP 26) are generated, the
flowrate will be displayed as zero.
The cut-off time has to be entered in seconds - maximum time is 999
seconds (about 15 minutes).

HF112PEN_v0501_04
Page 15
3 - DISPLAY
FUNCTION
31 The large 17mm digits can be set to display total or flowrate.
When "total" is selected, both total and flowrate are displayed
simultaneously.
When "flowrate" is selected, only flowrate will be displayed with it’s
measuring unit while total will be displayed after pressing SELECT.
4 - POWER MANAGEMENT
When used with the internal battery option, the user can expect reliable measurement over a long
period of time. The F112-P has several smart power management functions to extend the (optional)
battery life time significantly. Two of these functions can be set:
LCD NEW
41 The calculation of the display-information influences the power
consumption significantly. When the application does not require a fast
display update, it is strongly advised to select a slow refresh rate.
Please understand that NO information will be lost; every pulse will be
counted and the output signals will be generated in the normal way.
The following can be selected:
Fast - 1 sec - 3 sec - 15 sec - 30 sec - off.
Example 3: Battery life-time
battery life-time with a coil pick-up, 1KHz. pulses and FAST
update: about 2 years.
battery life-time with a coil pick-up, 1KHz. pulses and 1 sec
update: about 5 years.
Note: after a button has been pressed by the operator - the display
refresh rate will always switch to FAST for 30 seconds. When "OFF" is
selected, the display will be switched off after 30 seconds and will be
switched on as soon as a button has been pressed.
BATTERY-MODE
42 The unit has two modes: operational or shelf.
After "shelf" has been selected, the unit can be stored for several years; it
will not count pulses, the display is switched off but all settings and totals
are stored. In this mode, power consumption is extremely low.
To wake up the unit again, press the SELECT-key twice.

HF112PEN_v0501_04
Page 16
5 - FLOWMETER
SIGNAL
51 The F112-P is able to handle several types of input signal. The type of
flowmeter pickup / signal is selected with SETUP 51.
Note: The selections "active pulse" offer a detection level of 50% of the
supply voltage.
Read also par. 4.4.3. Flowmeter input terminal 09-11.
TYPE OF SIGNAL EXPLANATION RESISTANCE FREQ./MVREMARK
NPN NPN input 100K
pull-up 6 kHz. (open collector)
NPN - LP NPN input
with low pass filter 100K pull-up 2.2 kHz. (open collector)
less sensitive
REED Reed-switch input 1M
pull-up 1.2 kHz.
REED - LP Reed-switch input
with low pass filter 1M pull-up 120 Hz. Less sensitive
PNP PNP input 100K
pull-down 6 kHz.
PNP - LP PNP input
with low pass filter 100K pull-down 700 Hz. Less sensitive
NAMUR Namur input 820 Ohm
pull-down 4 kHz. External power
required
COIL HI High sensitive
sine-wave (coil) input - 20mVp-p.
Sensitive for
disturbance!
COIL LO Low sensitive
sine-wave (coil) input - 90mVp-p. Normal sensitivity
ACT_8.1 Active pulse input
8.1 VDC 3K9 10KHz.
External power
required
ACT_12 Active pulse input
12 VDC 4K 10KHz.
External power
required
ACT_24 Active pulse input
24 VDC 3K 10KHz.
External power
required

