FMI P324E Safety guide

For more information, visit www.fmiproducts.com
MODELS P324E, VP324E, P325E(B) AND VP325E(B)
NATURAL GAS
B-VENT DECORATIVE GAS FIREPLACE
OWNER’S OPERATION AND INSTALLATION MANUAL
FOR YOUR SAFETY
— Donotstoreorusegasolineoranyotherammable
vapors or liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Donottrytolightanyappliance.
• Donottouchanyelectricalswitch;
• Donotuseanyphoneinyourbuilding.
• Immediatelycallyourgassupplierfromaneighbor’s
phone.Followthegassupplier’sinstructions.
• Ifyoucannotreachyourgassupplier,callthere
department.
— Installationandservicemustbeperformedbyaquali-
edinstaller,serviceagencyorthegassupplier.
INSTALLER:Leavethismanualwiththeappliance.
CONSUMER:Retainthismanualforfuturereference.
WARNING:Iftheinformationintheseinstructions
isnotfollowedexactly,areorexplosionmayresult
causingpropertydamage,personalinjuryordeath.
PFS
®
US

www.fmiproducts.com 108794-01G2
 WARNING: Improper installation, adjustment, al-
teration, service or maintenance can cause injury or
propertydamage.Refertothismanualforcorrectin-
stallation and operational procedures. For assistance
or additional information consult a qualied installer,
service agency or the gas supplier.
NOT FOR USE WITH SOLID FUEL
CHECK LOCAL CODES PRIOR TO INSTALLATION
SAVE THIS BOOK
Thisbookisvaluable.Inadditiontoinstructingyouon
howtoinstallandmaintainyourappliance,italsocon-
tainsinformationthatwillenableyoutoobtainreplace-
mentpartsoroptionalaccessoryitemswhenneeded.
Keepitwithyourotherimportantpapers.
Thisappliancemaybeinstalledinanaftermarket*,per-
manentlylocated,manufactured(mobile)home,where
notprohibitedbystateorlocalcodes.
Thisapplianceisonlyforusewiththetypeofgasindi-
cated on the rating plate.
This appliance is not convertible for use with other
gases,unlessacertiedkitisused.
*Aftermarket:Completionofsale,notforpurposeofresale,fromthemanufacturer.
TABLE OF CONTENTS
Safety .................................................................. 3
Unpacking............................................................ 4
Introduction.......................................................... 4
Selecting Location ............................................... 5
Product Specications......................................... 6
Pre-Installation Preparation................................. 7
Venting Installation .............................................. 8
Fireplace Installation...........................................11
Operation........................................................... 18
Inspecting Burners ............................................ 19
Cleaning and Maintenance................................ 20
Replacement Parts............................................ 20
Service Hints ..................................................... 20
Technical Service............................................... 20
Wiring Diagram.................................................. 21
Troubleshooting................................................. 22
Accessories ....................................................... 25
Parts .................................................................. 26
Warranty ..............................................Back Cover

www.fmiproducts.com
108794-01G 3
SAFETY
WARNING: This product con-
tainsand/orgenerateschemicals
knowntotheStateofCalifornia
tocausecancerorbirthdefects
orotherreproductiveharm.
IMPORTANT:Readthisowner’s
manualcarefullyandcompletely
before trying to assemble, op-
erate or service this replace.
Improper use of this replace
cancauseseriousinjuryordeath
from burns, re, explosions,
electrical shock and carbon
monoxidepoisoning.
DANGER:Carbonmonoxide
poisoningmayleadtodeath!
This replace is a vented product. This replace
will not produce any gas leakage into your home
if properly installed. This replace must be
properly installed by a qualied service person.
If this unit is not properly installed by a qualied
service person, gas leakage can occur.
CarbonMonoxidePoisoning: Early signs of
carbon monoxide poisoning resemble the u,
with headaches, dizziness or nausea. If you
have these signs, the replace may not have
been installed properly. Getfreshairatonce!
Have replace inspected and serviced by a
qualied service person. Some people are more
affected by carbon monoxide than others. These
include pregnant women, people with heart or
lung disease or anemia, those under the inu-
ence of alcohol and those at high altitudes.
Propane/LP gas and natural gas are both
odorless. An odor-making agent is added
to each of these gases. The odor helps you
detect a gas leak. However, the odor added
to these gases can fade. Gas may be present
even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this replace.
WARNING: Any change to
thisreplaceoritscontrolscan
bedangerous.
1. This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases unless a certied kit is
used.
2. For propane/LP replace, do not place
propane/LP supply tank(s) inside any
structure. Locate propane/LP supply
tank(s) outdoors. To prevent performance
problems, do not use propane/LP fuel tank
of less than 100 lbs. capacity.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not
use any phone in your building
• immediately call your gas supplier from
a neighbor’s phone. Follow the gas sup-
plier's instructions
• if you cannot reach you gas supplier, call
the re department.
4. Never install the replace
• in a recreational vehicle
• where curtains, furniture, clothing or
other ammable objects are less than
36" from the front and 42" from the top
top of the replace. For side clearances
see Figure 6, page 7
• in high trafc areas
• in windy or drafty areas
5. This replace reaches high temperatures.
Keep children and adults away from hot
surfaces to avoid burns or clothing igni-
tion. Fireplace will remain hot for a time
after shutdown. Allow surfaces to cool
before touching.
6. Carefully supervise young children when
they are in the room with replace.
7. A hearth extension is not required with this
appliance. If one is installed, it is for aes-
thetic purposes only and does not have
to meet the standard requirements.
8. Turn replace off and let cool before ser-
vicing or repairing. Only a qualied service
person should install, service or repair
this replace. Have replace inspected
annually by a qualied service person.
9. You must keep control compartments,
burners and circulating air passages
clean. More frequent cleaning may be
needed due to excessive lint and dust
from carpeting, bedding material, etc.
Turn off the gas valve and pilot light before
cleaning replace.
10. Have venting system inspected annually by
a qualied service person. If needed, have
venting system cleaned or repaired. See
Cleaning and Maintenance, page 20.

