FOOING HZB-12B User manual

INSTRUCTION MANUAL
It is important that you read these instructions before using your portableice maker and we
strongly recommend that you keep them in a safe place for future reference.
Model:HZB-12B
PORTABLE AUTOMATIC ICE MAKER
www.fooing.com
[e-mail]

..8
..8
9
10

1.
2.
Open the cover, remove the ice basket and pour water into tank.
Keep water level below the water level mark.
Directly enter the next procedure when there is no need to clean the machine. If you want to
use the cleaning function, please follow the instructions below:
The machine enters standby mode (POWER indicator light flashes in green) after plugging in.
Press and hold the ON/OFF button for 3 seconds to enter cleaning mode,“L" and“S"
indicator lights will flash alternately. The cleaning process will last about 30 minutes. Without
any operations, the machine will automatically end cleaning and enter standby mode after 30
minutes.
If you want to stop cleaning during the cleaning process, press the ON/OFF button for 1
second, the machine will end cleaning and enter standby mode.
Press “Power” button on the control panel to begin the ice making cycle.
Select the ice cube size by pressing the “Select” button. If the room temperature is lower
than 60℉, it is recommended to select small ice cube in order to avoid ice sticking together.
The ice making cycle lasts approx. 6 to 13 minutes, depending on seletion of ice cube size
and the room temperature. The recommended room temperature is 50℉to 105 ℉
If water pump can’t inject water, the ice maker will stop automatically, and the “Add Water”
3.
4.
5.
6.
indicator will be on.Press “Power” button, fill water up to the max. water level mark and
press “Power” button again to turn on the unit again.Allow the refrigerant liquid inside the
compressor at least 3 minutes to settle before restarting.
7. The ice maker stops when the ice basket is full and the “Ice” indicator will be on. Warning:
Direct sunlight or sunlight reflection may cause infared sensor malfunction . If the
unit doesn ’t stop even ice cubes obstruct sensor, move the unit where no sunlight.
8. Change water in the water reservoir every 24 hours to ensure a reasonable hygiene level.
If unit isn’t to be used, drain all the water and dry the tank.

8

9
Mod el
Mod el HZB-12B
Protecti on
Protection Type Type I I
Power
Power 115 115V/ V/6 60Hz 0Hz
Ice
Ice Making Making Current Current 1.7 1.7A A
Ice
Ice Harvest Harvest Current Current 2.0 2.0A A
Refrigerant
Refrigerant R R600 600a a0.74Oz 0.74Oz / /2 21 1g g
Design
Design Pressure Pressure
High
High Side Side 290Psig 290Psig
Low
Low Side Side 88Psig 88Psig
Vesicant
Vesicant C C5
5H
H10
10
Net
Net Weight Weight 7.1 7.1Kg Kg
Dimension
Dimension ( (W W* *D D* *H H) )222 222x x313 313x x320 320mm mm
Enclosure
Enclosure Plastic Plastic

10
