Fortress Technologies FDH1010M User manual

FDH1010M / FDH1210E
DEHUMIDIFIER
USER MANUAL
*Before operating the unit, please read this manual thoroughly, and retain it for
future reference.

Contents
Page
Safety Information ___________________
Name of Parts _______________________
Control Panel Description ____________
Operation Instruction ________________
Drainage ___________________________
Maintenance Instruction ____________
Trouble shooting ____________________
Specification _______________________
Warranty ___________________________
1
2
3
4
5-6
7
8
9
10

Safety Instruction
1. To reduce electric shock, risk of fire or injury, please read the operating
instructions carefully before using your dehumidifier for the first time and
keep them in a safe place.
2. Never immerse the appliance in water or other liquids.
3. Never operate the appliance if a cable or connector has been damaged,
after appliance malfunction or if the appliance was dropped or any
damaged.
4. Electric appliance is only be repaired by qualified personal, improper repair
work can be a source of considerable danger for the users.
5. Children and infirm person are not aware of the hazards of electric
appliance. Therefore, never allow children to manipulate electric appliance
unless properly supervised.
6. Disconnect the appliance from mains power whenever it is not in use,
before relocating it, and before cleaning,
7. Operate the appliance is only at the voltage specified on the type plate.
8. Use the appliance only in the household, and only for the purpose it was
designed for.
9. Do not place any objects on the appliance.
10. To prevent spillage, empty the water tank before relocating the appliance.
11. Do not tip the appliance to any side as escaping water could damage the
appliance.
12. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
13. When the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
14. The devices should be installed at minimum distant of 10CM from the
wall or other obstacle.
15. Unplug the appliance before cleaning.
16. Don’t put any wet or dripping water’s cloths on top of dehumidifier.
17. Do not block air inlet and outlet.
18. Don’t use bug sprays or other flammable cleaners to the unit.
1

Name of Parts
Front
1. Control panel
2. Air inlet
3. Handle
4. Filter (inside the unit)
5. Water tank
6. Water level window
7. Caster
8. Handle for water tank
Rear
9. Air outlet
10. Drain hole for continuous
drain
11. Power cord compartment
12. Power cord
2

Mechanical Type (Model: FDH1010M)
13. Humidistat
14. “Water Full” indicator
15. Power operation indicator
Electronic Type (Model: FDH1210E)
16. ON/OFF button
17. Humidity setting button
18. SPEED (ventilation) button
19. Low speed indicator
20. High speed indicator
21. Humidity/Temperature display
22. Timer button
23. Set temperature button
24. Power indicator
25. “Full Water” indicator
26. Humidity indicator (continuous
working, humidity 50%, 60%, 70%,
80%)
3
Control Panel Description

Operation Instruction
Mechanical type
1. Plug the unit into a correct mains socket. (Please refer to the rating label
at the rear of the unit for correct voltage/frequency.)
2. Switch the HUMIDISTAT to required
humidity setting. The intensity of the
humidity extraction is increased clockwise.
For continuous working, set the humidistat to
position 'MAX'.
3. As the unit starts to work, the power
Indicator should come on.
4. As the water in the water tank is full, the
“Water Full” indicator will come on and the machine will stop working.
Electrical type
1. Plug the unit into a correct mains socket. (Please refer to the rating label at the rear of
the unit for correct voltage/frequency.)
2. Press ON/OFF button to turn on the unit. The compressor will start to work.
3. Press “HUM” (humidity) button to setting the working model you need: continuous
working, humidity 50%, 60%, 70% or 80%. The relative indicator will light on.
4. Press “SPEED: button to set the ventilation speed, high or low. The relative indicator
will light on.
5. Press the “TIMER”button to set the operating hour you need (1~24 hours). The
display window will show the hour(s) you set as you press the TIMER button, after
releasing it for 8 seconds around, the display window will return to the room humidity.
As the set time has been reached, the compressor will stop working automatically.
6. By pressing the ”TEMP” button, the display window will show the room temperature,
after releasing the button for 8 seconds around, the display window will return to the
room humidity.
7. To turn off the unit, press ON/OFF button again.
8. Pre-setting function: By pressing TIMER button but without turning on the
other functions (including ON/OFF button), you can PRE-SET the time for the machine
to work. For example, if you press the timer to ‘2’, the unit will work automatically
after 2 hours. 4

Drainage
While the water tank is full, the compressor will stop for self-protection and the water full
indicator will turn into red.
To move the water tank, pull it out squarely from the unit by using the handle at the water
tank.
After empting the water tank, place the water tank into space. Make sure it is properly
positioned, in order for the 'Water Full' sign to go out and your dehumidifier is operating.
Please note, in case, the water tank has not been positioned well, the water full indicator
will turn into red.
Continuous drainage
When the dehumidifier is operated at very high humidity environment, the water tank will
require more frequent drainage. In this situation, it may be more convenient to set the unit
up for continuous drainage with the following procedures:
1. Pull out the stopper from the
drain hole Aat the rear of the
machine ( see FIG. 1) and
connect the drain hole A with a
water tube of inner diameter 12
mm. (FIG.2)
☆Please note, the water tube is not
supplied with the unit.
FIG.1 FIG.2
5
Hole A
Hole A

