Follett C45184 Manual

Installation, Operation and Service Manual
-30 C Undercounter Plasma Freezer
00193482R00
801 Church Lane • Easton, PA 18040, USA
Toll free [phone] • [phone]
Fax [phone] • www.follettice.com
Following installation, please forward this manual
to the appropriate operations person.
Order parts online
www.follettice.com
Serial numbers C45184 and above

2

3
Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and
outstanding after-the-sale support. To ensure that this product delivers that same degree of service, we ask that
you take a moment to review this manual before beginning the installation. Should you have any questions or
require technical help at any point, please call our technical service group at [phone] or [phone].
Before you begin
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If
damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the ling
of a claim, if necessary.
Specications
Series specications
FZR5-PL
34" height for freestanding use or installation below standard 36" (915mm) high counter
2 drawers - up to 40 (350ml) plasma cartons
Maximum drawer load - 35 lbs (16kg) each.
Electrical specications
115V, 60Hz, 1 phase
Full load amps: 8.0
Minimum circuit ampacity: 15 amp
Maximum size of branch circuit overcurrent device: 15 amp
Refrigeration specications
Refrigerant – R404A
Charge size – 10 oz
Maximum design pressures:
High side – 383psi
Low side – 175psi
Installation specications
Ambient temperature must not exceed 30 C (86 F).
The front louvered panel must be kept free of any cabinet trim or obstructions to ensure proper ventilation of the
refrigeration system.
Important cautions
• Equipment must be wired according to local and NEC codes.
• Always disconnect power before servicing freezer.

4
Installation
Installing legs – required
1. Remove legs from plastic bag packed inside freezer.
2. Tip freezer back and screw legs in all the way to stop (they will extend
1/8" below base of freezer).
3. Adjust legs as needed to level freezer in both directions. To access
legs, remove the lower front panel. Turn legs clockwise to extend legs.
Temperature surveillance module
Follett’s all-in-one temperature alarm and chart recorder module (manufactured for Follett by Dickson) may be
included with your FZR5-PL. Please refer to the Dickson instructions packed with this module for set-up and
operation instructions.
Follett’s monitoring bottle and temperature probe has already been installed in the Follett FZR5-PL. Simply
connect the loose end of the probe wire on the back of the unit to the surveillance module to complete the install.
A box of sixty (60) -50 to +50 7-day charts have also been included with this module. Replacement charts and
pens can be ordered from Follett by calling Technical Service at 800-523-9361:
Item # 00162099 — Box of sixty (60), -50 to +50, 7-day replacement charts
Item # 00162081 — Box of six (6) replacement red pens
Charts with different temperature scales are also available. Contact Dickson at www.dicksondata.com
Fig. 1

Reversing the door swing – optional
NOTICE
When reinstalling latch and hinge screws, 242 blue Loctite* MUST be
applied to screws. Torque screws to 25 in-lbs.
1. Remove screws and latch from refrigerator cabinet (Fig. 2.1).
2. Use at screwdriver to carefully remove (do not scratch) hinge
covers (Fig. 3.1).
3. Support door and remove screws attaching hinge to refrigerator
cabinet (Fig. 3.2).
4. Cover hinge screw holes with screw hole plugs removed from
opposite side.
5. Reverse door. Apply 242 blue Loctite to hinge screws and reinstall
torqued to 25 in-lbs.
6. Reinstall latch on opposite side.
7. Remove screws and handle from door (Fig. 4.1).
8. Rotate handle (Fig. 4.2).
9. Apply 242 blue Loctite to latch screws and reinstall torqued to 25 in-lbs.
5
1
2
1
1
2
1
2
Fig. 2
Fig. 3
Fig. 4
*Loctite is a registered trademark of Henkel Corporation in the United States and other countries.

