INTRODUCTION
The Harbil NSC50 is a compact manual colorant dispenser that was
designed for exceptional reliability and ease of use. It is a nearly
maintenance free device that should deliver many years of reliable service.
Its features include:
• Heavy-duty components and a durable finish for long wear.
• Bottom agitation linked with rotation of the canisters.
• Special adjustable shelving to accommodate all can sizes.
SPECIFICATIONS
Height 60" (152.4 cm.) Max
Width 24" (609.6 cm.)
Depth 30" (762.0 cm.)
Weight 195 lbs (88.5 kg.)
Motor 1/6 HP (Draws 3.0 Amps @ 115 VAC)
TYPICAL ELECTRICAL SUPPLY
See name plate for specific information.
120 V 10%, 60 Hz 15 Amp
IMPORTANT:
If any damage is found, notify the carrier at once
and arrange for inspection in order to claim
recovery. Claims for damage must be made by
the consignee (YOU).The carrier assumes full
responsibility upon acceptance of shipment and
will not entertain any claims by the consignor
(Fluid Management).
CAUTION:
To reduce the risk of Electric Shock or Injury, Use
Indoors Only.

Fluid Ma na geme nt
®
6
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
ASSEMBLY &
INSTALLATION
MOUNTING THE CANISTERS
The Harbil NSC80 requires only the simple fastening of the individual
canisters to the turntable. The canisters must be mounted in the proper order.
Do not fill the canisters before that are mounted.
It is critical that the crank be captured by the bushings that are part of the
star wheel assembly. For machine configurations containing less than 12
canisters, hole plugs are provided (FM P/N 25956) to cover the unused
canister positions.
1. Unplug the machine before installing canisters.
2. The drive star rotates freely around the drive cam mechanism under the
turntable. Rotate drive star with fingers (or other object) inserted through
the large holes. Rotate until all of the nylon drive star bushings are
visible through all of the large holes. (See Figure 1)
ALL
BUSHINGS
VISIBLE
BUSHING
NOT
SHOWING
CORRECT NOT
CORRECT
Figure 1 BUSHING ALIGNMENT
3. Insert two screws into the threaded holes on bottom of the canister.
Allow about 1/8”-1/4” of thread (3-5 threads) to be exposed, as shown in
Figure 2 on page 7.
4. Align the screw heads with the button holes on the turntable for the front
canister position and rotate the agitation blade until the agitation crank is
aligned with the nylon bushing. (Figure 3 on page 7)
5. Lower the canister into position, assuring that the agitation crank is
captured by the nylon bushing and that the screw heads pass through the

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
7
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
1/8 to 1/4
button holes, as shown in figure 3-A. Rotate canister clockwise locking
it into place as shown in Figure 3-B.
NOTE: The dispense port will fall through its hole, and the canister will sit flat on
the turntable.
6. While holding canister in position, secure the canister to the turntable
using a screwdriver. Access holes are provided at the bottom of the
turntable to tighten the two screws. (Figure 4 on page 8) Do not
overtighten these screws.
1/4”- 20
CANISTER
MOUNTING
HOLES
CANISTER
AGITATION
CRANK 1/8”-
1/4”
BOTTOM
VIEW
Figure 2 CANISTER
7. Verify that the agitation crank is engaged by the nylon drive star
bushing. This is done by turning the agitation blade inside the canister.
Resistance to turning indicates that the agitation rod is engaged. If the
agitation blade turns freely, the agitation rod is not engaged and the
canister must be re-mounted.
IF AGITATION
BLADE MOVES
BY HAND, THE
CRANK IS NOT
CAPTURED BY
BUSHING.
ROTATE CLOCK-WISE
TO LOCK CANISTER
INTO PLACE.
(A ) (B )
BUTTO N
HOLE
Figure 3 BUTTON HOLE MOUNTING
8. After installing the first canister, lower the index lever and rotate the

