Frigidaire FDL25P User manual

Product No. FDL25P11 FDL25P12
Series Dehumidifer Dehumidifer
Color white white
Volts 115 115
Owner's Guide 220261d000 220261d000
Market North America North America
FDL25P cover.eps FDL25P.eps 2202609108.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995436713
05/05/20
(EN/SERVICE/WC)
099
ROOM DEHUMIDIFIER
Model No.
FDL25P
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995436713 FDL25P
05/05 2
RECOMMENDED SPARE PARTS

FDL25P Publication No: 5995436713
# Functional Parts 3 05/05
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
Model Index: AFDL25P (FDL25P11)
BFDL25P (FDL25P12)
POS. NO PART NO. DESCRIPTION
1 5304447105 A B Filter, air
2 5304447106 A B FRONT PANEL ASSEMBLY
3 5304447107 A B Evaporator
4 5304447108 A B CONDENSER-AIR COOL, REC.
5 5304447109 A B LEFT CONNECTION BOARD
6 5304447110 A B RIGHT CONNECTION BOARD
7 5304447111 A B SEAL, COND/EVAP COIL, FOAM
8 5304447237 A B Panel-left side
9 5304447238 A B COVER/TOP CAP ASSEMBLY
10 5304447239 A B COVER/TOP CAP
11 5304447240 A B MAIN CONTROL ASSEMBLY
12 5304447241 A B Overlay-control
13 5304447242 A B COVER-CONTROL BOX, E-PART BOX
14 5304447243 A B Display Board
15 5304447244 A B MAIN CONTROL BOARD
16 5304447245 A B CONTROL BOX, E-PART BOX COVER
17 5304447246 A B HUMIDITY SENSOR
18 5304447247 A B BRACKET, HUMIDITY SENSOR
19 5304447248 A B EVAPORATOR PIPE TEMP SENSOR
20 5304447249 A B WATER DEPTH SWITCH, OVERFLOW
21 5304447250 A B Bracket-fan motor
22 5304447251 A - FAN MOTOR
22 5304447278 - B FAN MOTOR
23 5304447252 A B Blade-fan
27 5304447253 A B Shroud-condenser
28 5304447254 A B FAN MOTOR CAPACITOR BOX
29 5304447255 A B TERMINAL-ELECTRIC
30 5304447256 A B FAN MOTOR CAPACITOR
31 5304447257 A B WATER DEPTH SWITCH BRACKET
32 5304447258 A B DRAIN TUBE
33 5304447259 A B TRAY-DRIP, WATER COLLECTOR
34 5304447260 A B WATER TANK ASSEMBLY
35 5304447261 A B Water Tank
36 5304447262 A B TANK HANDLE
37 5304447263 A B FLOAT, WATER DEPTH SWITCH PIN
38 5304447264 A B WATER TANK COVER
39 5304447265 A B WATER TANK BASE
40 5304447266 A B Caster
41 5304447267 A B SUPPORTING BAR 1
42 5304447268 A B Base
43 5304447269 A B SUPPORTING BAR II
44 5304447270 A B POWER CORD CLAMP
45 5304447271 A B Panel-side
46 5304447272 A B Compressor Assembly
50 5304447273 A B REAR PANEL ASSEMBLY
51 5304447274 A B REAR PANEL
52 5304447275 A B WATER DRAIN BRACKET
53 5304447276 A B DRAIN PLUG
54 5304447277 A B HOLDER, POWER CORD BOBBIN
* 5304448416 A B Power Cord

Publication No: 5995436713 FDL25P
05/05 4
WIRING DIAGRAM