www.fmiproducts.com 108794-01G4
11. Keep the area around your fireplace
clear of combustible materials, gasoline
and other ammable vapor and liquids.
Do not run fireplace where these are
used or stored. Do not place items such
as clothing or decorations on or around
replace.
12. Do not use this replace to cook food or
burn paper or other objects.
13. Do not use any solid fuels (wood, coal,
paper, cardboard, etc.) in this replace.
Use only the gas type indicated on re-
place nameplate.
14. This appliance, when installed, must be
electrically grounded in accordance with
local codes or, in the absence of local
SAFETY
Continued
These replace models are vented gas re-
places that use an electronic ignition system.
Models P325E/VP325E have a 5" B-vent and
P324E/VP324EA have a 4" B-vent. A properly
sized B-type venting system and a listed type
vent cap are not supplied but are required for
proper operation. See venting instructions
on page 9.
WARNING: This gas appli-
ancemustnotbeconnectedto
achimneyueservicingasolid
fuelburningappliance.
These models are factory equipped for use
with natural gas and must be converted when
intended for use with proper propane/LP gas.
Conversion kits PCBE-324 and PCBE-325
may be purchased for simple conversion to
propane/LP gas. See Accessories, page 25.
BEFORE YOU BEGIN
Before beginning installation of your appli-
ance, read these instructions completely.
codes, with the National Electrical Code,
ANSI/NFPA 70.
15. Do not install replace directly on carpet-
ing, vinyl tile or any combustible material
other than wood. The replace must set
on a metal or wood panel extending the
full width and depth of the replace.
16. Do not use replace if any part has been
exposed to or under water. Immediately
call a qualied service person to arrange
for replacement of the unit.
17. Do not operate fireplace if any log is
broken.
18. Provide adequate clearances around air
openings.
UNPACKING
The following items are packed inside the
rebox. Remove before positioning rebox
into framing.
• Ceramic Log Pack - Shrink-wrapped on
cardboard
• Three (3) plastic bags containing lava rock,
pan and ember materials
• Rear Log (P325E/VP325E Models Only)-
Remove the two plastic quick ties from
around burner and grate
• Grate Stand - Lift off of burner pan
Check all items for any shipping damage. If
damaged, promptly inform dealer or distributor
where you bought the product.
Safely retain these items for later installation.
INTRODUCTION
This FMI PRODUCTS, LLC appliance and its
approved components are safe when installed
according to this installation manual and are
operated as recommended by FMI PROD-
UCTS, LLC. Unless you use FMI PRODUCTS,
LLC approved components tested for this appli-
ance, YOUMAYCAUSEAFIREHAZARD!
The FMI PRODUCTS, LLC warranty will be
voided by and FMI PRODUCTS, LLC disclaims
any responsibility for the following actions :
A) Modication of the appliance or any of the
components.
B) Use of any component part not approved
by FMI PRODUCTS, LLC in combination
with this appliance.
C) Installation and/or operation in a manner
other than instructed in this manual.
D) The burning of anything other than the
type of gas approved for use in this gas
appliance.
The installation must conform with local codes
or, in the absence of local codes, with the cur-
rent National Fuel Gas Code, ANSI Z223.1/
NFPA 54. This appliance complies with ANSI
Z21.50.

www.fmiproducts.com
108794-01G 5
WARNING: Installation of
thisappliance shouldbe done
by a qualied service person
well trained in the installation
of such appliances. You will
alsoneedabuildingpermitfrom
your local Building and Safety
Commissionerbeforeinstalling
this appliance; otherwise your
insurance company may not
cover this appliance.
NOTICE: This appliance is not
intendedtobeusedasaprimary
source of heat.
INTRODUCTION
Continued
Figure 1 - Possible Locations for
Installing Appliance
INTERNAL WALL
INSTALLATION
CORNER
INSTALLATION
FULL
PROJECTION
INSTALLATION
FLUSH
INSTALLATION
To determine the safest and most efcient
location for your appliance, you must take into
consideration the following guidelines:
1. The location must allow for proper clear-
ances (see Clearances, page 7).
2. Consider a location where heat output
would not be affected by drafts, air con-
ditioning ducts, windows or doors.
3. A location that avoids the cutting of joists
or roof rafters will make installation easier.
Figure 1 shows a plan view of a few com-
mon locations.
Flush installations are recommended where
living space is limited or at a premium and
since the space required to enclose the ap-
pliance would be located beyond an outside
wall, this would also reduce the cutting of
joists, roof rafters and such. Check local
codes for any restrictions.
Projected installations can extend any
distance into the room. A projection may
be ideal for a new addition on an existing,
nished wall.
CAUTION: Do not connect
appliancebeforepressuretest-
inggaspiping.Damagetogas
valvemayresultandanunsafe
conditionmaybecaused.
The appliance and it’s individual shutoff valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of 1/2
psig (3.5 kPa).
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shutoff valve during any pressure
testing of the gas supply piping system at
test pressures equal to or less than 1/2 psig
(3.5 kPa).
For the purpose of input adjustment two
pressure taps (for IN and OUT pressures)
are provided on the gas control valve for test
gauge connections to the appliance.
SELECTING LOCATION
Corner installations make use of space
that may not normally be used and provides
a wider and more efcient range for radiant
heat transference.
Internalwallinstallations provide a discreet
option for room separation and can also be
ideal as an addition to an existing wall.

