for Living HOME MAISON 043-5866-8 User manual

Installation and User Manual
FAN HEATER
043-5866-8
Stop
Stop
Please read and understand this manual before any assembly or use of this
product.
Before beginning assembly of product, make sure all parts are present.
If you have any questions or need replacement parts, please call our toll-free
helpline at 1-866-788-7389.
STOP
Questions?
V1
Fan Heater

Ceramic Heater
2
Table of Contents
Technical Data .......................................................................................................................................................... 2
Important Safety Instructions................................................................................................................................... 3
Key Parts Diagram .................................................................................................................................................... 5
Important Information............................................................................................................................................... 6
Operation................................................................................................................................................................... 7
Care and Maintenance ......................................................................................................................................... 10
Warranty ................................................................................................................................................................... 11
Technical Data
Dimensions
Model Number : 043-5866-8
Operating Voltage : 120 V
Operating Frequency : 60 Hz
Power : 1500 W (high), 900 W (low)
9" (22.86 cm)
8 1/2" (21.59 cm)

Ceramic Heater
3
Important Safety Instructions
SAVE THESE INSTRUCTIONS.
IMPORTANT! READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE!
• Read all the instructions carefully and use the heater only as directed in the manual. Usage of the
heater in other ways may cause electrical shock, fire, or damage to persons or property.
• This heater is hot when in use. Do not let bare skin touch hot surfaces. Always wait until the heater has
cooled to move the unit.
• Make sure combustible materials, such as furniture, pillows, bedding, papers, cloths, and curtains, are
at least 3’ (0.9 m) away from all sides of the heater. Do not block the rear grille (air inlet) with walls,
drapes, or similar items.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory,
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction regarding use of the appliance by a person responsible for their safety. Children should
be supervised to ensure they do not play with the appliance.
• Always unplug heater when not in use.
• Keep pets away from heater to avoid injury.
• DO NOT operate the heater with a damaged power cord or if the heater has been dropped,
damaged, or has malfunctioned. Return the heater to an authorized service facility for inspection,
electrical or mechanical adjustment, or repair.
• DO NOT use heater outdoors.
• DO NOT use heater in any area where there is standing water. Do not locate heater where it may
fall into a bathtub, pool, or other water container.
• DO NOT run power cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings.
Make sure the cord is kept away from highly traveled areas so that it will not be tripped over.
• To disconnect the heater, turn controls to OFF, then remove the plug from the outlet.
• Connect power cord to properly polarized electrical outlets only.
• DO NOT allow foreign objects to enter any ventilation or exhaust opening in the heater as this may
cause electric shock, fire, or damage to the heater.
• To prevent a possible fire, do not block air intake or exhaust in any manner. Do not use on soft surfaces
like a bed, where openings may become blocked.
• The heater has hot, arcing, or sparking pads inside. Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored.
• To prevent overload and blown fuses, do not plug in or use another appliance on the same
electrical circuit as the heater.
• It is normal for the heater’s plug and cord to feel warm to the touch. A plug or cord that becomes
hot to the touch may be a result of a worn electrical outlet. Worn outlets should be replaced prior
to further use of the heater. Plugging the heater into a worn outlet may result in the power cord
overheating or fire.
• Ensure the heater is placed on a stable, secure surface to avoid risk of tipping it over.
• DO NOT use an extension cord or relocatable power tap (outlet/power strip). Always plug the
power cord directly into a wall outlet/receptacle.
• Make sure the power cable has not been damaged in any way during transportation.
• Make sure that no pieces of polystyrene or other packaging material have been left between
elements in the appliance. If necessary, use a vacuum cleaner to remove small pieces of
packaging.
WARNING! To avoid possible electric shock, switch o the power supply at the main fuse
or circuit breaker box before installing, servicing, or cleaning.

Ceramic Heater
4
Important Safety Instructions
SAVE THESE INSTRUCTIONS.
• Make sure the plug is fully inserted in the electrical outlet. Electrical outlets can deteriorate with use.
Check periodically for signs of overheating or deformation of the plug. If damage is found, do not use
the outlet and contact a certified electrician.
• In the event of overheating, the heater will automatically shut off due to a Thermal Cut-Off. To reset,
turn off or unplug the heater for five (5) minutes so components can cool down. The most common
cause of overheating is the collection of dust. Refer to the Care and Maintenance section in this
manual for cleaning instructions.
•CAUTION: TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Ceramic Heater
5
Key Parts Diagram
1
2
3
4
No. Name
1
Pilot Light
2
3
4
Power Control Knob
Power Cord
Safety Grill

