Foxwell TS7000 User manual

1
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Trademarks
FOXWELL is trademark of Shenzhen Foxwell Technology Co., Ltd.
All other marks are trademarks or registered trademarks of their respective
holders.
Copyright Information
©2023 Shenzhen Foxwell Technology Co., Ltd.
All rights reserved.
Disclaimer
The information, specifications and illustrations in this manual are based on the
latest information available at the time of printing.
Foxwell reserves the right to make changes at any time without notice.
Visit our website at
www.foxwelltech.us
For Technical Assistance, send us email at
[e-mail]

2
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Two-Year Limited Warranty
Subject to the conditions of this limited warranty, Shenzhen Foxwell
Technology Co., Ltd (“FOXWELL”) warrants its customer that this product is
free of defects in material and workmanship at the time of its original
purchase for a subsequent period of one (1) year.
In the event this product fails to operate under normal use, during the
warranty period, due to defects in materials and workmanship, FOXWELL
will, at its sole option, either repair or replace the product in accordance with
the terms and conditions stipulated herein.
Terms and Conditions
1 If FOXWELL repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period. No charge will be made to the customer for replacement parts or
labor charges incurred by FOXWELL in repairing or replacing the defective
parts.
2 The customer shall have no coverage or benefits under this limited
warranty if any of the following conditions are applicable:
a) The product has been subjected to abnormal use, abnormal conditions,
improper storage, exposure to moisture or dampness, unauthorized
modifications, unauthorized repair, misuse, neglect abuse, accident,
alteration, improper installation, or other acts which are not the fault of
FOXWELL, including damage caused by shipping.
b) The Product has been damaged from external causes such as collision
with an object, or from fire, flooding, sand, dirt, windstorm, lightning,
earthquake or damage from exposure to weather conditions, an Act of God,
or battery leakage, theft, blown fuse, improper use of any electrical source,
or the product was used in combination or connection with other product,
attachments, supplies or consumables not manufactured or distributed by
FOXWELL.
3 The customer shall bear the cost of shipping the product to FOXWELL.
And FOXWELL shall bear the cost of shipping the product back to the
customer after the completion of service under this limited warranty.
4 FOXWELL does not warrant uninterrupted or error-free operation of the
product. If a problem develops during the limited warranty period, the
consumer shall take the following step-by-step procedure:
a) The customer shall return the product to the place of purchase for repair
or replacement processing, contact your local FOXWELL distributor or visit
our website www.foxwelltech.us to get further information.

3
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
b) The customer shall include a return address, daytime phone number
and/or fax number, complete description of the problem and original invoice
specifying date of purchase and serial number.
c) The customer will be billed for any parts or labor charges not covered by
this limited warranty.
d) FOXWELL will repair the Product under the limited warranty within 30
days after receipt of the product. If FOXWELL cannot perform repairs
covered under this limited warranty within 30 days, or after a reasonable
number of attempts to repair the same defect, FOXWELL at its option, will
provide a replacement product or refund the purchase price of the product
less a reasonable amount for usage.
e) If the product is returned during the limited warranty period, but the
problem with the product is not covered under the terms and conditions of
this limited warranty, the customer will be notified and given an estimate of
the charges the customer must pay to have the product repaired, with all
shipping charges billed to the customer. If the estimate is refused, the
product will be returned freight collect. If the product is returned after the
expiration of the limited warranty period, FOXWELL’ normal service policies
shall apply and the customer will be responsible for all shipping charges.
5 ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS FOR
A PARTICULAR PURPOSE OR USE, SHALL BE LIMITED TO THE
DURATION OF THE FOREGOING LIMITED WRITTEN WARRANTY.
OTHERWISE, THE FOREGOING LIMITED WARRANTY IS THE
CONSUMER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED. FOXWELL SHALL NOT
BE LIABLE FOR SPECIAL, INCIDENTAL, PUNITIVE OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS
OF ANTICIPATED BENEFITS OR PROFITS, LOSS OF SAVINGS OR
REVENUE, LOSS OF DATA, PUNITIVE DAMAGES, LOSS OF USE OF
THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL,
COST OF ANY SUBSTITUTE EQUIPMENT OR FACILITIES, DOWNTIME,
THE CLAIMS OF ANY THIRD PARTIES, INCLUDING CUSTOMERS, AND
INJURY TO PROPERTY, RESULTING FROM THE PURC HASE OR USE
OF THE PRODUCT OR ARISING FROM BREACH OF THE WARRANTY,
BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY
OTHER LEGAL OR EQUITABLE THEORY, EVEN IF FOXWELL KNEW OF
THE LIKELIHOOD OF SUCH DAMAGES. FOXWELL SHALL NOT BE
LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE LIMITED
WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE
PRODUCT IS BEING REPAIRED.
6. Some states do not allow limitation of how long an implied warranty lasts,
so the one-year warranty limitation may not apply to you (the Consumer).
Some states do not allow the exclusion or limitation of incidental and

