The Force10 Networks S50 is a high performance, low cost, stackable, Layer 2 switch/Layer 3 router that
supports 48 built-in 10/100/1000 Base-T ports, four SFP (small form-factor pluggable) ports, and two
optional 10-Gigabit XFP or CX4 ports. For stacking details, see Chapter 3, Installing the S50, on page 22.
Figure 1 The S50 (Front View)
Figure 2 The S50 (Rear View)
Chapter 1 The S50 System
fn00157s50
OK
PWR
FAN
XFP1
Ethernet Ports
LEDs
PRI
BPS
TMP
XFP2
SFP RJ-45
Ports Management
Port
Status Panel Shared
10/100/1000
Ports
Stacking
Indicator
LEDs
fn00158s50
XFP2
LINK/ACT
XFP1
LINK/ACT
10-Gigabit Module
DC Power Module (optional)
A
C Power Receptacle
Ground Connector
Stack
Port A
Stack
Port B

8The S50 System
Equipment
The following items are necessary to install the S50 system:
• The switch
• One grounded AC power source per S50
• Cable to connect the AC power source to the S50 chassis (included)
• Brackets for rack installation (supplied)
• Screws for rack installation and #2 Phillips screwdriver (not supplied)
Other optional components are:
• Stacking cables for connecting S50s when stacked
• Backup DC Power Module (see Chapter 4, Installing Backup Power, on page 27)
• Power Supply Unit (AC-to-DC converter)
• External power shelf and cable to connect to the S50 chassis
• Optical networking components (see Chapter 5, Installing Ports, on page 31)
Features
• S50 CPU and switch processor
• S50 memory and MAC addresses
• Stackable switch features
• 19-inch rack-mountable
• Standard 1U chassis height
• Six built-in fans
• Internal power supply
• Up to 16K MAC address entries supported with hardware assisted aging
• Supports 9K jumbo frames
• Back-pressure support at half-duplex, IEEE 802.3x flow control at full duplex
• Extensive LED system with per-port LEDs
Ports
• Two optional XFP or CX4 10G ports
• 48 fixed 10/100/1000 Mbps auto-sensing and auto MDIX RJ45 ports
• Four ports capable of using 10/100/1000 Base-T or 1000 Base-X using auto-media detect
• Two 10G stacking ports
• Console port (see Accessing the Console Port on page 31): Supplied with console cable
(straight-through Ethernet copper cable) and terminal adapter (DB-9 to RJ-45)

Installing the S50 System 9
System Status
S50 status information can be derived in several ways, including physical LED displays and boot menu
options, both discussed here, along with CLI “show” commands, SNMP traps, and the SFTOS Web User
Interface. For details on those options, see the SFTOS Command Reference and the SFTOS Configuration
Guide.
LED Displays
As shown in Figure 1 on page 7, the S50 front panel contains several sets of LEDs:
• Stacking LEDs at the top right of the front panel: Eight LEDs, numbered 1 through 8, indicate the
number of this unit in the stack. For more on unit numbering, see Hot-swapping Units in a Stack on
page 24.
• Status indicator LEDs on the left side of the front panel, explained in Table 3.
• Each port has status indicator LEDs, described in Table 2.
*The LEDs for a 10/100/1000 port numbered 45 through 48 are inactive if the shared SFP port (also labeled 45 through
48) is enabled.
Table 2 Port LED Displays
Feature Description
10/100/1000 Port LED*Speed LED (left side of each port)
Green — 1000M
Amber — 100M
Off — 10M
Link/Active LED (right side of each port)
Green — Link up on this port
Blinking Green — Activity, transmitting or receiving packet at this port.
Off — No Link detected at this port
SFP Port LED*Link/Activity LED
Green — Link up on this port
Blinking Green — Activity, transmitting or receiving packet in link up state
Off — No Link detected at this port
XFP Port LED Link/Activity LED
Green — Link up on this port
Blinking Green — Activity, transmitting or receiving packet in link up state
Off — No Link detected at this port
Note: As suggested by the footnote above, the fiber SFP ports have priority over the four 10/100/1000
ports with the same number.

