Foundations Gaggle 4 Buggy User manual

AB20105E
1
Foundations Worldwide, Inc.
Gaggle®4 Buggy
Models Covered: 4142079, 4142039, 4142319
KEEP INSTRUCTIONS FOR FUTURE
USE.
Record product information here found on
the front frame square tube under the body.
VIN Number:
Manufacture Date:
Model Number:
FOR CUSTOMER SERVICE CALL
DO NOT CALL RETAILER OR RESELLER FOR SERVICE AS THEY ARE NOT
AUTHORIZED TO RESOLVE ANY SERVICE ISSUES.
FOR WARRANTY AND FEDERAL SAFETY STANDARD COMPLIANCE
CERTIFICATES, PLEASE VISIT OUR WEBSITE
Assembled Gaggle
AB20105_G2
Gaggle with Roof and Accessory Bag
AB20105_G1
For use with children whose weight is 50 lbs, (22.7 kg) or less.
Children MUST be buckled in the seats with harness properly adjusted.
ASSEMBLY INSTRUCTIONS
• Adult assembly required.
• Read all instructions BEFORE
assembly and use.
• Unpack carton, remove packing
materials, safely dispose of properly or
recycle where possible.
IMPORTANT: retain for future reference
read carefully.
Foundations strives for the highest quality
in our products but occasionally a missing
part or problem can occur during assembly.
If any parts are missing or broken or you
need assistance with assembly, DO NOT
return the product to your dealer. Go to
our website
call Foundations for assistance
(Monday through Friday, 9:00 a.m.– 4:00
p.m. Eastern Time). Please have the model
number and manufacture date available
when you call or write us at:
ASSEMBLY ASSISTANCE
WARNING

2
Failure to follow these warnings, assembly and maintenance
instructions could result in serious injury or death.
Avoid serious injury to children from falling or sliding out:
• ALWAYS use harness provided to safely hold child into seat.
• Snugly adjust harness around each child.
• NEVER leave children unattended, even when sleeping.
• Always keep children in view.
• DO NOT allow children to climb onto buggy or stand in seat.
• Always inspect harness for damage and excessive wear prior to
use. Discontinue use and replace harness immediately if
damaged.
Avoid serious injury to children:
• DO NOT allow children to sit or stand on trunk or roof.
• DO NOT place any child weighing more than 50 lbs (22.7 kg)
or taller than 45 inches (114 cm) in this buggy.
• Use caution when pushing buggy near traffic or in highly
congested areas.
• DO NOT use buggy on stairs or escalators.
• DO NOT lift buggy by push handle.
• NEVER place objects on roof.
Avoid loss of control:
• Use caution when pushing buggy on uneven terrain or hills.
• ALWAYS engage parking brake when buggy is stopped.
• NEVER leave buggy unattended on a hill or incline even when
parking brake is set.
Avoid injury from buggy tipping over:
• DO NOT allow children to climb into buggy unassisted.
• DO NOT allow children to play or hang on to buggy.
• DO NOT overload buggy.
• DO NOT carry more than 4 children, one per seat, or place extra
parcels or goods in or on the buggy including roof.
• DO NOT add unauthorized package carrying accessories, attach
items or hang objects from buggy because it may cause unstable,
hazardous conditions. Use Only Foundations authorized
Accessories designed for this buggy.
• DO NOT place over 15 lbs (6.7kg.)in accessory bag. When
accessory bag is in use, vehicle stability will be affected.
• ALWAYS distribute weight as evenly as possible on each side of
buggy.
Avoid pinch injury:
• Keep children’s fingers away from wheels, and brake lever.
• When in operation or making adjustments always make sure
children’s body parts and fingers are clear of any moving parts.
WARNING: This product is not suitable for running or skating.
WARNING

ABC
DEFG
HI
X4
AB20105_G3
J
A. G4 Front Seat
B. G4 Back Seat
C. Handle Assembly
D. Right-side Frame
E. Left-side Frame
F. Axle
G. Axle cover
H. Front Wheel Assembly
I. Back Wheel Assembly
J. Seat Belt Harness
PARTS LIST
Part Description Part Number Quantity
42300067
42300068
42300075
42300071
42300070
12100072
12100074
12100066
12100060
11300101
1
1
1
1
1
2
1
2
2
4
3

U
AB20105_G4
K
M
N
O
Q
RST
P
K. 5/16” - 18 Hex Head 2 1/2” Bolt
M. 5/16” - 18 Hex Head 1 3/4” Bolt
N. 5/16” - 18 Hex Head 1 1/2” Bolt
O. 5/16” - 18 Hex Head 7/8” Bolt
P. Retaining Pin
Q. 5/16” - 18 Acorn Nut
R. Cap Nut
S. Cap Nut Washer
T. 7/16” Washer
U. Assembly Washer
HARDWARE LIST
Part Description Part Number Quantity
11200500
11200502
11200503
11200504
11200682
11200506
11300070
11200320
11200275
11200507
1
4
4
4
2
1
1
1
2
12
4

