Showven SPARKULAR mini User manual

USER MANUAL
SPARKULAR®mini
V2.1
2022/06/22
Showven Technologies Co., Ltd.

Thanks for choosing SPARKULAR®mini, we wish it will sparks up your show.
Please read the following manual carefully before operating this product.
ΔSafety Instructions
\Unauthorized repair are prohibited, it may cause serious incident.
\Keep SPARKULAR®mini dry and do NOT use in rain or snow.
\Make sure lid of feeding hopper are well covered when use SPARKULAR®mini.
\Accidentally burning of consumable can only use sands to extinguish.
\Consumable should keep away from moisture and stored in a dry sealed environment.
\Check whether there is consumable aggregate in the output nozzle both before and after
each show, if any, please clean it up, or it will affect the firing effect or even damage
SPARKULAR®mini.
\There will be some sparks drop to ground when use HC8200 LARGE, suggest to use HC8200
MEDIUM or SMALL for indoor events.
\The SPARKULAR®mini power supply cable maximum allowed cascade is 6pcs (BT06) / 3pcs
(BT07), exceed connecting may result in damage or even cause fire.
\For better heat dissipation, block the air intake and air outlet is prohibited.
\Cover the output nozzle of SPARKULAR®mini are forbidden, inspect the machine before
each show, making sure no objects or material will block the output nozzle.
\Never touch the nozzle of SPARKULAR®, danger of getting burnt
\Never touch the sparks which shooting out from the nozzle
Safety Distance
\Keep audience and flammable material at a minimum distance of 1m from SPARKULAR®
mini.
\Make sure sparks shoot out from SPARKULAR®mini can NOT touch any objects. And keep a
clearance with minimum 1m from the setting maximum effect height.
\In windy environment, increase the safety distance according to the wind direction and speed.
\The safety zone area changes accordingly when machine installed in tilt position. Please
increase the safety distance in the direction which machine tilt.
\Sparks and consumables from the machine can lead to serious eye injury. Always wear safety
goggles when enter the safety zone.

ΔDescription
SPARKULAR®mini is an affordable sparks solution based on SPARKULAR®platform, it is with
fixed sparks effects at around 2-3m. Equipped with wireless remote and DMX double control
ensure the versatile use for wedding, party, clubs, cruise ships etc. venues and stages.
ΔTechnical Specifications
\MODEL: BT06/BT07
\DIMENSION: 168× 180× 228mm
\WEIGHT: 4.5kg
\VOLTAGE: 220V(BT06)/110V(BT07), 50/60Hz
\WORK POWER: 380W
\EFFECT HEIGHT: 2-2.5m (HC8200 MEDIUM), 3-3.5m (HC8200 LARGE)
\INTERFACE: 3-pin XLR, POWER IN/OUT
\CONTROL: DMX 2 channels, Wireless Remote

ΔStructure of SPRKULAR®mini
1. Output Nozzle
2. Feeding Hopper Lid
3. Cooling Fan
4. LCD Screen
5. Power Switch
6. Fuse
7. DMX OUT
8. DMX IN
9. POWER IN
10.POWER OUT
Diagram of Bottom Panel

ΔOperation Panel
1. LED display area
READY DMX FAULT HEAT
READY: After turn on machine, it will automatically preheat around 5 minutes, when the
"READY" green light turns from flashing into long on, indicates that the machine is
ready to work.
DMX: Flashing shows that DMX signal is connected, otherwise is without signal
FAULT: When any malfunction, the indicate light turn on
HEAT: When the machine is heating, signal light turn on
2. Control button area
MENU Short press to switch interface, press and hold for 3 seconds can switch to the
advanced setup interface
-: Parameters down
+: Parameters up
ENTER Confirm and save parameters.
3. RFID area
Composite Ti with RFID card, swiping cards used to identify parameters and types of granules.
The RFID card is disposable, one card can only use one time.

