TANGENTTM TABLE ENSEMBLE
FREESTANDING INSTALLATION INSTRUCTIONS
page 1 of 2 | Rev. 06-03-13
T 800.451.0410 | www.forms-surfaces.com
© 2013 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.
TOOLS NEEDEDMATERIALS INCLUDED
STEP BY STEP FOR ALL FREESTANDING TANGENT TABLE ENSEMBLES (SETAN-4BS SHOWN)
7/32" hex bit for
tamper-resistant screws
Attach legs to central hub
• Attach legs to central hub with 1/4"-20 x 3/4" flat socket-cap
screws (a) using drill and 7/32" hex bit for tamper-resistant screws
(provided).
Attach top bracket to legs
• Attach top bracket to legs with 1/4"-20 x 3/4" flat socket-cap
screws (a) using drill and 7/32" hex bit for tamper-resistant
screws.
Attach table top to top bracket
• Attach table top to top bracket with 3/8"-16 x 3/4" button head
cap screws (b) using drill and 7/32" hex bit for tamper-resistant
screws. Note that 4-seat ensembles will use 8 flat socket-cap
screws, and 6-seat ensembles will use 6 flat socket-cap screws.
hammer drill
3/16" hex key
2 per leg
b
4 per leg
Loctite
c
b
c
a c
b
aa
bb
Attach seats to seat cradle brackets
• Attach seats to seat cradle brackets with 3/8"-16 x 3/4" button
head cap screws (b) using a drill and 7/32" hex bit for tamper-
resistant screws. Note that the indicator arrow on the seat cradle
bracket should be pointing towards the front of the seat.

TANGENTTM TABLE ENSEMBLE
FREESTANDING INSTALLATION INSTRUCTIONS
page 2 of 2 | Rev. 06-03-13
T 800.451.0410 | www.forms-surfaces.com
© 2013 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.
STEP BY STEP FOR ALL FREESTANDING TANGENT TABLE ENSEMBLES (SETAN-4BS SHOWN)
c
Attach seats to legs
• Attach seat cradles to legs with with 3/8"-16 x 1" flat socket cap
screws (c) using a drill and 7/32" hex bit for tamper-resistant
screws.
Tighten screws
• Tighten all screws until snug.
