fluxia PD5H-25 User manual

PD5H-25
COMPACT OUTDOOR DMX HEX-LED PAR48 CAN
Item ref: 154.321UK
User Manual
A weatherproof LED lighting PAR48 can in aluminium housing
with adjustable stand bracket. Full colour mixing can be
accessed through stand-alone control or via DMX512 input.
Built-in 6-in-1 HEX LEDs are capable of displaying red, green,
blue, white, amber and UV. These LEDs allow for richer and
warmer colour blending. A versatile fixture for adding dynamic
colour to indoor or outdoor areas.
Installation:
This PAR can is powered by mains, therefore installation should be carried out certified electrician
only. Before installation, always ensure the mains is switched OFF at the consumer unit and the fuse
block should be removed on the circuitry that you are working on to ensure the mains will not be
accidentally switched back on while working.
This PAR can is supplied with a double bracket for free standing on the floor or overhead mounting.
There is also a fixed U bracket at the back for the unit to be mounting on a spade bracket.
IP65 rating applies to the unit only. If more units are requiring connect together at a distance longer
than attached leads, we recommend to strip the water proof connector and extend the connections
using waterproof junction box and gland or waterproof resin jointing kit for full IP65 protection.
Below table shows wire colour and connection, please ensure all connections are made correctly.
Wire colour reference
Colour
Carries
Brown
Mains –live
Blue
Mains –neutral
Yellow/Green
Mains –earth
Red
DMX –dmx+ signal
White
DMX –dmx- signal
Please read through this manual thoroughly before
use, any damage caused by misuse of the product will
not be covered by the warranty.

154.322UK User Manual
Product layout
Manual control menu
Press the “menu” button to enter setting menu.
Press “up” and “down” to navigate through various setting options.
Press “enter” to enter desire setting.
Choose set value by “up” and “down” buttons and confirm setting by pressing “enter”.
Display
Mode
Press ENTER for setting

DMX address
to 

Channel mode
Select DMX control through 2, 3, 4, 5, 9 channels

Slave mode
= master, = slave

Auto mode
Option of fade (colour scroll), jump, auto or 63
preset static colours.

Sound activation
= sound to light on, = sound to light off

Microphone sensitivity
(0-100% gain)

RGB colour mixing mode
Press up and down to set individual RBG dimmer to
allow colour mixing.

LED display
 = stays on, = turns off after 10 sec
untouched

LED display inverted
 / (normal or inverted display)

Fixture test sequence
Fixture steps through all functions –press MENU to
exit

Fixture hours
Displays how many hours of use for the fixture
Operation
This PAR Can can operate in stand-alone, master, slave or DMX modes.
Stand-alone
Enter Stand-alone menu by press enter on on the LCD display, 4 auto mode options are available as follows:
Fade (scroll) –press enter at  to set unit to scroll through preset static colours. Options for scroll speed  to 
and dimming  to  are available to adjust.
Jump –press enter at  to set unit to jump through preset static colours. Options for jump speed  to  and
dimming  to  are available to adjust.

