FMUser FUTV3506 User manual

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
FUTV3506
DVB-T2 Modulator
User’s Manual
NMS Version: 3.3.8
SW: 0.12
HW: 2.1
FMUSER International Group Inc.

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
2/ 35
Directory
CHAPTER 1 INTRODUCTION ..........................................................................................................................3
1.1 OUTLINE .............................................................................................................................................................. 3
1.2 FEATURES ............................................................................................................................................................ 3
1.3 SPECIFICATIONS .......................................................................................................................................................4
1.4 PRINCIPLE CHART ..................................................................................................................................................... 5
1.5 APPEARANCE AND DESCRIPTION .................................................................................................................................. 5
CHAPTER 2 INSTALLATION GUIDE .............................................................................................................. 7
2.1 ACQUISITION CHECK ................................................................................................................................................. 7
2.2 INSTALLATION PREPARATION ....................................................................................................................................... 7
2.3 WIRE’S CONNECTION ................................................................................................................................................ 8
2.4 SIGNAL CABLES CONNECTION ..................................................................................................................................... 9
CHAPTER 3 FRONT PANEL OPERATION ...................................................................................................... 10
3.1 LCDMENU TREE ..................................................................................................................................................... 10
3.2 GENERAL SETTINGS ................................................................................................................................................ 12
CHAPTER 4 WEB NMS OPERATION ............................................................................................................. 23
4.1 LOGIN ..................................................................................................................................................................23
4.2 OPERATION ........................................................................................................................................................... 24
CHAPTER 5 TROUBLESHOOTING ............................................................................................................... 32
CHAPTER 6 PACKING LIST ........................................................................................................................... 33
ANNEX1 ............................................................................................................................................................... 34

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
3/ 35
1.1 Outline
Chapter 1 Introduction
FUTV3506 DVB-T2 modulator is our new product developed complying with the
DVB-T2 standard. With its advanced modulating technology, this modulator can
effectively make use of the ground spectrum resources and make it possible to
provide reliable signals for fixed, mobile and portable devices. Compared with
DVB-T, the channel capacity is increased by 30% under the similar carrier to
noise ratio (CNR) threshold. FUTV3506 DVB-T2 modulator also supports
single-PLP and can receive transmission data and synchronous information from
DVB-T2 Gateway through its ASI and IP ports.
Moreover, this device can be upgraded and controlled through network system,
which allows it to be widely used in setting up digital broadcasting network and
provide good signals for scientific laboratory and DVB-T2 STB.
1.2 Features
l Fully complying with EN302 755 standard
l 4 ASI inputs (3 for backup), 10MHz input/loop out, 1PPS input/loop out
l Supports single PLP

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
4/ 35
l Support MISO and SISO
l Support QPSK/16QAM/64QAM/256QAM (normal or rotated)
lSupport TS input through ASI port
l High performance output: MER>43dB, shoulder level>56dB
l Output signal bandwidth: 5M, 6M, 7M, 8MHz
l Support MFN net mode
l RF frequency range: 30MHz～999MHz
l RF output level: -25~+3 dBm, 0.1db stepping
l Supports non-linear and linear digital pre-distortion (DPD)
l Constant temperature crystal oscillator, as high as 0.1ppm stability
l Support online upgrade
l Keyboard operation and LCD display
l Web-based Network management system
1.3 Specifications
TS input over ASI
Input
Modulation

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
5/ 35
Connector
RF range
N Type, 50ΩImpedance
30~999Mhz, 1hz stepping
RF Out Output level ATT -25~+3 dBm, 0.1db stepping
MER > 43db
Shoulder Level >56dB
RF In Input Level -20 to +10 dBm (>-10 dBm is suggested.)
System LCD display, keyboard and Network management
Supporting software upgrading through network
Demission (W*L*H) 482mm×410mm×44mm
Weight 4.8kg
General Temperature
Power supply
Power Consumption
0~45℃(operation), -20~80℃(storage)
AC 220V±10%,50/60Hz
34W
1.4 Principle Chart
1.5 Appearance and Description
Front Panel Illustration

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
6/ 35
1
2
LCD Screen
Indicators
1
3
4
5
6
Left /Right /Up /Down Arrows
Enter key
Menu Key
Lock key
Rear Panel Illustration
RF Input Port
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RF Loop out Port
ASI Input Port 1
ASI Input Port 2
ASI Input Port 3
ASI Input Port 4
Data Port (reserved for future use)
NMS Port
External Clock 10MHz Input & Loop out Ports
GPS 1PPS Input & Loop out Ports
RF test out port (F type)
RF Output Port (N type)
Power Switch
AC Power Socket
Grounding