HF112PEN_v0501_04
Page 17
6 - LINEARISATION
The linearization function is available to approach the real flow curve better as with the general
K-factor (KF0) entered with setup 14 and 24. This to obtain a more accurate flowrate, total and
accumulated total as well as the analog and pulse output at any flowmeter frequency.
A maximum of 15 linearization-positions can be entered while the interpolation will calculate any
other position in-between.
For each linearization position, the frequency and a Meter Factor (MF) must be entered.
The Meter Factor for each frequency is calculated with following formula:
Meter-Factor = K-Factor at flowrate X
KF0
The lowest frequency and MF you enter will be valid from 0Hz. The highest frequency and MF will
be valid till 10KHz. It is advised to enter the frequencies in increasing order, however it is not
necessary. Please have a look at following example to understand the method of linearization:
FREQUENCY /
M-FACTOR
61 TO 6F
The frequency is displayed at the bottom line of the display.
The maximum frequency is 9,999.9 Hz. With value 0.0Hz, the M-Factor is
disabled. (Please read Setup function 6H - decimals frequency)
The M-Factor is displayed at the top-line of the display. The minimum
value to be entered is 0.000001 and the maximum value is 9.999999.
Please note that this value has always six decimals while the "dot" is not
displayed.
Most M-factors will be around 1.000000 like 0.945354 or 1.132573.
DISABLE / ENABLE
6G With this setup function, you can easily enable / disable the linearization
function.
DECIMALS
FREQUENCY
6H
For the frequency, following decimal positions can be selected:
00000 - 1111.1 - 222.22 - 33.333

HF112PEN_v0501_04
Page 18
7 - ANALOG OUTPUT
A linear analog (0)4-20mA or 0-10V signal is generated according to the flowrate with a 10 bits
resolution. The settings for flowrate (SETUP - 2) influence the analog output directly.
The relationship between rate and analog output is set with the following functions:
DISABLE / ENABLE
71 The analog output can be disabled.
In case of a passive analog output type AP, 3.5mA will be generated if a
power supply is available but the output is disabled.
MINIMUM FLOWRATE
72 Enter here the flowrate at which the output should generate the minimum
signal (0/4mA or 0V) - in most applications at flowrate "zero".
The number of decimals displayed depend upon SETUP 23.
The time and measuring units (L/min for example) depend upon SETUP
21 and 22 but are not displayed.
MAXIMUM FLOWRATE
73 Enter here the flowrate at which the output should generate the maximum
signal (20mA or 10V) - in most applications at maximum flow.
The number of decimals displayed depend upon SETUP 23.
The time and measuring units (L/min for example) depend upon SETUP
21 and 22 but cannot be displayed.
CUT-OFF
74 To ignore leakage of the flow for example, a low flow cut-off can be set as
a percentage of the full range of 16mA, (or 20mA or 10V).
When the flow is less than the required rate, the current will be the
minimum signal (0/4mA or 10V).
Examples:
4MA
(SETUP
72)
20MA
(SETUP
73)
CUT-OFF
(SETUP 74) REQUIRED RATE OUTPUT
0 L/min 100 L/min 2% (100-0)*2% = 2.0 L/min 4+(16*2%) = 4.32mA
20 L/min 800 L/min 3.5% (800-20)*3.5%= 27.3 L/min 4+(16*3.5%)=4.56mA
TUNE MIN / 4MA
75 The initial minimum analog output value is 0/4mA or 0V. However, this
value might differ slightly due to external influences such as temperature
for example. The 0/4mA or 0V value can be tuned precisely with this
setting.
Before tuning the signal, be sure that the analog signal is not
being used for any application!
After pressing PROG, the current will be about 4mA (or 0mA / 0V). The
current can be increased / decreased with the arrow-keys and is directly
active. Press ENTER to store the new value.
Remark: the analog output value can be programmed “up-side-down” if
desired, so 20mA at minimum flowrate for example!
TUNE MAX / 20MA
76 The initial maximum analog output value is 20mA (or 10V). However, this
value might differ slightly due to external influences such as temperature
for example. The 20mA value (or 10V) can be tuned precisely with this
setting.
Before tuning the signal, be sure that the analog signal is not
being used for any application!
After pressing PROG, the current will be about 20mA. The current can be
increased / decreased with the arrow-keys and is directly active. Press
ENTER to store the new value.
Remark: the analog output value can be programmed “up-side-down” if
desired, so 4mA at maximum flowrate for example!
Continued next page >>>