www.fmiproducts.com 108794-01G6
PRODUCT SPECIFICATIONS
Figure 2 - Appliance Dimensions
6
7
/ 8 "
2
1
/ 4 "
7"
7"
Alternate Gas
Supply Inlet
13
1
/ 4 "
32
1
/ 4 "
* 27
1
/ 2 "
29"
* 13
3
/ 4 "
14
1
/ 2 "
* 20
3
/ 8 "
21
1
/ 2 "
2
1
/ 2 "
8
1
/ 4 "
11
3
/ 4 "
22
3
/ 8 "
For Use
With B-1
Vent Pipe
Only 16
3
/ 4 "
7
5
/ 8 "
10
5
/ 8 "
8
1
/ 8 "
10
1
/ 2 "
8
3
/ 8 "
2
1
/ 2 "
8
1
/ 4 "
5/8" 34
1
/ 2 "
35
3
/ 8 "
29
1
/ 2 "
18
1
/ 4 "
7"
7"
16
3
/ 4 "
36
1
/ 2 "
* WITH REFRACTORY
DIMENSIONS
HEARTH AREA
GAS RATING - NATURAL
P324E,VP324E P325E(B),VP325E(B)
Max. Input Rating: 15,000 Btu/Hr 25,000 Btu/Hr
Manifold Pressure: 3.5" WC (.87 kPa) 3.5" WC (.87 kPa)
Minimum Supply Pressure: 4.5" WC (1.12 kPa) 4.5" WC (1.12 kPa)
Maximum Supply Pressure: 10.5" WC (2.66 kPa) 10.5" WC (2.66 kPa)
Orice Size: # 49 # 40
GAS RATING - PROPANE/LP
Max. Input Rating: 15,000 Btu/Hr 25,000 Btu/Hr
Manifold Pressure: 10" WC (2.49 kPa) 10" WC (2.49 kPa)
Minimum Supply Pressure: 11" WC (2.74 kPa) 11" WC (2.74 kPa)
Maximum Supply Pressure: 13" WC (3.23 kPa) 13" WC (3.23 kPa)
Orice Size: # 56 # 54

www.fmiproducts.com
108794-01G 7
PRE-INSTALLATION PREPARATION
Figure 3 - Minimum Clearances
(Top View)
0"
0" Clearance
Nailing
Flange
Front Face
Left Side
Surround Back
Drywall
2 x 4 Stud
Figure 4 - Minimum Clearances
(Front View)
MANTEL CLEARANCES AND WALL
DETAILS
A combustible mantle shelf maybe installed
a maximum 12" (22.90 cm) from the wall.
Figures 5 and 6 show the minimum allow-
able distances from various combustible
mantle components in relation to the replace
opening.
Figure 5 - Mantel Clearances - Side View
(Cross Section)
Figure 6 - Side Clearances - Top View
(Cross Section)
** **
42" (10.67 cm)
Min. Clearance
from Opening to
Ceiling
0" Clearance
Ceiling
1" (2.5 cm) Min.
Clearance to
"B" Vent's Outer Pipe
Required
Air Spaces
are Indicated
with an "
*
".
Do Not
Pack with
Insulation or
Any Other
Material
DO NOT BLOCK
OR OBSTRUCT
OPENINGS
0" Clearance
to Wood or
Noncombustible
Flooring
Spacer
3" (7.6 cm)
1 1/2"
(3.8 cm) Max.
8" (20.3 cm)
6" (15.2 cm)
13" (33 cm)
12"
(22.9 cm)
Combustible
Materials
Header
1 1/2" (3.8 cm)
Max.
3" (7.6 cm)
Max.
6" (15.2 cm)
Max. 9"
(22.86 cm)
12"
(30.48 cm)
Outer Surround
Combustible
Material May
Be Used
TOP VIEW
SAFE
ZONE
Perpendicular
Wall
CLEARANCES
Minimum clearances to combustibles are:
• Top of Spacers 0" min.
• Back/Sides of Outer Surround 0" min.
• Drywall to Sides of Front Face
(Nailing Flanges) 0" min.
• “B” Vent Surfaces 1" min.
• Ceiling to Opening 42" min.
• Floor 0" min.
• Perpendicular Wall See Figure 6
 CAUTION: Do not block
required air spaces with insu-
lationoranyothermaterial.Do
not obstruct effective opening
of appliance with any type of
facingmaterial.