ΔInterface
1. Main Interface
First line: Display DMX address is “1”
Second line: Display the present inner core temperature and the temperature progress bar;
isplays remaining time is 7 minutes and 24 seconds
2. Error Information
3. Setting Menu
Press “MENU” to enter the Setting interface, press the “MENU” button to enter different
options until you return to the main interface
4. Advanced Menu
Press and hold “MENU” for 3 seconds to enter the advanced setup interface, press MENU key
to enter different options, wait 3 seconds to return to the main interface.
Error information
Explanation
E0 System IC
Systematic error
E2 Temp. Sensor
Temperature sensor is not connected or damage
E3 P Temp. Over
Chassis over-temperature
E4 Time Remain
Insufficient granules or remaining time, please swiping time card
E5 K Temp. Over
Heating chamber over-temperature
E6 Heat Fail
Heating failed
E7 Tip Over
Machine slant over 45 degrees.
Options
Range
Default
Explanation
Set DMX Address
1-512
1
Set the DMX address, machine become a wireless host
and can send out DMX signal when its address is
“1++”
Wireless Control
ON/OFF
ON
Wireless function switch, you can match machine with
remote controller when at “ON” status
Manual Fountain
ON/OFF
OFF
Manual fountain switch , for testing purposes only
Options
Range
Default
Explanation
Set Temperature
480-620
550
Setup inner Core temperature
Auto Heat
ON/OFF
ON
Auto preheat function switch after turn on
machine
Density
70-100
90
Adjust the sparks density
Mode Selection
Factory Mode
User Mode
Factory Mode is factory debugging mode,

5. DMX Mode
When using the DMX controller, the system takes 2 channels
If use together with HOST CONTROLLER ZK6200/6300, each unit of SPARKULAR®must use
different DMX address, otherwise it may leads to signal interference.
ΔOperation Guide
1. Install SPARKULAR®mini
a) Horizontal installation is preferred for SPARKULAR®mini. If need to installed SPARKULAR®
mini in angles, please turn the Tip over to OFF status first, maximum firing angle is 45 ° and
can only be angled to the right side as below picture.
b) Make sure the machine is securely installed to avoid tipping.
c) The safety zone area shifts accordingly when machine installed in tilt position. Please
increase the safety distance in the direction which machine tilt.
d) Check carefully the output nozzle of each machine, make sure the output nozzle is in good
shape and there is no powder aggregate.
User Mode
User Mode is using mode
DMX Channel
Mode
2 / 4 / 2+3
DMX Channel
2 DMX
channel
Don’t change. 4 DMX Channel and 2+3 DMX
Channel are for special use.
Tip Over Error
ON/OFF
ON
Tilt function switch
Default
Parameter
Useless
Standby Switch
ON/OFF
OFF
When ON, the machine can firing only when
heating up was finished
The First channel
Functions
0-15
Fountain OFF
16-255
Fountain ON
The second channel
Functions
60-80
Clear Material
20-40
Emergency Stop
0-10
Pre-heat OFF
240-255
Pre-heat ON

2. Fill SPARKULAR®mini
a) Open powder bags and fill the feeding hopper. Hopper capacity of SPARKULAR®mini is
100g.
b) Choose correct consumable according to the application scenario. HC8200 LARGE will have
some sparks drop on ground, suggest HC8200 MEDIUM or SMALL for indoor use.
c) Maximum effect height for HC8200 LARGE is 3.5m, HC8200 MEDIUM is 2.5m.
d) Make sure the lid of hopper is locked tight after filling.
3. Connect Power / DMX cable
a) Connect a power cable to the POWER IN socket of SPARKULAR® mini. Connect the other
end of power cable to the power source. Make sure power supply in consistent with the
rated voltage of the equipment, and the socket must well grounded.
b) If connect machine in sequence, please connect a power link cable to the POWER OUT of
previous machine, connect the other end of the power link cable to POWER IN of the next
machine.
c) The SPARKULAR® mini power supply cable maximum allowed cascade is 6 units (220V
version) / 3pcs (110V version). Do not connect exceed units to a single electrical circuit.
d) Power ON all SPARKULAR®mini.
e) Assign DMX address for each unit of SPARKULAR® mini. If use SHOWVEN host controller or
FXcommander to control the machine please allocate a unique DMX address for each unit
of machine.
If use remote controller to control SPARKULAR® mini wirelessly, please set machine to
wireless ON status and match machine with remote controller. For DMX cable control please
execute below operations (f to h).
f) Connect a DMX cable to the DMX IN socket of first unit of SPARKULAR® mini, connect the
male connector end of DMX cable to your DMX controller (FXcommander, HOST
CONTROLLER, light console etc).
g) Connect a DMX cable to the DMX OUT of previous machine, and the other end of to the
DMX IN of next machine. Connect all devices in series in this way.
a) Suggest to plug in a DMX terminator into the DMX OUT in last unit of machine to improve
signal reliability. Signal amplifier is required for long distance (>200m) DMX signal
transmission.