4
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
consequential damages, so certain of the above limitations or exclusions
may not apply to you (the Consumer). This limited warranty gives the
Consumer specific legal rights and the Consumer may also have other rights
which vary from state to state.

5
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Safety Information
For your own safety and the safety of others, and to prevent damage to the
equipment and vehicles, read this manual thoroughly before operating your
tool. The safety messages presented below and throughout this user’s
manual are reminders to the operator to exercise extreme care when using
this device. Always refer to and follow safety messages and test procedures
provided by vehicle manufacturer. Read, understand and follow all safety
messages and instructions in this manual.
Safety Message Conventions Used
We provide safety messages to help prevent personal injury and equipment
damage. Below are signal words we used to indicate the hazard level in a
condition.
Indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, may result
in moderate or minor injury to the operator or to bystanders.
Important Safety Instructions
And always use your tool as described in the user’s manual, and follow all
safety messages.
● Do not route the test cable in a manner that would interfere with driving
controls.
● Do not exceed voltage limits between inputs specified in this user’s
manual.
● Always wear ANSI approved goggles to protect your eyes from propelled
objects as well as hot or caustic liquids.
● Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid, refrigerant and
other debris produced by a malfunction engine can cause serious injury

6
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
or death. Do not use the tool in areas where explosive vapor may collect,
such as in below-ground pits, confined areas, or areas that are less than
18 inches (45 cm) above the floor.
● Do not smoke, strike a match, or cause a spark near the vehicle while
testing and keep all sparks, heated items and open flames away from the
battery and fuel / fuel vapors as they are highly flammable.
● Keep a dry chemical fire extinguisher suitable for gasoline, chemical and
electrical fires in work area.
● Always be aware of rotating parts that move at high speed when an engine
is running and keep a safe distance from these parts as well as other
potentially moving objects to avoid serious injury.
● Do not touch engine components that get very hot when an engine is
running to avoid severe burns.
● Block drive wheels before testing with engine running. Put the
transmission in park (for automatic transmission) or neutral (for manual
transmission). And never leave a running engine unattended.
● Do not wear jewelry or loose fitting clothing when working on engine.
● Don't connect or disconnect the equipments while the ignition is on or the
engine is running.

7
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Table of Contents
ONE-YEAR LIMITED WARRANTY .................................................................................................... 2
SAFETY INFORMATION ....................................................................................................................5
1 USING THIS MANUAL .................................................................................................................. 10
1.1 BOLD TEXT ...............................................................................................................................10
1.2 SYMBOLS AND ICONS ................................................................................................................ 10
2 INTRODUCTION ............................................................................................................................11
3 GETTING STARTED ..................................................................................................................... 14
3.1 POWERING UP THE SCANNER .................................................................................................... 14
3.2 SHUTTING DOWN THE SCANNER ................................................................................................ 15
3.3 SCREEN LAYOUT OF HOME SCREEN .......................................................................................... 15
4 VEHICLE IDENTIFICATION .......................................................................................................... 17
4.1 VEHICLE CONNECTION .............................................................................................................. 18
4.2 VIN READING ........................................................................................................................... 18
4.3 MANUAL SELECTION ................................................................................................................. 21
4.4 VEHICLE HISTORY .....................................................................................................................24
5 MY ACCOUNT ...............................................................................................................................25
5.1 REGISTRATION ..........................................................................................................................26
5.2 SIGN IN .................................................................................................................................... 29
5.3 MYACCOUNT ........................................................................................................................... 31
5.4 MYPRODUCTS ......................................................................................................................... 32
5.5 FEEDBACK AND SUGGESTIONS .................................................................................................. 32
6 UPDATE ........................................................................................................................................ 34
7 VCI MANAGER ..............................................................................................................................35
8 FIRMWARE UPDATE ....................................................................................................................38
9 DIAGNOSIS ...................................................................................................................................39
9.1 VEHICLE IDENTIFICATION ........................................................................................................... 40
9.1.1 Quick Scan ......................................................................................................................40
9.1.2 Control Modules .............................................................................................................. 43
9.2 DIAGNOSTIC OPERATIONS ......................................................................................................... 44
9.2.1 Read Codes .................................................................................................................... 44
9.2.2 Clear Codes .................................................................................................................... 47