10 The S50 System
The following table describes the LED status indicators on the left side of the front panel.
Table 3 Status Panel LED Display
Label LED Color Description
OK Green
Off
Green Blinking
Amber Blinking
Unit is operational.
Unit is powered off.
Unit is booting up.
File download is in progress.
Note: The blinking rate for the OK (green) LED is 1 Hz.
PWR Green
Amber
Main power supply is OK.
Main power supply is operating outside expected parameters.
FAN Green
Amber
All Fans are OK.
At least one fan is operating outside expected parameters.
XFP1 Green
Blinking Green
Off
10G1 link
10G1 active
10G1 no link
PRI Green
OFF
This is the primary unit.
This is not the primary unit.
BPS Green
Amber
Redundant power supply is OK.
Redundant power supply is operating outside expected parameters or
is not installed.
TEMP Green
Amber
Temperature is OK.
Temperature is operating outside expected parameters.
XFP2 Green
Blinking Green
Off
10G2 link
10G2 active
10G2 no link

Installing the S50 System 11
This chapter describes requirements and procedures to install your S50 system. This chapter covers the
following topics:
•Site Selection
•Cabinet Placement
•Rack Mounting
•Fans and Airflow
•Power
•Storing Components
For detailed S50 specifications, refer to Chapter 6, S50 Specifications, on page 35.
Site Selection
Make sure that the area where you install your S50 chassis meets the following safety requirements:
• Near an adequate power source. Connect the system to the appropriate branch circuit protection as
defined by your local electrical codes.
• Environmental temperature between 32° – 122°F (0° – 40°C).
• Relative humidity that does not exceed 95% non-condensing.
• In a dry, clean, well-ventilated and temperature-controlled room, away from heat sources such as hot
air vents or direct sunlight.
• Away from sources of severe electromagnetic noise.
• Positioned in a rack, cabinet, or on a desktop with adequate space in the front, rear, and sides of the
unit for proper ventilation, and access.
Chapter 2 Site Preparations
Note: Install the S50 into a rack or cabinet before installing any optional components.

12 Site Preparations
Cabinet Placement
The cabinet must meet the following criteria:
• Minimum cabinet size and airflow are according to the EIA standard.
• Minimum of 5 inches (12.7 cm) between the side intake and exhaust vents and the cabinet wall.
Rack Mounting
When you prepare your equipment rack, ensure that the rack is earth ground. The equipment rack must be
grounded to the same ground point used by the power service in your area. The ground path must be
permanent.
Fans and Airflow
For proper ventilation, position the S50 chassis in an equipment rack (or cabinet) with a minimum of five
inches (12.7 cm) of clearance around the side intake and exhaust vents. When two S50 systems are
installed side by side, position the two S50 chassis at least 5 inches (12.7 cm) apart to permit proper
airflow. The acceptable ambient temperature ranges are listed in Environmental Parameters on page 35.
As listed in Table 3, “Status Panel LED Display,” on page 10, the front panel of the S50 has both a fan
status LED and a temperature LED. The fan status LED is green when all of the six fans are operating
normally, amber when any are not operating normally. The fan speed increases when the temperature of
either of the two sensors reaches 72 degrees C, and decreases to normal speed when the temperature falls
to 57 degrees C. The switch never intentionally stops managing traffic.
The temperature status LED is also green when the switch is operating within required temperature
parameters. The LED turns amber when either of the two temperature sensors indicates an out-of-range
temperature, and returns to green when the temperature returns to normal. SFTOS logs a temperature
warning message when a temperature of 77 degrees C is reached, and logs another message when the
temperature returns to normal.
Use the show logging buffered command to see the log messages. For details, see the Syslog chapters
of the SFTOS Command Reference or SFTOS Configuration Guide.
In a stack, each unit has its own temperature monitoring and control. Status logging is identified by unit in
the system log.
Fan replacement is not offered as an option in the field.

Installing the S50 System 13
Power
Use the power cord shipped with the S50 chassis to connect the chassis to the AC power outlet.
Storing Components
If you do not install your system and components immediately, Force10 Networks recommends that you
properly store the S50 and all optional components until you are ready to install them.
Follow these storage guidelines:
• Storage temperature should remain constant ranging from -4° to 158° F (-20°C to 70° C).
• Store on a dry surface or floor, away from direct sunlight, heat, and air conditioning ducts.
• Store in a dust-free environment.
Caution: The power supply cord is used as the main disconnect device; ensure that the
socket-outlet is located/installed near the equipment and is easily accessible.
Warning: Electrostatic discharge (ESD) damage can occur when components are mishandled.
Always wear an ESD-preventive wrist or heel ground strap when handling the S50 and its
accessories. After you remove the original packaging, place the S50 and its components on an
antistatic surface.