4. Activate SPARKULAR®mini machine by swipe RFID card
a) Swipe an RFID card. Read the card as show below. SPARKULAR®mini shows time remain if
read successfully.
b) SPARKULAR®mini report E4 when remaining time is less than 8 minutes.
c) Please note each RFID card come with 50g package HC8200 can increase single machine
4min working time, the maximum recharge time for SPARKULAR®mini is 30min, when
time remain reached 30min, it can’t recharge anymore RFID card.
C N .00000001
5. Programming and Firing
a) Programming SPARKULAR®mini, set the firing height, firing sequences etc.
a) Heating up machine, it takes around 5min. it varies according to the voltage and
environment temperature.
b) Make sure the prescribed safety zone is clear.
c) Suggest to clear material before firing.
b) Firing. In order to prevent overheat in the heating chamber and protect machine, the
maximum continuous firing time for SPARKULAR®mini is 30s.
c) The operator should always have a clear view of the device, so that he/she can stop the
show immediately when there is danger.
d) Clear material for SPARKULAR®mini for 5s after show, clear material will remove the
remaining particles from heating chamber. For angled installation please elongate clear
material time.
6. Turn off and Clean up
a) Power off SPARKULAR®mini, allow SPARKULAR®mini to cool down.
b) Disconnect all POWER and DMX cables.
c) Empty the remaining HC8200 in hopper, and store the remaining HC8200 in a dry sealed
bottle for next time use. Never touch the output nozzle of SPARKULAR® mini when empty
the hopper. DANGER OF GET BURNT!
d) Operators can use handheld vacuum cleaner to empty the feeding hopper. Do make sure
the machine was cool down when clean it. Do NOT use high-power vacuum cleaners to
avoid hot consumables being sucked into the vacuum cleaner from the heating chamber
and cause fire.
e) Clean the surroundings to remove powder residues.

ΔWireless Control Information
1. Wireless remote control mode:
When use wireless remote control, please unplug DMX cable connection on machine, set
Wireless Control at ON status, match the remote controller with machine, pull out the antenna
on remote controller.
1 ON
DMX address “1” ON
1 OFF
DMX address “1” OFF
2 ON
DMX address “3” ON
2 OFF
DMX address “3” OFF
3 ON
DMX address “5” ON
3 OFF
DMX address “5” OFF
SET
Match the machine with
remote
CLEAR
Clean material for 3
seconds
5 S
All firing 5s
15 S
All firing 15s
30 S
All firing 30s
OFF
All stop
NOTE:
a) When the indicator light becomes weak on the remote controller, please replace the
battery. The battery type is 12V23A.
b) When the machine is occasionally not working, may be caused by interference, please press
the start button again.
c) Wireless control is easily influenced by interference, suggests to stay as close to machine as
possible when use remote controller, and machines cannot use metal shielding
3. Wireless host SPARKULAR®mini mode (requires communication cables)
a) In occasion of strong interference, using the wireless host can avoid interference, ensure
stable control.
b) Set the first unit of SPARKULAR®mini DMX address into “1++”, this machine address is “1”,
but it can also output DMX signal and turns into wireless host SPARKULAR®mini.
c) Use communication cables to connect all SPARKULAR®minis, the host SPARKULAR®mini
will receive the signal from remote controller and transfer to all other SPARKULAR®mini
via communication cable to realize stable signal transmission.

ΔMaintenance
a) Empty the feeding hopper before shipment of machine.
b) Empty the feeding hopper if long time not use, for high humidity environment we suggest
to empty feeding hopper after show.
c) Clear material both before and after the show for SPARKULAR®mini.
d) Recommended to wash or replace the air intake filter every two months.
ΔWarranty Instructions
\Sincere thanks for your choosing our products, you will receive quality service from us
\The product warranty period is one year. If there are any quality problems within 7 days after
shipping out from our factory, we can exchange a brand new same model machine for you.
\We will offer free of charge maintenance service for machines which with hardware
malfunction (except for the instrument damage caused by human factors) in warranty period.
Please don't repair machine without factory permission
Below situations NOT included in warranty service:
\Damage caused by use other type of consumable which is not from SHOWVEN®or
SHOWVEN®authorized distributor.
\Damage caused by improper transportation, usage, management, and maintenance, or
damage caused by human factors;
\Disassemble, modify or repair products without permission;
\Damage caused by external reasons (lightning strike, power supply etc.)
\Damage caused by improper installation or use;
For product damage not included in warranty range, we can provide paid service.
Invoice is necessary when applying for maintenance service from SHOWVEN®.

Showven Technologies Co., Ltd.
Tel: [phone]
Web: www.showven.cn E-mail: [e-mail]
Add: No.1 Tengda Road, Liuyang Economic & Technical Development Zone, 410300, Changsha,
Hunan, P.R.China