PREPARATION GAGGLE ®4 ASSEMBLY
Carefully remove and lay out all hardware and parts. Check quantities and
match the parts list. Construct the Gaggle Buggy on an even at oor.
Note: During the assembly process whenever using nuts or bolts, Check
each with the parts list by letter and size identication. Place each nut or
bolt on the diagram of the item which is sketched actual size. Be sure to
use the proper size specied in the assembly directions. If any parts are
missing or broken or you need assistance with assembly
DO NOT return your product to the dealer. Please identify the Gaggle
Buggy by the model number identication label on the bottom of the frame
when you call or write to Foundations. Make note of all identification
numbers and include this information with your request.
DO NOT Substitute Parts! Only replacement parts supplied or
recommended by the manufacturer or distributor shall be used.
SUGGESTED TOOLS
1/2 in. wrench and 1/2 in. socket and matching ratchet wrench.
STEP 1
G
AB20105_G6
D
E
ASSEMBLY LEGEND
Hand tighten only:
Tighten fully with wrench:
5

STEP 2
STEP 3
F
AB20105_G7
I
P
F
I
P
C
AB20105_G5
X2
X2
6

STEP 4
STEP 5
N
AB20105_G8
U
B
AB20105_G9
A
B
A
B
7

STEP 6
STEP 7
AB20105_G10
H
H
D(E)
A
U
M
O
AB20105_G13
NU
X10
8

STEP 9
J (X4)
AB20105_G12
STEP 8
R
K
S
T
Q
C
T
R
K
S
T
T
Q
C
AB20105_G11
9

1. Shoulder harness should be adjusted
prior to child being placed in seat. The
lowest position (1) is for a small child. The
middle position (2) is for a medium size
child. The top position (3) is for a large size
child up to 50 lbs. The shoulder belts should
be as even with the shoulders as possible.
See Figure 1
To reposition to a different height, Pull out
the Harness Strap Anchor from the back of
the seat. Rotate the Anchor 90 degrees and
push through the seat from the back to front.
Select the correct opening and reverse the
procedure. Pull on the strap to make sure
the anchor is seated securly.
Refer to Step 9 of the assembly.
AB20105_G14
3
2
1
Figure 1
Avoid Serious injury To children From Falling or Sliding out:
•ALWAYS use harness provided to safely hold child into seat.
•Snugly adjust harness around each child.
• NEVER leave children unattended, even when sleeping.
•Always keep children in view.
•DO NOT allow children to climb onto buggy or stand in seat.
SECURING CHILDREN - HARNESS OPERATION
WARNING
STEP 1
1. Secure child with harness straps by
positioning harness strap (X) between legs
and placing shoulder harness strap (V)
over shoulders and waist strap (Z) over
childs thighs. Snap buckle tabs together
into top of harness buckle (W).
2. To secure the child into the seat and
tighten the entire harness, adjust the
strap (Z) around the waist using the slip
buckles (Y).
See Figure 2 and 3
AB20105_G15
V
W
X
Y
Z
Figure 2
STEP 2
10
Note: Make sure both seat back anchors are placed into a slot at the same hieght.

AB20105_G17
V
X
W
Y
Z
Y
Figure 3
STEP 2
BRAKE OPERATION
AB20105_G18
11

GAGGLE MAINTENANCE AND CARE
Buggy cleaning:
• Buggy may be cleaned with a mild solution of soap and water.
• Rinse well with clear water to remove soap solution.
• Never use cleaning agents that may contain chemicals hazardous to children.
• Do not use cleaners with abrasives.
• Harness straps can be cleaned with soap and water and should be wiped or
air dried after cleaning.
For assistance call or write:
Foundations Worldwide, Inc.
GAGGLE ®4 ACCESSORIES
AB20105_G2
The Gaggle®4 has an optional roof that is
offered in various coordinating colors and
can be purchased separately to protect
children from exposure to sun and rain.
Item numbers: 4143159, 4143239, 4143329,
4143259.
The Gaggle®4 accessory bag can be
purchased for additional storage of child
care items.
Item number: 4144239
The Gaggle®4 Infant seat provides head
support for younger babies. Sold seperately
Item Number: 4164077
The Gaggle®4 All Weather Storage Cover
protects your buggy when stored outdoors.
Sold seperately.
Item Number: 4145259
12
Available through dealers or at foundations.com
Foundations recommends the use
of the Gaggle®infant seat for
children less than 25 lbs.
