FMX FSR-TDUV Series User manual

®
UL File# E468299
FSR-TDUV SERIES
Encapsulated Time Delay Relay
BE SURE TO REMOVE ALL POWER SUPPLYING THIS EQUIPMENT BEFORE CONNECTING OR DISCONNECTING WIRING.
READ INSTRUCTIONS BEFORE INSTALLING OR OPERATING THIS DEVICE. KEEP FOR FUTURE REFERENCE.
DANGER! Potentially hazardous voltages are present. Electrical shock can cause death or serious injury.
Installation should be done by qualied personnel following all National, State & Local Codes.
Switch Settings
1. Panel mount with (1) #10 screw
2. Wire per the wiring diagram using 1/4" quick-connect terminals
3. Setup using the 6-position DIP switch (see table below)
• Set switches A & B to ON or OFF to select the Function.
• Set Switches C & D to ON or OFF to select the Time Range.
• Set Switches E & F to ON or OFF to select either onboard or
remote adjustment
INSTALLATION, WIRING & SETUP
Trigger
COM
N.O.N.C.
Ext. Res.
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
Wiring Diagram
(Terminals 6 & 7 are only on -14F & -34F)
FUNCTION DESCRIPTIONS
NOTE: (1) Function and Pot Select cannot be changed with power applied to the unit.
(2) Time Range must be changed prior to the start of a timing cycle.
(3) 2 onboard Pots
PART NUMBER FUNCTION (1) SWITCHES TIME RANGE (2) SWITCHES POT SELECT (1) SWITCHES
AB C D E F
FSR-TDUV-14F
ON DELAY ON ON 0.1–10S ON ON ONBOARD POT ON ON
OFF DELAY OFF ON 1–100S OFF ON REMOTE POT 100K OFF ON
INTERVAL ON OFF 10–1000S ON OFF REMOTE POT 1M ON OFF
SINGLE SHOT OFF OFF 1–100M OFF OFF REMOTE POT 2M OFF OFF
FSR-TDUV-34F
FLASHER OFF ON ON 0.1–10S ON ON ONBOARD POT ON ON
FLASHER ON OFF ON 1–100S OFF ON REMOTE POT 100K OFF ON
WATCHDOG ON OFF 10–1000S ON OFF REMOTE POT 1M ON OFF
ONE SHOT
FALLING EDGE OFF OFF 1–100M OFF OFF REMOTE POT 2M OFF OFF
PART NUMBER FUNCTION (1) SWITCHES TIME RANGE
(t1)
SWITCHES TIME RANGE (t2) SWITCHES
AB C D E F
FSR-TDUV-54F (3)
REPEAT CYCLE OFF ON ON 0.1–10S ON ON 0.1–10S ON ON
REPEAT CYCLE ON OFF ON 1–100S OFF ON 1–100S OFF ON
DELAYED INTERVAL ON OFF 1–100M ON OFF 1–100M ON OFF
TRIGGERED
DELAYED INTERVAL OFF OFF 10–1000M OFF OFF 10–1000M OFF OFF
FSR-TDUV-34F
FUNCTION TIMING CHART
FLASHER
Repeat Cycle
OFF
FLASHER
Repeat Cycle
ON
WATCHDOG*
Rising Edge
with Retrigger
SINGLE SHOT
FALLING
EDGE*
Falling Edge
with Retrigger
FSR-TDUV-14F
FUNCTION TIMING CHART
ON DELAY
Delay on Make
Delay on
Operate
INTERVAL ON
OFF DELAY
Signal OFF
Delay with
Retrigger
SINGLE SHOT*
Rising Edge
One Shot
FSR-TDUV-54F
FUNCTION TIMING CHART
REPEAT CYCLE
Asymetric Repeat
Cycle OFF First
REPEAT CYCLE
Asymmetric
Repeat Cycle ON
DELAYED
INTERVAL
Asymetric Single
Cycle OFF
TRIGGERED
DELAYED
INTERVAL*
Signal Asymetric
Single Cycle OFF
*Requires Trigger
*Requires Trigger
*Requires Trigger
FSR-TDUV-14F & -34F
FSR-TDUV-54F

Factorymation, LLC. 160 Bluffs Ct. Canton, GA 30114
901-0000-319 / Version 6.3.16
®
Relay Common
• Relay Common as a separate terminal, connect the wires as shown
in Fig. A.
• Internal connection between Input Voltage & the relay common
(Fig. B)
• Add jumper between terminals 1 & 2 as shown in Fig. C to simulate
the internal connection (see arrow below).
No other connection is required to Terminal 1 other than this
jumper:
NOTE: (Terminals 6 & 7 are only on -14F & -34F)
Trigger (Control Switch)
• Isolate Trigger, make wire connections as shown in Fig. D.
• Connect Trigger Switch to Input Voltage, connect one wire of the
Trigger Switch to Pin 5 & the other wire to Input Voltage as shown in
Fig. E (see arrow below):
NOTE: (Terminals 6 & 7 are only on -14F & -34F)
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
Fig.D Fig.E
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
Fig.C
Fig.BFig.A
INPUT VOLTAGE 24 - 240VAC/ 12 - 125VDC
+10/-15% (50/60Hz)
CONTACT RATING 10A@240VAC, 7A@28VDC, SPDT
MAX POWER CONSUMPTION 2VA
SETTING ACCURACY Max.(adjustable): +5%, -0%
Min. (adjustable): +0%, -50%
REPEAT ACCURACY
(CONSTANT VOLTAGE &
TEMPERATURE)
±0.1% or ±0.04s, whichever is greater
RESET TIME Triggered with Input Voltage: 100ms
Triggered with Control Switch: 40ms
START-UP TIME Time from power applied until unit is timing: 0.05s
MAINTAIN FUNCTION TIME Time unit continues to operate after power is removed:
0.01s
UNITS TRIGGERED BY
CONTROL SWITCH Min. trigger switch closure time: 50ms
MOUNTING Panel Mount: 1 (#8 or #10 screw); Torque: 15in-lb
DIN rail: 35mm
AMBIENT TEMPERATURE Operating: -18 to 149°F (-28 to 65°C)
Storage: -40 to 185°F (-40 to 85°C)
LIFE Mechanical: 10,000,000 operations
Full Load: 100,000 operations
GENERAL SPECIFICATIONS
OPTIONAL CONNECTIONS
2.00
(51)
0.25 (6)
DIA.
2.00
(51)
0.79
(20)
1.14
(29)
DIMENSIONS
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
DC
AC
(+) (—)
(L) (N)
INPUT
INPUT