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
7/ 35
Chapter 2 Installation Guide
2.1 Acquisition Check
After user open the package of the device, it is necessary to check items according to
packing list. Normally it should include the following items:
Ø FUTV3506 DVB-T2 Modulator
Ø Usr’s Manual
Ø ASI Cable
Ø Power Adapter
If any item is missing or mismatching with the list above, please contact the local
manufacturer.
2.2 Installation Preparation
When user installs the device, please follow the steps below:
Ø Checking the possible device missing or damage during the transportation
Ø Preparing the relevant and correct environment for installation
Ø connecting Internet cable
Ø Connecting signal cables
2.2.1 Device’s Installation Flow Chart Illustrated as following：
Connecting
Acquisition
Check
Installing
Device
Grounding
Wire and
Power
Cord
Connecting
Signal
cable
Setting
Parameter Running Device

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
8/ 35
2.2.2 Environment Requirement
Item
Requirement
Machine Hall Space
Machine Hall Floor
Environment
Temperature
Relative Humidity
Pressure
Door & Window
Wal
Fire Protection
Power
When user installs machine frame array in one machine hall,
the distance between 2 rows of machine frames should be
1.2~1.5m and the distance against wall should be no les
than 0.8m.
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material:
1X107~1X1010Ω，Grounding current limiting resistance: 1MΩ
(Floor bearing should be greater than 450Kg/㎡)
5~40℃(sustainable )，0~45℃(short time)，
installing air-conditioning is recommended
20%~80% sustainable 10%~90% short time
86~105KPa
Installing rubber strip for sealing door-gaps and dual level
glasses for window
It can be covered with wallpaper, or brightness less paint.
Fire alarm system and extinguisher
Requiring device power, air-conditioning power and lighting
power are independent to each other. Device power requires
AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz. Please
carefully check before running.
2.3 Wire’s Connection
Ø Connecting Power Cord
User can insert one end into power supply socket, while insert the other end to
DC power.
Caution:
Before connecting power cord to FUTV3506 DVB-T2 Modulator, user should set
the power switch to “OFF”.

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
9/ 35
2.4 Signal Cables Connection
The signal connections include the connection of input signal, output signal and
loop-through. The details are as follows:
2.4.1 ASI cables illustration:
2.4.2 Network cable illustration:
2.4.3 RF in & loop out cables illustration:

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
10 / 35
Chapter 3 Front Panel Operation
FUTV3506 DVB-T2 Modulato’s front panel is user operation interface, where
users start their business. The LCD is a 2-line * 40-character back-lit dot-matrix
user interface with pushbuttons for UP, DOWN, LEFT, RIGHT, ENTER,
MENU, and LOCK for front panel control.
User can decide whether to directly use the factory setting, or customize the
input/output parameters and business setting manually.
Detailed operations go as follows:
Keyboard Function Description
LEFT/RIGHT: To choose and set the parameters
UP/DOWN：To modify activated parameters or page up/down when parameter
is inactivated.
MENU：To cancel presently entered value, resume previous setting;
ENTER：To activate the parameters which need modification, and confirm the
changes after modification.
LOCK：Lock the screen / cancel the lock state .After pressing lock key, the
system will question the users to save or not .If not, the LCD will display the
current configuration state
At the “Resume Factory Setting” page, user firstly presses “ENTER” key,
consequently system resumes factory parameter setting.
3.1 LCD Menu Tree

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
11 / 35
Initializing
Current General
Working Status
1 Alarm Status
2 System Setting
3 Output Setting
4 Network Setting
5 Saving Configuration
6 Loading Configuration
7 Version
Error Count
2.1 Net Mode
2.2 TS Input Port
2.3 Reference Clock Set
2.4 T2 Parameter
2.5 PLP Set
3.1 RF Frequency
3.2 RF Output Level
3.3 Spectrum Invert
3.4 RF Level Offset
3.5 RF Output
3.6 Pre-Distortion
4.1 IP Address
4.2 Subnet Mask
4.3 Gateway
4.4 Console Address
4.5 MAC Address
Yes No
6.1 Load Saved CFG
6.2 Load Default CFG
Version Information
Error Description
MFN
ASI1 ASI2 ASI3 ASI4
2.3.1 REF Clock Select
2.3.2 REF Clock Adjust
2.4.01 Input Type
2.4.02 Output Mode
2.4.03 FFT Size
2.4.04 Guard Interval
2.4.05 RF Bandwidth
2.4.06 Pilot Pattern
2.4.07 L1 Constellation
2.4.08 T2 Frames Number
2.4.09 Num Data Symbol
2.4.10 Cell ID
2.4.11 Network ID
2.4.12 T2 System ID
2.5.01 Transmission
2.5.02 LDPC Size
2.5.03 Code Rate
2.5.04 Constellation
2.5.05 Rotation
2.5.06 Time IL Length
3.6.1 Non-Linear
3.6.2 Linear