Ceramic Heater
6
Important Information
1. Features
1.1. Power Indicator
This indicator glows to indicate that the heater/fan is ON.
1.2. Power Level Switch
The power level switch is used to turn the heater on or off. The heater will operate at different power
ratings when setting the power level switch at Fan, LO and HI positions.
At the Power OFF position (1) the heater is OFF.
At the Fan position (2) the heater is in Fan Mode (15 W).
At LO Heat Setting position (3) the heater is operating in LO Mode (900 W).
At HI Heat Setting position (4) the heater is operating in HI Mode (1500 W).
2. Safety Features
2.1. Polarized Plug
The heater power cord is equipped with a polarized plug to prevent electric shocks. In a polarized plug
one of the blades is wider than the other. The wider blade can be plugged into a socket with a wider
slot in only one way, thus preventing an electric shock. Contact a qualified electrician if the plug does
not fit into the socket.
2.2. Thermal Fuse
In the event that the unit reaches extremely high temperatures, the heater’s fuse will shut off
permanently. Should this occur, the heater should be inspected and repair by a certified electrician
only.
2.2. Tip-Over Switch
As an additional safety measure, the heater will shut off in the event of it being knocked over. Should
this occur, turn the heater OFF and stand it back up to a correct position. Locate the heater so that it
cannot be tipped over. Turn the heater back ON.
4
3
2
1

Ceramic Heater
7
Operation - Heater mode
1. Locating the heater
2. Connecting the heater to the power supply
WARNING!
•Read each step carefully before beginning any installation and make sure you
understand each step.
•Keep children and pets away during heater operation.
•During first use, the heater may emit an odor and/or a trace of smoke. This is normal. Oil
from the manufacturing process is evaporating and should not re-occur. Make sure that
the room the appliance is operating in is well ventilated during operation. It is normal for
the appliance to make small cracking sounds when you turn it on for the first time.
• Place the heater on a firm, level surface free
from obstructions, and at least 3' (0.9 m) away
from any wall and any other combustible
materials such as furniture, pillows, papers,
clothes and curtains. The heater should be in an
upright position during operation.
3’ (0.9 m)
• Make sure the power level switch is in the (OFF)
position. Connect the power cord of the heater
into a grounded 120 V AC, 60 Hz outlet.
WARNING!
•Make sure the plug fits tightly in the outlet. A loose connection may cause overheating
and damage to the plug or heater.
•Disconnect the heater from the power supply when the heater is not in use.

Ceramic Heater
8
Operation - Heater mode
3. Turning ON the heater
4. Turning OFF the heater
• Turn the power level switch from the OFF
position (1) to the Fan (2), LO (3), or HI (4)
setting. The pilot light will come on, indicating
the heater is operating.
• Turn the switch to the HI (4) setting to heat up a
room quickly, then turn down to LO (3) to
reduce electrical consumption and prevent the
room from becoming too warm.
4
3
2
1
• Turn the power level switch to the OFF position
(1) and unplug the power cord from the outlet
after using the heater.

Ceramic Heater
9
Care and Maintenance
It is recommended to clean the heater at least once a month and also before off-season storage.
• After use, always turn off the heater and allow the heater to cool.
• Use a soft, damp cloth to gently wipe off dirt from the heater surface. Do not use any detergents
or abrasives or immerse the heater in water. Allow the heater to dry completely before use.
• Use a vacuum cleaner with a crevice tool attachment to clean the interior and remove dust.
• If the heater is not in use for a certain period, store the heater in a dry place.
Storage
•Clean the heater as described in this manual.
• Dry the heater with a clean, dry cloth.
•Store the heater in a plastic bag and store it in a cool, dry place.
Troubleshooting
WARNING!
•Before cleaning the heater, always turn off the power switch and unplug the heater.
•Do not allow water to enter the interior of the heater. Doing so may cause electric shock
or fire.
WARNING!
•Do not attempt to open or repair the heater. Doing so may void the warranty and could
cause damage or personal injury.
Problem Probable Cause Solution
Heater will not power ON Heater’s fuse has been
permanently shut off due to
extreme heat.
Do not attempt to fix heater yourself.
Contact a certified electrician to service
the heater.
Unit is not heating Thermal Cut-Off has been
activated due to an
overheating event.
Turn the heater OFF. Unplug heater and
allow it to completely cool down. Inspect
and remove an objects on or adjacent to
the heater. Wait 5 to 10 minutes before
plugging unit back in.

Ceramic Heater
10
Warranty
Limited 1-year Warranty
This product carries a one (1) year warranty against defects in workmanship and materials.
Trileaf Distribution agrees to replace a defective product, within the stated warranty period,
when returned to the place of purchase with proof of purchase. This product is not
guaranteed against wear or breakage due to misuse and/or abuse.
Imported by Trileaf Distribution Trifeuil
Toronto, Canada M4S 2B8