HF112PEN_v0501_04
Page 19
7 - ANALOG OUTPUT (CONTINUED)
FILTER
77 This function is used to stabilize the analog output signal.
The output value is updated every 0.1 second. With the help of this digital
filter a more stable but less precise reading can be obtained.
The filter principal is based on three input values: the filter level (01-99),
the last analog output value and the last average value. The higher the
filter level, the longer the response time on a value change will be.
Below, several filter levels with their response times are indicated:
FILTER VALUE RESPONSE TIME ON STEP CHANGE OF ANALOG VALUE.
TIME IN SECONDS
50%INFLUENCE 75%INFLUENCE 90% INFLUENCE 99%INFLUENCE
01 filter disabled filter disabled filter disabled filter disabled
02 0.1 second 0.2 second 0.4 second 0.7 second
03 0.2 second 0.4 second 0.6 second 1.2 seconds
05 0.4 second 0.7 second 1.1 seconds 2.1 seconds
10 0.7 second 1.4 seconds 2.2 seconds 4.4 seconds
20 1.4 seconds 2.8 seconds 4.5 seconds 9.0 seconds
30 2.1 seconds 4 seconds 7 seconds 14 seconds
50 3.5 seconds 7 seconds 11 seconds 23 seconds
75 5.2 seconds 10 seconds 17 seconds 34 seconds
99 6.9 seconds 14 seconds 23 seconds 45 seconds
8 - RELAY OUTPUT
One transistor or mechanic relay output is available as scaled pulse output according to the
accumulated total.
PERIOD TIME
PULSE OUTPUT
81
The period time determines the time that the transistor or relay will be
switched; in other words the pulse length. The minimum time between the
pulses is as long as the selected period time.
One period is approx. 7.8 msec. If the value selected is “zero”, the pulse
output is disabled. The maximum value is 255 periods.
Note: If the frequency should go out of range - when the flowrate
increases for example - an internal buffer will be used to "store the missed
pulses": As soon as the flowrate reduces again, the buffer will be
"emptied".
It might be that pulses will be missed due to a buffer-overflow, so it is
advised to program this setting within it's range.
If a mechanic relay is used for the pulse output, it is recommended to
reduce the max. output frequency to 0.5Hz, else the life time will be
reduced significantly.
NUMBER OF PERIODS PERIOD TIME MAX.FREQUENCY
0 disabled disabled
1 0,0078 seconds 64 Hz.
2 0,0156 seconds 32 Hz.
3 0,0234 seconds 21 Hz.
64 0,5000 seconds 1 Hz.
255 1,9922 seconds 0.25 Hz.
PULSE PER
82 According to the measurement unit settings for total, a pulse will be
generated every X-quantity. Enter this quantity here while taking the
displayed decimal position and measuring unit into account.

HF112PEN_v0501_04
Page 20
9 - COMMUNICATION (OPTIONAL)
The functions described below deal with hardware that is not part of the standard delivery.
Programming of these functions does not have any effect if this hardware has not been installed.
Consult Appendix C and the Modbus communication protocol description for a detailed explanation.
BAUDRATE
91 For external control, the following communication speeds can be selected:
1200 - 2400 - 4800 - 9600 baud
BUS ADDRESS
92 For communication purposes, a unique identity can be attributed to every
F112-P. This address can vary from 1-255.
MODE
93 The communication protocol is Modbus RTU mode. Select OFF, to
disable this communication function.
A - OTHERS
TYPE OF MODEL
A1 For support and maintenance it is important to have information about the
characteristics of the F112-P.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
VERSION SOFTWARE
A2 For support and maintenance it is important to have information about the
characteristics of the F112-P.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
SERIAL NUMBER
A3 For support and maintenance it is important to have information about the
characteristics of the F112-P.
Your supplier will ask for this information in the case of a serious
breakdown or to assess the suitability of your model for upgrade
considerations.
PASS CODE
A4 All SETUP-values can be pass code protected.
This protection is disabled with value 0000 (zero).
Up to and including 4 digits can be programmed, for example 1234.
TAGNUMBER
A5 For identification of the unit and communication purposes, a unique tag
number of maximum 7 digits can be entered.
