Forms + Surfaces AXIS RECEPTACLE User manual

AXISTM RECEPTACLE
ATTACHMENT INSTRUCTIONS
page 1 of 2 | 09-17-15
© 2015 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.
T 800.451.0410 | www.forms-surfaces.com
MATERIALS INCLUDED
STEP BY STEP
Insert top attachment plate
• Each Axis Receptacle comes with one
attachment plate and four screws. To
attach two receptacles you will need two
attachment plates and eight screws.
• Insert top attachment plate (b) into
slot along the straight flat end of the
receptacle, below the lid.
• Align holes in top attachment plate with
holes in top receptacle frame.
Attach top attachment plate
• Insert 1/4"-20 x 1/2" Phillips bit pan
head screws (a) through receptacle
frame and top attachment plate to secure
top attachment plate to receptacle.
• Use Philips head screwdriver to tighten
screws until snug.
Insert bottom attachment plate
• Insert bottom attachment plate (b) into
slot along the straight flat end of the
receptacle, below the body and above
the base.
• Align holes in bottom attachment plate
with holes in bottom receptacle frame.
TO ATTACH TWO AXIS RECEPTACLES
a b
TOOLS NEEDED
philips head
screwdriver

AXISTM RECEPTACLE
ATTACHMENT INSTRUCTIONS
page 2 of 2 | 09-17-15
© 2015 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.
T 800.451.0410 | www.forms-surfaces.com
Attach bottom attachment plate
• Insert 1/4"-20 x 1/2" Phillips bit pan
head screws (a) through receptacle
frame and bottom attachment plate
to secure bottom attachment plate to
receptacle.
• Use Philips head screwdriver to tighten
screws until snug.
Both attachment plates secured
• Both attachment plates should now be
secured on the first receptacle and ready
to be attached to the second receptacle.
STEP BY STEP
Align and attach second receptacle
• Align top and bottom attachment plates
from the first receptacle with the slots in
the second receptacle.
• Secure attachments plates with 1/4"-20
x 1/2" Phillips bit pan head screws (a)
to second receptacle as in Step 2 and
Step 4.
• Use Philips head screwdriver to tighten
screws until snug.
TO ATTACH TWO AXIS RECEPTACLES
