FMT Wireless SmartDip Operating instructions

Installation and Operation Guide
WIRELESS TANK LEVEL MONITORING | FREE ACCESS TO YOUR ONLINE PORTAL

Introduction
This manual serves as a comprehensive guide for the
installation, configuration, and operation of Wireless
SmartDip.
In this manual, you will find detailed instructions on in-
stalling Wireless SmartDip, configuring the system using
the web portal, and utilizing its features for real-time data
access.
Additionally, you will gain insights into the technical
specifications, such as accuracy, battery life, and operating
temperature ranges.
For support during the installation process or accessing
your tank data, please contact FMT.
For support, please contact:
Phone: [phone]
Email: [email protected]
For Terms and Conditions, please visit:
https://fmtweb.com/terms-and-conditions/

General Information
Wireless SmartDip is a wireless tank gauging product, de-
signed to be installed in tanks that do not have a SmartFill
Fuel Management System installed.
Wireless SmartDip’s set-and-forget automatic gauging sys-
tem and lightweight design can be installed in less than five
minutes, without drilling holes, running wires, or draining
your fuel tank.
Internally, Wireless SmartDip is comprised of a solar panel,
PCB and battery. The Wireless SmartDip enclosure should
always be kept closed and tightly sealed, the o-ring seal
should be clean and free of debris, and the screws holding
the lid down should be adequately tight.
Access to your tank data is via cloud-based web portal,
FMTData.com This platform can be accessed by using a
web browser and no special software is needed.
Wireless SmartDip is subject to FMT’s standard 2 year war-
ranty period. For further information and exclusions, visit:
https://fmtweb.com/terms-and-conditions/

Installing the Wireless SmartDip
Lower the probe into the tank.
Ensure the probe does not rest in sludge or grime in the
bottom of the tank. This will cause major faults.

Secure the Wireless SmartDip unit to the tank by rotating
the unit clockwise until the thread is tight.
Open the Wireless SmartDip lid by removing 2 screws
using a phillips head screwdriver.
Installing the Wireless SmartDip

Installing the Wireless SmartDip
Slide the battery connector on to the pins, being careful not
to bend any pins.

Scan the QR code on the top of the
Wireless SmartDip unit to begin setting up.
Installing the Wireless SmartDip

Setting the Tank Dimensions
When the QR code is scanned, you will be taken to an au-
tomated setup wizard. This wizard is designed to help you
make sure the Wireless SmartDip is configured correctly
and working as intended.
The first page of the wizard is a welcome page.

The second page is a security check to ensure you are
authorised to setup the Wireless SmartDip.
The default PIN is 6789
Setting the Tank Dimensions

The third page is the tank information page.
This page is where you will enter the dimensions or
20-point dip for the tank.
Setting the Tank Dimensions

The next page will prompt for additional information
needed such as the type of fluid in the tank, and the local
time of the Wireless SmartDip unit.
Setting the Tank Dimensions

When prompted, press the WakeUp button on the Wireless
SmartDip. Once pressed, tick the box then click Next.
Setting the Tank Dimensions

While the Wireless SmartDip syncs to the cloud and down-
loads the configuration from previous step, you will see this
animation. The sync process can take up to 1 minute.
Setting the Tank Dimensions

Once connected, you will need to input a manual dip of the
tank level. This is a check to ensure the Wireless SmartDip
is operating and configured correctly.
Setting the Tank Dimensions

Once the Wireless SmartDip confirms it’s functioning cor-
rectly, you will see a congratulations screen with your tank
levels displayed.
Setting the Tank Dimensions

You’ve finished setting up your Wireless SmartDip!
Setting the Tank Dimensions

Seal the Wireless SmartDip lid and re-fasten the screws to
secure it.
Installing the Wireless SmartDip

Navigate to www.fmtdata.com/new
If you currently have an account, click “Yes” then login to
add your new Wireless SmartDip.
Adding the Tank to your Portal
If this is your first time using FMTData, click “No” and follow
the steps to create your account.

Accessing your Tank Data
Open your web browser and navigate to www.fmtdata.com
then log into your account.
Click the Tanks button along the left-hand side of the
screen.

On this page, you can see the most recent tank level
readings.
To view previous readings, click the Dips tab and select the
date range you’d like to see the readings for.
Accessing your Tank Data
