Fortress Technologies S Series User manual

Instructions for Use
S-Series
S425 - S700
MOBILITY SCOOTER
Manuel d’utilisation

2Fortress S-Series

3
Fortress S-Series
Table of Contents
English Owner’s Manual starting on page 4.
Foreword 5
Label Explanation / Word definitions 5
Use 6
Area of application 6
Features 7
Contents 8
1.0 Your Scooter 8
2.0 How to Use This Manual 9
3.0 Label Explanation/Definitions 9
4.0 Safety Information 10
5.0 Assembly & Options 16
6.0 Using The Scooter 22
7.0 Scooter Control System 26
8.0 Troubleshooting - Display 30
9.0 Batteries and Charging 32
10.0 Adjustments 35
11.0 Cleaning 36
12.0 Shipping and Storage 36
13.0 Disposal 38
14.0 Torque Settings 38
15.0 Specification Sheets 38
16.0 Guarantee 41
17.0 Service Advice/History 41
18.0 Service and Maintenance 42
19.0 Nameplate 45
Manuel d’utilisation en français débute à la page 46.
Avant-propos 46
Explication des étiquettes / Définitions des termes 47
Utilisation 48
Champ d’application 48
Caractéristiques 49
Sommaire 50
1.0 Votre scooter 50
2.0 Comment utiliser ce manuel 51
3.0 Explication des étiquettes / Définitions 51
4.0 Sécurité 52
5.0 Assemblage & Options 58
6.0 Après l’utilisation de votre scooter 64
7.0 Système de commande du scooter 68
8.0 Dépannage - Affichage 72
9.0 Batteries et recharge 74
10.0 Réglages 77
11.0 Nettoyage 78
12.0 Livraison et stockage 78
13.0 Enlèvement 80
14.0 Serrage dynamométrique 80
15.0 Feuilles produit (EN 12184 et ISO 7176-15) 80
16.0 Garantie 83
17.0 Révisions / Historique 83
18.0 Révision et entretien 84
19.0 Plaque signalétique 87

4Fortress S-Series
If you are visually impaired, this document can be viewed in PDF format at:
www.SunriseMedical.ca
For further information on the full specification and options and accessories,
please refer to the order form.
All information is subject to change without notification.
Please consult Sunrise Medical with any questions you may have.
DANGER!
IF YOU REQUIRE LARGE TEXT, SUNRISE MEDICAL
STRONGLY RECOMMENDS THAT YOU SEEK A CLINICAL
EYESIGHT ASSESSMENT BEFORE USING THIS PRODUCT.
www.SunriseMedical.ca
For the purposes of official communication, this product can be positively identified by referring to the serial number
label located on the seat post of the scooter, and also on a duplicate serial number label attached to this owner’s
manual.

5
Fortress S-Series
Foreword
Dear Customer,
We are very happy that you have decided in favour of a
high-quality SUNRISE MEDICAL product.
This Owner’s Manual will provide numerous tips and
ideas so that your new scooter can become a trustworthy
and reliable partner in your life.
We want you to be satisfied with our products and
service. Sunrise Medical has been consistently working
at continuously developing its product so, for this
reason, changes can occur in our portfolio of products
with regard to form, technology and equipment.
Consequently, no claims can be construed from the data
or pictures contained in this Owner’s Manual.
The management system of SUNRISE MEDICAL is certi-
fied to ISO 9001, ISO 13485 and ISO 14001.
As the manufacturer, SUNRISE MEDICAL,
declares that the scooters conform to the
93/42/EEC, amended by 2008/47/EC
guideline.
Please contact your local, authorized SUNRISE
MEDICAL dealer if you have any questions regarding the
use, maintenance or safety of your scooter.
In case there is no authorized dealer in your area, or you
have any questions, contact Sunrise Medical either in
writing or by telephone (contact addresses can also be
found on the back page).
Distributed by:
Sunrise Medical Canada Inc.
237 Romina Drive, Unit 3
Concord, ON
L4K 4V3
Phone: [phone]
Fax: [phone]
www.SunriseMedical.ca
Label Explanation / Word definitions
Word Definition
DANGER!
Advice to the user of Potential Risk of
serious injury or death if the advice is
not followed
WARNING! Advice to the user of a potential risk
of injury if the advice is not followed
CAUTION!
Advice to user that potential damage
to equipment may occur if the advice
is not followed
NOTE: General advice or best practice
Reference to a related document
This vehicle is NOT crash tested.
This label is also located on the rear
frame of the scooter next to the Anti-
tip wheels.
Secure with straps for transport.
Do not travel on-board scooter
Quick Start Guide
Affix Serial Number Label Here
Quick Start Guide
See Sections:
5.0 Seat Removal
5.3 Batteries