Fluid Ma na geme nt
®
8
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
turntable to the next position.
9. Repeat steps 3-6 for each of the remaining canisters until all are
installed.
10. After completing canister assembly, connect machine to power, and turn
on the agitation switch. Verify that all the agitation blades are turning
properly.
Figure 4 SECURING CANISTER

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
9
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
CONNECTING TO THE POWER SOURCE
GROUNDING
In the event of an electrical short circuit, grounding reduces the risk of
electrical shock by providing an escape wire for the electric current. The 3-
prong plug, equipped with grounding wire, must be plugged into a 3-slot
receptacle that is properly installed and grounded in accordance with all
local codes and ordinances.
DANGER:
Improper use of the grounding plug can
result in a risk of electric shock.
GROUNDED
OUTLET
GROUNDING
PIN
Figure 5 Grounding Methods
DO NOT connect the grounding wire to a flat-blade terminal. The wire with
the insulation having an outer surface that is green (with or without yellow
stripes) is the grounding wire.
Check with a qualified electrician or serviceman if you are not sure how to
ground this machine. Under no circumstances should you modify the
plug if it does not fit the outlet.
WARNING:
After you have plugged the unit into a
dedicated power line and leveled it, inspect
to be sure that you have removed the
shipping materials.

Fluid Ma na geme nt
®
10
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
Connect the 115 volt models only to a 115 volt outlet rated at at least 15
ampere. Connect the 220 volt models only to a 220 volt outlet rated at at
least 15 ampere. The equipment requires a single, grounded outlet.
EXTENSION CORDS
Extension cords for 220 VAC models are not recommended. If an extension
cord is to be used, it should not be combined with others. Use only a 3-wire
extension cord that has a 3-pole grounding plug. Power should be provided
by a 3-pole receptacle that will accept the plug on the product. Make sure
that your extension cord is in good condition. It must have # 16 AWG
conductors up to 25 feet long. An extension cord 25 feet long, but no longer
than 50 feet is permissible provided it has conductors of at least # 12 AWG.
It must be heavy enough to carry the current your product will draw. An
undersized cord can cause a drop in line voltage resulting in loss of power,
overheating and damage to the motor.
Under no circumstances should you modify the plug if it does not fit the
outlet.
Check with a qualified electrician or serviceman if you are not sure how to
ground this machine.
DISTANCE
25
ft
50
ft
100
ft
150
ft
200
ft
250
ft
300
ft
400
ft
500
ft
GAUGE
SIZE
220V
14 14 12 10 10 8 8 6 6
GAUGE
SIZE
115V
14 12 8 6 6 4 4 2 2

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
11
AS
S
E
M
B
L
Y
& IN
S
T
A
L
L
A
T
ION
FILLING CANISTERS
After all of the canisters have been installed on the turntable, they can be
filled. Each canister has a maximum capacity of 2-1/2 quarts. It is
recommended that each canister be filled with two (2) quarts of colorant.
The maximum capacity of the pump is two (2) ounces.
The following steps represent the process by which the canisters should be
filled:
1. Locate the first canister and determine which colorant is to be placed
into that canister.
2. Place the appropriate decal on the canister.
3. Shake of stir the colorant following manufacturers recommendations.
4. Slowly, pour the colorant into the canister to the level of approximately
two (2) quarts.
5. Place the top on the canister.
6. Repeat these steps for each of the remaining canisters.
7. After all of the canisters have been filled, agitate by turning on the
agitation motor. This will release any air trapped in the colorant.
PRIMING OF PUMPS
Once the canisters have been both filled and agitated, the pumps attached to
each of the canisters must be properly primed. Follow these steps to prime
the pumps.
1. Locate the first canister.
2. Slowly pull the pump handle all of the way to the top of its stroke and
wait in this position for a count of approximately three (3) seconds.
3. Slowly press the pump handle all of the way down to the bottom of its
stroke.
4. Repeat these steps five (5) times.
5. Repeat steps 1 through 4 for each of the remaining canisters.