2. Pull out the water tank. Use the
stopper taken from Hole Ato stick into
drain Hole B (FIG. 3).
3. Ensure the water will always drain
away freely and the tube will remain
in right place. Note! In very cold
weather conditions, precautions
should be taken to prevent the water
tube from freezing.
FIG.3
4. Put the water tank back to its position
(FIG. 4).
FIG.4
6

Maintenance Instruction
Always unplug the unit from the mains before carrying out any maintenance or cleaning of the
unit.
CLEANING THE BODY
Use soft cloth to wipe the unit clean.
Don't ever use volatile chemicals, gasoline, detergents, chemically treated clothes, or other
cleansing solutions. These all could possibly hurt the cabinet.
CLEANING THE AIR FILTER
Remove the water tank & extract
the filter holder (fig.1).
Use a vacuum cleaner or tap
the filter lightly for easy
cleaning. If the filter is
particularly dirty, use warm
water with a small amount of
medium strength (fig.2).
Make sure the filter is
completely dry before placing.
Do not expose the filter to sunlight.
STORAGE
If not use the unit for an extended period of time. Please:
Turing the unit off, unplug and tidy AC cord.
Completely empty the water tank and wipe it clean.
Clean the filter.
Cover the unit and store where it will not receive direct sunlight.
7
fig.1
fig.2

Trouble shooting
THE UNIT DOES NOT OPERATE:
Is the unit plugged in?
Is the house electricity on?
Is the room temperature below 5oC or above 35oC? If so, then it is out of the working
range of the unit.
Ensure the ON/OFF switch is turned on.
Check the water tank is positioned properly in the unit and it is not full.
Make sure the air inlet and outlet are not obstructed.
THE UNIT SEEMS TO DO NOTHING:
Q: Is the filter dusty, contaminated?
A: Use a vacuum cleaner or tap the filter lightly. If the filter is particularly dirty, use
warm water (below 40 degree) with a small amount of medium strength.
Q: Is the air intake or outlet blocked up?
A: Please move the object away from the air intake or outlet.
Q: Is the room humidity already quite low?
A: Dehumidifier shall not operate if the humidity setting is higher than the ambient
humidity.
THE UNIT SEEMS TO DO LITTLE:
Q: Are too many windows or doors open?
A: Please close the windows or doors when operating the dehumidifier.
Q: Is there something in the room producing lots of humidity?
A: Please put these stuffs into another room, close toilet lid and cover a glass of water.
THE UNIT IS TOO NOISY:
Check whether the unit is sitting on a level surface.
THE UNIT IS LEAKING:
Make sure the unit is in good shape.
If you are not using continuous drainage, make sure the rubber plug (at the bottom of
the unit) is in its position.
8

Specification
Model no.
FDH1010M
FDH1210E
Power supply
220-240V~, 50Hz
Dehumidification capacity
10 L/day
12 L/day
Power consumption
260W
280W
Air volume (max.)
180m3/h
Fan speed
1
2
Timer
NIL
1~24h
Refrigerant
R134a
Working range
5 ~ 35oC
Water tank capacity
3.6 L
Size (WxDxH)
33 x 25 x 52.2 cm
N.W.
11.5 kg
12 kg
9

WARRANTY
1. The product has 2 years warranty from the date of purchase.
2. The warranty shall not apply:
a. to any Product subjected to accident, misuse, neglect, alteration, Acts of God,
improper handling, improper transport, improper use, improper testing or unauthorized
repair;
b. to cosmetic problems or defects which result from normal wear and tear under ordinary
use, and do not affect the performance or use of the product. All warranties are void
if the product is opened, altered, and/or damaged;
c. to any packing, transportation, export / import tax or any related expenses.
3. CUSTOMER MUST PRESENT THE SALES INVOICE OR RECEIPT FOR 2 YEARS
WARRANTY SERVICES.
4. Please bring along the product and sales invoice or receipt to our services center for warranty
services during office hour.
Hong Kong Service Centre:
Address：Unit D, 20/F, Yip Shing Ind Bldg, No.19, Yip Shing Street, Kwai Chung.
Service Hotline：[phone]
Macau Service Centre:
Address：Avenida Almirante Lacerda 162 –172, H –J
Service Hotline：[phone]
Service Hours -
Monday-Friday ：9:00am - 1:00pm / 2:00pm - 6:00pm
Saturday ：9:00am - 1:00pm
Sunday & Public Holiday ：Closed
5. THE UNIT IS FOR DOEMSTIC USE ONLY.
IMPORTANT NOTICES
THE UNIT IS FOR DOMESTIC USE ONLY
IN NO EVENT SHALL OUR COMPANY OR THE SUPPLIER BE LIABLE TO YOU OR ANY OTHER PARTY
FOR ANY DIRECT, INDIRECT, GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY
OR OTHER DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR INJURY, LOSS OF PROPERTY, BUSINESS
PROFITS, BUSINESS INTERRUPTION) OR FROM ANY BREACH OF WARRANTY, EVEN IF OUR
COMPANY OR SUPPLIER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO
CASE SHALL OUR COMPANY OR SUPPLIER’S LIABILITY EXCEED THE AMOUNT YOU PAID FOR THE
PRODUCT.
Specifications, designs and dimensions subject to change without prior notice.
10