6Fortress S-Series
Use
Intended Use of Scooters:
They are intended for use in public places and similar
locations where there are pavements, pedestrian paths
or floors that have hard and firm surfaces. The safe limit
for slopes and obstacles shall be observed.
They may NOT be used as vehicles on the roads. They
are intended for a user who has difficulty in walking or
limited mobility and is for their own personal use.
The maximum user weight limit, includes both the user
and any weight of accessories fitted to the scooter. It is
marked on the serial number label, which is affixed to the
seat post.
Warranty coverage can only be applied if the product
is used under the specified conditions and for the
intended purposes. No unauthorized modifications
should be made to the scooter. Only approved parts and
accessories shall be fitted.
The intended lifetime of the scooter is 5 years. Please
DO NOT use or fit any 3rd party components to the
scooter unless they are officially approved by
Sunrise Medical.
Area of application
The electrical power, simple steering and automatic
braking make the scooter suitable for people who have
limited mobility due to, for example:
• Joint pain and/or stiffness due for example to arthritis
or rheumatism
• Difficulty breathing due to respiratory or heart
conditions.
• Difficulty walking due to stroke
• Certain cases of obesity
The following should be taken into consideration in
relation to the provision of the scooter and any specific
options available:
• The user’s body size and weight including the
distribution of body weight.
• The mass of any carry on or stowed items should be
added to the user’s body mass and together should
not exceed the maximum load of the scooter.
• The user’s physical and psychological constitution.
• The age of the user, their living conditions and the
environment in which the scooter is going to be used,
e.g. home surroundings and the intended area of
use.
If in doubt, please consult a health care professional
to ensure the user is not exposed to unacceptable
risks. A risk assessment may be required in certain
circumstances.
Sunrise Medical is ISO 9001 certified, which ensures
quality at all stages of the development and production of
this scooter.
Important:
Do not use your scooter until this manual has
been read and understood.

1
11
10
9
8
7
6
5
4
3
2
7
7
Fortress S-Series
Features
Features of Fortress S-Series Scooters:
Due to their modular design, simplicity and wide range
of adjustments, the Fortress S-Series Scooters are
a perfect choice for easy service, refurbishment and
recycle requirements.
As a part of our ongoing product improvement
initiative, Sunrise Medical reserves the right to change
specifications and design without notice. Further, not
all features and options offered are compatible with all
configurations of the scooter.
All dimensions are approximate and may be subject to
change.
1. Control Panel
2. Wig-Wag Throttle
3. Adjustable Seating
4. Flip-up Armrests
5. Free-wheel Lever
6. Battery Cover
7. Alloy Wheels
8. Foot-board
9. Front Bumper
10. Basket
11. LED Lights
1
11
10
9
8
7
6
5
4
3
2
7
If your scooter is an S425, If your scooter is an S700,
use the diagram below.use the diagram below.

8Fortress S-Series
Contents 1.0 Your Scooter
1.1 PRODUCT INFORMATION:
We at Sunrise Medical want you to get the best out of
your Fortress S-Series scooter. This Owner’s Manual
will familiarize you with the scooter and its features. It
contains hints on everyday usage and general care in
addition to information on the high quality standards
which we adhere to and details about the guarantee.
Your scooter should be delivered ready for your use;
there are a wide range of accessories available for the
scooter. For further information about these you should
contact your Sunrise Medical authorized dealer.
Your scooter will reach you in excellent condition having
been personally inspected before leaving our factory.
Following the guidelines for maintenance and cleaning
your scooter will maintain its first class condition and give
you complete satisfaction.
This scooter is designed for comfort, safety and durability
and has been exhaustively researched and tested by our
experts. The Fortress S-Series S425 is classified as a
category B vehicle and the S700 as a category C under
the European scooter standard EN 12184.
It is intended for the use of people of all ages who may
have difficulty walking distances or for periods of time.
It is ideal for indoor, (S425), shopping malls and outdoor
use, (S700) and suitable for users up to 160 kg for S700
model and 150 kg for S425 model. Variation in load
weight can affect performance. The scooter is designed
to be driven on paved ground but should not be driven
through mud, water, snow or loose unstable ground. If
you are in any doubt as to the suitability of the power
scooter, contact your local Sunrise Medical approved
supplier for clarification, prior to commencing use.
NOTE: Using your scooter on walk-ways and paved
areas may be subject to the applicable legal requirements
of local traffic laws.
It is very important to read the relevant section of
the owner’s manual when making any minor
adjustments. Consult the Technical Manual or
your local Sunrise Medical authorized dealer for
more complex adjustments.
NOTE: Sunrise Medical recommends, as a safeguard,
that you review the various insurance policies available
for scooter users.
DEALER ADDRESS/STAMP
NOTE: Please keep a note of your local service agent’s
address and telephone number in the space below.
In the event of a breakdown, contact them and try to give
all relevant details so they can help you quickly.
NOTE: If you have any questions about the use,
maintenance or safety of your scooter, please contact
your local approved Sunrise Medical service agent. If
you do not know of an approved dealer in your area or
have any other questions please write or telephone:
Distributed by:
Sunrise Medical Canada Inc.
237 Romina Drive, Unit 3
Concord, ON
L4K 4V3
Phone: [phone]
Fax: [phone]
www.SunriseMedical.ca
Foreword 3
Label Explanation / Word definitions 3
Use 4
Area of application 4
Features 5
Contents 6
1.0 Your Scooter 6
2.0 How to Use This Manual 7
3.0 Label Explanation/Definitions 7
4.0 Safety Information 8
5.0 Assembly & Options 14
6.0 Using The Scooter 20
7.0 Scooter Control System 24
8.0 Troubleshooting - Display 28
9.0 Batteries and Charging 30
10.0 Adjustments 33
11.0 Cleaning 34
12.0 Shipping and Storage 34
13.0 Disposal 36
14.0 Torque Settings 36
15.0 Specification Sheets 36
16.0 Guarantee 40
17.0 Service Advice/History 40
18.0 Service and Maintenance 41
19.0 Nameplate 44