www.fmiproducts.com 108794-01G8
PRE-INSTALLATION PREPARATION
Continued
FRAMING
1. Frame appliance enclosure as illustrated
in Figures 7 and 8.
Note: If a wall covering is used to line
enclosure, then all measurements must
be from surface of covering.
2. Place appliance into framing and secure.
Note: If appliance is to be raised above
oor level, a platform must be built to
support appliance.
3. Install supply line to appliance using a
1/2" NPT black iron gas line terminating
2 5/16" above bottom of appliance. The gas
line must be installed through the lower
left side access point or alternate access
hole in bottom of appliance (see Figure
16, page 12).
4. Feed exible gas line through one of three
gas line conduit sleeves and repack insu-
lation to cover any openings. Prepare the
incoming gas line with teon tape or pipe
joint compound and hook up incoming gas
line to exible gas line.
Note: If 1/2" NPT black iron pipe does not
mate with tting at end of exible gas line,
remove tting and replace with a 37° are
3/4"-12, 1/2" NPT (female) tting.
 WARNING: When nishing
appliance,donotoverlapcom-
bustiblematerialontotheblack
frontface.Brick,tileorothernon-
combustible materials may be
applied to the face provided that
anygapisbetweenthematerial
usedandthefaceiscaulkedwith
anoncombustiblecaulking.
Figure 7 - Rough Opening for Installing
in Wall
Figure 8 - Corner Installation Guidelines
16 3/4"
12"
39 3/8"
55 5/8"
34 1/2"
16"
These Dimensions Allow for a 3/4"
Clearance at Sides and Back of Fireplace.
However, 0" Clearance is Permitted
3/4" Clearance Not Required at
Nailing Flanges
VENTING INSTALLATION
16 1/8"
34 3/4"
36 5/8"
A B-type venting system must be connected to
appliance for venting to outside of building.
The following section is provided as a guide
to a standard B-type vent installation.
Standing codes requirements concerning B-
type vent installations may vary within your
state, province or local codes jurisdiction.
Therefore, it is recommended that you check
with your local building codes for specic
requirements or in absence of local codes,
follow Section 7.0 of the current National Fuel
Gas Code ANSI Z223.1/NFPA 54.
This gas appliance must be vented to the
outdoors only and may not be terminated into
an attic space or into a chimney ue servicing
a solid fuel burning appliance.

www.fmiproducts.com
108794-01G 9
This appliance may be vented through a
manufactured chimney system or a masonry
chimney using a B-vent adapter or a chim-
ney liner system if all are listed, inspected
and approved by local codes and/or building
authorities.
The examples shown in Figure 9 are typi-
cal of most B-vent installations and codes
practices.
Example1: Shows the minimum allowable
system height and lateral offset for a 60° or
greater inclination. Code species that offsets
at 60° or greater are considered horizontal
and must follow the 75% rule for lateral to
total vertical system height. Codes also al-
lows only one offset in the total system when
at 60° or greater. The total vertical height in
this example represents the minimum height
of 8 feet and therefore the allowable lateral
is 6 feet when the 75% rule applies. If the
lateral length must exceed 75% then the
system must be sized in accordance with the
Category I venting tables.
Example2: Shows a multiple offset each at
45° of inclination. Multiple offsets are permit-
ted if they do not exceed 45° of inclination. The
total lengths of the two offsets are not required
to meet the 75% allowable rule.
Example3:Shows a single offset at 45° of
inclination and therefore the lateral length at
10 feet of offset does not have to meet the
75% rule.
Maintain
Listed
Clearance
Maintain
Listed
Clearance
12' Min.
12' Min. 45°
45°
6'
8'
12' Min.
60° 45°
Position
Firestop
Position
Firestop
Position
Firestop
Listed
Vent Cap
Listed
Vent Cap
Listed
Vent Cap
Maintain
Listed
Clearance
Maintain
Listed
Clearance
Maintain
Listed
Clearance
Maintain
Listed
Clearance
Support Each
Lateral At
Least Every
6 Feet
Maintain
Listed
Clearance
10'
EXAMPLE 3EXAMPLE 2
EXAMPLE 1
Figure 9 - Typical B-Vent Conguration
VENTING INSTALLATION
Continued
In each case the offsets must be supported
and restops must be positioned wherever
the vent must pass through a sub-oor, ceil-
ing joist or an attic overhang. The vent pipe
must terminate vertically into a listed type vent
cap and extend a sufcient height through
an approved roof ashing, roof jack or a roof
thimble. At all points the listed clearances
must be maintained.
Vent terminations must be located in ac-
cordance with height and proximity rules of
NFPA No. 54. These rules apply to vents at
12" diameter or less and require a minimum
height in accordance with the roof pitch and a
minimum of 8 feet distance from a vertical wall
or obstruction (see Figure 10, page 10).
If venting horizontally through a side wall be-
comes necessary, a listed thimble approved
for use with B-type vent must be used. Check
with your local codes before venting through
a side wall.
Some codes areas allow the use of existing B-
type vent systems if the system is at or above
the recommended diameter of the ue.
The ue connection must be made using
listed B-type connectors and the existing
system must be code inspected for damage
and proper installation.

