Foxjet Marksman MATRIX User manual

Marksman
MATRIX & ELITE
High Resolution Printing
for the Real World
2465-623
Revision E
User
Manual
1 Missouri Research Park Drive • St. Charles, MO 63304
Tel: [phone] • Fax: [phone]
Illinois Tool Works Inc © 2018

www.foxjet.com Marksman
MATRIX & ELITE
Ink Jet System
User Manual
2465-623
The information contained in this manual
is correct and accurate at the time of its
publication. ITW reserves the right to
change or alter any information or
technical specifications at any time and
without notice.
©2018 Illinois Tool Works Inc.
All rights reserved

Warranty:
The Marksman© Matrix & Elite Ink Jet system, including all components unless other
wise specified, carries a limited warranty.
The inks and conditioners used with the Marksman© Matrix & Elite Ink Jet system
carry a limited warranty.
For all warranty terms and conditions, contact the Distributor for a complete copy of the
Limited Warranty Statement.

Marksman Matrix & Elite
2465-623 User Manual Rev E
Section 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 2: Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Section 3: System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Integrated Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Bracketry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Photosensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Inks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Waste Bottle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Section 4: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Materials Required for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing Bracketry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mounting the Print System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting Up the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mounting the Photosensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Ship Caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
The Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Electrical Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Priming the Print Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Section 5: Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Counts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
User Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Configure, Print Head: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Configure, System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Section 6: BoxWriter© Matrix & Elite Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Define . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
ToolBar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Perspective . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Section 7: Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
APS - Automatic Priming System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Shutdown Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Ink Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Section 8: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Troubleshooting Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Troubleshooting Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Print Quality Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Marksman Matrix & Elite
2465-623 User Manual Rev E
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Matrix Controller Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Elite Controller Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Print Head Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Appendix B: Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
The Marksman© Matrix & Elite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Print Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Photosensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Matrix Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Elite Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Appendix C: Parts and Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Matrix Spare Parts Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Elite Spare Parts Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
384e and 768e Print System Service Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Appendix D: Testing the Electrical Outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Electrical Line Transients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Appendix E: Database Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Database Start Task Routine Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Database Lookup Definition - Global Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Database Start Task . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Serial Port Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Printer Report Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Appendix F: Hand Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Scan and Shoot Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Appendix G: Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Font List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Font Samples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Appendix H: Standard Operating Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
FJSOP1 - Removal of FoxJet High Resolution Printheads . . . . . . . . . . . . . . . . . . . . . . . . . . 113
FJSOP2 - Daily Maintenance for AMS/APS Printheads . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
FJSOP4 - Installation of FoxJet High Resolution AMS/APS Printheads . . . . . . . . . . . . . . . 117

Section 1: Introduction
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 1
Section 1: Introduction
The Marksman© Matrix & Elite are advanced high-resolution ink jet controllers that runs on
a Microsoft Windows 7® platform. It includes a built-in keypad with a TFT display with
touch-screen control. The Marksman© Matrix & Elite can control up to 4 Pro Series high-
resolution print heads for printing industry compliant barcodes, graphics or alphanumeric
text on porous materials and cases.
This manual covers the operation of the Marksman© Matrix & Elite Ink Jet Printing System,
Marksman© Matrix & Elite Controller and Print Heads.

Section 2: Safety
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 2
Section 2: Safety
Following is a list of safety symbols and their meanings, which will be found throughout this
manual. Pay attention to these symbols where they appear in the manual.
Wear safety goggles when performing the procedure described!
Caution or Warning! Denotes possible personal injury and/or damage to the equip-
ment.
Caution or Warning! Denotes possible personal injury and/or equipment damage
due to electrical hazard.
NOTE: (Will be followed by a brief comment or explanation.)
Only trained personnel should operate and service the equipment.
NOTE: It is extremely important to:
• Clean up all ink spills with the appropriate conditioners immediately and dispose of all
waste according to local and state regulations.
• Wear safety glasses and protective clothing, including gloves, when handling all inks
and conditioners.
• Store inks and conditioners under the recommended conditions found on the MSDS
(Material Safety Data Sheet).
PRODUCT COMPLIANCE DISCLAIMER NOTE:
This product meets the requirements of CAN/CSA-22.2 NO.60950-00 * UL 60950 using
FoxJet an ITW Company approved items. Units are only tested and qualified with FoxJet
an ITW Company approved inks, parts and accessories. Use of other inks, parts or acces-
sories may introduce potential risks that FoxJet an ITW Company can assume no liability
for.
!

