Foxtech TEMPHAWK User manual

Fox-Tech Co. All Rights Reserved. Do not redistribute. Document Version: V3.1
With connectivity
User Manual
TEMPHAWK
Introduction
V4.1
1

Contents USB charging cable x1TEMPHAWK device x1 Adaptor x1
Temperature &
Humidity sensor cable
x1
Fox-Tech Co. All Rights Reserved. Do not redistribute. 2

Fox-Tech Co. All Rights Reserved. Do not redistribute.
TEMPHAWK Device
The Device
•Overall Dimensions:68 x 86 x 36 mm
•Device Sensing Range: -20°C to +60°C
•Micro USB (certified with IP67)
3.8 cm
Sensor Probe
•Sensor cable length: 1.5 M
•Temperature Range: -40°C to +125°C
•Humidity Range (%RH): 0% to 100%
Product Identification
•Each device has an exclusive QR code
as ID
LVD
3

Fox-Tech Co. All Rights Reserved. Do not redistribute.
Charging
•Plug the charging cable into the
charging port.
•The LED light shows red when a
device is being charged.
•It takes about 5 hours for a device
to be fully charged.
•Once the device is being fully
charged, it can last for at least 10
months.
Charging port
Sensor port
Waterproof
Cover
4

Fox-Tech Co. All Rights Reserved. Do not redistribute.
LED Light Indication
LED Light
Status Description Status icon
Charging Light glows
Charging
Completed
Low power
(<15%)
None
Blink
When the device is in low power mode, the LED
light will blink 3 times every 5 minutes.
5

Fox-Tech Co. All Rights Reserved. Do not redistribute.
Installation
▸Step 1
•Plug the sensor cable into the device to turn it on.
▸Step 2
•Secure the sensor cable with the screw on the
sensor port. Once being securely screwed; the
device is ready for monitoring.
▸Step 3
•Deploy TEMPHAWK solution in the environment
where you’dlike to monitor.
Notice：
•The TEMPHAWK device cannot be deployed in an
environment that is fully covered with metal.
•The direction of the device can affect the signal strength. For
better signal, please place the device with an upper position.
6

Fox-Tech Co. All Rights Reserved. Do not redistribute.
Please provide the following information
and send it to [e-mail]
•Company Name
•Contact person
•Order Number
•Product Name
•Device ID
•Time of problem occurred (YY/MM/DD
hh:mm)
•For Full Manual Version Please
Download from
http://www.temphawk.net/
Hardware
Troubleshooting -
Contact us
