Foxtech S81108 User manual

User Manual
V1.1
Foxtech Portable Handheld RF
Spectrum Analyzer(240~960MHz)
2018.11

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 1
Portable Spectrum Prole
Product Features
Specications
Introduction to the Buttons, Ports, and Function
IntroductiontothePortandIndicatorLights
FunctionandUse
Typical Applications
User Information and Maintenance
NormalUse
ApplicationofEnvironmental
BatteryMattersNeedingAttention
2
2
3
4
4
4
10
11
11
11
11
Contents

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 2
At the scene of the RF test, wireless optimization, cloth net, interfere with the application process, including
often need to test signal spectrum distribution; Field measurement needs to be portable, and Europe and
the United States of the portable spectrometer is 3 kg, field test is not convenient.
Real-time Spectrum Analysis Functions: Real-time spectrum scan SPAN/RBW/CENT/MARKER function，
MAXHLOD function，Maximum power automatic detection.，
Frequency Chromatogram Function: Show a period of time the whole time and frequency spectrum
characteristics of recycled record all spectrum distribution within 5 minutes, facilitate the frequency
interference to or launch leakage and other problems.
Heat Map Function: Spectrum shows that over a period of time spectrum overlap density contour,
repetitions show tend to be more red, more facilitate spectrum statistical characteristics of analysis for a
period of time.
Portable Spectrum Prole
Product Features
1.1 S11 Test Pattern

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 3
PROJECT
S11(Typical Value)
Frequency Range
In-band Flatness
RBW
DANL
Amplitude Precision
Sweep Time
MAXHOLD Function
Reference Level is ADJ
Display Refresh Rate
LCD Resolution
LCD Size
RF Interface
Spectrogram Mode
Thermal Spectrum Mode
Built-in RTC Clock
Battery Capacity
Battery Type
Charging Time
Charging Interface
Battery Life
Overall Dimensions
Working Temperature
Storage Temperature
Signal Measurement Range
PARAMETER
-20dB
240~960MHz
0.5dB
3，5，10，20，30，50，100，200 ，300and 500kHz
-120dBm，typical value，
+-1dBm
200ms
Support
Support
5Hz
TFT 800，480
5 inch
SMA-K
Support
Support
Support
3300mAh，typical，
Panasonic 18650 lithium batteries
45h
Micro USB interface
9h
135mm*101mm*30mm，Do not include the knob and the antenna height，
-20，45°
-20，70°
-100 ~ -15dBm，(Large signal attenuator to enter.)，
Specifications

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 4
Introduction to the Buttons, Ports,
and Function
Introduction to the Port and Indicator Lights
Function and Use
1.Light blue light in the normal boot, bright red when charging, the charging light green.
2.USB interface for Micro USB, the use of power is 5V / 1 A.
3.Antenna interface is the instrument for the standard SMA female head (SMA - K outside screw hole)
should be with standard male head (SMA) - J internal screw needle. Note that SMA interface normal service
life of about 1000 times (more than life, signal loss bigger or contact unstable), frequent replacement of
antenna or using radio frequency cable, SMA connector should be used the original life of interface.
KEYS FUNCTION GENERAL INTRODUCTION，
1.F1~F6 function keys (F1) with the LCD menu label one-to-one correspondence, select it and press
respectively into the corresponding function.
2.POWER (F6) key is on/off key, long press the POWER (F6) key to turn it off. (Note: Shutdown operation
under the return to the main interface is effective, other interface to return to the main interface
operation.)
2.1 The port is introduced.

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 5
Real-time Spectrum Function
2.2 Real-time spectrum mode (UP Page)
2.3 Center Frequency Setup Submenu
For the instrument at the top of the rotary encoder, rotating around the adjustable corresponding numerical
size, confirm function press the knob.
1.F1 key corresponding setting function of center frequency (Note: Frequency setting range of 240 ~ 960
MHz) :
1) F3 corresponding Settings adjust step precision for 10;
2) F4 corresponding Settings adjust step precision for 1;
3) F5 corresponding Settings adjust step precision is 0.1;
4) F6 corresponding returns on an interface.
2.The F2 key corresponding setting function of scanning bandwidth (Note: Set the range 0 to 720 MHz
bandwidth, specific operation with the center frequency setting.)
3.The F3 key corresponding setting start frequency function. (Note: Set the starting frequency range
240 MHz ~ the end frequency and specific operation with the center frequency setting.)
4.The F4 keys corresponding to set the end frequency function. (Note: Set the starting frequency range
Start frequency ~ 960 MHz, specific operation with the center frequency setting.)
5.F5 key corresponding to the setting function markers (Note: Frequency measurement range start
frequency to the end frequency.) :