8
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
9.2.3 Live Data ......................................................................................................................... 47
9.2.3.1 All Data .................................................................................................................... 48
9.2.3.2 Custom List .............................................................................................................. 50
9.2.3.3 Record data ............................................................................................................. 51
9.2.4 Active Test .................................................................................................................. 52
9.2.5 ECU Information ......................................................................................................... 53
9.3 COMPLAINTS ............................................................................................................................ 55
10 MAINTENANCE ...........................................................................................................................56
10.1 OIL RESET ............................................................................................................................. 57
10.2 ELECTRONIC PARKING BRAKE (EPB) SERVICE .........................................................................57
10.3 BATTERY REPLACEMENT (BRT) ...............................................................................................59
10.4 DIESEL PARTICULATE FILTER (DPF) REGENERATION ................................................................59
10.5 THROTTLE BODY ALIGNMENT (TPS/TBA) ................................................................................ 59
10.6 STEERING ANGLE SENSOR (SAS) CALIBRATION ....................................................................... 60
10.7 CONTINUOUS VARIABLE TRANSMISSION (CVT) ......................................................................... 60
10.8 GEAR LEARNING ..................................................................................................................... 60
10.9 TIRE PRESSURE MONITORING SYSTEM PROGRAMMING .............................................................60
10.10 INJECTOR CODING ................................................................................................................ 60
10.11 ABS BLEEDING .....................................................................................................................61
10.12 IMMOBILIZER .........................................................................................................................61
11 TPMS SERVICE OPERATIONS ..................................................................................................61
11.1 VEHICLE IDENTIFICATION ......................................................................................................... 61
11.2 TRIGGER OPERATIONS ............................................................................................................66
11.3 LEARN HELP ...........................................................................................................................75
12 DATA MANAGER ........................................................................................................................79
12.1 IMAGE .................................................................................................................................... 80
12.2 PDF REPORT ......................................................................................................................... 81
12.3 DATA PLAYBACK ..................................................................................................................... 83
13 SETTINGS ................................................................................................................................... 84
13.1 UNITS .................................................................................................................................... 84
13.2 LANGUAGE ............................................................................................................................. 84
13.3 FONT SIZE ..............................................................................................................................84
13.4 MODULE SORTING .................................................................................................................. 85
13.5 SORT TILES ............................................................................................................................88
13.6 REMOTE CONTROL ..................................................................................................................88
13.7 AUTOMATIC UPDATE ............................................................................................................... 89
13.8 SYSTEM SETTINGS ..................................................................................................................89
13.9 GENERAL ............................................................................................................................... 89
13.10 UNINSTALL VEHICLE SOFTWARE ............................................................................................ 89
13.11 CLEAR APP DATA .................................................................................................................. 90
13.12 PRINT SETTINGS ...................................................................................................................90

9
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
13.13 ABOUT ................................................................................................................................. 92
14 REMOTE SUPPORT ....................................................................................................................92
15 COVERAGE LIST ........................................................................................................................93
16 REMOTE KEY FREQUENCY MONITORING .............................................................................. 94
17 SENSOR INFORMATION ............................................................................................................94
18 AUXILIARY TOOLS .................................................................................................................... 95

10
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
1 Using This Manual
We provide tool usage instructions in this manual. Below are the
conventions we used in the manual.
1.1 Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
Example:
Select Diagnostic from the Home screen of the TS7000 application.
1.2 Symbols and Icons
1.2.1 Solid Spot
Operation tips and lists that apply to specific tool are introduced by a solid
spot.
Example:
When VIN hotkey is selected, a menu that lists all available options displays.
Menu options include:
●Automatic Read
●Scan VIN
●Manual Entry
1.2.2 Arrow Icon
An arrow icon indicates a procedure.
Example:
To connect to wall plug:
1. Connect the USB Type-C charge cable to scanner and plug it to the wall
socket.
2. Press the power switch of the scan tool to power it on; meanwhile the
scanner tool starts charging automatically also.
1.2.3 Note and Important Message
Note
A NOTE provides helpful information such as additional explanations, tips,
and comments.
Example:
NOTE
Test results do not necessarily indicate a faulty component or system.

