fox fury D10 User manual

PRODUCT MANUAL
700-313 | 700-318
D10D10

2
TABLE OF CONTENTS
INTRODUCTION
Reference Guide 3
Overview 4
Physical Characteristics 4
BATTERY
Charging the Battery 5
OPERATIONAL MODES
Modes 5
Modes, Output, & Battery Life 5
INSTALLATION 6
WARNINGS/WARRANTY 8
CARE/CLEANING 8
CONTACT FOXFURY 9

3
D10 REFERENCE GUIDE
D10 LIGHT
WHAT'S INCLUDED
LIGHT
POWER/MODE BUTTON
CHARGING PORT
D10 Light (White or IR)
Flat Mounting Pad
Micro USB Cable
VHB 5915 1x1
D Series Dual Lock Velcro
D Series Mount Set includes
(*P/N 700-813 Only):
• Flat Mounting Pad
• Ops-Core Mount
• Base/MOLLE Mount
• VHB 5915
• Dual Lock Velcro
FLAT MOUNTING PAD OPS-CORE MOUNT* BASE/MOLLE MOUNT*

4
WARNINGS
Please fully charge the D10 before using it for the first time.
Do not stare into the LEDs for long periods of time or from a close range (less than
2 ft/ 0.6 m).
While using any FoxFury product, please operate at safe speeds.
It is the responsibility of drone/UAV users to follow the FAA laws and regulations
and/or the laws and regulations applicable to the flight location.
OVERVIEW
The D10 is a multi-function utility light that is proudly made in the USA. It
mounts to most drones and helmets with the Flat Mounting Pad via Dual-Loc
Velcro or 5915 VHB Tape. OPS-CORE and Base/MOLLE mounts expand the
mounting capabilities. The D10's 30° LED operates on continuous or strobe
light modes. This rechargeable and splashproof light is durable and compact
for a variety of uses where light is needed in a tight space.
Please fully charge the D10 before using it for the first time.
PHYSICAL CHARACTERISTICS
DIMENSIONS 1.07 x 0.77 x 1.4 in (27.3 x 19.5 x 36 mm)
WEIGHT 0.48 oz (13.7 g)

5
WARNING:
Unplug the light once charged to avoid impacting battery life.
If battery is fully discharged because the unit may have not been in use for
many months, please charge fully.
OPERATIONAL MODES
Press and hold Power/Mode Button for 3 sec to turn light on ON.
For IR version the green light will blink once, before turning on the invisible
light.
Press Power/Mode Button again to the turn light to STROBE.
For IR the green light will blink twice before light output is in strobe mode.
Press the Power/Mode Button again to turn light OFF. For IR, the green
light will blink three times before turning OFF.
CHARGING THE BATTERY
Connect the provided Micro USB Cable to the Charging Port, and to a
USB source.
While charging, a green light will blink. Once charged, the green light will
remain steady on.
Charge time should be approximately 2.5 hours.
OPERATIONAL MODES
BATTERY
MODE WHITE
LUMENS
IR
mW BATTERY LIFE
ON 200 400 30 - 40 minutes
STROBE 200 400 60 - 80 minutes

6
INSTALLATION
FLAT MOUNTING PAD/ OPS-CORE MOUNT
Align bottom of D10 with snap lock location on mount and snap D10 light in
place. Spin them and tug to make sure they are properly attached.
(image shown is Flat Mounting Pad.)
BASE/MOLLE MOUNT
Align bottom of D10 with the hole on the Base/MOLLE mount as shown. Push
each of the eight tabs in individually. Make sure that the light turns and all the
tabs have engaged.
TA B

7
NOTES

8
Any FoxFury product should
be operated at speeds safe
enough to maneuver around
surrounding obstacles.
Do not use under the influence
of drugs or alcohol.
ONE YEAR WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for one year after
purchase. LiPo batteries have a one
year pro-rated or 300 re-charge cycle
pro-rated warranty, whichever the
user reaches first.
This warranty is given only to the
original end user of the accompanying
product. If you purchased a product
from someone other than an
authorized FoxFury reseller/distributor
or if the product was used, (including
but not limited to demo models, show
models or refurbished product by
someone other than FoxFury) prior
to your purchase, you are not the
Original Purchaser and the product
that you purchased is not covered by
this warranty. This warranty is VOID
if this Product has been altered or
modified in any way (including but not
limited to attempted warranty repair
without authorization from FoxFury
and/or alteration/removal of the
serial number). To expedite warranty
concerns, we encourage the end user
to register their FoxFury Product at
www.foxfury.com/pages/warranty-
registration.
PRODUCT DURABILITY
PRODUCT NAME: D10 & D10 IR
PART NUMBER: 700-313 & 700-318
CARE/CLEANING
Your FoxFury product is a professional
tool. Regular maintenance and care of
your light will maximize performance for
you. As needed, clean your FoxFury
product using a damp soft washcloth.
Do not immerse.
ACCESSORIES
D Series Mount Set (P/N 850-730)
WARNINGS
FoxFury, LLC is not responsible for the
incorrect use of any FoxFury Lighting
product.
Lights are strong enough to cause
damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft/ 0.6 m).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is
being used by a minor.
WARRANTY AND OTHER
INFORMATION

9
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED EXCEPT
WHERE SUCH LIMITATION IS
PROHIBITED BY LAW.
You may have other specific legal
rights which vary by jurisdiction. Go to
www.foxfury.com/pages/warranty for a
complete copy of the warranty. Retain
your receipt for proof of purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Toll-Free: 844-FOXFURY
Te l : 760.945.4231
Fax: [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury products
are manufactured with the highest
quality USA and foreign parts.
Products are assembled in either
FoxFury’s controlled plant in Asia or the
USA, under strict quality control.
CALIFORNIA
PROPOSITION 65
This product can expose you to
chemicals including Lead and DEHP,
which are known to the State of
California to cause cancer and
birth defects or other reproductive
harm. For more information go to
www.P65Warnings.ca.gov.

FOXFURY.COM 10/2020
