FORWODE DB-HBS42 User manual

Model:DB-HBS22 INSTRUCTIONS
PAGE 1
INSTRUCTION
1
Model:DB-HBS42
2-BIKE HITCH-TIGHTENING
SYSTEM & FLEXIBLE WHEEL
Model:DB-HBS42 INSTRUCTIONS
TOOLS
REQUIRED
• Adjustable Wrenches
Or 11/16" & 3/4"
Wrenches
• Phillips Screwdriver

PRODUCT PARTS CATALOG
A
B
C
H
D2
D1
C
V
D1
D2
G2
G1
R
Q
P
K
J
I
T
M
O
N
S
U
A B C
D1 D2 G1 G2
H I J K M
N O P Q R
S T U
ABottom tube
Vertical tube
Cross tube assembly
Tire carrier assembly 1
Tire carrier assembly 2
Fixed hook 1 assembly
Fixed hook 2 assembly
Half tooth carriage bolt M12
Self-locking nut M12
ITEM NO. DESCRIPTION
B
C
D1
D2
G1
G2
H
I
1
1
2
2
2
1
1
1
1
QTY.
Round with positioning spacer
J
K
1
2
U-connector
Fixing plate
Trailer lock
M
N
O
P
Q
R
S
T
2
2
2
1
1
4
1
4
U 4
V 3
Trailer lock KeyW 2
Cross-rail fixed assembly Key
X4
V
X
W
2
W X

STEP 2:
Insert Cinto figure B, the 4 holes on the side are
connected with 4 sets of standard parts S-T-U
locking respectively（Install the two inner holes
first and then the outermost hole）.
STEP 3:
Insert D1 and D2 into figure C, respectively, and
lock the connection with their own hand screw
nuts.
3
S T U
Two pieces of Kare loaded into the inside of Ain advance. (The two cylinders of Kare inserted into
the two small holes).
Insert Binto the interior of Aand then connect in order with I-J-H fasteners.
STEP 1:
INSTALLATION STEPS
A
I,J,H
B
C
B
S,T,U
C
D1 D2
H I J K
K

4
STEP 4:
Insert the G1 and G2 components into the upper square
opening of the assembled bike frame B and position the
sliding position with the keys Xcarried on the G1,G2
components, adjust to suitable position, lock G1 G2 with
key X.
STEP 5:
STEP 6:
A
B
G1 G2 X
• After the handle is locked, Pand Qwill be locked
by M, N and Owith a wrench.
• Remove the O-M-N with the handle and take off the
P-Q and put it away.
DISASSEMBLY STEPS
Insert the Vat the place marked by the arrow
above, and tighten it with a screwdriver.
V
Insert Rinto the tariler bar.
Lock the trailer lock (R) with the key (W) and keep
the key
Pass P,Qthrough O,M,N and lock them with
wrench.
V
W
P
Q
N
M
O
P
Q
N
M
O

RACK FOLDING STEPS
Press the column slightly to the left, while pressing
the pop-up buckle as shown, and fold the column
to the right.
Pop-up buckle
Pop-up buckle
Fold to Right
Light Press
Up Wards
Light Press
STEP 1: STEP 2:
•Hold with your left hand
and pull it outward slightly.
•Squeeze tightly with the
right hand and tighten.
•Loosen .
•Pull out and rotate
•Insert and rotate the
handle clockwise until
tightened.
•Pull out with force
and rotate back to the
initial state to tighten again.
•Disassembly steps refer to
tightening steps.
TIGHTEN THE HANDLE
Handle head
b
Handle grip
c
Fine-tuning preload knob
a
Positioning pins
d
b
b
a
d
d
c
b c
Press the downed column slightly downward, while
pressing the pop-up buckle as shown in the
picture, and lift the column to the left.

T-pull handle
Pull out the T-handle and put it down.
Pull up the handle to fold up when not carrying bikes.
STEP 4:
then fold and collect the T-pull after releasing it.And
the sheet metal slot for positioning.
T-pull handle
Cube
STEP 3:
6
RACK TILT STEPS

7
GENERAL CONSIDERATIONS WARNING WHEN INSTALLING THE FRAME
1.Every month new designs and bodies are introduced
to the market.
2.While the FORWODE bike carrier design team strives
to make most products universal to the cars on the
market. It is impossible for a single bike carrier to fit all
models of cars on the market.
3.Before you purchase a rack, please check if the rack
fits your vehicle with an authorized FORWODE Bike
Rack dealer or distributor.
4.Before installation, please read the instructions and
then follow the attached instructions.
preset and in working condition. For any missing or
damaged parts, please contact your authorized FOR-
WODE Bike Rack dealer or distributor.
6.Please always keep this manual for future reference.
1. When the vehicle is equipped with an electric
rear fender, the power must be turned off when
installing the rear carrier. If this option is not
available, do not use the rear bike carrier.
2. Clean the receiver connector thoroughly
before installing.
3. When the vehicle is equipped with a spoiler or
similar item, it is necessary to change the
mounting method of the bike carrier. If this
happens, please contact an authorized FOR-
WODE bike carrier verifying dealer or distributor.
4. When using the bike carrier, please observe
local traffic laws.
before washing your bike.
WARNING WHEN MOUNTING THE BICYCLE WARRANTY AND LIABILITY
1. When you ride your bicycle, make sure that it does not touch
the vehicle, especially the pedals. Using protective foam pads
may be helpful.
2. Remove all loose items before mounting the bike. For exam-
ple, water bottles.
3. Bicycle tires must be kept away from vehicle exhaust fumes.
per bicycle) and the capacity of the bicycle, according to the
manufacturer's recommendations.
vehicles. Use extreme caution when driving in high winds, sharp
km/h)
6. Vehicles with bike racks installed have extra width and length.
Also, make sure that the bicycle is mounted in the middle to avoid
excessive protrusion.
7. When the vehicle is equipped with a bicycle rack, check the
km while driving. It is the driver's responsibility to ensure the
safety of passengers and others!
1.FORWODE does not bother to
assume any liability for any damages
(to the vehicle, damage caused by
incorrect installation and use of this
product or its accessories, goods
and/or persons in connection with the
purchase, use or handling of this
product).
2.If you have further questions about
our limited lifetime warranty or need
any support, you can start a conver-
sation with us at
[email protected].
FORWODEBIKE