www.fmiproducts.com 108794-01G10
VENTING INSTALLATION
Continued
It is not recommended that this appliance be
common vented with an existing gas burning
appliance. However, if it becomes necessary
to common vent this appliance, the venting
system must be sized and congured in ac-
cordance with the common venting guides
Appendix G of the current National Fuel Gas
Code NFPA No. 54/ANSI Z223.1.
Note: Before connecting this appliance to an
existing vent system or a common venting
system consult with your local architect, plan-
ner, or building ofcial.
WARNING: This appliance
must be properly connected
to a system and must not be
connected to a chimney ue
servicing a separate solid fuel
burningappliance.
CHECKING FOR PROPER VENTING
After completing and checking electrical,
gas and vent connections, follow lighting
instructions and allow main burner to run
for approximately 5 minutes. Hold a lighted
match or cigarette near top edge of replace
opening and play it along entire length of
the opening (see Figure 12). Proper venting
should tend to draw the ame or smoke into
the appliance. Improper venting or escaping
of spillage of burned gas, is indicated when
the match ickers or goes out. Smoke from a
cigarette will also tend to disperse away from
the appliance.
If the appliance is found to be improperly
venting, shut it off and notify your installer
or a qualied service agency to inspect the
venting system.
NOTICE: This appliance is
equipped with a vent safety
shutoff switch which will shut
downtheapplianceinthecase
of a venting problem. Do not
bypasstheventsafetyswitch.If
theapplianceshouldshutdown,
contactaqualiedinstaller,ser-
vice agency or your gas supplier
tohavetheventinspectedbefore
operating.
Lowest
Discharge
Opening
Listed
Ve nt Cap
8 Ft. Min.
Roof Pitch x/12
Listed Clearance
12
x
Listed
Gas
Ve nt
H (Min)
Height
From Roof
Roof Pitch H(Min.)Ft. m
Flat to 6/12 1.0 0.30
6/12 to 7/12 1.25 0.38
Over 7/12 to 8/12 1.5 0.46
Over 8/12 to 9/12 2.0 0.61
Over 9/12 to 10/12 2.5 0.76
Over 10/12 to 11/12 3.25 0.99
Over 11/12 to 12/12 4.0 1.22
Over 12/12 to 14/12 5.0 1.52
Over 14/12 to 16/12 6.0 1.83
Over 16/12 to 18/12 7.0 2.13
Over 18/12 to 20/12 7.5 2.27
Over 20/12 to 21/12 8.0 2.44
Figure 10 - B-Vent Terminations
Check this area
along entire top
edge of replace
opening. Smoke
or ame should
be drawn into
appliance opening.
Figure 11 - Checking for Spillage

www.fmiproducts.com
108794-01G 11
FIREPLACE INSTALLATION
Figure 12 - Removing Front Refractory
Access Panel (P325E/VP325E Model
Shown)
Figure 13 - Installing the WRC Remote
Receiver
Fireplace
Receptacle Remote
Control
Receiver
Extension
Cord
Ignition Module
Plug
Figure 14 - Installing Battery into Back of
Handset
Pull to Remove
Insulation Tab
Battery Cover
12 Volt Battery
Back of
Handset
WALL SWITCH INSTALLATION
The installation of a wall switch allows you
to activate the gas control valve and turn the
replace on and off. The wall switch is to be
connected to the incoming 120 volt regular
household wiring that supplies the electricity
to the replace. Refer to Wiring Diagram,
page 21.
OPTIONAL REMOTE CONTROL
INSTALLATION(ModelWRC)
Note: If using optional wireless hand-held
remote control, wall switch must be in ON
position to be operational. The remote control
then becomes the switching mechanism for
replace operation.
1. Remove front refractory access panel by
lifting up and angling out of rebox open-
ing (see Figure 12).
2. WRC model receiver does not require a
battery. Receiver can be installed by rst
plugging short extension cord into replace
receptacle. Plug receiver unit into exten-
sion cord. Finally, plug ignition module plug
into receiver unit (see Figure 13).
3. Activate remote handset battery by re-
moving insulating tab on back of handset
(see Figure 14). Battery is included pre-
installed.
4. Once battery is activated, unit is ready to
use.
5. Replace front refractory access panel.

www.fmiproducts.com 108794-01G12
GAS LINE HOOK-UP
 WARNING: Gas line hookup
shouldbedonebyyourgassuppli-
eroraqualiedserviceperson.
WARNING: Before you pro-
ceed,makesureyourgassupply
is OFF.
The appliance and it’s individual shutoff valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of 1/2
psig (3.5 kPa).
The appliance must be isolated from the gas
supply piping system by closing its individual
equipment shutoff valve during any pressure
testing of gas supply piping system at test pres-
sures equal to or less than 1/2 psig (3.5 kPa).
An equipment shutoff valve has been included
in the appliance’s gas supply system. You may
consider installing an extra gas shutoff valve
outside the appliance’s enclosure (check with
local codes) where it can be accessed more
conveniently with a key through a wall as
shown in Figure 15.
In conformance with local codes, route a
1/2" NPT gas line towards the appliance
coming in from any of the 3 directions shown
in Figure 16.
CAUTION:Donotkinkex-
iblegasline.
FMI PRODUCTS, LLC recommends that a
black iron gas line be routed from the gas
source, through a sediment trap (shown in
Figure 17, page 13) and into appliance. Once
connected through appliance, a exible gas
line may be used for ease of installation to gas
control valve (see Figure 18, page 13).
Before connecting black iron gas line to inside
of appliance a sediment trap must be included
outside appliance between gas line and gas
shutoff valve. It must extend down 3" beyond
center of pipe. Prepare incoming black iron
gas line with teon tape or pipe joint com-
pound (Check with local building codes).
FIREPLACE INSTALLATION
Continued
CAUTION:Compoundsused
onthreadedjointsofgaspiping
shallberesistanttotheaction
of Liqueed Petroleum (LP or
propane)andshouldbeapplied
lightlytoensureexcesssealant
does not enter the gas line.
WARNING: All gas piping
andconnectionsmustbetested
forleaksaftertheinstallationis
completed.
After ensuring that the gas valve
ison,applyacommercialleak
detection solution to all con-
nectionsandjoints.Ifbubbles
appear, leaks can be detected
and corrected.
Donotuseanopenameforleak
testing and do not operate any
applianceifaleakisdetected.
Complete your gas installation by connect-
ing incoming gas line with exible gas line.
Secure tightly with wrench but DO NOT
OVERTIGHTEN.
Figure 15 - Shutoff Valve Installation
Typical Exterior Wall Gas
Shutoff Installation
Key
Extension
Shutoff
Valve
Figure 16 - Routing Incoming Gas Line
8
3
/
8
"10
5
/
8
"
1/2" NPT Incoming
Black Iron Gas Line
Flexible
Gas Line
(1 Provided)
Can Be
Extended Out
Either Side
7"
7"
Alternate Gas Supply
Through Sub-Floor

