For-x XQ-500.1D User manual

OWNERS MAUAL
XQ-500.1D/XQ-1000.1D
XQ-225.2D/XQ-400.2D
XQ-80.4D/XQ-125.4D/XQ-225.4D

1
FRONT PANEL
INPUT
The amplifier support High/Low level RCA signal input.
When choose PRE IN, Input sensitivity is 0.35-3.5V;
When choose SPK IN, input sensitivity is 0.7-7V.
GAIN CONTROL
INPUT LEVEL(PRE IN/SPK IN)
HPF CONTROL
FULL/HPF/LPF(BPF)
FREQ CONTROL
LPF CONTROL
BASS BOOST CONTROL
XQ-80.4D/XQ-125.4D/XQ-225.4D
XQ-225.2D/XQ-400.2D
XQ-500.1D/XQ-1000.1D
1

REAR PANEL
GND
Used to connect power amplifier grounding cable. The power supply grounding cable need
to be firmly connected to the frame of the vehicle or other places with good conductivity.
Please use the cable with same specifications as the power supply cable and connect to
frame of the vehicle near the installation position of the power amplifier. Please ensure
that the grounding point is good and take appropriate anti-oxidation measures.
REM
Remote control terminal. The remote control cable must be connected with source unit
remote terminal so the amplifier will switch on and off automatically with source unit.
+12V
Used to connect the positive terminal 12V car battery. In order to ensure adequate power
supply for the amplifier, special cable should be used to connect directly to the positive
pole of the battery, and the fuse should be connected in series within 20 centimeters from
the positive pole of the battery.
SPEAKER
Connect your speakers correctly which means plus to plus and minus to minus. Never
connect speaker cables with chassis ground directly. It may destroy your amplifier.
1
2
XQ-500.1D/XQ-1000.1D
XQ-225.2D/XQ-400.2D
XQ-80.4D/XQ-125.4D/XQ-225.4D

2 - 8 Ohm
Source Unit 2 - 8 Ohm
2 - 8 Ohm 2 - 8 Ohm
Car battery
DC 12V
-+
Connected to the metal
frame of the vehicle FUSE
Control
wire output
1
3
XQ-80.4D/XQ-125.4D/XQ-225.4D

Source Unit 4 - 8 Ohm
4 - 8 Ohm
Car battery
DC 12V
-+
Connected to the metal
frame of the vehicle FUSE
Control
wire output
1
4
XQ-80.4D/XQ-125.4D/XQ-225.4D

Car battery
DC 12V
-+
Connected to the metal
frame of the vehicle FUSE
2 - 8 Ohm 2 - 8 Ohm
Source Unit
Control
wire output
1
5
XQ-225.2D/XQ-400.2D

FUSE
Control
wire output
4 - 8 Ohm
Source Unit
Car battery
DC 12V
-+
Connected to the metal
frame of the vehicle
XQ-225.2D/XQ-400.2D
1
6

Source Unit
4Ohm Minimum or
4Ohm Minimum
2Ohm Minimum
1
7
XQ-500.1D/XQ-1000.1D

1
8
SPECIFICATIONS
HPF/FULL/BPF
165
40Hz
7.5V 16V~
155
46
0dB ~12dB0dB~12dB
XQ-500.1D
186 165 186 165
XQ-1000.1D XQ-225.2D XQ-400.2D XQ-80.4D XQ-125.4D XQ-225.4D
LPF/FULL/HPF
40Hz 40Hz 40Hz
0dB~12dB 0dB ~12dB
2Ohm
165
7.5V 16V~7.5V 16V~7.5V 16V~7.5V 16V~7.5V 16V~7.5V 16V~
Features
SMT Parts / Double-Sided FR-4 PCB
DIMENSION
YES NA
Length ( mm )
Model
2Ohm Load
4Ohm Load
Bridged 4Ohm Load
Input Level
Frequency Response
Subsonic/HPF
Bass Boost Level
S/N Ratio
Minimum Load
Voltage Range
Components & PCB
Height ( mm )
Width ( mm )
X-over Type
Bass Boost Frequency
Intelligent Power
Management System
Optional Bass Remote
NA
YESYESYES
2Ohm2Ohm2Ohm 2Ohm 2Ohm 2Ohm
NA NA NA NA
Peak Power 4Ohm Load
The contents of this manual the specications of this product are subject to change without notice.
HPF/FULL/BPF HPF/FULL/BPF HPF/FULL/BPF LPF/FULL/HPF LPF/FULL/HPF
550W x 1
380W x 1
325W x 2
225W x 2
600W x 2
400W x 2
1200W x 1
300W x 4 225W x 4
600W x 2
180W x 4
125W x 4
360W x 2
1000W x 1
665W x 1
130W x 4
80W x 4
260W x 2
260W x 41100W x 1
650W x 1
650W x 2 360W x 42000W x 1 600W x 41200W x 2
NANA
10~30KHz10Hz~35KHz 10Hz~30KHz10Hz~30KHz10Hz~25KHz10Hz~25KHz 10~30KHz
GROUP A: 0 300Hz / GROUP B: 50Hz 300Hz~ ~
50Hz 300Hz~
OFF~300Hz OFF~300Hz
OFF~300Hz OFF~300Hz
OFF~300Hz OFF~300Hz
OFF~300Hz OFF~300Hz
>91dB
>96dB>101dB >95dB >95dB
>95dB>96dB
PRE INPUT : 0.35~3.5V / SPK INPUT : 0.7~7V
Overload protection, Shortcircuit protection, Overheat protection, Low voltage protection, Over voltage protection.
186
LPF
NA NA NA
RMS Power at 14.4V

PRECAUTIONS
No Function:
Please check whether the power cable / ground cable / remote control cable
connection is wrong. Make sure all connections are correct and in good
contact. If the fuse is damaged, please pay attention to the correct value of a
new fuse.
No Sound:
Speaker cable or speaker plug are not connected correctly.
No Sound /Red LED Protection Shines:
The plus and minus wires of the speaker cable have contact, thus eliminate
the short circuit. If you use a 2 Ohm speaker in stereo mode, a 4 Ohm
speaker in.bridge mode or tri-mode and the set is overloaded, then turn the
gain control to "min" until the operation is free of trouble.
Poor Sound Quality ( Distortions ):
The speakers are overloaded, therefore turn down the volume level and
check the volume control positions.
No Stereo Sound And A Weak Bass:
Speaker cables (+) and (-) are mixed up, unit wired out of phase.
This unit is designed for negative ground 12V DC operation only
Avoid installing the unit where:
- It would be subject to high temperatures, such as from direct sunlight or hot
air from the heater.
- It would be exposed to rain or moisture.
- It would be subject to dust or dirt.
If your car is parked in direct sunlight and there is a considerable rise in
temperature inside the car, allow the unit to cool off before operation.
When installing the unit horizontally, be sure not to cover the heatsink fins
with the floor carpet.
If this unit is placed too close to the car radio, an interference may occur. In
this case, separate the amplifier from the car radio.
This power amplifier employs a protection circuit to protect the transistors
and speakers if the amplifier malfunctions. Do not attempt to test the
protection circuits by covering the heatsink or connecting improper loads.
Do not use the unit with a weak auto battery as its optimum performance
depends on a normal battery supply voltage.
For safety reasons, keep the volume of your car audio system moderate so
that you can still hear normal traffic sounds outside your car.
If the product contains desiccant, do not eat, avoid touching the liquid, and
keep away from children.
