Flyzone Micro Super Cub User manual

Please read through this instruction booklet to THOROUGHLY familiarize yourself with the assembly and flight characteristics of this airplane
prior to assembly. Please inspect all parts carefully before starting assembly! If any parts are missing, broken or defective, or if you have any
questions about the assembly or flying of this airplane, please call us at [phone] and we’ll be glad to help.
Hobbico®Inc. guarantees this kit to be free from defects in both material and workmanship at the date of purchase. This warranty does not
cover any component parts damaged by use or modification. In no case shall Hobbico’s liability exceed the original cost of the
purchased kit. Further, Hobbico, Inc. reserves the right to change or modify this warranty without notice. In that Hobbico, Inc. has no
control over the final assembly or material used for final assembly, no liability shall be assumed nor accepted for any damage resulting from
the use by the user of the final user-assembled product. By the act of using the user-assembled product, the user accepts all resulting
liability. If the buyer is not prepared to accept the liability associated with the use of this product, the buyer is advised to return this kit
immediately in new and unused condition to the place of purchase. To make a warranty claim send the defective part or item to Hobby
Services at the address below:
Include a letter stating your name, return shipping address, as much contact information as possible
(daytime telephone number, fax number, e-mail address), a detailed description of the problem and a
photocopy of the purchase receipt. Upon receipt of the package, the problem will be evaluated as quickly
as possible.
© 2011 Hobbico®, Inc. All rights reserved. Printed in China HCAA2552 Mnl
ASSEMBLE ONLY WITH ADULT SUPERVISION
This product is suitable only for people of 14 years and older. WARRANTY
Hobby Services
3002 N. Apollo Dr. Suite 1
Champaign IL 61822 USA
™
™
Please read through this instruction booklet to
THO
ROU
GHL
Y
f
amiliarize
y
oursel
f
with the assembl
y
and
f
light characteristics o
f
this airplane
prior to assembl
y
. Please inspect all parts care
f
ull
y
be
f
ore starting assembl
y
! I
f
an
y
parts are missing, broken or de
f
ective, or i
f
y
ou have an
y
que
stions about the assembl
y o
r flyi
ng
of this airplane, please call us at
(
217
)
398-8970 and we’ll be glad to hel
p.
Hob
bic
o
®
Inc
.
guarantees this kit to be
f
ree
f
rom de
f
ects in both material and workmanship at the date o
f
purchase. This warranty does n
ot
A
SS
EMBLE
O
NLY WITH ADULT
S
UPERVI
S
I
O
N
This
p
ro
duct i
s
su
itable
o
nl
y
fo
r
pe
op
le
o
f14
y
ea
rs
a
nd
o
ld
er
This
product
is
suitable
only
for
people
of
14
years
and
older
.
WA
RR
AN
TY
™
™

2
Check the parts against those shown. If
any parts are damaged or missing, please
call Hobby Services at: [phone].
This device complies with part 15 of the FCC rules.Operation is subject to the following two conditions.
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may cause
undesired operation.
NOTE:THEMANUFACTURERISNOTRESPONSIBLEFORANYRADIOORTVINTERFERENCECAUSEDBYUNAUTHORIZEDMODIFICATIONS
TOTHIS EQUIPMENT.SUCH MODIFICATIONS COULDVOID THE USER’SAUTHORITYTO OPERATETHE EQUIPMENT.
FCC REQUIREMENT
CE COMPLIANCE INFORMATION FOR THE EUROPEAN UNION
Instructions for Disposal of Waste Equipment by Private Users in the European Union: This symbol on the product
or its packaging indicates this product must not be disposed of with other household waste. Instead, it is the user’s
responsibility to dispose of their waste equipment by handing it over to a designated collection point for the recycling
of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the
time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment for recycling, please contact
your local city office, your household waste disposal service or location where you purchased the product.
Declaration of Conformity:
Product: Tactic TTX402 2.4GHz 4-Channel Tx Rx
Item number: TACJ2402, Equipment class: 1
Tactic TTX402 transmitter and Tactic TR421 receiver: The objects
of the declaration described here are in conformity with the
requirements of the specifications listed below, following the
provisions of the European 2006/95/EC Low Voltage Directive:
EN 60950-1:2006 Safety
The objects of the declaration described here are in conformity
with the requirements of the specifications listed below, following
the provisions of the European R&TTE directive 1995/5/EC:
ETSI EN 300 328 V1.7.1 Technical requirements for radio equipment
ETSI EN 301 489-1 V1.8.1, 301 489-17 V1.3.2 General EMC
requirements for radio equipment
Tactic™
c/o Hobbico, Inc.
2904 Research Road
Champaign, IL USA 61826
The associated regulatory agencies of the following
countries recognize the noted certifications to this
product as authorized for sale and use.
UK DE DK BG SE FI FR
EE LV LT PL CZ SK HU
RO SI AT IT ES PT IE
NL LU MT CY GR
INCLUDED ITEMS
FCC AND ETSI

