Flyer 8411-182 User manual

Assembly Instructions
Kid’s Wheelbarrow
Model # 8411-182
KETTLER
®
International Inc. · 1355 London Bridge Road · Virginia Beach, VA 23453 USA
www.kettlerusa.com / [e-mail] / 866-804-0440
Picture Similar



Readtheseinstructionscarefullybeforeassemblingtheproductorusingitforthefirsttime.They
containimportantinformationforyoursafetyandforthecorrectuseandmaintenanceofthis
product.Keeptheinstructionsinasafeplaceforinformationorfororderingspareparts.

WARNING–*TOAVOIDSERIOUSINJURY*Adultsupervisionrequired.
Neverusenearsteps,slopes,driveways,hills,roadways,alleys,or
swimmingpoolareas.Alwayswearshoes.Neverusenearmotorvehicles.
Neverallowmorethanonerider.Theuseofprotectivegearandsafety
helmetishighlyrecommended.Ridersshouldalwayswearaproperly
fittedhelmetthatcomplieswithConsumerProductSafetyCommission
(CPSC)Standard16CFR1203.Adultassemblyrequired.

Caution!AdultAssemblyRequired.Thispackagecontainssmallparts.
Keepawayfromchildrenuntilassembled.

Thisproducthasbeendesignedinaccordancewiththelateststandardsofsafetyandsubjectedto
constantqualitymonitoring.Thedatagainedfromthisqualityprocessisthenincorporatedinthe
developmentofourproducts.Forthisreason,wereservetherighttomakechangesindesignand
technologyinordertoofferourcustomersproductsofthehigheststandardofqualityatalltimes.

Foryoursafety
■Thistoyshouldbeusedforitsintendedpurposeonly,i.e.one(1)childonly.Itshould
notbeusedinanyotherway,asthismaybedangerous.Themanufacturercannotbeheld
liablefordamageorinjurycausedbyincorrectuse.
■Thisproductisatoyandisnotsuitableforuseintrafficoronpublicroads.
■Alwayskeepawatchfuleyeonyourchildinordertoavoidrisksbythoughtlessandhastymove‐
ments.
■Pleasecareforthefactthatthistoyisonlyusedonsafeground.
■Thisproductissuitableforchildrenbetween3‐7years.
■Thewheelbarrowbucketcanhaulupto30lbs.Excessiveweightmaycauseahazardousor
unstablecondition.
■Thetoyisanunlightedplayimplement.Itsuseinthedarkisdangerous.
■Thistoyisdesignedonlyforprivateuse(nocommercialorpublicuse).
■Thewheelbarrowmustnotbeconnectedwithothervehicles,sportsorsimilardevicesandnot
bedriven/pulledbythem.
■Damagedcomponentsmayendangerthesafetyofyourchildorshortenthelifespanofthepro‐
duct.Inspectitatregularintervalstoensurethatnoneofthecomponentsaredamagedand
thatnoneoftheboltsorotherjointshaveworkedloose.

2


■Replacewornordamagedpartsimmediatelyandensurethattheproductisnotusedagainuntil
thishasbeendone.Ifanypartsrequirereplacement,useonlyoriginalsparesmanufactured
byKETTLER®.

UseoftheToy
■Ensurethatthetoyisnotuseduntilithasbeenproperlyassembledandcheckedbyan
adultperson.
■Instructyourchildhowtousethewheelbarrowcorrectlyanddrawattentiontopossiblesourcesof
danger.
■Althoughdangeroussituationsareunlikelytooccurifthewheelbarrowisusedcorrectly,childrenat
playshould,ifpossible,besupervised.
■Whenchildrenareatplay,situationsmayarisewhichcannotbepredictedbythemanufacturer
andforwhichhecannotbeheldresponsible.
■Keepthisunitcleananddry.Wipeoffdirt,moisture,andoilwithacleansoftcloth.Neveruse
corrosiveorabrasivesubstancestocleanthetoy.Neverusesubstanceswhichmaycause
pollutionoftheenvironment.

Assemblyofthewheelbarrow
■Pleaseensurethatthewheelbarrowwillonlybeusedforplayingwhenassemblyhasbeencarried
outcorrectly,andchecked,byanadult.
■Thetoymustbeassembledcarefullybyanadultperson.Studytheassemblyinstructions
carefullybeforebeginningwork.Thisisessentialforthesafefunctionanduseofthe
wheelbarrow.
■Pleasenotethatthereisalwaysadangerofinjurywhenworkingwithtoolsordoingmanual
work.Thereforepleasebecarefulwhenassemblingthisproduct.
■Ensurethatyourworkingareaisfreeofpossiblesourcesofdanger,forexampledon’tleaveany
toolslyingaround.Alwaysdisposepackagingmaterialinsuchawaythatitmaynotcauseany
danger.Thereisalwaysariskofsuffocationifchildrenplaywithplasticbags!
■Boltallthepartstogetherlooselyatfirst,andcheckthattheyhavebeenassembledcorrectly.
Tightenthelocknutsbyhanduntilresistanceisfelt,thenusewrenchtofinallytightennuts
completelyagainstresistance(lockingdevice).Thencheckthatallscrewconnectionshavebeen
tightenedfirmly.Attention:oncelocknutshavebeenunscrewedtheynolongerfunction
correctly(thelockingdeviceisdestroyed),andmustbereplaced.
■Pleasekeeporiginalpackagingofthisarticle,sothatitmaybeusedfortransportatalaterdate,
ifnecessary.
■Fortechnicalreasons,wereservetherighttocarryoutpreliminaryassemblywork(e.g.addition
oftubingplugs).