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 6
1) F2 corresponding setting test frequency input tag (Note: Specific operation with the center frequency
setting).
2) F3 corresponding tag set point frequency to the center frequency.
3) the F4 corresponding to set the maximum frequency to the center frequency.
4) F6 corresponding returns on an interface.
6.The F6 corresponding set to switch to the on the next page.
7.F1 correspond to set the resolution function. (Note: set the range resolution 3,5,10,20, 30, 50, 100, 200,
300,500 KHz.) :
1)F1 corresponding Settings manually enter the resolution. (Note: Manually after will be manual mode.) :
2.4 Mark Point Setup Submenu
2.5 Real-time Spectrum Mode ( DOWN Page)
2.6 Resolution Settings Interface
2.7 The Resolution of the Input Interface
**Can be directly through the knob in 3,5,10,20, 30, 50, 100, 200,300 and 500 KHz switching.

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 7
2)F3 corresponding set automatically set the resolution mode.
3)F6 corresponds to return to the interface of a function.
8.F2 key corresponding to the reference level set function. (Note: The reference level range - 120 ~ 0
dBm, specific operation with the center frequency setting.)
9.Set the maximum keep the F3 key function turned on or off.
Center frequency, scanning bandwidth, start frequency, end, resolution and reference level operation
frequency, marked points and functionality as above (real-time spectrum interface).
Spectrogam Function
2.8 Spectrogram Mode(UP Page)
2.9SpectrogramMode(DOWNPage)

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 8
Set the F3 key chromatography update to stop or start, chromatogram can be stop update at any time, with
detailed analysis of the overall distribution. (Note: In this mode, only the marked points and stop and
start function is available.)
Center frequency, scanning bandwidth, start frequency, end, resolution and reference level operation
frequency, marked points and functionality as above (real-time spectrum interface).
Thermal Spectrum Function
2.10 Thermal Spectrum Mode(UP Page)
2.11 Thermal Spectrum Mode(DOWN Page)，
**Set the F3 key manually screen clearing.

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 9
Set the Interface
2.12 SET UP
F1, F2, F3 and F4 keys even display Settings. As defined by the knob corresponds to the function of rotating
around the adjustable corresponding numerical values. Long press F6. Key corresponding to return to the
interface of a function.
1.The dormancy Settings, select by knob to adjust time, after can be determined by identifying key after
adjustment.(Note: The range of 1 ~ 60 minutes and set to never automatic shutdown.)
2.The time Settings, F1 ~ F6 and when (date) (month) (year) minutes respectively, set up after the
completion of the unified according to the identification of key.
3.Brightness Settings, select can adjust brightness, through the knob after adjusted can be determined by
identifying key.(Note: The relative brightness range 0 ~ 100%.)
4.After selecting language Settings, can choose the language through the knob, after the completion of the
language selection can be determined by identifying key.(Note: The language types in English Chinese.)

Foxtech Portable Handheld RF Spectrum Analyzer(10MHz~2.7GHz) User Manual
©2018 FOXTECH All Rights Reserved 10
This content is subject to change.
Download the latest version from
https://www.foxtechfpv.com/foxtech-portable-handle-rf-spectrum-analyzer.html
For everyday updates, please follow Foxtech facebook page"Foxtechhobby".
YouTube Channel: Foxtech
User Information and Maintenance
Normal Use
Application of Environmental
Battery Matters Needing Attention
Note that large signal coverage not to exceed bid, so as not to damage the instrument to receive the
front end.
When installing the antenna or RF cable, screw thread, but do not be too hard to avoid slippery silk.
Should maintain adequate power, in order to avoid shutdown without electricity.
USB interface is fragile, plug not too hard, also avoid lateral force.
Pay attention to the storage temperature and temperature range, such as exposure do not put in the car.
Long-distance transportation should be put in boxes or suitcase, conventional scratch the LCD panel to
avoid hard objects.
It is recommended to use connector, life in order to increase the original interface.
RF connectors cleaning once every 3 month, using alcohol.
Instrument, shake the water sound or other obvious abnormal, do not use.
A thunderstorm do not test the outdoor equipment, including installation of surge arrester outdoor
equipment.
Normal warranty period is one year, such as touch, and to remove the water, not in the warranty scope.
From outdoor enter a indoor of central heating in winter, avoid instrument internal condensation, such as
condensation should be after drying in the boot.
Instrument commissioning or charging should stay away from flammable items, pay attention to
ventilation, instruments and shall not cover other things on the charger.
In order to protect the battery, please recharge instruments frequently, try not to lack of electrical
warning in charging, etc.
Ban floating for a long time, if the instrument is used for a long time to continuous charging work, please
don't please under the intermittent use of batteries in order to increase the battery life.
Instrument for a long time need not, should be charged after storage. During storage at least once every
three months with elect.