Section 3: System Components
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 3
Section 3: System Components
1 Controller, Matrix or Elite
2 Proseries Print Head
3 Conveyor
4 Product
5 Print System Bracketry
6 Encoder
7 Ink Supply
8 Photo Sensor
9 Vacuum Waste Collector Bottle
10 Encoder Cable
11 Alarm Beacon (Strobe)

Section 3: System Components
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 4
The Marksman© Ink Jet System is available with the following components, options and
service kits:
Part Number Description
Print Head
2464076 ProSeries 384e
2464076F ProSeries 384e, Flushed
2464078 ProSeries 384e, 90°
2464078F ProSeries 384e, 90°, Flushed
2464079 ProSeries 384e, Modular
2464079F ProSeries 384e, Modular, Flushed
2464082 ProSeries 768e
2464082F ProSeries 768e, Flushed
2464083 ProSeries 768e, Modular
2464083F ProSeries 768e, Modular, Flushed
2464084 ProSeries 768e, 90 Degree
2464084F ProSeries 768e, 90 Degree, Flushed
Matrix Controller Assembly
2465006D2 Controller Assembly, Marksman© Matrix, 2 Head, Domestic
2465006E2 Controller Assembly, Marksman© Matrix, 2 Head, European
2465006D4 Controller Assembly, Marksman© Matrix, 4 Head, Domestic
2465006E4 Controller Assembly, Marksman© Matrix, 4 Head, European
Elite Controller Assembly
2465004D2 Controller Assembly, Marksman© Elite, 2 Head, Domestic
2465004E2 Controller Assembly, Marksman© Elite, 2 Head, European
Remote PHC Board & Elite board kit
2465321 Assembly, Marksman remote PHC Board
2465246 Elite PHC Board Kit
Print Head/Controller Bracketry
2464550 Print Head Conveyor Mount Bracket
2464553 Print Head Pivot Bracket
2464561 X-Y Axis Linear Adjustment, Tool-Less Bracket
2464562 Conveyor Mount/Roller Bracket for 768 Print Head
2464563 Print Head Floor Mount Bracket Kit
2464564 Conveyor Mount/Roller Bracket for 384/352 Print Head
2464565 Conveyor Mounting Bracket with Integrated Guide Rails for 384/768 Print Head
2465243 Kit, T-Stand, Matrix & Elite
2465244 Kit, Conveyor Mounting, Matrix & Elite
2465254 Kit, Pivot Bracket, Matrix & Elite
Encoder, Photosensor, Alarm Beacon
2465224 Photosensor, ProSeries
2465253 Alarm Beacon (Strobe), 3-Color
2465525 Photosensor, Auxiliary, APS Controller

Section 3: System Components
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 5
Integrated Print Head
Cabling
2464182-010 Cable, Straight Thru, DB9, 10 Ft.
2464182-025 Cable, Straight Thru, DB9, 25Ft.
2464182-050 Cable, Straight Thru, DB9, 50 Ft.
2465155-002 Cable Kit, Print Head, DB25, 2 Ft.
2465155-010 Cable Kit, Print Head, DB25, 10 Ft.
2465155-025 Cable Kit, Print Head, DB25, 25 Ft.
2464312 Cable, APS Photocell Network ("Y" Cable for sharing Auxiliary Photocell)
INK SYSTEM
WASTE BOTTLE
PRINT HEAD
INK BOTTLE

Section 3: System Components
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 6
Bracketry
Bracketry is the structure that supports the controller, print system and other accessories.
This manual details instructions for mounting all system components to a conveyor. Other
mounting options for the controller and print system include the floor mount and the retract-
ing bracket. Assembly instructions are included with parts kits.
Retracting Bracket
Floor Mount
Conveyor Mount

Section 3: System Components
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 7
Photosensor
The photosensor is both a light source and a sensor. It emits light and detects the arrival of
a product when the product reflects the light source back to the sensor. The sensor then
sends a signal to the controller to start the printing cycle.
Encoder
The encoder assembly provides conveyor line
speed information to the controller. It also allows
automatic disabling of printing when the line
stops.
The Marksman© Matrix & Elite System uses a
5000 ppr open collector output encoder. The
wheel is sized to provide the correct timing
inputs to allow the print heads to print from 150
to 300 dpi.
Inks
Ink is supplied via 500 mL plastic containers. ScanTrue® II PLUS is a pigmented ink formu-
lated for use on porous substrates.
NOTE: Check the label on the Print Head for correct ink type.
NOTE: Inks are not miscible. Do NOT mix the inks.
Waste Bottle
The APS includes a Waste Collection Bottle mounted on the rear of the Print Head assem-
bly. This bottle must be changed when full to prevent improper operation of the system.
Instructions for waste disposal are on the collection bottle.
ENCODER ASSEMBLY

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 8
Section 4: Installation
The figure below illustrates a typical conveyor-mounted installation. (Cables are not
shown.)
Materials Required for Installation
You will need the following items:
• Lint-free wipes
• Safety goggles
•Level
• Tape measure
Use appropriate safety equipment and procedures. Leave print heads in their shipping car-
tons until all bracketry is in place and tightened down.