www.fmiproducts.com
108794-01G 13
3" Min.
(7.6 cm)
Side Wall
Of Appliance
Incoming
1/2" Gas Line
Permitted by
Local Codes
Sediment Trap
(Not Supplied)
Figure 17- Sediment Trap
FIREPLACE INSTALLATION
Continued
Figure 18 - Connecting Flexible Gas Line to Millivolt Valve
1/2" NPT Incoming
Gas Line Inlet Pressure Tap
Outlet Pressure Tap
Equipment
Shutoff Valve Flexible Gas Line
Do NOT Kink
Note:
1) Wire Connections Not Shown for Clarity
2) * 1/8" NPT Plugged Tapping
Red Surface Indicates For
Propane/LP Use Only
GRATE PLACEMENT
The grate must be placed in the burner pan so that the back grate ngers (P325E/VP325E)
or pins (P324E/VP324E) t into notches on back of burner pan and front legs t inside burner
pan as shown in Figure 19.
Figure 19 - Placing Grate into Burner Pan
P324E/VP324E
(Back)
P325E/VP325E
(Back)
Pins
Notches
Pins
Notches
Back Grate Fingers
Back Grate Fingers
Burner Pan
Burner Pan
Front
Leg
Front
Leg

www.fmiproducts.com 108794-01G14
0.5"
0.5"
Figure 22 - Pan and Ember Material
Clearances
Grate
Burner Pan
Pan and Ember
Material
EMBER AND PAN MATERIAL
PLACEMENT
1. Open bag(s) of vermiculite and ll entire
burner pan until burner tube is completely
covered (see Figure 20).
2. Smooth pan material just even with edges
of burner pan.
3. Remove ember material from bag and
atten small amounts into quarter size
pieces and lay on top of surface of pan
material (see Figure 21).
4. Place just enough to cover entire surface
and leave about a 1/2" gap under lower
grate members to allow air to ow (see
Figure 22).
Figure 20 - Fill Entire Burner Pan with
Vermiculite (P324E, VP325E Shown)
Figure 21 - Ember Material on Surface of
Pan Material (Vermiculite)
(P324E, VP325E Shown)
Vermiculite
(Pan Material) Burner Pan
Grate
Ember Material
Burner
Pan
Vermiculite (Pan Material)
Grate
FIREPLACE INSTALLATION
Continued
LOG PLACEMENT FOR P324E/
VP324E MODELS
1. Place front log (log 1) onto front of grate
sliding log all the way forward against
grate ngers (see Figure 23).
2. Insert pegs on bottom of rear log (log 2) into
holes in rear of grate (see Figure 23).
3. Place log 3 into notches on left side of
logs 1 and 2 (see Figure 24, page 15).
4. Place log 4 into notches on right side of
logs 1 and 2 (see Figure 24, page 15).
To enhance the look of the hearth you may
optionally place provided lava rock around
front and sides of burner.
NOTICE: Do not put lava rock
insidetheburnerpanoraround
theairmixertting.Placinglava
rock inside the burner pan or
blockingtheopeningsofthepro-
pane/LPair-mixercould cause
performanceproblems.
Figure 23 - Installing Logs 1 and 2
Log 1
Log 2

www.fmiproducts.com
108794-01G 15
Figure 24 - Installing Logs 3 and 4
Log 4
Log 3
FIREPLACE INSTALLATION
Continued
LOGPLACEMENTFORP325E(B)/
VP325E(B)MODELS
1. Place large back log (log 1) onto grate
making sure notches rest over grate (see
Figure 25).
2. Place log 2 onto front right side of grate
and back of log 2 into notch on right front
of log 1 (see Figure 25).
Figure 25 - Installing Logs 1 and 2
Figure 26 - Installing Log 3
Log 1
Log 2
Log 3
Log 1
Figure 27 - Installing Logs 4 and 5
Log 5
Log 4
Log 1
Log 3
3. Rest front of log 3 between rst two grate
ngers on left of grate assembly and rear
of log 3 into notch on left front of log 1(see
Figure 26).
4. Place top of log 4 into notch on log 1.
Rest log 4 on center of grate as shown
in Figure 27.
5. Place top of log 5 into notch on top right
of log 1 (see Figure 27). Rest log 5 be-
tween two middle grate ngers as shown
in Figure 28, page 16
To enhance the look of the hearth you may
optionally place provided lava rock around
front and sides of burner.