Fluid Ma na geme nt
®
12
BA
S
IC O
P
E
RA
T
ION
BASIC
OPERATION
This dispensing equipment is designed for ease of use. The following steps
represent the method by which a formula is to be dispensed:
1. Determine the formula of the color selected by the customer.
2. Refer to the formula book and select the proper base paint.
3. Remove the lid on the base paint.
4. Pull out the appropriate shelf and place the can of base paint on the shelf.
5. Press the indexing lever down and rotate the turntable to the position
indicated by the formula book.
6. Turn the pump gauge to center the indicator pointer.
7. Lift the pump handle up until the indicator is opposite the notch on the
gauge.
8. Turn the gauge into the notch that represents the desired amount of
colorant per the formula book.
9. After the pump handle has been in this position for about three (3)
seconds, slowly pull the valve lever down and hold in that position with
the left hand.
10. While holding the valve down with the left hand, turn the gauge to the
center of the indicator and slowly push the pump handle down all of the
way to the bottom of the stroke. This will dispense a metered amount of
colorant into the base paint. (Repeat this step as may be required by the
formula book.)
11. Referring to the formula book, Pull down the indexing lever and rotate
the turntable to the next position indicated and repeat these steps for
each of the colorants in the formula.
12. At this point in the process, the can of base paint has been tinted.
Remove the can, press the lid back on and mix appropriately.

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
13
M
AIN
T
E
NANCE
P
ROCEDUR
E
S
MAINTENANCE
PROCEDURES
To ensure safe, dependable operation of the equipment, follow the
maintenance schedule detailed below:
DAILY
Cleaning & Filling:
• Agitate colorants every morning for five (5) to ten (10) minites.
• Clean nozzles & outside cabinet surfaces with soap and water.
• Check canisters and fill as required.
WEEKLY
Cleaning & Nozzle Maintenance:
• Dispense a full measure of any colorant that has not been used
during the previous week. Dispense into a clean container and
return to the appropriate canister.
• Clean all accessible inside surfaces with soap and water.
GENERAL MAINTENANCE
If a nozzle becomes clogged, the obstruction can generally be cleared by
inserting a paper clip or similar object in the valve opening. Before inserting
such a device, open the valve by pulling the valve lever down and holding
while clearing the opening. BE SURE THAT THE VALVE IS OPENED,
AND STAYS OPEN WHILE CLEANING IN THIS WAY. IF THE
VALVE CLOSES AT ANY TIME DURING THIS OPERATION, THE
VALVE COULD BE DAMAGED. If colorant leaks develop at the top of
the pump, or if colorant can be observed on the pump piston rod, the pump
assembly must be repaired. The Pump Repair Kit (P/N 4223212) can be
purchased from the Fluid Management Customer Service Department. A
colorant leak at the bottom of the pump assembly generally indicates that the
pump assembly has been damaged. In this case, the valve assembly must be
replaced with either the Viton Valve Repair Kit (P/N 4231002) or the
Thiokol Repair Kit (P/N 4231011).

Fluid Ma na geme nt
®
14
P
A
R
T
S
:
PARTS:
EQUIPMENT MAINTENANCE LOG
RECORD MODEL NUMBER HERE: _________________________
RECORD SERIAL NUMBER HERE: _________________________
SERVICE DESCRIPTION & PARTS REPLACED SERVICED
DATE
(STATE IF UNDER WARRANTY)
BY

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
15
SPARE PARTS ORDER
Fluid Management Parts Order Form
Photocopy and use this form to
Mail or fax orders to:
Fluid Management A unit of IDEX | Phone: [phone]
1
0
2
3
W
h
e
eli
n
g
R
o
ad
|
Fax: 1
(
847
)
537
-
5530
W
h
eeli
n
g
,
I
L
6
0
090
|
|
Sold To: Ship To:
Purchase Order Number:
Ship Via: __________ _____
☐
☐☐
☐Collect ☐
☐☐
☐Prepaid ☐
☐☐
☐Taxable
☐
☐☐
☐Tax Exempt (Fax copy of exemption certificate.)
QUANTITY
PART
NUMBER DESCRIPTION
UNIT
PRICE
Comments:
_________________________________________________
Signature
______________
Date

