Flymo Sabre Power Pack User manual

IMPORTANT INFORMATION
Read before use
& retain for future reference
For all customer enquiries or for replacement parts, contact:-
☎☎01325 300303
www.flymo.com
customer[email protected]
5107420-01
Husqvarna Outdoor Products
Aycliffe Industrial Park
NEWTON AYCLIFFE
Co.Durham DL5 6UP
ENGLAND
Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339
UK Customer Helpline - 01325 300303 Fax - 01325 310339
Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.
Sabre
Power Pack

Carton Contents
IMPORTANT ! Please check the contents of the carton are correct BEFORE assembling your new product.
IF ANY PARTS ARE MISSING CONTACT:-
Husqvarna Outdoor Products Customer Service Department direct
Telephone : [phone], Fax : [phone]
Safety
1. Always charge the Power Pack indoors and store in
a cool dry place - out of the reach of children.
2. Use only the charger provided with your unit. Use of
any other charger could permanently damage the
Power Pack.
3. Use the charger with standard domestic household
electrical outlets only.
4. Do not abuse the charger or charger cord.
5. Do not use the charger if the charger or charger
cord is damaged.
6. Use the charger indoors only.
7. Do not use the charger outdoors.
8. Do not charge the Power Pack or use the unit in an
explosive or corrosive environment. Avoid areas
where flammable liquids or gases are present to
avoid creating a fire or explosion.
9. Do not attempt to repair the unit including the Power Pack.
10.Do not incinerate or mutilate the Power Pack.
Batteries contain hazardous chemicals. Dispose of
properly.
If not used properly this product can be dangerous! This product can cause serious injury to the operator and others,
the warnings and safety instructions must be followed to ensure reasonable safety and efficiency in using this product.
The operator is responsible for following the warning and safety instructions in this manual and on the product.
Explanation of Symbols on your product
Warning
Read the user instructions carefully to
make sure you understand all the con-
trols and what they do.
Power Pack Care
1. If over a period of time the Power Pack quickly runs
down after a full 24 hour charging period, a
replacement Power Pack is needed.
2. There will be some charge present in the Power
Pack but to ensure maximum running time, recharge
your Power Pack for 24 hours before use.
3. Permanent connection to the charger in a well
ventilated area will automatically keep your Power
Pack fully charged ready for use.
4. To prevent permanent Power Pack damage, never
store in a discharged condition.
5. Contact your local approved service
centre/dealer/distributor for a replacement Power
Pack and for safe disposal of your old Power Pack.
6. Battery
24 Volt 4.5 Amp/Hour "High Power"
Sealed for Life No maintenance required
• IMPORTANT
DISPOSE OF YOUR OLD POWER PACK SAFELY
DO NOT CUT OPEN, BURN OR INCINERATE.
Power Pack Replacement
Your Power Pack is non-servicable. Should your Power
Pack need to be replaced contact your local approved
service centre or dealer who will replace your old Power
Pack with a genuine Flymo replacement Power Pack.
Winter Storage
1. Fully charge for 24 hours before winter storage.
2. If you are unable to leave your Power Pack on per-
manent charge, re-charge the Power Pack every 3 to
4 months for a full 24 hour charging period to top up
the Power Pack charge during winter storage.
3. Avoid extended storage without re-charge.
4. Store in a cool dry place.
For further information on Power Pack replacement
contact Husqvarna Outdoor Products Customer
Service direct:-
Telephone : [phone]
Fax : [phone]
Power Pack
Fitting the Battery Charger and Charging the Power Pack
A
1
• Attach the Power Pack charger bracket to the wall
using the four screws provided (A)
• IMPORTANT !
Switch charger off at the socket before connecting or
disconnecting the Power Pack to the charger bracket
Initial Charging Procedure
• The Power Pack should be charged for 24 hours
before use.
• Re-charge your Power Pack immediately after
every use for the full 24 hour charging period.
• The Power Pack can be left connected to the
charger permanently, with the charger switched
on, without fear of overcharging.
• The charger will automatically keep the Power
Pack topped up with charge during storage and
will ensure that the Power Pack is ready for use.
1. Use the charger indoors only.
2. Ensure the charger is not exposed to moisture. Keep
the charger and Power Pack dry at all times. Keep
the charger well ventilated during charging.
3. Ensure the Power Pack is correctly located into the
bracket (B) and the charge connector (A1).
4. Plug the charger into a suitable household electrical
socket and switch on.(B1)
5. The indicator lamp glows continuously during charging.
6. Full charge will be achieved in 24 hours. During
charging the charger becomes warm. This is normal
and means the charger is operating correctly.
Re-Charging Your Power Pack
1. Re-charge the Power Pack as soon as the cutting power
of your product begins to die and slow down.
2. Avoid running the cordless product into "deep" discharge,
i.e. avoid flattening the Power Pack completely.
3. Follow the procedure outlined in the Initial Charging
Procedure.
4. Charging the Power Pack according to these instructions
should ensure maximum battery life.
B
Environmental Information
Husqvarna Outdoor Products are manufactured under an
Environmental Management System (ISO 14001) using,
where practical, components manufactured in the most
environmentally responsible manner, according to com-
pany procedures, and with the potential for recycling at
the end of the products’ life.
• Packaging is recyclable and plastic components have
been labelled (where practical) for categorised recycling.
• Awareness of the environment must be considered
when disposing of ‘end-of-life’ product.
• If necessary, contact your local authority for disposal
information.
BATTERY DISPOSAL
• The battery should be taken to an Approved Service
Centre or your local Recycling Station.
• Do NOT dispose of used battery with household waste
• Do NOT dispose of battery to water.
• Lead/Acid batteries can be harmful and should be dis-
posed of through the recognised recycling facility in
accordance with European Regulation
• Do NOT incinerate
The symbol on the product or on its packaging
indicates that this product may not be treated as house-
hold waste. Instead it shall be handed over to the appli-
cable collection point for the recycling of electrical and
electronic equipment.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the envi-
ronment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
For more detailed information about recycling of this
product, please contact your local council office, your
household waste disposal service or the shop where you
purchased the product.
instruction
manual
Storing the Sabre Handle
1. Attach the Sabre Handle Storage Holder to the wall
with the two screws provided (C)
2. Store the Sabre Handle in the holder as illustrated
in Fig D
Storing the Sabre Handle
Sabre
Handle
C D
screws x 4
screws x 4
Power Pack
Power Pack
charger bracket
Sabre Handle
storage holder
Power Pack
charger
1