www.fmiproducts.com 108794-01G16
FIREPLACE INSTALLATION
Continued
COMBUSTION AIR KIT MODEL AK4
(OPTIONAL)
The outside air kit may be installed on the left
side of replace only. The vent can be installed
through any outside wall a minimum of 3 feet
below replace termination cap. The handle to
operate damper door for the outside air inlet
will be located inside the left “screen pocket”
of rebox (see Figure 29). Pull handle to open
or push to close.
CAUTION: Air inlet ducts are
nottoterminateinatticspace.
Figure 29 - Air Kit Handle Location
Air Kit
Handle
Screen
Pocket
APPLIANCE ENCLOSURE
Before nishing enclosure around appliance,
inspect all joints around outer surround. Any
gaps between nailing anges and framing
should be sealed with noncombustible insula-
tion or caulking.
If mounted on a raised platform, it must be a
continuous surface and not on blocks without
a solid surface. This will prevent entry of cold
air by means of conduction through total bot-
tom of appliance (see Figure 30).
Side
Framing
Side
Framing
Caulk Here Pack Insulation
Figure 30 - Sealing Between Appliance
and Framing
INSTALLING OPTIONAL GLASS
DOOR ACCESSORY
CAUTION: Use only glass
doorscertiedforusewiththis
appliance.
Note: Glass door may be heavy for some
individuals. If this is the case, please request
help.
These B-vent replaces are approved for
use with optional bi-fold glass doors (see Ac-
cessories, page 25). The glass panels may
be ordered and installed anytime after the
replace installation is complete.
Follow these steps to install left and right
panels:
1. With handle at the bottom, completely fold
panel on its hinges.
2. With handle facing center of rebox open-
ing, insert lower pivot pin on glass door
panel into hole in pivot plate on bottom
edge of replace opening (see Figure 31,
page 17).
3. Keeping folded door tilted, slide upper two
pins into guide track found under upper
facial edge of rebox opening.
Figure 28 - Logs Installed
NOTICE: Do not put lava rock
insidetheburnerpanoraround
theairmixertting.Placinglava
rock inside the burner pan or
blockingtheopeningsofthepro-
pane/LPair-mixercould cause
performanceproblems.

www.fmiproducts.com
108794-01G 17
FIREPLACE INSTALLATION
Continued
Figure 31 - Installing Optional Glass
Door
Spring Clip
Insert Pin Into Spring Clip
Insert Bottom Pivot Pin Into
Pivot Plate and Swing Door
Into Vertical Position
Pivot Plate
Slide Top
Pin Into
Door Track
4. Tilt glass assembly fully vertical until outer
pivot pin snaps into mounting hole in up-
per spring clip (see Figure 31).
5. Once top and bottom pins are secured,
unfold door into closed position.
6. Repeat process for opposite door as-
sembly.
7. To adjust doors, slide them partially open.
Using a screwdriver, loosen hold-down
screws in spring clip and pivot plate (see
Figure 32).
8. Close both doors until evenly joined at
middle and note gap at outer edges of
the face.
9. Reopen one door at a time and retighten
upper and lower hold-down screws.
10. Repeat process until both doors are even-
ly joined, spaced and working freely.
CAUTION: The glass pan-
els become very hot while the
appliance is operating. Do not
attempt to adjust or clean the
glass doors until the appliance
has fully cooled.
RemovingGlassDoorsforReplacement
or Cleaning
1. Partially open door and press up on upper
spring clip with a screw driver until outer
top pivot pin is free of clip.
2. Fully fold frame assembly and slide upper
edge towards center of rebox opening
until guide pins are free of frame rail (see
Figure 33).
 CAUTION: Always operate
theappliancewiththedoorsei-
ther fully opened or fully closed.
Operating the appliance with
the doors partially open can re-
sultinimproperventingofue
products.
Figure 32 - Adjusting Glass Doors
Spring
Clip
Hold-Down
Screw
Side
Front
Face
Partially
Opened
Door
Figure 33 - Removing Glass Doors
Spring Clip
Depress
Spring Clip
to Release
Pivot Pin
Remove Bottom Pin
From Pivot Plate While
Sliding Door Out of
Upper Track
Pivot Plate
Fold Bi-Fold
Door After
Releasing
Spring Clip
and Slide
Door Out of
Upper Track

www.fmiproducts.com 108794-01G18
OPERATION
1. STOP! Read safety information, column 1.
2. Turn wall switch to the OFF position.
3. Turn off all electric power to appliance.
4. Fully open glass doors if installed.
5. Remove front refractory brick access
panel.
6. Turn equipment shutoff valve clockwise
to the OFF position (see Figure 34).
7. Wait ve (5) minutes to clear out any gas.
Then smell for gas, including near the
oor. If you smell gas, STOP! Follow “B”
in the safety information, column 1. If you
don’t smell gas, go to the next step.
8. Turn equipment shutoff valve counter-
clockwise to the ON position.
9. Replace front refractory brick access
panel.
10. Fully close glass doors if installed.
11. Turn on all electric power to appliance.
12. Turn wall switch to ON position.
13. Visually locate the pilot. The ignitor should
begin to spark and the main burner should
ignite once ame appears at pilot.
• If lighting the appliance for the rst time
each season, it may take several at-
tempts before the supply gas can reach
the pilot and main burners.
• If the appliance will not stay lit after
several attempts, follow the instructions
To Turn Off Gas To Appliance, page 19,
and call your service technician or gas
supplier.
Figure 34 - Turning Equipment Shutoff
Valve to the OFF Position
Equipment
Shutoff Valve
Adjustment
Screw
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: If you do not fol-
lowthese instructions exactly,
a re or explosion may result
causingpropertydamage,per-
sonalinjuryorlossoflife.
A. Thisappliancehasapilotwhichmust
be lighted by hand. When lighting
the pilot, follow these instructions
exactly.
B. BEFORE LIGHTING smell all around
the appliance area for gas. Be sure to
smellnexttotheoorbecausesome
gasisheavierthanairandwillsettle
ontheoor.
WHAT TO DO IF YOU SMELL GAS
•Donottrytolightanyappliance.
•Donottouchanyelectricswitch;do
notuseanyphoneinyourbuilding.
•Immediately call your gas supplier
fromaneighbor’sphone.Followthe
gassupplier’sinstructions.
•Ifyoucannotreachyourgassupplier,
calltheredepartment.
C. Use only your hand to push in or turn
thegascontrolknob.Neverusetools.
Iftheknobwillnotpushinorturnby
hand,don’ttrytorepairit,callaquali-
edservicetechnicianorgassupplier.
Forceorattemptedrepairmayresultin
areorexplosion.
D. Do not use this appliance if any part
hasbeenunderwater.Immediatelycall
aqualiedservicetechniciantoinspect
the appliance and to replace any part of
thecontrolsystemandanygascontrol
whichhasbeenunderwater.
LIGHTING
INSTRUCTIONS
NOTICE: During initial operation
ofnewheater,burninglogswill
giveoffapaper-burningsmell.
Orangeamewillalsobepres-
ent.Opendamperorwindowto
ventsmell.Thiswillonlylasta
fewhours.