3
Your Micro Super Cub should not be considered a toy, but rather a sophisticated, working model that functions very
much like a full-size airplane. Because of its performance capabilities, the Micro Super Cub, if not assembled and
operated correctly, could possibly cause injury to yourself or spectators and damage to property.
1. Operate the plane according to the instructions. DO NOT alter or modify the model. If you make any modifications,
you void your warranty.
2. Test the operation of the model before each flight to ensure that all equipment is operating properly and that the
model remains structurally sound.
3. Fly only indoors or outdoors on very calm days (with wind speeds less than 5mph) and in large open areas free
of trees, people, buildings, or any other obstacles.
4. Although the Micro Super Cub is designed to be successfully flown by the first time pilot, you may still benefit
from the assistance of an experienced pilot for your first flights. If you’re not a member of an R/C club, your local
hobby shop has information about clubs in your area whose membership includes experienced pilots. You can
also contact the National Academy of Aeronautics (AMA) which has over 2,500 chartered clubs across the country.
Instructor training programs and insured newcomer training are available through any of these clubs. Contact the
AMA at the following address or toll-free phone number:
Academy of Model Aeronautics
5151 East Memorial Drive Ph. [phone]
Muncie, IN 47302-9252 Fx. [phone]
www.modelaircraft.org
The R/C model hobby becomes more and more enjoyable as your experience grows. Your chances for success and
graduation to higher levels are very good if you take your time and follow the flying instructions carefully and completely.
We hope you enjoy flying your Micro Super Cub.
TRANSMITTER CAUTIONS
●Do not use rechargeable (NiCd) batteries.
●Do not mix old and new batteries.
●Do not mix alkaline, standard (carbon-zinc) or
rechargeable (NiCd) batteries.
BATTERY CHARGING PRECAUTIONS
❏1. Always remove the battery from your Micro Super
Cub before charging.
❏2. Do not leave a charging battery unattended!
Unplug the battery if it gets warm, even if the charge
LED has not gone out.
❏3. Use only the charger that comes with your Micro
Super Cub!
WARNING: Misuse or malfunction may overheat the
battery and charger, resulting in personal injury or
damage to surroundings.
PRECAUTIONS
LITHIUM POLYMER BATTERY RECYCLING
ATTENTION: The product you have
purchased is powered by a rechargeable
battery. At the end of the battery’s useful
life, under various state and local laws, it
may be illegal to dispose of this battery
into the municipal waste system. Check with your local
solid waste officials for details in your area for recycling
options or proper disposal.
WARNING: This product contains a chemical known
to the State of California to cause cancer.

●Lithium Polymer (LiPo) Battery: Rechargeable battery which is used to power the airplane. LiPo batteries are
lighter and smaller than most other types of rechargeable batteries.
●Transmitter (Tx): This is the hand-held unit that sends the signal to the control unit, or receiver (Rx).
●Rudder: The control surface on the airplane that turns the plane left and right.
●Elevator: The control surface that makes the plane climb and descend.
●Servo: The device on the model that moves the control surfaces.
●Glide Slope: The proper path for an airplane approaching a landing strip.
GLOSSARY
PREPARETHETTX402TRANSMITTER
For more information on the Tactic Radio System included with the Super Cub visit tacticrc.com
Leave the TTX402
unpowered.
Push in and
slide to remove
the battery door.
Install (5) “AA” batteries.
4

Leave the TTX402
unpowered.
Push in and slide
to open the charge
port cover.
Illuminated green light
indicates charging and will
go out when charging is
complete (approximately
20-30 minutes).
Insert battery to charge.
Make sure the battery
plug is oriented properly
before inserting.
5
CHARGETHE 3.7V 130MAH LIPO BATTERY
Do not use the charge feature while flying the Super Cub!
Peel the paper backing from the
adhesive tabs at the ends of the
wing struts.
Press the tabs onto the indents on
the underside of the wing, making
sure that the struts align with the
indents on the fuselage.
Press the other ends of the struts
onto the indents on the fuselage,
being careful not to affect the
angle of the wing.
INSTALLTHEWING STRUTS