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 9
System Installation Overview
NOTE: The following steps give an overview of the procedure to properly install the Marks-
man© Matrix or Elite print system. Refer to the appropriate section for details.
1. Carefully plan the mounting location of the equipment. Keep in mind bracketry hard-
ware location and printer equipment size.
2. Remove equipment from packaging.
3. Assemble all bracketry to the floor, conveyor, or other bracketry per bracketry installa-
tion section.
4. Mount the print system to its appropriate bracketry. Do not connect to power outlet.
5. Assemble the optional retracting bracket to each print head, if applicable.
6. Mount the print head(s) to their appropriate bracketry and in the approximate location
relative to the carton.
7. Mount the photosensor, optional bracketry, and optional encoder per procedure.
CAUTION: Remove the print head Ship Cap prior to operating the Print Heads.
Installing Bracketry
This section shows controller bracketry mounted to a conveyor. This is the most common
mounting method, and the most stable, as all bracketry is bolted directly to the conveyor.
Detailed assembly instructions are included with the parts kit.
Other mounting options, including parts kit numbers, are listed in Section 3, System Com-
ponents.
Corner brackets are attached to aluminum bars as shown.
!
ATTACHING
CORNER
BRACKET
Single T-nut
Corner Bracket

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 10
Mounting the Print System
Unpack the print head just before mounting to the bracketry.
Attach the print head to the bracketry with a print head mounting bracket.
The print head must be mounted in close proximity to the product. To maintain consistent
print, the head should be mounted no more than 1/8" from the substrate. An optional
retracting bracket is available to mount the head and control the distance from the head to
the substrate. The retracting bracket allows the head to bump the product and retract as
required to maintain a consistent throw distance. (See Section 3, System Components for
bracketry options.)
NOTE: Install optional retracting bracket kit on the print head prior to mounting the print
head to the conveyor bracket.
It may be necessary to vertically adjust each bracket's horizontal bar later to fine-tune mes-
sage placement. This is especially true when using multiple print heads, as message lines
will need to be synchronized with each other.
NOTE: When adjusting the horizontal bar or print head mounting bracket, always support
the print head with your hand to keep it from falling forward onto the conveyor.
NOTE: The ProSeries print heads work on gravity and capillary ink feed, internal in the
print head. The head must be mounted in a level position from front to back to prevent leak-
age.

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 11
Setting Up the Print Head
The Matrix/Classic Series print heads are mounted using the 10-32 tapped holes on the
right or left side of the Ink System bottom case. The print head angle can be set between 0°
and 90°.
To adjust the head to its correct angle:
1. Loosen the two set screws (1/8" hex head) on the print head side of the head mount.
2. Rotate the head to the desired angle.
3. Secure the set screws.
Mounting the Photosensor
The product detect Photocell can be mounted on either side of the print head, depending
on the direction of print. Remove the plugs or set screws (3/32" hex head) in the photocell
mounting holes, then attach the Photocell Mounting Bracket with the 10-32 x 1/2" screws
provided with the bracket.

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 12
Ship Caps
CAUTION: Do not operate APS Print Heads with the Print Head Ship Cap installed! Oper-
ating a closed system can cause a siphoning effect which can drain the ink supply.
384e/768e Print Heads
Loosen the two thumbscrews
and remove the Ship Cap.
(See illustration at right.)
NOTE: If you place the Print Head Ship Cap on a hot print head and do not fasten it
securely, the print head will weep ink until the head has cooled down.
NOTE: Ink may accumulate behind the ship cap during shipping.
!
THUMBSCREWS
SHIP CAP

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 13
Remove the Ship Cap
and Install the Filter.
Remove the Reservoir
Ship Cap and Install
the Ink Bottle. Save
caps in a zip-lock bag
for future use.
CAUTION: Do not
over-tighten the ink
bottle when screwing
into the Reservoir.
Over-tightening will
damage the Reservoir.
The Encoder
The encoder uses a wheel
that rolls against the con-
veyor line to track the speed.
It sends a signal to the con-
troller, which makes adjust-
ments for reported changes in
the line speed.
It is not necessary to install
the encoder immediately adja-
cent to the print heads. It is
more important to place it
where it will accurately mea-
sure the speed of the con-
veyor. Install it in contact with
the conveyor, or with a wheel
or roller moving the same
speed as the conveyor.
The encoder's mounting
bracket is spring-loaded.
Adjust the spring collar to
ensure that the encoder main-
tains stable contact with the
conveyor.
CAUTION: Do not jam the encoder wheel against the surface of the conveyor. A radial
force of over 40 lbs. will reduce the life of the bearings.
!
Spring
Mounting
Bracket
Encoder
Wheel
Conveyor
Out to Controller
Mounting Bracket
Shaft
Encoder
ENCODER
ASSEMBLY
!

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 14
Electrical Cable Connections
PRINT
SYSTEM
PRINT HEAD CABLE
SENSOR
ENCODER
SYSTEM
PRINT
ALARM
BEACON
(STROBE)
MARKSMAN MATRIX OR ELITE CONTROLLER
24V

Section 4: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev E Page 15
Views
Bottom view of Matrix Controller
(With Optional second PHC Board
ETHERNET
LINE OUT
12 VDC USB
VGA DVI-D
COM 1 STROBECOM 2 ENCODER
1
2
OUTPUT TO
PRINTHEAD
4
3
PRINT HEAD CARDS
Bottom view of Elite Controller
Back view of Print System
