Foxun SX-KVM801 User manual

Operating Instructions
8-PORT HDMI KVM Switch
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Using only 1 set of keyboard, mouse and monitor to control 8 host devices.
Support Windows 95/98/2000/2003/NT/XP/WIN7/WIN8, Linux, Unix, MAC.
Support hot plug, connect or disconnect devices to the KVM switch in any
time and without turn off devices.
Support auto switching (monitor the devices in a specified time interval.
Support keyboard hot keys to control KVM switch.
Available to use keyboard and mouse without any delay after switch host
devices.
Support auto switching host devices by just moving mouse.
Support resolution up to 1920*1440.
With mounting ears.
NOTICE
Our company reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
1
8-PORT HDMI KVM SWITCH

Operating Instructions
SPECIFICATIONS
Function KVM801
Port Selection HotKey, Pushbutton
Connectors
Console Ports
Keyboard 1xUSB Type A Female
Video 1x HDMI Female
Mouse 1x USB Type A Female
KVM Ports
Keyboard/Mouse 8xUSB TypeB Female
Video 8xHDMI Femal
Power 1xDC Jack
Switches
Port Selection 8xPushbutton
Reset 1xPushbutton
Switch control way Auto Switching, Timming Switch, Mouse movement switching
LEDS
USB Link 8( Green)
On line/Selected 8( Green)
Rest 1( Red )
Emulation Keyboard/Mouse USB
Bandwidth 2.25Gbps
Vedio Resolution (Max) reach up to 1080p(1920*1440)
Scan interval More than 1's ( Default 6 secs)
Power Consumption DC 12V,5watts ( Max)
Enviroment
Operation Temperature +32 to +104 ℉(0 to +40℃）
Storage Temperature -4 to +140 ℉(-20 to +60℃）
Humidity 20-90%RH(No condensation)
Physical Properties
Housing Metal, Black
Weight 1.85kg
Dimensions(LxWxH) 48.1X14.2X4.4cm
Note: Specifications are subject to change without notice. Mass and
dimensions are approximate.
PACKING CONTENTS
1) HDMI KVM switch
2) 12VDC Power Supply.
3) Mounting ear 1 pair.
2

Operating Instructions
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will , for the length of
the period indicated as below, (Parts(2)Year ,Labor(90) Days) which starts with
the date of original purchase ("Limited Warranty period"), at its option either(a)
repair your product with new or refurbished parts, or (b) replace it with a new of a
refurbished product. The decision to repair or replace will be made by the
warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is extended
only to the original purchaser and only covers product purchased as new. A
purchase receipt or other proof of original purchase date is required for Limited
Warranty service.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and
provide a day time phone and/or email address where you can be reached.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.
The Limited Warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by warrantor,or
failures which result from accidents,misuse,abuse,neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments, misadjustment of
consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service center or other
Authorized Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
"LIMITED WARRANTY COVERAGE".THE WARRANTOR IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE
OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY.
(As examples, this excludes damages for lost time, cost of having someone
remove or re-install an installed unit if applicable, travel to and from the service,
loss of or damage to media or images, data or other recorded content. The items
listed are not exclusive, but are for illustration only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
6
Operating Instructions
PANEL DESCRIPTIONS
Front Panel
1) Working status indicators. 2) Switch button.
3) Reset button. 4) Rest status indication.
Back Panel
1) 12V DC power input. 2) HDMI out port.
3) USB keyboard and mouse output ports. 4) HDMI in ports.
5) USB keyboard and mouse input ports.
Connecting and Operating
(1) Connect all the PCs to the HDMI KVM switch, then start all the PCs.
(2) After all the PCs are started in step 1, then you can switch to any PC by
keyboard hot key or the key pad on the KVM panel. (For example, if you want
to control the PC connected to HDMI IN 2 just press the key under the PORT 2
LED indicator, or the keyboard hotkey commands described following).
3

Operating Instructions
CONNECTION DIAGRAM
HOW TO USE KEYBOARD HOT KEYS:
1) Hit ScroIILock key twice within 2 seconds, then the buzzer will beep twice.
2) After step 1 then enter following hot key commands within 3 seconds, the
KVM will execute the corresponding commands.
4
Operating Instructions
FAQ
Problems Solutions
Keyboard and mouse don’t work at all no
matter which input port is switched to
Try below ways:
1. Unplug and plug the USB keyboard and mouse
2. Make sure the USB cable connections from
KVM switch to host devices are all correct
3. Reset the KVM switch by press RESET key
4. Unplug and plug the power cord of the KVM
switch then press RESET key
5. Make sure the precision of the mouse is less
than 2000DPI
Only after switch to some input port the
keyboard and mouse don’t work
Make sure the USB cable connection from KVM
switch to host devices is correct and the USB
cable isn’t broken
Mouse is slowed down/lag/delayed in
Windows 95/98/2000 system
1. Go to device manager of the Windows, make
sure the KVM USB device is recognized by
Windows, if not, go to Windows control panel and
add new hardware manually
2. After KVM USB device is recognized by
Windows, install USB drivers in Windows device
manager
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine
to clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in
performance;
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to authorized
servicing personnel.
3) Replacement parts: When parts need replacing ensure the service uses
parts specified by the manufacturer or parts that have the same characteristics
as the original parts. Unauthorized substitutes may result in fire, electric shock,
or other hazards.
5