154.322UK User Manual
Auto –press enter at  to set unit to auto mode. Sound activation function can be enable in this mode by setting
tofrom the main menu.
Static colour –there are 63 preset colours available to choose from. Press enter at , static colours are chosen
through  to  and dimming  to  are available to adjust within the same menu.
Master/slave mode
One or more PAR Cans can be synchronised to one master unit. Simply set the main control unit to master () on
 menu and the synchronising units to slave () on  menu. Connect DMX out from the master unit to DMX in
of the slave unit; further slave units can be controlled by daisy chain DMX out signal from the slave unit.
DMX mode
This PAR Can will enter DMX mode automatically when DMX signals are detected, ensure the DMX initial address is set so
that it’s function can be controlled correctly. DMX initial address can be set under  menu, simply press enter to enter
and up/down for address value and enter again to confirm.
This PAR Can can be controlled by 2/3/4/5/6/9 DMX channel modes, different DMX control modes can be set via the 
menu.
2CH –2 channels
Channel
Value
Function
Channel 1
000 - 255
Master dimmer 0-100%
Channel 2
000 - 255
Static colour selection
3CH1 –3 channels Op1
3CH2 –3 channels Op2
4CH –4 channels
Channel
Value
Function
Channel 1
000 - 255
Red dimmer 0-100%
Channel 2
000 - 255
Green dimmer 0-100%
Channel 3
000 - 255
Blue dimmer 0-100%
Channel 4
000 - 255
White dimmer 0-100%
5CH –5 channels
Channel
Value
Function
Channel 1
000 - 255
Red dimmer 0-100%
Channel 2
000 - 255
Green dimmer 0-100%
Channel 3
000 - 255
Blue dimmer 0-100%
Channel 4
000 - 255
White dimmer 0-100%
Channel 5
000 - 255
Amber dimmer 0-100%
6CH –6 channels
Channel
Value
Function
Channel 1
000 - 255
Red dimmer 0-100%
Channel 2
000 - 255
Green dimmer 0-100%
Channel 3
000 - 255
Blue dimmer 0-100%
Channel 4
000 - 255
White dimmer 0-100%
Channel 5
000 - 255
Amber dimmer 0-100%
Channel 6
000 - 255
UV dimmer 0-100%
9CH –9 channels
Channel
Value
Function
Channel 1
000 - 255
Master dimmer 0-100%
Channel 2
000 - 255
Strobe slow to fast
Channel 3
000 - 004
Black out
005 - 080
Static colour selection
081 - 150
Colour jump, speed increase with value
151 - 220
Colour scroll, speed increase with value
221 - 255
Sound to light chase
Channel
Value
Function
Channel 1
000 - 255
Red dimmer 0-100%
Channel 2
000 - 255
Green dimmer 0-100%
Channel 3
000 - 255
Blue dimmer 0-100%

154.322UK User Manual
Channel
Value
Function
Channel 1
000 - 255
Master dimmer 0-100%
Channel 2
000 - 255
Strobe, speed 0-100%
Channel 3
000 - 255
Red dimmer 0-100%
Channel 4
000 - 255
Green dimmer 0-100%
Channel 5
000 - 255
Blue dimmer 0-100%
Channel 6
000 - 255
White dimmer 0-100%
Channel 7
000 - 255
Amber dimmer 0-100%
Channel 8
000 - 255
UV dimmer 0-100%
Channel 9
000 - 004
N/A
005 - 080
Static colour selection
081 - 150
Colour jump, speed increase with value
151 - 220
Colour scroll, speed increase with value
221 - 255
Sound to light chase
Specifications
Power
100-240Vac, 50/60Hz
Fuse
F3A
Power consumption
100W
Total luminous flux
2212lm
Luminous efficacy
22.1lm/W
LED quantity
5
LED power
18W
LED colour
6-in-1 HEX (red, green, blue,
UV, amber & white)
LED lifespan
50,000 hours
Beam angle
25º
Housing material
Aluminium
Projection distance
10m
Housing colour
Black
DMX connection
Red: DMX+, White: DMX-,
Braid: ground
DMX channels
2, 3, 4, 5, 6, 9
Luminance : red
900Lux @1m
Luminance : green
1700Lux @1m
Luminance : blue
1700Lux @1m
Luminance : white
1900Lux @1m
Luminance : amber
550Lux @1m
Luminance : ultra-violet
600Lux @1m
Luminance : full on
7000Lux @1m
Operating temperature
-20°C to +45°C
IP rating
IP65
Dimensions
220 x 245 x 130mm
Weight
3kg
Troubleshooting
No power (mains)
Check mains wiring is correctly to mains in connection
Check mains outlet and consumer unit is switched on
No LED display
Press any control panel button and check LED setting in menu
No light output
Check control panel mode settings ensure dimming is not set to minimum
Check DMX settings from controller (dimmer levels, blackout etc.)
No strobe output
Check strobe settings on control panel or from DMX controller
Unresponsive to DMX
Check DMX connection/joints to ensure dmx + and –not
shorted and ground is continuous to eliminate interference
Check that DMX mode is enabled (set “Addr” on control panel)
Check dmx lead and connector is in good workable condition
Overheating/cutting out
Ensure that the unit is not too close to a heat source
Ensure that adequate airflow is afforded for cooling
Ensure alien object and dirt is not built up between heat sink fins
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste
at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