Fluid Ma na geme nt
®
16
P
A
R
T
S
:
TURNTABLE
(12 CANISTER SHOWN)
25318
CAP
F0060T13XR
(16 CANISTER)
25033
(12 CANISTER)
BUSHING
24039
CAM
25219
SPACERS
25224
NUT
07046
WASHER
25249
DRIVE
PLATE
25317
(16 CANISTER)
25032
(12 CANISTER)
WHEEL
25222
CIRCLE SHEAR
25316
(16 CANISTER)
25030
(12 CANISTER)
MOTOR
8100001
MOUNTING
PLATE
25225
LEVER
SPRING
4110906
SWITCH
4000033
SHELF
4110909
COUNTER TOP MODELS

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
17
P
AR
T
NO
07046
D
ES
CR
I
P
TI
ON
N
O
R
E
Q
1
5/8”-11 NUT
24039 BUSHING
1 PER CANISTER
25030 CIRCLE SHEAR (12 CANISTER UNITS ONLY) 1
25032 DRIVE PLATE (12 CANISTER UNITS ONLY) 1
25033 CIRCLE SHEAR (12 CANISTER UNITS ONLY) 1
25219 CAM ASSY 1
25222 WHEEL 5
25224 SPACER
10
25225 MOTOR MOUNTING PLATE
1
25249 5/8” FLAT WASHER
1
25318 TURNTABLE (16 CANISTER UNITS ONLY)
1
4000033 POWER SWITCH 1
4110906 LEVER SPRING 1
4110909 SHELF 1
8100001 DRIVE MOTOR 1
F0030T13XR CAP 1

Fluid Ma na geme nt
®
18
P
A
R
T
S
:
TURNTABLE (12 CANISTER SHOWN)
25318
CAP
F0060T13XR
(16 CANISTER)
25033
(12 CANISTER)
NUT
07046
WASHER
25249
BUSHING
24039
CAM
25219
DRIVE
PLATE
25317
(16 CANISTER)
25032
(12 CANISTER)
WHEEL
25222
CIRCLE SHEAR
25316
(16 CANISTER)
25030
(12 CANISTER)
LEVER
SPRING
4110906
SPACER
25224
MOUNTING
PLATE
25225
MOTOR
8100001
(120VAC/60HZ)
23252
(220VAC/50HZ)
SWITCH
4000033
KNOB
4000008
FLOOR MODELS

N
S
C
5
0
Ope
r
at
i
n
g
&
Ins
t
r
u
cti
o
n
Ma
n
u
al
19
P
AR
T
NO
07046
D
ES
CR
I
P
TI
ON
N
O
R
E
Q
1
5/8”-11 NUT
23252 DRIVE MOTOR
(220VAC/50HZ UNITS ONLY)
1
24039 BUSHING
1 PER CANISTER
25030 CIRCLE SHEAR (12 CANISTER UNITS ONLY) 1
25032 DRIVE PLATE (12 CANISTER UNITS ONLY) 1
25033 TURNTABLE (12 CANISTER UNITS ONLY) 1
25219 CAM 1
25222 WHEEL 5
25224 SPACER 10
25225 MOTOR MOUNTING PLATE
1
25249 5/8” FLAT WASHER
1
25316 CIRCLE SHEAR (16 CANISTER UNITS ONLY)
1
25318 TURNTABLE (16 CANISTER UNITS ONLY)
1
4000008 BLACK
1
4000033 POWER SWITCH 1
4110906 LEVER SPRING 1
8100001 DRIVE MOTOR
(120VAC/60HZ UNITS ONLY)
1
F0060T13XR CAP 1

Fluid Ma na geme nt
®
20
P
A
R
T
S
:
PIN
8101106
CRANK
SHAFT
24383
AGITATION
BLADE
23243
CANISTER
4215000
(FOR 1 OZ. PUMP)
4215011
(FOR 2 OZ. PUMP)