www.fmiproducts.com
108794-01G 19
TO TURN OFF GAS
TO APPLIANCE
1. Turn off wall switch.
2. Turn off all electric power to appliance if
service is to be performed.
3. Fully open glass doors if installed.
4. Remove front hearth brick and control
access panel.
OPERATION
Continued
Check pilot ame pattern and burner ame
patterns often.
PILOT ASSEMBLY
The pilot assembly is factory preset for the
proper ame. Alterations may have occurred
during shipping and handling. The pilot is lo-
cated on the back right hand side of burner.
The ame must envelope 1/4" of top of the
ignitor/sensor and grounding stem.
If your pilot assembly does not meet these
requirements:
• Turn adjustment screw marked PILOT
clockwise to decrease or counterclockwise
to increase ame to proper size (see Figure
36). Do not remove adjustment screw.
• see Troubleshooting, page 22
5. Turn equipment shutoff valve clockwise
to the OFF position. Do not force.
6. Replace front refractory brick access
panel.
7. Fully close glass doors if installed.
OPTIONAL REMOTE
OPERATION
Note: The WRC receiver and hand-held re-
mote control kit must be purchased separately
(see Accessories, page 25). Follow installa-
tion instructions on page 11.
Turn equipment shutoff valve to the ON posi-
tion. You can now turn the burner on and off
with the hand-held remote control unit.
IMPORTANT: Be sure to press the ON/OFF
buttons on the hand-held remote control unit for
up to 3 seconds to assure proper operation.
Figure 35 - Pilot
Sensing
Rod
Pilot
Burner
Ignitor
Pilot
Burner
Ignitor/
Sensor
Figure 36 - Correct Pilot Flame Pattern
Sensing
Rod
BURNER FLAME PATTERN
Burner ames will be steady, not lifting or oat-
ing. Flames should go up through the middle
of log set. Flames should not "spill" to edges
of pan or sides of log set.
Figure 37 shows a typical ame pattern. If burn-
er ame pattern differs from that described:
• turn appliance off (see To Turn Off Gas to
Appliance, above)
• see Troubleshooting, page 22
Figure 37 - Typical Flame Pattern
P325E(B) and VP325E(B) Models
P324E and VP324E Models
INSPECTING BURNERS

www.fmiproducts.com 108794-01G20
CLEANING AND MAINTENANCE
WARNING: Installation and
repairshouldbedonebyaquali-
edserviceperson.Theappli-
anceshouldbeinspectedbefore
each use and at least annually
by a qualied service person.
Morefrequentcleaningmaybe
required due to excessive lint
from carpeting, bedding mate-
rial,pethair,etc.Itisimperative
thatthecontrolcompartments,
burnersandcirculatingairsys-
tembekeptclean.
WARNING:Thelogscanbe
hot.Handleonlywhencool.
WARNING: Turn off gas and
electricalpowerbeforeservicing
appliance.
 WARNING: Failure to keep
the primary air opening(s) of
theburner(s)cleanmayresultin
sootingandpropertydamage.
PILOT AND BURNER
• Remove logs and ember material before
cleaning burner and replace when cleaning
is complete.
• Burner and controls should be cleaned
with compressed air to remove dust, dirt
or lint.
• Use a vacuum cleaner or small, soft bristled
brush to remove excess dust, dirt or lint.
LOGS
• If you remove logs for cleaning, refer to
log placement information on page 14 to
properly replace logs.
• Use a vacuum cleaner to remove any
carbon buildup on logs.
• Replace log(s) if broken. See Replacement
Parts.
• Replace ember material periodically as
needed. See Replacement Parts.
REPLACEMENT PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call FMI PRODUCTS, LLC at 1-866-
328-4537.
When calling, have ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
Usually, we will ask you to return the part to
the factory.
SERVICE HINTS
WhenGasPressureIsTooLow
• pilot will not stay lit
• burner will have delayed ignition
• replace will not produce specied heat
• propane/LP gas supply may be low if using
propane/LP gas
If using propane/LP gas, you may feel your
gas pressure is too low. If so, contact your
local propane/LP gas supplier.
TECHNICAL SERVICE
You may have further questions about instal-
lation, operation, or troubleshooting. If so,
contact FMI PRODUCTS, LLC at 1-866-328-
4537. When calling please have your model
and serial numbers of your heater ready.
You can also visit our web site at
www.fmiproducts.com.