14 Site Preparations

Installing the S50 System 15
To install the S50 system, Force10 Networks recommends that you complete the installation procedures in
the order presented below.
•Inserting the 10-Gigabit Module (optional)
•Inserting Backup Power (optional)
•Tabletop Installation
•Rack or Cabinet Installation
•Connecting Stacking Ports (optional)
•Supplying Power
Inserting the 10-Gigabit Module (optional)
The S50 has a slot at the right rear of the chassis, for which there are two types of 10-Gigabit module
available (see Figure 2)—fiber (optical) and copper (10GBase-CX4). Both have two ports (the system
numbers them 49 and 50). The fiber module requires additional XFP inserts (see Installing XFPs on
page 33). The ports in the copper CX4 module use the same kind of stacking cable that you use for the
stacking ports.
To install a 10-Gigabit module, follow the steps below:
Chapter 3 Installing the S50
Warning: As with all electrical devices of this type, take all the necessary safety precautions to
prevent injury when installing this system. Electrostatic discharge (ESD) damage can occur if
components are mishandled. Always wear an ESD-preventive wrist or heel ground strap when
handling the S50 and its components.
Note: Before installing the CX4 card, contact Force10 TAC for instructions on connectors and on
configuration.
Step Task
1. Power down the S50; unplug the S50 from its power source.
2. Remove the 10-Gigabit module faceplate located at the far right rear of the S50.

16 Installing the S50
Inserting Backup Power (optional)
The S50 switch has an optional DC power module that you install in the rear of the S50 chassis (see
Figure 2). If you have purchased the backup power option, Force10 recommends that you install the DC
power module before installing the unit in a rack, and that you connect the module to its AC-to-DC
converter before powering up the S50. See Installing Backup Power on page 27.
Tabletop Installation
The S50 can be positioned on a stable tabletop. Keep the following in mind when using a tabletop for your
S50:
• Ensure that your tabletop is stable and can handle the weight of the S50 or a stack of S50s, along with
any added backup power supplies.
• Position the table so that there is proper ventilation and easy access to power outlets.
Rack or Cabinet Installation
The S50 provides three rack-mounting methods:
•Two-Post Rack Mounting
•Four-Post Rack-mounting with Threaded Rails
•Four-Post Rack-mounting with Cage Nuts
3. Remove the 10-Gigabit module from its packaging and slide the module into the 10-Gigabit slot.
4. Secure the captive screws on either side of the module.
5. Connect the S50 to its power source and power up the S50.
Step Task
f
n00144s50

Installing the S50 System 17
Two-Post Rack Mounting
The S50 is shipped with the universal front-mounting brackets (rack ears) attached. Ensure that there is
adequate clearance surrounding the rack to permit access and airflow. If you are installing two S50 systems
side-by-side, position the two S50 chassis at least 5 inches (12.7 cm) apart to permit proper airflow.
Position the S50 chassis in the rack. Secure the chassis with two screws through each bracket and onto the
rack post.
Figure 3 S50 Two-post (Front-mounted) Rack-mounting

18 Installing the S50
Four-Post Rack-mounting with Threaded Rails
Ensure that there is adequate clearance surrounding the cabinet or rack to permit access and airflow. If you
are installing two S50 systems side-by-side, position the two S50 chassis at least 5 inches (12.7 cm) apart
to permit proper airflow. Follow the steps below to install the S50 chassis into a four-post 19-inch
equipment rack, using the attached front mounting brackets and the optional adjustable rear-mounting
brackets.
Step Task
1. Align the three screw holes of the adjustable rear mounting bracket with the three holes in the S50
chassis, and secure the mounting bracket with three screws.
2. Insert the S50 into the rack, and secure the chassis to the front post with two screws. Then secure the
chassis to the rear posts with two screws.

Installing the S50 System 19
3. Set the adjustable rear mounting bracket to the length (one of three lengths) for your bracket. Secure
the length with the four screws.
Figure 4 Four-post Rack-mounting with Adjustable Rear-mounting Brackets
Step Task

20 Installing the S50
Four-Post Rack-mounting with Cage Nuts
Ensure that there is adequate clearance surrounding the cabinet or rack to permit access and airflow. If you
are installing two S50 systems side-by-side, position them at least 5 inches (12.7 cm) apart. Follow the
steps below to install the S50 chassis into a four-post rack mounting with cage nuts.
Step Task
1. Attach the two rear brackets to the side panels. Align the three holes in the bracket with the three
holes on the S50 chassis, and secure the brackets to the chassis using the screws.
2. Align and secure the adjustable bracket onto the rear bracket.
3. Insert the S50 chassis into the rear of the rack. Position and secure the chassis with two screws into
each front bracket flange and into the rack post.
fn00147f_s50
Align brackets
Top View of Brackets
fn00147a_s50