Controller operation
In normal operation the controller displays cabinet temperatures in
degrees C (default) or user-selected degrees F.
The controller is pre-programmed with a -35 C (-31 F) set point
which provides a compressor cut-in at -33 C (-27F) and cut-out at
-35 C (-31 F). The controller set point can be raised to -25 C
(-13 F) when a lower temperature is not desired. Follow instructions
for changing temperature cut-out below.
All set points have a 2 C differential. The 2 C differential means that
with a -35 C set point, for example, the compressor will turn off at -35
C (-31 F) and turn on when the cabinet reaches -33 C (-27 F).
This temperature may not reect the temperature of the blood products in the freezer. The temperature of the
blood products will be reected on the recorder chart and the recorder's digital temperature display. At times there
may be a difference between the two displayed temperatures. Adjust the controller SET value to achieve your
desired blood product temperature as displayed on your chart recorder.
To display temperature cut-out
STEP INPUT DISPLAY
1 Press and release SET Current cut-out temperature will display for approximately 5 seconds.
Display will return to current refrigerator temperature.
To change temperature cut-out
STEP INPUT DISPLAY
1 Press and hold SET for Current cut-out temperature displayed and °C will ash
3 seconds
2 Press UP or DOWN arrows to New cut-out temperature displayed
desired cut-out temperature
3 Press and release SET New cut-out temperature blinks three times, then current refrigerator
temperature will display
Programming freezer from a key (download)
1. TURN OFF freezer.
2. Remove 6 screws from panel holding controller to access back of controller.
3. Insert degree F programmed key into 5 PIN receptacle on controller back.
4. TURN ON freezer.
5. Values from key automatically download to freezer (“dol” message blinks followed by “end”).
6. After 10 seconds display returns to current freezer temperature and controller will restart with new values.
7. TURN OFF.
8. Remove key.
9. Reinstall panel.
Note: An “Err” message displays for failed programming. Turn freezer OFF then ON to restart download, or
remove key to abort.
6
°C
- 35
evaporator
fan
energized
defrost
refrigeration
system
energized
Fig. 5

Controller security
The controller panel can be locked to prevent inadvertent or intentional programming changes. In locked mode,
the controller will display cabinet temperature and cut-out set point only.
To lock the controller
1. Press the UP and DOWN ARROW buttons together for 3 seconds until “PoF” displays (will ash 3 times).
2. Programmer is now locked.
To unlock the controller
1. Press UP and DOWN ARROW buttons together for 3 seconds until “Pon” displays (will ash 3 times).
2. Programmer is now unlocked.
Controller programming key degrees C (optional accessory)
A controller programming key is available from Follett to provide fast and easy reprogramming of factory settings
(part# 00193391).
7

8
Operation
The temperature controller and probe indicate when the refrigeration system is required to turn on and off.
The refrigeration system removes heat from the cabinet interior and rejects it to the surrounding room air. When the
cabinet interior temperature reaches 2 C (4 F) above the controller set point, the probe signals the controller to turn
the refrigeration system on. The normally-open controller contacts 4 and 5 close and energize the evaporator and
condenser fan motors, compressor and door heater. The snowake and fan LED's on the controller will come on to
indicate the refrigeration system is on. The compressor uses a current-style starting relay and a starting capacitor to
start the compressor motor.
When the cabinet interior temperature falls to the set point, the probe signals the controller to turn the refrigeration
system off. The controller contact 5 reopens, which de-energizes the condenser fan motor and the compressor. The
snowake LED will go out, the fan LED will remain on.
Any accumulated frost on the evaporator coils melts during the defrost cycle. Freezer products will remain at or
below -20 C (-4 F) during the defrost cycle. The condensate drains to a drain pan mounted along the condensing
unit. The heat from the condensing unit evaporates any condensate in the drain pan.
Temperature control
The temperature control system is preset by the factory to maintain a cabinet temperature of -33 C (-27 F). If
desired, the cut-out temperature can be raised as high as -25 C (-13 F) by following the instructions on page 6
for changing the temperature set point. The 2 C cut-out differential will be maintained regardless of the controller
set point.
Defrosting
The FZR5-PL undercounter freezer controls frost accumulation on the evaporator through automatic timed defrost
cycles. The defrost cycle is initiated by the temperature controller every 4 hours. Contacts 4 and 5 on the controller
open and the refrigeration system is turned off. Contact 2 is closed and the defrost heater is energized. The melting
snowake LED on the controller will come on, and the temperature display will read: “dEF” to indicate the freezer is
in the defrost cycle.
The heater warms the evaporator coil and drain pan to melt the frost and drain the water to the condensate pan.
The temperature controller monitors evaporator temperature using a probe embedded in the coil. The controller
terminates the defrost cycle when the evaporator temperature reaches 5 C (41 F) or after 25 minutes of defrost
time, whichever occurs rst. As the defrost cycle terminates, the controller de-energizes the heater and restarts
the compressor and condenser fan. The snowake LED on the controller will come on to indicate the refrigeration
system is running.
There is a 10 minute delay before the evaporator fan motor is re-energized. The fan LED on the controller will
come on to indicate the fan is running and the temperature display resumes displaying cabinet temperature. A
defrost cycle can be initiated manually at any time by depressing and holding the melting snowake button for
approximately three seconds. As a safety feature, a temperature safety switch mounted on the evaporator will turn
off the defrost heater if the temperature of the evaporator reaches +27 C (+80 F) regardless of controller operation.
Cleaning
Interior – Using a sponge or soft cloth, clean unit with a non-abrasive, non-chlorinated, all-purpose detergent.
Exterior – Wipe exterior with a soft cloth in the direction of grain as needed. Stainless steel polish may be used to
enhance the nish of the unit.
Use only non-chlorine-based cleaners. Cleaners containing chlorine can cause staining and pitting of the
stainless steel.
!