Listofsparepartspage7
Whenorderingspareparts,alwaysstatethefullarticlenumber,spare‐partnumber,andthequantity
required.
Exampleorder:Model#8427‐182/spare‐partno.8427‐182#01/1piece
Pleasekeeporiginalpackagingofthisarticle,sothatitmaybeusedfortransportatalaterdate,if
necessary.Goodsmayonlybereturnedafterpriorarrangementandin(internal)packaging,which
issafefortransportation,intheoriginalboxifpossible.
3

Itisimportanttoprovideadetaileddefectdescription/damagereport!Important:sparepart
pricesdonotincludefasteningmaterial;iffasteningmaterial(bolts,nuts,washersetc.)isrequired,
thisshouldbeclearlystatedontheorderbyaddingthewords“withfasteningmaterial”.
WasteDisposal
KETTLERproductsarerecyclable.Attheendofitsusefullifepleasedisposeofthisarticlecorrectly
andsafely(localrefusesites).

KETTLERInternationalInc.∙1355LondonBridgeRoad∙VA23453USA
www.kettlerusa.com



THEREARENOWARRANTIES,EXPRESSEDORIMPLIED,MADEBYEITHERTHEDISTRIBUTORORTHE
MANUFACTURERONKETTLER®PRODUCTS,EXCEPTTHEMANUFACTURER’SLIMITEDWARRANTY
AGAINSTDEFECTSINMATERIALSETOUTBELOW:
ThisKETTLER®LimitedWarrantyappliestoproductssoldthroughtheKETTLER®AuthorizedDealer
Networktotheoriginalretailpurchaserandauthenticatedbyproofofpurchasefromaretailer
locatedintheUnitedStates.Anyshipmentsmadeunderthiswarrantywillbeshippedtothe
UnitedStatesonly.AnyshipmentoutsideoftheUnitedStateswillbeatthesolecostofthe
customer.ThisKETTLER®LimitedWarrantyisamanufacturer’swarrantyandisnotchangedor
modifiedbyadditionalwarrantiesextendedbyindividualretailersatthepointofsale.
Manufacturerwarrantsthisproducttobefreefromdefectsinmaterialatthetimeofthe
product’stenderofdeliveryforaperiodof1yearforresidentialuse.ThisLimitedWarrantyisnot
transferableanddoesnotcovernormalwearandtear(including,butnotlimitedto,damageand
weartotires,powershocks,drivebeltsandothernon‐durableparts).Theliabilityofthe
manufacturerunderthisLimitedWarrantyshallnotincludeanyliabilityfordirect,indirect,or
consequentialdamagesresultingfromthedefect.ThisLimitedWarrantyisvoidiftheproductis
damagedbyaccident,unreasonableuse,improperservice,failuretofollowinstructionsprovided,
modificationfromitsoriginalstate,orothercausesdeterminednotarisingoutofdefectsin
material.

Thiswarrantygivesyouspecificlegalrights.Shouldthisproductbecomedefectiveduetomaterial
withinthewarrantyperiod,contactKETTLER®Parts&ServiceDept.byphoneat866.804.0440,fax
at757.563.9273,ore‐mailat[email protected].
THISLIMITEDWARRANTYISEXPRESSLYINLIEUOFANYOTHERWARRANTIES,EXPRESSEDOR
IMPLIED,INCLUDINGANYIMPLIEDWARRANTYOFMERCHANTABILITYORFITNESSFORA
PARTICULARPURPOSE,ANDOFANYOTHEROBLIGATIONSORLIABILITYONTHEPARTOFTHE
MANUFACTURER.KETTLER®NEITHERASSUMESNORAUTHORIZESANYOTHERPERSONTO
ASSUMEFORITANYOTHERLIABILITYINCONNECTIONWITHSUCHPRODUCTS.

4

1
2
2
2
1
2
M6X40
PARTS & HARDWARE LIST
Lower Handle Arm
Steel Tub
Upper Handle Arm
Wheel
Support Bracket
2
1
2
M6X42
M8X90
M6x10
4
6
4x20 Screws
M6 Hex Nut
M8 Hex Nut
1
Front Wheel Sleeve
1
5

ASSEMBLY
Step 1
Step 2
M8x90 Bolt &
Sleeve
M8 Nut
M8x90 Bolt &
Sleeve
M8 Nut
6

Pos. Description QT
Y
Part#
1 Bucket,Red1 8410‐182#01
2 Wheel1 2385.02.04
3 Leg 2 8410‐182#03
4 Handle 2 8410‐182#04
5 Arm 2 8410‐182#05
6 HardwareBag(notillustrated) 1 HDWRBAG8410‐182
SparePartsDrawingandList
for8411‐182ClassicFlyerbyKettlerWheelbarrow
2
3
1
5
4
©2010KETTLER®.Allrightsreserved.Nopartofthismanualmaybereproduced,storedinaretrievalsystem,
ortransmittedinanyform,orbyanymeans,suchaselectronic,mechanical,photocopyingorotherwise,
withoutthepriorwrittenpermissionofKETTLER®.
docu05/26/10
7