9
Fortress S-Series
2.0 How to Use This Manual
2.1 INTRODUCTION:
The scooters shown and described in this manual may
not be exactly the same in every detail as your own
model. However, all instructions are still entirely relevant,
irrespective of detail differences.
NOTE: The manufacturer reserves the right to alter
without notice any weights, measurements or other
technical data shown in this manual. All figures,
measurements and capacities shown in this manual are
approximate and do not constitute specifications.
•Informationregardingthecontinuedsafeuseofyour
product, such as product safety notices or recalls (also
known as FSN/FSCA Field Safety Notice/Field Safety
Corrective Action) may be issued by Sunrise Medical
as required. These can be accessed on the Sunrise
Medical web site (Safety Notifications). The information
will also be provided to the organization which supplied
your product in order that any required actions can
be implemented. It is important that you keep this
organization updated with any changes in your contact
details or if you no longer use this product. Please pass
this manual on to any subsequent users of the product.
2.2 GUARANTEE:
Please fill in the warranty card and return it to us to
register your product.
2.3 WARRANTY-REPAIR-SERVICE CONDITIONS:
1) The repair or replacement will be carried out by an
authorized Sunrise Medical dealer/service agent.
2) Should your scooter require attention under these
arrangements, notify the designated Sunrise Medical
service agent immediately giving full information about
the nature of the difficulty. Should you be operating
the scooter away from the locality of the designated
Sunrise Medical service agent, work under the
“Warranty Conditions” will be carried out by any other
service agent designated by the manufacturer.
3) Should any part of the scooter require repair or
replacement, as a result of a specific manufacturing
or material defect, within twenty four months, from
the date on which the possession of the scooter was
transferred to the original purchaser, and subject to
it remaining within that ownership, the company will
supply free of charge replacement, (or repaired),
parts, to the authorized dealer/service agent. If you
are unsure who your local servicing agent is, please
contact Sunrise Medical using the contact details on
the previous page.
4) Any repaired or replaced part will benefit from these
arrangements for the balance of the warranty period
applicable to the scooter.
5) Parts replaced after the original warranty has expired
are covered for a further six months.
6) Items of a consumable nature will not generally be
covered during the normal warranty period, unless
such items have clearly suffered undue wear as a
direct result of an original manufacturing defect. These
items include amongst others; upholstery, tires, inner
tubes, batteries, motor brushes etc.
7) The above warranty conditions apply to all scooter
parts for models purchased at full retail price.
8) Under normal circumstances, no responsibility will
be accepted where the scooter has required repair or
replacement as a direct result of,
• The scooter or part not having been maintained
or serviced in accordance with the manufacturer’s
recommendations, as stated in the Owner’s Manual
and/or Service Manual.
• Failing to use only the specified original equipment
parts.
• The scooter or part having been damaged by
neglect, accident or improper use.
• The scooter or part having been altered from the
manufacturer’s specifications, or repairs having been
attempted prior to the service agent being notified.
9) Warranty can only be provided if the product is used
under the specified conditions and for the intended
purpose.
10) Warranty does not include the cost of labour to repair,
remove or install parts.
The expected lifetime is 5 Years.
3.0 Label Explanation/Definitions
LABEL MEANING
This label shows the
model number, serial
number, max weight and
manufacturer details.
This label shows the
position of the free-wheel
lever.
FREE-WHEEL
DRIVE
This label shows the
location of the power ON
and OFF for the scooter
and ‘read the user manual’
warning.