11
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Important
IMPORTANT indicates a situation, which if not avoided, may result in
damage to the test equipment or vehicle.
Example:
IMPORTANT
Do not soak scanner as water might find its way into the scanner.
2 Introduction
The brand new Android scan tool TS7000 series inherits the same Foxwell
advantages in car fault diagnostic tech, such as multi manufacturer coverage,
service functions and accurate test data, making it the perfect tool for busy
garages or workshops, who need the latest technology at unbeatable value.
What’s more, TS7000 offer a full TPMS diagnosis and service, which
accurately activates and decodes TPM sensors and displays the data or any
faults.And It can do programming for Foxwell sensors.
2.1 Scanner Descriptions
This section illustrates external features, ports and connectors of the
scanner.
Figure 2-1 Front View

12
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
17” TFT LCD Touch Screen- shows menus, test results and operation
tips.
2Power Status Indicator - indicates the power status of the scanner.
The red light indicates that is charging or the battery is low, and the
green light indicates that it is fully charged or has electricity.
Figure 2-2 Top View
3TPMS Trigger - shows the location of the signal transmitter such as tire
pressure activation and programming.
4Power Switch - turns on the scanner, goes to sleep mode or wake up
the scanner from sleep mode. Press and hold for 3 seconds for start or
emergency shutdown. Double click to screenshot.
5USB Type-C Port - connects to wall plug to charge the scanner and can
be used for data transfer.
Figure 2-3 Back View
6Rear-Facing Camera - takes pictures of VIN number, faulty parts and
plates and shoots test videos.
7Speaker – outputs audio.

13
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
IMPORTANT
Do not use solvents such as alcohol to clean display.
Use a mild nonabrasive detergent and a soft cotton cloth.
2.2 Accessories
This section lists the accessories that go with the scanner. If you find any of
the following items missing from your package, contact your local dealer for
assistance.
Table 2-2 Accessories
2.3 Technical Specifications
Item
Description
Screen
7’’ TFT Capacitive LCD screen; 1024*600 pixel
Operation System
Android 9.0
Processor
Quad-core, 1.3GHz
Memory
2GB
SSD Hard drive
32GB
Camera
5 megapixel reat-facing
Communication
interface
WIFI 802.11 b/g/n Wireless LAN
Built-in Battery
5000mAh, Lithium-polymer battery, chargeable via 5V USB

14
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Table 2-3 Technical Specifications
3 Getting Started
This section describes how to power on/down the scanner, provides brief
introductions of applications loaded on the scanner and display screen
layout of the scan tool.
3.1 Powering up the Scanner
Before using the TS7000 applications (including updating the scanner),
please make sure to provide power to the scanner.
The unit operates on any of the following sources:
●Internal Battery Pack
●External Power Supply
3.1.1 Internal Battery Pack
The tablet scanner can be powered with the internal rechargeable battery.
The fully charged battery is capable of providing power for 5 hours of
continuous operation.
NOTE
Please turn off the tablet to save power when not use.
3.1.2 External Power Supply
The tablet can also be powered from a wall socket using the USB charging
adapter. The tablet also charges its internal battery pack through USB
Type-C cable.
power supply
Protocols
ISO9141-2, ISO14230-2, ISO15765-4, K/L lines, Double K Line
SAE-J1850 VPW,SAE-J1850PWM,CAN ISO 11898,
High-speed, Middle-speed, Lows-peed and Single wire CAN,
KW81, KW82, GM UART, UART Echo Byte Protocol, Honda
Diag-H Protocol, TP2.0, TP1.6, SAE J1939, SAE J1939, SAE
J1708,Fault-Tolerant CAN,CAN FD, DOIP
Working Temperature
-10 to 70°C
Storage Temperature
-20 to 80°C
Operating Humidity
5%-95% Non-Condensing
Dimensions
220*130*28mm (L*W*H)
Weight
0.87kg (Main unit)

15
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
3.2 Shutting Down the Scanner
All vehicle communication must be terminated before shutting down the
scanner. Exit the Diagnostic application before powering down.
To shut down the scanner:
1. Press and hold the Power button of the scanner for 3 seconds.
2. Click the Power off to shut down or Reboot to restart.
3.3 Screen Layout of Home Screen
After the scanner turning on, the screen show main menu of the application.
Figure 3-1 Sample Home Screen