Annual cleaning
Removal of dust and other particulates from air intake areas and the
condenser is important for proper operation. Some environments with
large amounts of dust may require more frequent cleaning.
1. Disconnect power to unit by turning switch on the lower
front panel to the OFF position, switching circuit breaker
to OFF position, and removing power cord from receptacle.
2. Remove lower front panel (Fig. 6.1).
Note: Front louvered panel may be completely removed for
easier cleaning by disconnecting the controller wiring plugs from
the freezer.
3. Remove drain pan (Fig. 6.2).
4. Clean drain pan with a non-abrasive, non-chlorinated
all-purpose detergent.
5. Reinstall drain pan.
6. Use a vacuum cleaner with brush attachment to clean
condenser through lower front panel and compressor
motor and related parts through lower rear panel.
7. Reinstall lower front panel.
Service
Latch adjustment
To adjust for proper latch engagement
1. Loosen striker plate mounting screws (Fig. 7.1).
2. Move striker plate up or down as required and tighten screws.
3. Test operation of latch.
To adjust for proper gasket seal
1. Loosen striker depth adjustment screw (Fig. 7.2).
2. Adjust stop in or out and tighten screws.
3. Test operation of latch.
Door gasket replacement
1. Remove existing gasket from mounting track.
2. Verify mounting track is free of any remaining gasket material.
3. Align new gasket with mounting track and press rmly in place.
4. Open and close door, checking for proper gasket seal without
pinching against freezer.
5. Adjust latch and or striker as necessary for proper door closure.
Slide-out compressor tray
Follett’s slide-out compressor tray allows technicians to partially slide
the condensing unit from the freezer back without cutting refrigerant
lines.
1. Remove rear panel (Fig. 8.1).
2. Remove two bolts securing condensing unit to freezer base
(Fig. 8.2).
3. Gently slide condensing unit out (Fig. 8.3).
Note: Do not put undue strain on the refrigerant lines.
9
1
2
Fig. 7
208264
Product
ModuleNo.
ServiceNo.
EastonPennsylvania
MOTORCOMPRESSORTHERMALLYPROTECTED
DESIGNPRESSUREHIGH SIDE
MIN.BRANCHCIRCUITAMP
ACITY
MAX.BRANCHCIRCUITFUSE SIZE
SINGLE
PHASE
LOWSIDE
L
THEUSA
MADEIN
OZ
PSIG
R
C
NS
F
U
L
PART N O
HZ
CHARGE
AMPS
R
AMPS
U
VOLTS
CORPORATION
SERIALNO
MODEL
FULLLOADAMPS
REFRIGERANT
1
2
3
Fig. 8
Fig. 6
1
2

Removing drawers
1. Pull drawer forward to stop.
2. Lift drawer front to free front rollers from sides.
3. Still lifted, pull drawer forward to free back rollers from sides.
Removing slides
1. Push slides all the way back.
2. Swing bottom of slide away from refrigerator wall and lift slide off of rollers.
Controller replacement
1. Disconnect power to unit.
a. Push front panel rocker switch to OFF position.
b. Disconnect power cord.
2. Remove 6 screws from front panel and slide panel forward to access back of controller.
3. Disconnect front panel and wiring harness from freezer at the 3, 4, and 5 pin connectors and door heater to
simplify replacement.
4. Push in on center of side brackets (on controller) to release and slide brackets back and off controller.
5. Push controller and wires out through front of front panel.
6. Using wiring schematic (attached to front panel and below) as a guide, remove wires one at a time from back
of existing controller and connect to corresponding terminals on replacement controller.
7. Insert replacement controller back through front of panel.
8. Slide brackets onto sides of controller and push against back of front panel.
9. Reconnect 3, 4, and 5 pin connectors of wiring harness to freezer.
10. Keeping wiring clear of condenser, replace front panel.
11. Restore power and test operation. Reprogram replacement controller if necessary.
Wiring diagram
BLK
GROUND SCREWS
GRN
YEL
WHT
3
2
11
2
3
12
11
10
97654321
VAC
SUPPLY
WHT RED
WHT
VIO
EVAPORATOR
THERMISTOR
CHAMBER
THERMISTOR
BLK
3
2
11
2
3
44
3
2
11
2
3
44
55
DEFROST
HEATER
FAN
DOOR
HEATER
EVAPORATOR UNIT
RED
BLK
BLU
WHT
BLU
WHT
WHT
WHT
DEFROST
SAFETY SWITCH
BLK
RED
WHT WHT
BLK
BLK BLK
L1
L2
GND
1 PHASE
120 VAC
15 AMPS
FAN
CONDENSING UNIT
COMP
1110
1312
14
SR
BLK
WHT
10