10 Fortress S-Series
4.0 Safety Information
If you follow the instructions given in this manual, you will
enjoy many trouble-free years of use.
4.1 GENERAL WARNINGS:
WARNING!
• The S700 is primarily intended for outdoor use, it is
therefore larger than the S425. Due to the increased
dimensions, when using the S700 within the confines
of a building, please ensure that the building has
suitable emergency escape routes capable of
allowing free access for you and your scooter.
• This scooter should NOT be used on public streets or
roadways.
• Load data always refers to one single person as
operator.
• The scooter is authorized for use by one person.
• Do not operate your scooter whilst under detrimental
influence of alcohol, drugs or bouts of severe/acute
illness .
• Please observe all relevant rules and regulations
pertaining to pedestrians and road users, at all times.
• Always ensure that your scooter is switched off
before attempting to mount or dismount.
• Always ensure that you are able to operate all
controls from a comfortable position. Paying attention
to your posture is essential to ensure your continued
comfort and well being.
• Always make sure that you can be seen clearly,
especially if you intend using your scooter in poor
light.
• Switch on the scooter lights to make yourself visible
when there are low levels of light, day or night.
• The scooter has been built to match the needs of
the majority of users. If a personal risk assessment
highlights specific needs, the scooter may need to be
adjusted and/or reprogrammed.
• Do not let children or others use your scooter.
• Do not lift the scooter by any detachable parts such
as seat, arm rests, etc.
• Do not attempt inclines when any of the following
accessories are fitted, rear storage bag, rear
mounted wheelchair/walker holder or oxygen bottle
holder, as they may cause the scooter to become
unstable.
• Do not attempt to ascend or descend escalators or
stairways.
CAUTION!
4.2 FEATURES AND OPTIONS:
Some of the options shown in this manual may not be
available in your country and some features may be
restricted (e.g. max. speed, user weight limit, range, etc.).
Any limitations are marked on the order form, in
the technical manual and in this owner’s manual.
For further information please consult your Sunrise
Medical authorized dealer.
DANGER!
4.3 PRELIMINARY CHECKS:
• Always check that Drive is selected before setting the
scooter in motion.
• The scooter emits an audible warning when Free-
wheel is selected and will not allow the scooter to
drive.
• You should not try to maneuver at full speed.
• If you have to make a sudden turn, slow down first
by releasing the control lever or the speed control
feature. This is very important if you are going down
a hill.
• Failure to slow down during a maneuver may result in
your overturning the scooter.
• Always check that the scooter is switched off before
trying to get on or off.
• Always check that you can be seen clearly, especially
if you are using the scooter in conditions of low
visibility.
4.4 EMERGENCY BRAKING:
WARNING!
Turning the ON-OFF key to the OFF position during
driving will cut the power and immediately apply the
brake. This method of stopping is not recommended
except for emergencies, since the stop will be extremely
sudden.
CAUTION!
Routine use of emergency braking will cause damage to
your scooter.

11
Fortress S-Series
4.5 TIRES:
The tires of a scooter suffer wear depending on how
much the scooter is used. Check them regularly,
especially for inflation pressure, according to the service
instructions in this manual.
Each tire pressure should be:
S425 = 2.7 bar (40 P.S.I.)
S700 = 2.7 bar (40 P.S.I.).
See Section 5.26 for solid tire information.
DANGER!
Never inflate the tires with a service station air pump. It
is recommended that you use a manual pump or a pump
fitted with a pressure regulator (manometer).
4.6 CURBS, (FIG.4.1):
DANGER!
• Be aware of other vehicles and pedestrians when
curb climbing.
• Do not attempt to mount curbs in excess of 50 mm
(2”), for S425 or 100 mm (4”) for S700.
• Always mount and dismount curbs with caution and
directly facing the curb.
• Do not attempt to mount or dismount curbs in
reverse.
• Do not attempt to descend from, a curb of more than
50 mm height.
• Do not attempt to ascend high curbs, steep slopes or
cambers due to the risk of falling out of the scooter or
tipping over.
• Do not attempt to ascend any curb in the vicinity of a
drain cover, uneven surfaces, or gravel covering.
• Do not attempt to climb or descend any curb at an
oblique angle. Approach only at an angle of 90° with
at least 500 mm (20”) run-up.
• Do not attempt curb climbing/descents when any of
the following accessories are fitted, rear storage bag,
rear mounted wheelchair/walker holder or oxygen
bottle holder, as they may cause the scooter to
become unstable.
FIG.4.1
4.7 TRANSPORTATION IN VEHICLES:
This scooter is not suitable to use as a seat in a vehicle.
Not crash tested
DANGER!
A scooter secured in a vehicle will not provide the
equivalent level of safety and security of a vehicle seating
system. It is always recommended that the user transfers
to the vehicle seating.
NOTE: For transportation by road, rail, sea or air please
refer to Section 12, Shipping and Storage.
4.8 FREE-WHEEL DEVICE, (FIG.4.2):
The scooter has two modes of movement:
Drive or Free-wheel.
• DRIVE = All movement, including braking, is
exclusively controlled by operation of the electronic
control system.
• FREE-WHEEL = Movement is by manual means,
e.g. pushed or by gravity, (pot holes, curbs, hills or
inclines, etc).
Push the red knob down and forward to put the scooter
into free-wheel, (FIG.4.2).
DANGER!
• Only use the free-wheel function to push the scooter
manually from one spot to another.
• Keep in mind that while the free-wheel system is
in operation, the scooter is without an automatic
braking system.
• Selecting free-wheel causes a loud audible warning
beeping tone from the scooter horn.
• For safety reasons the scooter can no longer be
moved using the control levers.
• Do not operate the free-wheel device while seated in
the scooter
• The free-wheel device should only be operated by a
person who has the strength and agility to be able to
fully maneuver the scooter safely, during free-wheel.
• Always put the scooter back in drive.
• Always check that drive is engaged before using the
scooter.
• Do not disengage the free-wheel on or near a slope.
• Do not allow yourself to be pushed by others, or
towed, while the scooter is in free-wheel.
• Do not allow clothing or items such as bags etc,
to come into contact with the free-wheel device,
particularly any items hanging or being carried on the
back of the scooter seat
FIG.4.2
Free-wheel
Lever