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
12 / 35
3.2 General Settings
After switching on the Modulator, the LCD sequentially displays as below:
Current maximum input bit rate
Device Name Current effective bit rate supported in current configurations
FUTV3506 TS=09.85/23.80Mbps
… RF=750.000MHz TS Input port = ASI1 MFN ...
By pressing “LOCK” key to enter the main menu, the LCD will display the
following pages:
1. Alarm status 2. System Setting
3. Output Setting 4. Network Setting
5. Saving Config 6. Loading Config
7. Version
Press “UP” and “DOWN” or “LEFT” and “RIGHT” key to specify the menu
item, and then press “ENTER” to enter the submenu as following pages:
3.2.1 Alarm status
When there are errors occurring, the alarm indicator will turn on and user can
enter this menu to check the error count and content.
Error Count: 2
Error Count:
“2” staFUTV for the number of errors. Whenever an abnormal event happens, the
number will increase 1.
Error Description:
Press “ENTER” to check the error information. For example:

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
13 / 35
2 TS Lose 12 RF Lock Lose
3.2.2 System Setting
Press “MENU” to return to the main menu and then press “UP/DOWN” or
“LEFT/RIGHT” to choose this item, and “ENTER” to set the parameters.
2.1 Net Mode 2.2 TS Input Port
2.3 REF Clock Set 2.4 T2 Parameter
2.5 PLP Set
3.2.2.1 Net Mode
FUTV3506 currently supports only MFN (Multi-Frequency Network) net mode.
Menu 2.1 is read-only for checking the net mode.
2.1 Net Mode
MFN
3.2.2.2 TS Input Port
Users can select the TS input port from the 4 options at menu 2.2 according to the
source port you connected.
The item with bracket
indicates the current state.
The first page of
the current menu
The total number of pages
of the current menu

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
14 / 35
FNote: The explanations in red boxes above are applied to this whole manual.
User can press RIGHT/LEFT keys to move the bracket and press
ENTER key to confirm the modification. Press MENU key to step
back to the upper level menu.
3.2.2.3 Reference Clock Set
After entering 2.3, the LCD displays submenus as follows:
2.3.1 REF Clock select 2.3.2 REF Clock adjust
Under menu 2.3.1, user can select the reference clock mode from the 3 modes
showing below:
2.4.1 REF clock select 1/1
[Inter] Exter Auto
Internal: This modulator uses internal 10MHz crystal oscillator as reference clock.
External: This modulator uses external 10MHz input as reference clock.
Auto: The modulator will preferably select the external 10MHz input if it exists.
Otherwise the modulator will select the internal 10MHz crystal oscillator’s output as
reference clock.
And under menu 2.3.2, reference clock ad can be set manually. (From -7.000 to 7.000
Hz)
2.3.2 REF clock adjust
0 000Hz
3.2.2.4 T2 Parameter
After entering 2.4, the LCD displays submenus as follows:

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
15 / 35
2.4.01 Input Type 2.4.02 Output Mode
2.4.03 FFT Size 2.4.04 Guard Interval
2.4.05 RF Bandwidth 2.4.06 Pilot Pattern
2.4.07 L1 Constellation 2.4.08 T2 Frames Number
2.4.09 Num Data Symbol 2.4.10 Cell ID
2.4.11 Network ID 2.4.12 T2 System ID
Ø Input Type
Currently, FUTV3506 supports TS input over ASI ports. It s a read-only interface.
2.4.01 Input Type
TS
Ø Output Mode
Currently, FUTV3506 supports 2 output modes: SISO (Single Input Single Output) and
MISO (Multi Input Single Output).
2.4.02 Output Mode 1/1
[SISO] MISO
Ø FFT Size
FUTV3506 supports modes: 1K, 2K, 4K, 8K+Ext, 8K, 16K+Ext, 16K, 32+Ext, and
32K.
“+Ext” means with Extension. Option with “+Ext” is a little bigger than the original
value. For example, “8K+Ext” is a little bigger than 8K.
2.4.03 FFT Size 1/3
[1K ] 2K 4K 8K+Ext
Ø Guard Interval
All the Guard Interval modes include: 1/128, 1/32, 1/16, 19/256, 1/8, 19/128 and 1/4.
Different combination of Output Mode and FFT Size will have an impact on the
guard interval options provided with invalid options hidden. (See Appendix 1 for

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
16 / 35
details.)
2.4.04 Guard Interval 1/1
[1/16] 1/8 1/4
Ø RF Bandwidth
FUTV3506 supports 5M, 6M, 7M and 8M bandwidth.
2.4.05 RF Bandwidth 1/1
[5M] 6M 7M 8M
Ø Pilot Pattern
All the Pilot Patterns are from PP1 to PP8.
Different combination of Output Mode, FFT Size and Guard Interval will have an
impact on the Pilot Pattern options provided with invalid options hidden. (See
Appendix 1 for details.)
2.4.06 Pilot Pattern 1/1
[PP4] PP5
Ø L1 Constellation
Users can select one L1 (Layer 1) constellation from the options provided as below:
2.4.07 L1 Constellation 1/1
BPSK [QPSK] 16 QAM 64 QAM
Ø T2 Frames Number
Users can set the number of T2-frames per super-frame at this menu.
Number Range: 2-255
2.4.08 T2 Frames Number
002
Ø Number of Data Symbol
It is the number of data OFDM symbols per T2-frame.

