WARNING: Bikes or rack falling in road can cause serious accidents resulting in bodily injury-do not use rack on any vehicle
on which it can not be properly mounted as described in this instruction sheet.
•Rack should only be used on vehicles with 2" receiver hitches.
•NEVER use on trailers or front of vehicles.
•Bikes must be tied to rack using tie-downs, or additional straps if necessary.
•Check periodically during use that all bolts and pins are tight, and that rack and bicycles are secure.
•Never carry more than 2 bikes (max capacity 70 LB)
FORWODE
- no tandems, mopeds, or recumbent. Car tail lights must remain visible.
•The presence of the cushion in the upper assembly of the functional model vertical tube requires it to be squeezed
deformation, the holes can be aligned.
•Drive conservatively, especially over bumps. Never use off-road.
•
Do not use if any part of the rack is damaged, worn, or missing. Contact for replacement parts.
CAUTION: Use Forwode only in accordance with local motor vehicle and
IMPORTANT:
Because of the presence of the
cushion pad, so it needs to be
made to squeeze deformation,
the holes could be aligned.
CAUTION:
In order to protect the product, increase
durability and reduce noise, a buffer pad
is added here. When the U-shaped crossbar
is folded, it is necessary to squeeze the
buffer pad hard, and then pull the pin.
IMPORTANT:
WHEN RACK IS IN AN UPRIGHT POSITRION.
WIRE RETAINER ON CLIP SHOULD
ALWAYS BE IN A CLOSED POSITION
TO KEEP RACK FROM FALLING OVER
DURING USE.
traffic regulations.
• Install rack and load bicycles only at a safe distance away from moving
traffic.
• Make sure that all of rack and bicycles are kept at a safe distance from road
and hot exhaust.
• Only operate vehicle with rack in an upright, locked position.
• Bicycles should never extend beyond sides of vehicle.
• Remove rack from car, or fold carry arms down when not in use.
•Put two pieces of Kinto the interior of Cin advance.
(The two cylinders of K are inserted into the two
small holes).
•Insert Binto the inside of C, then connect them
in order with D-F-F-Gfasteners.
•Plug Aand Btogether, and connect the two holes on the side with two
sets of standard parts E-F-F-Glocking.
•Connect one hole on the front side with H-I-J
locking.
•TIGHTEN NUT AND BOLT FIRRRRRMLY
USING TRWO WRENCHES.
UPON COMPLETION, BOTH PARTS
SHOULD BE FIRMLY JOINED TOGETHER.
NOTE:
TOOLS REQUIRED:2--5/8" WRENCH & 2--11/16" WRENCH;
OR 2--ADJUSTALE WRENCHES
PARTES:BOX SHOULD CONTAIN THE
FOLLOEING ITEMS:
A. ASSEMBLING RACK:
B.
STEP 1 STEP 2
INSTRUCTIONS
MODEL: DB-HMS32 PAGE 1
A
B
L
C
D
E
F
G
H
I
J
K
M
N
O
P
Q
R
Base Assembly
Vertical Tube
Vertical tube upper assembly
External hexagon bolts M10*80
External hexagon bolts M10*65
Flat pad Θ10
Self-locking nuts
External hexagon bolts M8*20
Bouncing Pad Θ8
Flat pad Θ8
Round shims with positioning
Anti-collision cotton cover
Heavy Duty Bullet Pads Θ10
Big Flat pad Θ10
Hexagonal nuts M10
U-connector
Fixed plate
Trailer lock
A
E
F
FG
H、I、J
K
K
D
F
FG
C
B
K
Trailer Lock Key