12 Fortress S-Series
WARNING!
4.9 EMC - RADIO TRANSMITTING DEVICES:
When operating two-way radio, walkie-talkies, C.B,
amateur radio, public mobile radio and other powerful
transmitting devices the scooter should be brought to
a halt and turned off. The operation of cordless, mobile
telephones and cell phones including hands-free devices
is permitted but if abnormal driving performance of the
scooter is encountered then the scooter must be brought
immediately to a halt and turned off.
NOTE: The electrical systems of the scooter may disturb
the performance of alarm systems in retail shops.
DANGER!
4.10 SHARP TURNS:
Full speed turns should not be attempted. If you need to
turn sharply you must reduce your speed with the control
panel speed setting. This is particularly important when
travelling across or down a slope. Disregarding this
advice could lead to your scooter tipping over.
DANGER!
4.11 WEIGHT LIMIT:
• The user, plus options and accessories, plus items
carried should never exceed the total weight as listed
in Section 1.1 .
• Never sit in the scooter while weight training.
Exceeding the weight limit is likely to damage the
seat, frame or fasteners and may cause severe
injury to you or others from scooter failure.
• Exceeding the weight limit will void the warranty.
• Do not hang shopping bags from the handlebars as
they could swing and cause loss of steering control.
4.12 HOT/COLD SURFACES:
WARNING!
After prolonged use, the drive unit motors will produce
heat, which is radiated through the motors’ outer casing.
• Do not remove the rear drive unit battery cover for at
least 30 minutes after using the scooter.
• Do not touch the motors’ outer casing for at least 30
minutes after using the scooter, to allow it to cool.
• Not only motors can become hot during the
operation of the scooter, but the seat upholstery
material and armrests may also heat up when
standing in the sun.
• Be aware that in extremely cold weather, exposed
metal parts can present a freeze burn hazard,
particularly if the hands are wet.
4.13 ROAD CAUTION:
Please show the utmost consideration for pedestrians
and other road users.
DANGER!
• Remember that the last thing a car or truck driver
expects to see is a scooter driving off the curb into
the road.
• If in any doubt, do not risk crossing the road until you
are certain that it is safe.
• When crossing roads, do so as quickly as possible;
there may be other traffic.
• Be seen! Always wear something bright such as light
coloured clothing, a reflective or day glow vest.
• To improve driver visibility, it is recommended to use
a safety flag.
• At night, in dull conditions or in poor visibility, always
use the lights, particularly when crossing the road.
• Obey all of the rules for pedestrians and traffic.
• Remember, when crossing the road you are a
pedestrian.
• Use the footpath with the speed control set at the
appropriate speed, (less than 4 mph/6 kph).
• Do not hang bags off the handle bars or tiller
adjustment lever.
4.14 ADVERSE CONDITIONS:
DANGER!
• Be aware that when driving your scooter in adverse
conditions, e.g. on wet grass, mud, ice, snow or other
slippery surfaces, you may experience a reduction in
the grip and traction of your scooter. We recommend
you take extra precautions in these conditions,
particularly on hills and slopes. Your scooter could
become unstable or skid causing possible injury.
DANGER!
When you are using a powered scooter or wheelchair,
take extra care with loose or long items of clothing.
Moving parts, such as wheels, can be potentially
dangerous or even fatal if clothing becomes entangled.
NOTE: Extreme variances in temperature may trigger
the self protect mechanism in the control system. If this
occurs the control system will temporarily shut down to
prevent damage to the electronics or the scooter.