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
17 / 35
The range is determined conjointly by FFT size and Guard Interval.
If you set an inappropriate value (lower the minimum value or higher than the
maximum value), it can automatically cast it to a proper value. To be specific, if you
input a value lower than the minimum value allowed, the system will cast it to the
minimum value. Similarly, the system will cast it to the maximum value allowed if
you put an over-high value.
2.4.09 Num Data Symbol
0007
Ø Cell ID
Users can set the cell ID at this menu. It ranges from 0x0000 to 0xffff. (It is
hexadecimal)
2.4.10 Cell ID
0x0000
Ø Network ID
Users can set the network ID at this menu. It ranges from 0x0000 to 0xffff. This is a
16-bit field which uniquely identifies the current DVB network.
2.4.11 Network ID
0x0000
Ø T2 System ID
Users can set the system ID for the modulator at this menu. It ranges from 0x0000 to
0xffff. This 16-bit field uniquely identifies a T2 system within the DVB network
(identified by NETWORK_ID).
2.4.12 T2 System ID
0x8001
3.2.2.5 PLP Set

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
18 / 35
PLP: Physical Layer Pipe
After entering 2.5, the LCD displays submenus as follows:
2.5. 1 Transmission 2.5.2 LDPC Size
2.5.3 Code Rate 2.5.4 Constellation
2.5.5 Rotation 2.5.6 Time IL Length
Ø Transmission
FUTV3506 supports both NM (Normal Mode) and HEM (High-Efficiency Mode)
transmission modes.
HEM mode can enhance the total output bit rate a little.
2.5. 1 Transmission 1/1
[NM] HEM
Ø LDPC Size
FUTV3506 has two types of LDPC (Low Density Parity Check) size as below:
2.5.2 LDPC Size 1/1
[16K] 64K
Ø Code Rate
Users can adjust the code rate among 1/2, 3/5, 2/3, 3/4, 4/5 and 5/6.
2.5.3 Code Rate 1/1
[1/2] 3/5 2/3 3/4 4/5 5/6
Ø Constellation
Users can set the constellation among QPSK, 16QAM, 64QAM and 256QAM.
2.5.4 Constellation 1/1
[QPSK] 16QAM 64QAM 256QAM

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
19 / 35
Ø Rotation
Users can set the constellation rotation at this menu.
2.5.5 Rotation 1/1
[Off] On
When constellation rotation is used, the normalized cell values of each FEC block
coming from the constellation mapper are rotated in the complex plane and the
imaginary part cyclically delayed by one cell within a FEC block.
When constellation rotation is not used, the cells are passed onto the cell interleave
unmodified.
Ø Time IL Length
Users can set the time interleaving length at this menu. An inappropriate value will be
automatically and compulsorily corrected to adapt the settings.
The time interleave will typically act as a buffer for PLP data and therefore the output
may be delayed by a varying amount with respect to the input even when time
interleaving is not used.
If time interleaving is not used, set the Time IL Length=0.
2.5.6 Time IL Length
000
3.2.3 Output Setting
After entering Menu 3, the LCD displays submenus as follows:
3.1 RF Frequency 3.2 RF Output Level
3.3 Spectrum Invert 3.4 RF Level offset
3.5 RF Output 3.6 Pre-distortion

FMUSER INTERNATIONAL GROUP INC. 广州市汉婷生物技术开发有限公司
20 / 35
Press “UP/DOWN” or “LEFT/RIGHT” to choose this item and “ENTER” to set
the parameters or select the mode of corresponding items. The system displays
as following pages:
3.1 RF Frequency
750.000000 MHz
3.2 RF Output Level
+00.0 dbm
3.3 Spectrum Invert 1/1
[ Normal ] Invert
3.4 RF Level Offset
+0.0 dbm
3.5 RF Output 1/1
Single tone [modulation] off
3.6.1 Non-Linear 3.6.2 Linear
3.6.1 Non-Linear 1/1
[off] update hold
3.6.2 Linear 1/1
[off] update hold
3.2.4 Network Setting
4.1 IP Address 4.2 Subnet Mask
4.3 Gateway 4.4 Console Address
4.5 MAC Address