Keep hands clear of propeller during battery installation and removal.
Use two fingers to secure
connector during battery
installation and removal.
Connect the LiPo to the battery. Press battery into
place to secure.
6
INSTALLATION AND REMOVAL OFTHE LIPO BATTERY
Disconnect and remove the battery after use by holding the battery lead with two fingers and removing the battery
from the lead with the other hand. Do not yank or jerk the battery from the aircraft. This could pull the TR421 Rx
board loose from the fuselage.
Illuminated red light
indicates the TTX402
is powered and transmitting.
Center the rudder and
elevator trims.
Leave the left stick
(throttle control) in
the minimum position
during setup.
Power switch “ON”.
TRIM ADJUSTMENT
Full extent.............Centered ........... Full extent
Constant «beep» .....Single «beep» ..... Constant «beep»
POWERTHETTX402 AND CENTERTHETRIMS

Moving the right stick
to the left causes the
rudder to move left.
Moving the right stick down
causes the elevator to move up.
Before flight, center rudder control
surface with rudder trim adjustment.
Before flight, center elevator control
surface with elevator trim adjustment.
7
CHECKTHE CONTROL SURFACE DIRECTION
CENTERTHE CONTROL SURFACE DIRECTION

8
Moving the pushrod inward
increases the control throw
Control Surface
Moving the pushrod outward
decreases the control throw Use caution when removing
and reinstalling the pushrod
in the control horn to avoid
accidentally disconnecting
the linkage from the Rx board.
ADJUSTMENT OF LINKAGES: ELEVATOR AND RUDDER
To increase or decrease the control throws, follow these steps. Be sure to unpower the model before attempting to
mechanically adjust the linkages.
Keep hands and onlookers clear of the propeller during arming and operation.
Throttle control stick is in the low
or minimum position.
Return the throttle control stick to
the minimum position. «Beep Beep»
The motor is now armed.
Raise the throttle control stick
to the maximum or high position.
«Beep»
ARMTHE PROPELLER
Press and hold one of the corresponding
control surface trim buttons and cycle the
power to reverse any control surface.
REVERSETHE CONTROLTHROWS
Unplug the battery from the plane before reversing
the control throws. Only perform this procedure if the
control surfaces move in the wrong direction.

9
With the throttle stick in the full up position, hand launch the
Super Cub into the wind (or if inside, launch in a direction
that will provide you with the largest available space to make
your first turn), at a slight upward angle. The Cub can also
take off from the ground if the surface is smooth.
When your airplane is moving away from you, moving the
right control stick to the left will make your plane turn to
the left. Moving the stick to the right will make the airplane
turn to the right. A small amount of up elevator (move the
right stick down) will keep the plane level during the turn.
Don’t let the airplane get too far away from you. The farther
away it is, the harder it is to see what the airplane is doing.
When learning to fly, it is best to keep the airplane high
enough so that if you make a mistake, you have enough altitude to correct the mistake.
FLYINGTHE SUPER CUB
CHOOSE A FLYING SITE
5 minute flight times
(outdoor)
8–10 minute flight times
(indoor)
With the transmitter turned on and the battery plugged into the Super Cub, walk 50' [15m] from the aircraft and check
the control functions for proper operation.
RANGE CHECK
50' [15m]

10
Repairs can be made to the Super Cub by using the following items:
●Non-butane lighter fluid “Naphtha” (for parts removal and debonding)
●Thick Foam Safe CA (for parts adhesion), GPMR6072
●Foam safe CA accelerator, GPMR6035
●Two sets of needle nose pliers or hemostats, HCAR0625
●Hobby Knife (#11 blade), RMXR6900
●Clear tape
●Hinge tape, DUBQ0916
REPAIRS
Stock No. Description
HCAA6370 Wing Set
HCAA6371 Tail Set
HCAA6372 Fuselage
HCAA6373 Landing Gear
HCAA6374 Pushrods
HCAA6375 Wing Struts
HCAA6376 Control Horns
HCAA6377 Spinner Cone
HCAA6378Decal Sheet
HCAA6348Propeller
HCAA6350 Gear Box Version 2
HCAA6307 Motor
HCAA6309 LiPo Battery
TACJ2402 TTX402 Micro Tactic 4 channel Tx
TACL0421 TR421 4ch Rx Control Board with Actuators
To order replacement parts for the Super Cub, use the order numbers in the list below. Replacement parts are available
only as listed. Replacement parts are not available from Product Support, but can be purchased from hobby shops or
mail order/Internet order firms. If you need assistance locating a dealer to purchase parts from, contact:
Product Support
Phone: [phone] Fax: [phone] E-mail: [email protected]
REPLACEMENT PARTS
To replace or reinstall the propeller, unpower the
model, then hold the motor shaft with needlenose
pliers and push the propeller back onto the shaft.
Once re-installed, add a drop of CA glue to the
propeller to hold it to the shaft.
PROPELLER REPLACEMENT

11
notes

™
™