13
Fortress S-Series
4.15 RAMPS:
DANGER!
• When using a ramp for access, please ensure that
it is capable of taking the combined weight of the
scooter and yourself.
• When a ramp is being used, please ensure that the
ramp is stable and properly secured.
• Always approach the ramp head-on and exercise
caution.
• Please ensure the ramp is suitable for the purpose
you are using it for.
• Maximum ramp angle: S700 = 10° (18%), S425 = 8°
(14%)
• Follow all the user instructions supplied with the
ramp.
• Be aware that accessories attached to the scooter,
may affect the overall stability.
• Do not attempt to use ramps when any of the
following accessories are fitted, rear storage bag,
rear mounted wheelchair/walker holder or oxygen
bottle holder, as they may cause the scooter to
become unstable.
4.16 TRANSFER TO AND FROM THE SCOOTER
Mounting your scooter
1. Ensure that the key is turned to the off position.
2. Stand at the side of the scooter and lift the nearest
arm rest, (FIG.4.3).
3. Push the seat rotate lever forwards and rotate the seat
until it faces you, (FIG.4.4 - 4.5)).
4. Make sure that the seat is locked securely into
position.
5. Position yourself comfortably in the seat (FIG.4.6).
6. Push the seat rotate lever forwards and rotate the seat
until facing forward (FIG.4.7).
7. Make sure that the seat is locked securely into position
and the arm rest is down, (FIG.4.8).
8. Ensure that your feet are placed firmly on the foot
board of the scooter and that you can reach all the
controls comfortably, (FIG.4.8).
Dismounting your scooter
1. Bring your scooter to a complete stop.
2. Make sure that the key is turned to the off position.
3. Push the seat rotate lever forwards and rotate the seat
until you are facing the side of the scooter, (FIG.4.6).
4. Make sure that the seat is locked securely into
position and that both feet are on the ground.
5. Carefully get out of the seat and stand by the side of
your scooter, (FIG.4.3).
6. You may leave the seat in this position or return it to
facing forward.
FIG.4.3
FIG.4.4
FIG.4.5
FIG.4.6
FIG.4.7
FIG.4.8

14 Fortress S-Series
4.17 ANTI-TIPS:
WARNING!
• Ensure the anti-tips are fitted before using the
scooter.
• Ensure that anti-tips are not damaged or worn before
using your scooter.
• Attendants must be aware of the location of the
anti-tips to prevent feet being trapped underneath
causing injury.
• Do not allow adults or children to stand on the
anti-tips, or any other part of the scooter as this could
cause the scooter to become unstable.
4.18 USE ON A SLOPE:
Your scooter has been designed and tested to allow its
use on slopes or gradients of up to: S700 = 10° (18%)
S425 = 8° (14%).
To improve stability lean forward when driving uphill.
Set the seat to its lowest height in the furthest forward
position and set the back upright.
When travelling downhill sit in an upright position or
recline the back rest slightly to compensate.
WARNING!
• Do not exceed the maximum slope of: S700 = 10° /
S425 = 8°.
• Stop and return the back rest to an upright position
before attempting to climb a slope. Failure to do this
may cause the scooter to become unstable.
• If you are in any doubt about the capabilities of your
scooter on a slope then do not attempt to drive up or
down the slope/curb; try to find an alternative route.
• Wherever possible always travel up or down the
slope directly facing the slope, (FIG.4.9).
• Never attempt a non-stop “U” turn when going up or
down steep slopes, (FIG.4.9).
• Be aware that accessories attached to the scooter,
may affect the overall stability.
FIG.4.9
4.19 GRADIENTS: ASCENTS:
When going uphill, keep the scooter moving if it is safe
and clear to do so.
Maneuver by using gentle tiller and throttle movements.
The seat should be set to its lowest height in its furthest
forward position and the back should be upright.
WARNING!
• If you have stopped on a hill, you should start off
again slowly.
• Avoid sudden acceleration or hard braking.
• Avoid hard turns.
• Be aware that stopping distances may increase when
traveling down hill.
4.20 GRADIENTS: DESCENTS:
WARNING!
• On descents, it is important not to let the scooter
accelerate beyond its normal level of ground speed.
• It is safer to proceed slowly down steep descents
(below the speed of 3 mph/5 kph) and stop, if any
anxiety arises regarding the descent.
• If the scooter picks up speed, release the control
lever to stop all forward movement, then restart
slowly and do not allow the speed to increase beyond
a comfortable level.
4.21 LAP BELT (IF INCLUDED):
Before using your scooter ensure the lap belt is worn and
correctly adjusted before use.
The lap belt is fitted to the scooter as shown in the fitting
photographs, (FIG.4.10 - 4.15). It is important that the belt
is fitted correctly and is not twisted.
To lock the belt:
Pull the buckle over your lap and push firmly into the slot
in the receiver, (1).
Ensure that there is no excess belt material, and the belt
is tensioned correctly. (FIG.4.10)
To release the belt:
Push the red button marked ‘PRESS’ to release the belt,
(2), (FIG.4.10).
DANGER!
• The lap belt is fixed so that the straps sit at an angle
of approximately 45°, and when correctly adjusted
should not allow the upper body to slip down in the
seat, (FIG.4.11)
• The lap belt is not suitable for use when the scooter
and occupant are transported in a vehicle.
FIG.4.10
1 2