Refrigeration system
The FZR5-PL -30 C (-22 F) freezer refrigeration system is designed to give many years of trouble-free service.
Except for routine cleaning of the air-cooled condenser and related parts, the refrigeration system requires no
service or maintenance. The system uses a thermostatic expansion valve and is critically charged. Access ttings
are provided for ease of service. However, the connection of refrigeration service hoses to the ttings will almost
invariably result in a signicant change in the system charge. This change can adversely affect the performance
of your freezer. Therefore, Follett recommends that if hoses are ever connected to the refrigeration system for
service, the refrigerant should be recovered, the system evacuated, and recharged by weighing in the correct
refrigerant charge.
Note: Do not charge the system by pressures.
Checking refrigeration system pressures
1. Remove the rear access panel (Fig. 8).
2. Turn the power switch to the on position.
3. Following the instructions on page 5 verify that the temperature controller is set to the original factory
set point cut out setting of -35 C (-31 F).
4. Allow the freezer to operate and stabilize at least 60 minutes, verifying the cut-out temperature is
being reached.
5. Connect refrigerant hoses to access ttings and measure air temperature at condenser intake grille.
6. Verify correct pressures with the temperature chart below.
7. Troubleshoot refrigeration system as needed.
Note: Do not attempt to obtain correct refrigeration pressures by adjusting the system charge.
11
Condenser inlet air temperature 70 F 80 F
Discharge pressure (psi) 197 225
Suction pressure (psi) 4 5
DRYER
HIGH PRESSURE VAPOR LOW PRESSURE VAPORHIGH PRESSURE LIQUID LOW PRESSURE LIQUID
COMPRESSOR
FAN
10oz. Charge
High Psi
Liquid
Low Psi
Liquid
High Psi
Vapor
Low Psi
Vapor
HEAT EXCHANGE
EVAPORATOR FAN
EVAPORATOR/DEFROST UNIT CONDENSING UNIT
DEFROST HEATER
EVAPORATOR
TXV
LOW SIDE
SERVICE PORT
HIGH SIDE
SERVICE PORT
Refrigeration system diagram

Possible cause
1. Power switch faulty or in OFF
position; loose connection.
2. Freezer not plugged in.
3. No power to cord.
4. Temp controller not energizing
components.
5. Probe not sensing cut in
temperature.
1. Thermal overload open or
defective.
2. Capacitor and/or relay defective.
3. Compressor defective.
1. No power on terminal 5 of
controller (during cooling).
1. No power on terminal 4 of
controller (during cooling).
1. Controller not sensing cut off
temperature.
2. Controller keeping refrigeration
system energized.
1. Condenser or evaporator coil
needs cleaning.
2. Faulty door gasket.
3. Excessively high ambient.
4. Refrigerant leak.
5. Incorrect refrigerant charge.
6. Plugged expansion valve.
7. Inefficient compressor.
8. Evaporator coil blocked with ice.
1. Defective defrost heater.
2. Faulty heater safety switch.
3. No power on terminal 2 of
controller (during defrost).
Solution
1. Turn power switch to ON position;
check switch and connections.
2. Connect plug.
3. Restore power.
4. Check controller contact terminals for
power. Replace controller if needed.
5. Replace controller and/or probe.
1. Allow to cool or replace.
2. Replace as required.
3. Replace compressor.
1. Replace controller
1. Replace controller.
1. Replace controller and/or probe.
2. Replace controller.
1. Clean coils as needed.
2. Replace door gasket.
3. Maximum recommended ambient is
30 C (86 F).
4. Locate and repair leak.
5. Recover, evacuate and weigh in
correct charge.
6. Replace expansion valve.
7. Consult technical service.
8. Depress defrost button on controller
to defrost coil.
1. Replace defrost heater
2. Replace switch.
3. Replace controller.
Symptom
Freezer does not operate
(no components run).
Compressor does not run.
Compressor and condenser fan do
not run.
Evaporator fan motor does not run.
Freezer does not shut off.
Freezer does not maintain
temperature (all components run).
Evaporator does not defrost.
12
If problems persist after following this basic troubleshooting guide, call Follett’s technical
service group at [phone] or [phone].
Freezer troubleshooting guide
Before calling for service
1. Check that unit is plugged in.
2. Test outlet with another appliance to verify power.