16
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
3.3.1 Application Menu
Figure 3-2 Sample Main Menu of Application
This section briefly introduces the applications that are preloaded into the
scanner:
●TPMS - leads to screens for TPMS function.
●Diagnostic - leads to test screens for diagnostic trouble code information,
freeze frame, live data and ECU information.
●Maintenance - leads to screens for common used special functions like
Oil light reset, EPB, BRT, and DPF etc.
●OE - enters vehicle selection by selecting "sensor brand" and part
number (OE number) at one time..
●OBDII - leads to OBDII screens for all 10 generic OBD system tests.
●Update - leads to screens for Foxwell ID registration and updating the
scanner.
●Vehicle History - leads to the record of vehicle tests,
●Data Manager - leads to screens for saved screenshots, pictures and
test reports, and playing back live data, as well as debug logging data.
●My Account - displays your Foxwell ID information like registered
products and personal information and allows for sending us feedbacks
about the scanner.
●Settings - leads to screens for adjusting default settings to meet your
own preference and view information about the scanner.
●VCI Manager - VCI manage (Bluetooth and VCI binding, unbinding,
rescan vehicle software)
●Firmware Update - VCI firmware update.
●Remote Control - leads to TeamViewer to get remote support from
Foxwell team or remote vehicle diagnostic.

17
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
●Cover List - leads to the list of software coverage.
●Remote key - leads to screens for checking RF Remote Keyless Entry
(key FOB).
●Sensor information - leads to screens for checking own sennsor
information.
●Auxiliary tools – more tools like camera and file browser.
3.3.2 Diagnostic Menu
Touch Diagnostic at the TS7000 application menu, and the Diagnostic
menu will display. The operations of the buttons of Diagnostic menu are
described in the below table.
Figure 3-3 Sample Diagnostic Menu Screen
No.
Name
Description
1
Search
Lets you search a vehicle make quickly.
2
VIN
Shortcut for VIN reading menu, which typically
includes Automatic Read, Scan VIN and
Manual Entry.
3
Quick Location
Allows you to find a vehicle by initials.
Table 3-1 Title Bar of Diagnostic Menus
4 Vehicle Identification
This section illustrates how to use the scanner to identify the specifications
of the vehicle under test.

18
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
The vehicle identification information presented is provided by the ECM of
the vehicle being tested. Therefore, certain attributes of the test vehicle must
be entered into the scan tool to ensure the data displays correctly. The
vehicle identification sequence is menu driven. Simply follow the screen
prompts and make a series of choices. Each selection you make advances
you to the next screen. Exact procedures may vary somewhat by vehicle.
It typically identifies a vehicle by any of the following means:
●VIN Reading
●Manual Selection
NOTE
Not all identification options listed above are applicable to all vehicles.
Available options may vary by vehicle manufacturer.
4.1 Vehicle Connection
To connect to vehicle:
1. Locate the data link connector (DLC). The DLC is generally located under
the dash on the driver side of the vehicle.
Figure 4-1 Sample Vehicle Connection Screen
2. Attached the diagnostic cable to the scanner and tighten the captive
screws to ensure good connection.
3. Connect a correct adapter to the data cable according to the vehicle
being serviced and plug it into the vehicle DLC.
4. Switch the ignition key to the ON position.
4.2 VIN Reading
VIN button on the title bar is a shortcut for VIN reading menu, which
includes Automatic Read,Manual Entry, eliminating the need for
navigating through complicated car identification process.

19
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Figure 4-2 Sample VIN Hotkey Screen
4.2.1 Automatic Read
Automatic Read allows to identify a vehicle by automatically reading the
vehicle identification number (VIN).
To identify a vehicle by Automatic Read:
1. Select Diagnostic from home screen of the TS7000 application.
2. Click VIN and choose Automatic Read from the option list.
3. When the scan tool builds connection with the vehicle, the VIN number
displays. If the Vehicle Specification or VIN code is correct, press the OK
to continue.

20
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
Figure 4-3 Sample Automatic Read Screen
4. If it takes too long to get the VIN code, press Cancel to stop and input the
VIN manually. Or if failed to identify the VIN, please input the VIN
manually or click Cancel to quit.
Figure 4-4 Sample Manual Entry Screen
4.2.2 Manual Entry
Manual Entry allows to identify a vehicle by inputting VIN manually.
To identify a vehicle by Manual Entry:
1. Select Diagnostic from home screen of the TS7000 application.