15
Fortress S-Series
• The lap belt must be checked on a daily basis to
ensure it is adjusted correctly and it is free from any
obstruction or adverse wear.
• Failure to make sure that the lap belt is secure and
adjusted prior to use could cause serious injury to
the user. e.g. too loose a strap may allow the user to
slip down in the seat and risk suffocation.
Maintenance:
• Check lap belt, and securing components, at regular
intervals for any sign of fraying or damage.
• Replace if necessary.
• Clean the lap belt with warm soapy water and allow
to dry.
• The lap belt should easily allow a hand width of
space between the body and the belt, (FIG.4.12).
• Sunrise Medical also recommend that the fit of the
belt is checked on a daily basis to reduce the risk of
the end user inadvertently re-adjusting the belt to an
excessive length.
• If in doubt about the use and operation of the seat
belt then ask your healthcare professional, dealer, or
carer for assistance.
For your comfort, the lap belt must be correctly fitted to
the scooter. If you are unsure about the fitting or opera-
tion of this option, please contact your approved Sunrise
Medical dealer.
FIG.4.12
FIG.4.13
FIG.4.14
FIG.4.15FIG.4.11
45°

16 Fortress S-Series
4.22 SAFETY CHECKS
WARNING!
• The scooter driver plus items should never exceed
the total weight listed in section 1.1.
• Before you use the scooter, check that it is not in
free-wheel and that all of the controls are functioning
correctly.
• If you discover any scooter malfunction, take it to be
repaired or reset. Your dealer can help you to find the
fault and correct it.
• Make sure batteries are charged. Do not use the
scooter when battery is low. The scooter may come
to a sudden, unexpected stop.
• Be aware that there is a point during every transfer
when the scooter seat is not below you.
• Use extra care when you drive your scooter in
reverse. If one of the wheels hits an obstacle, you
could lose control of the scooter or fall out.
• Never use your scooter on a slope unless you are
sure you can do so without losing traction.
• When travelling along, always ensure the backrest is
upright and the seat faces forwards.
• Lift the scooter only by non-detachable parts of the
main frame.
• Never short-circuit electrical connections as you
could cause an explosion.
• Do not use the scooter if any of the tires are
damaged or under/over-inflated.
• When using mobile phones you should switch the
scooter off.
• Do not smoke while on-board the scooter.
• If you take a break from driving, but remain seated in
the scooter for more than just a moment, switch the
scooter off at the ignition key.
5.0 Assembly & Options
5.1 SEAT ADJUSTMENTS
WARNING!
Observe correct lifting techniques at all times when lifting
components over 10 kg/22 lbs.
Flip Up Armrests, (FIG.5.1). By pulling up on the front
end of either armrest, the armrest will flip back for easy
transfer on and off of your scooter.
Adjusting the Armrest Width, (FIG.5.1).
Loosen the two hand wheels, (A) and pull out the
armrests to the desired width. Tighten the hand-wheels
firmly, (A).
FIG.5.1
FIG.5.2
FIG.5.4
FIG.5.3
A

17
Fortress S-Series
FIG.5.5
FIG.5.6
FIG.5.7
5.2. ANTI-TIP WHEELS:
These are factory fitted and should not be removed.
The anti-tip assembly is bolted to the rear frame of the
scooter, (FIG.5.8).
WARNING!
Never use the scooter without the anti-tip wheels fitted.
FIG.5.8
Removing the Armrests, (FIG.5.1).
Loosen the two hand wheels, (A) and pull the armrests
completely out of the receiver assembly. Store in a safe
place
Seat Rotate Lever (FIG.5.2): This is found under the
right side of the seat. Push it forwards to allow the seat to
rotate 360 degree and release to lock in any 45 degree
position desired.
Seat Height Adjustment: (FIG.5.3) The seat post is
height adjustable, providing 3 height positions. Carefully
unscrew the bolt and nut, and insert into desirable
position and tighten nut to a torque value of 25 Nm.
Sliding Mechanism (FIG.5.4): This allows forward and
backward movement of the seat. Pull up lever found on
the right of the seat and use legs and body to move to
the required position and release lever.
Seat Removal (FIG.5.5 - 5.8)
1. Push the seat rotate lever forwards and turn seat 45°.
2. Stand behind the seat, flip up the arm rests and
fold the backrest forward by lifting up the backrest
adjustment lever.
4. Place hands on either side of seat base, push the seat
rotate lever forwards and lift the seat vertically keeping
back posture upright. Bend the knees if required.
WARNING!
The seat is heavy, (35 kg/77 lbs.). Please seek
assistance.

