foxunhd FX-SW07 User manual

Operating Instructions
www.foxunhd.com
FX-SW07
18Gbps 4x1 HDMI 2.0 Switch
4K@60Hz YUV4:4:4 ARC,CEC,HDR
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual for
future reference.
ABLE OF CONTENTS
Feature
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Remote Control Description
Product Service
Warranty

Operating Instructions
www.foxunhd.com
Feature
HDMI2.0 version(Support4K@60Hz YUV 4:4:4)
Bandwidth upto 18Gbps
HDCP2.2,CEC,ARC
Support HDR10
Support 4xHDMI in,IR or switch button to choose source out
Support output with audio extraction,RCA 2.0 SPDIF 5.1
Support audio mixing,Aux 2.0,SPDIF 5.1 (by pass mode)
Support Dolby True HD and DTS-HD master audio
Power supply:DC 5V
Dimension (L×W×H):178x84.1x28.1mm
NOTICE
Our company reserve the right to make changes in the hardware, packaging and any accompanying
documentation without prior written notice.
SPECIFICATIONS
Operating Temperature Range
-5 to +40℃(+23 to +104℉)
Operating Humidity Range
5 to 90%RH (No Condensation)
HDCP version
HDCP2.2 HDCP1.4(Auto choose depand TV version)
Support Audio format
Analog audio 2.0,SPDIF 5.1,Audio extraction
Support Video format
DTV/HDTV:4kx2k@60Hz YUV4:4:4
/1080P/1080i/720P/576P/576i/480P/480i
Control ways
Switch button and remoter control
Support Audio Format
Dolby true-HD etc and DTS-HD Master Audio(HDMI out)
Data transfer speed rate
6.75Gbps
Power supply
DC 5V
Transmission Distance
1080P 20m,4K@30Hz 10m,4K@60Hz under HDR can
support 3m
Dimension (L×W×H)
178x84.1x28.1mm
Note: Specifications are subject to change without notice. Mass and dimensions are approximate.
PACKING CONTENTS
1) Main Unit. 1xHDMI switch
2) 1x5V DC Power Supply.

Operating Instructions
www.foxunhd.com
3) Remote controller
4) 1xOperating Instructions
Notes: Please confirm if the product and the accessories and all in duded, if not please contact with
the dealers.
PANEL DESCRIPTION
Front Panel
1）SPDIF Audio out 2）Analog Audio out 3）IR Receiver
4）Source and Audio Led Led Lights 5）Switch Button 6）ARC Button
7）EDID Button 8）Audio in 9) Power Led light
10) Upgrade USB port
Back Panel
1）HDMI output port 2）HDMI input port 3）Analog audio in
4）SPDIF audio in 5) Power supply port
CONNECT AND OPERATE
1) Connect source devices to input ports of the switch by HDMI cable.
2) Connect HDMI output port to TV or other HDMI sink devices by HDMI cable.
3) Connet DC 5V power supply

Operating Instructions
www.foxunhd.com
Application1
Application 2
Attention: 1) Insert/Extract cable gently.
2) Please don’t insert into or pull out HDMI Cable when power on. please connect Cable only when power is off.

Operating Instructions
www.foxunhd.com
Remote Control Description
①Power on/off
②HDMI sources(1~4)
③ARC on/off
④Audio select button by EDID
⑤Mix Audio input select button
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzene to clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified service personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described in these operating
instructions. Refer all other servicing to authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts specified by the
manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes
may result in fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks to confirm that the unit
is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or workmanship, our Company

Operating Instructions
www.foxunhd.com
(referred to as "the warrantor" ) will , for the length of the period indicated as below,
(Parts(2)Year ,Labor(90) Days) which starts with the date of original purchase ("Limited Warranty period"),
at its option either(a) repair your product with new or refurbished parts, or (b) replace it with a new of a
refurbished product. The decision to repair or replace will be made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in your product during
the warranty period. This Limited Warranty is extended only to the original purchaser and only covers
product purchased as new. A purchase receipt or other proof of original purchase date is required for
Limited Warranty service.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES
NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER
damages which occurred in shipment, or failures which are caused by products not supplied by
warrantor,or failures which result from accidents,misuse,abuse,neglect, mishandling, misapplication,
alteration, faulty installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, or service by anyone other than a Factory
Service center or other Authorized Servicer, or damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY
COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS
WARRNTY. (As examples, this excludes damages for lost time, cost of having someone remove or
re-install an installed unit if applicable, travel to and from the service, loss of or damage to media or images,
data or other recorded content. The items listed are not exclusive, but are for illustration only.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR
RESPONSIBILITY.