48
9
10
11
7
6
3
12
5
1
2
13
13
Reference # Description Part #
1 Cover, evaporator (includes 00152892) 00155564
2 Fan guard 00152892
3 Fan blade 00152991
4 Bracket, fan motor 00152983
5 Fan motor, evaporator 00104919
6 Defrost heater 00152645
7 Drain pan, evaporator, FZR5 00162511
8 Evaporator 00151563
9 Heater safety switch 00153932
10 Expansion valve (includes 00106534) 00155671
11 Insulation, bulb 00106534
12 Air baffle 00165126
13 Clips, defrost heater (2 needed) 00161554
Replacement parts
Evaporator

14
1
2
3
4
5
8
7
6
Reference # Description Part #
Condensing unit 00153874
1 Condenser 00157339
2 Shroud, condenser 00157347
3 Condenser fan blade 00105007
4 Condenser fan motor 00104992
5 Fan motor bracket 00157412
6 Compressor 00157313
7 Starting capacitor 00104968
8 Filter drier 502724
Not shown Cap, starting capacitor 00105627
Not shown Starting relay 00157305
Not shown Overload protector 00104984
Condensing Unit

15
14
11
12
8
10
13
9
15
1
2
3
4
5
6
7
16
1
Hardware
Reference # Description Part #
1 Latch & striker includes screws 00105023
2 Latch screws, 3 per latch 00103507
3 Door (includes gasket - 21 3/8" x 21 3/8") 00105015
4 Hinge, each - 2 required, includes screws 00105031
5 Hinge screws, each - 6 per hinge 00105080
6 Gasket 00125732
7 Strip sealer (set of 4) 00130138
8 Drawer (includes 8 and 4 each of 10, 11 & 15) 00165134
9 Drawer slides (pair) 00161927
10 Nut, acorn, each (4 required per drawer) 00161802
11 Screw, 5/8", each (4 required per drawer) 200093
12 Screw, 7/8", each (4 required per drawer) 00161794
13 Washer, each (4 required per drawer) 00161786
Kit Drawer & slide mounting hardware kit
(includes 8, 9, 4 each of 10, 11, 12, 13 and 8 each of 15) 00165142
14 Striker screws, each - 2 per striker 502287
15 Bearing, roller 00167726
Kit Slide & bearings (includes 9 (pair) and 4 each of 12, 13 & 15) 00167924
Kit Bearings & screws kit 00167957
(includes 8 each of 15 and 4 each of 10, 11, 12 & 13)
16 Door heater (includes 00130138) 00155531

18
00193482R00
04/08
801 Church Lane • Easton, PA 18040, USA
Toll free [phone] • [phone]
Fax [phone] • www.follettice.com
Chart recorder related items
Reference # Description Part #
Not shown Gasket, bottle 00171124
Not shown Bracket, bottle 00171132
Not shown Bottle 00171116
Not shown Battery 00112177
Not shown 6" replacement, 7 day charts (quantity of 60) 00162099
Not shown Replacement pens (quantity of 6) 00162081
Not shown Probe, chart recorder 00162073
Hardware & electrical components
Reference # Description Part #
1 Temperature controller 00900118
Not shown Temperature probe & harness 00155705
2 Power switch 00114371
3 Front panel (includes 00114371 and 00105379) 00173559
4 Front panel screws, each - 6 per panel 00105379
Not shown Rear panel, includes screws 00130161
Not shown Rear panel screws, each - 6 per panel 00105387
5 Condensate pan 00155622
6 Evaporator drain line, sold by the foot 203627
Not shown FZR5-PL programming key, degrees C 00193391
Not shown Power cord 00103903
4
1
2
3
5
6