18 Fortress S-Series
5.3 BATTERIES:
Read section 9.0 of this manual for additional
battery and charging information.
DANGER!
• Do not smoke near, or expose the batteries to direct
heat (i.e. naked flame, gas fire).
• Do not attempt to change the fuses yourself.
• Do not attempt to by-pass the fuse as this would be
very dangerous and could cause a fire.
• If you suspect a fault, contact your Sunrise Medical
authorized dealer as soon as possible.
• Do not short circuit the battery terminals. Remember
tools, jewelry, etc. can conduct and if dropped across
the battery terminals may cause severe burns and/or
explosion!
• Ensure the battery terminal covers are fitted.
• Batteries are heavy. Use correct lifting techniques
when removing them from the scooter.
• Always use the handles provided to lift the batteries.
• Always refit the retaining bar after refitting or
replacing the batteries.
Battery Removal:
1. Remove the seat (FIG.5.5 - 5.8 previous page)
2. Remove the battery cover by unscrewing the
three hand wheels and lifting it off. Note: Please
disconnect the plugs for rear lights, (FIG.5.9 - 5.10)
3. Pull the two halves of the plastic battery connector
plugs apart, (FIG.5.11).
4. If replacing the batteries or battery looms, pull back
the terminal cover and disconnect battery terminals,
using an 11 mm wrench (FIG.5.12).
5. Remove or release the battery retaining straps.
6. Bend knees with battery positioned centrally in front
of you, rest your forearms on your knees for support
(FIG.5.13).
7. Grab battery handle with both hands (FIG.5.13).
8. Lift vertically by straightening legs, keeping back
posture upright (FIG.5.14).
9. Move the battery to a safe place, keeping back
posture upright and bending knees when setting it
down.
FIG.5.12
FIG.5.11
Battery Type Total Weight*
55 Ah @ 20 hrs. S425 36 kg (80 lbs.)
75 Ah @ 20 hrs. S700 48 kg (105 lbs.)
*Exact weight is dependent on the specific battery type used.
Battery Weights:
FIG.5.9
FIG.5.10

19
Fortress S-Series
FIG.5.13
FIG.5.14
5.4 CRUTCH/WALKING STICK HOLDER:
FIG.5.15
WARNING!
• Ensure that the crutch holder is securely fastened to
the seat back rest.
• Ensure that the crutch is not interfering with the
mechanisms of the scooter.
• Ensure that the crutch does not protrude from the
sides of the scooter.
• Do not attempt to remove the crutch while the
scooter is in motion.
• Always come to a complete stop and turn off the
power to the controls before attempting to remove
the crutch. This will avoid accidentally operating the
scooter.
5.5 LIGHTS AND INDICATORS:
Front FIG.5.16
Rear FIG.5.17
Ensure that the lights and indicators are functioning
correctly and lenses are clean before going outdoors at
night or in poor visibility.
NOTE: The light clusters fitted to the scooter comprise
of LED lights. They are very efficient and reliable,
which means that there is no “bulb” to change. Should
a light cluster become damaged, please contact your
local Sunrise Medical approved servicing agent for any
warranty, service or repair work required.
FIG.5.16
FIG.5.17
FIG.5.15

20 Fortress S-Series
5.6 SEAT COVER:
This option offers additional protection to the seat,
(FIG.5.18).
WARNING!
Ensure the seat cover is correctly fitted and is not
obstructing the controls of the scooter or in contact with
the scooter moving parts.
5.7 HEAD REST:
The head rest is supplied as standard fitted to the seat.
To adjust the height, squeeze the clip on the left hand
stem guide and move the head rest until it clicks into
the nearest notch to the desired position. To remove the
head rest do the same, but lift the head rest completely
out, (FIG.5.19).
5.8 REAR STORAGE BAG:
The bag is used for storing items, and is strapped to
the back of the seat. Please follow fitting instructions
provided with the bag, (FIG.5.20).
WARNING!
• Maximum Carrying Load = 10 kg/22 lbs.
• The weight of the driver plus any luggage, should not
exceed the maximum user weight of the scooter.
• Do not attempt inclines with this accessory fitted, as
it may cause the scooter to become unstable.
5.9 REAR MOUNT WHEELCHAIR/WALKER HOLDER:
The rear mount is used for carrying a wheelchair or
walker items, and is mounted to the rear accessory
mount on the back of the seat. Please follow fitting
instructions provided with rear mount, (FIG.5.21).
WARNING!
• Maximum Carrying Load = 15 kg/33 lbs.
• The weight of the driver plus any luggage, should not
exceed the maximum user weight of the scooter.
• Be aware that attached accessories increase the
effective footprint of the scooter.
• Take extra care when maneuvering if you have a
rollator, walker, or wheelchair on board.
• Ensure that the load is secured properly before
moving off.
• Be aware that the load you are carrying may obscure
the rear lights on the scooter. If this is the case,
please use the foot path while carrying the load,
particularly at night.
• Do not attempt inclines with this accessory fitted, as
it may cause the scooter to become unstable.
FIG.5.19
FIG.5.18
FIG.5.20
FIG.5.21
