WARNING:
If the information in these instructions are not followed ex-
actly,afireorexplosionmayresultcausingpropertydamage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
donotuseanyphoneinyourbuild-
ing.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
908-785e
MODELS: U31-NG2 Natural Gas U31-LP2 Propane
07/15/09
U31 Gas Insert
Owners &
Installation Manual
www.regency-fire.com
www.hampton-fire.com
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.excalibur-fire.com

WARNING
HOT GLASS
DO NOT TOUCH
NEVER
WILL
CAUSE BURNS
GLASS
UNTIL COOLED
ALLOW CHILDREN
TO TOUCH GLASS
CHILDREN AND ADULTS SHOULD BE ALERTED TO
THE HAZARDS OF HIGH SURFACE TEMPERATURES,
ESPECIALLY THE FIREPLACE GLASS, AND SHOULD
STAYAWAYTOAVOIDBURNSORCLOTHINGIGNITION.

2FPI U31-2 Gas Fireplace Insert
FPI GAS
FIREPLACE INSERT
Note: Oversize faceplate is 44" x 28" (1118 mm x 711mm)
TO THE NEW OWNER
Congratulations! You are the owner of a state-of-the-art Gas Insert by FPI.
The FPI Gas Insert Series of hand crafted appliances has been designed to provide you
with all the warmth and charm of a fireplace, at the flick of a switch. The models U31-NG2
and U31-LP2 of this series have been approved by Warnock Hersey for both safety and ef-
ficiency. As it also bears our own mark, it promises to provide you with economy, comfort
and security for many trouble free years to follow. Please take a moment now to acquaint
yourself with these instructions and the many features of your FPI Fireplace.

3
FPI U31-2 Gas Fireplace Insert
TABLE OF CONTENTS
FPI GAS FIREPLACE INSERT
OPERATING INSTRUCTIONS
Operating Instructions .............................................23
Lighting Procedure ..................................................23
Shutdown Procedure...............................................24
First Fire .............................................................24
Automatic Convection Fan Operation......................24
Normal Operating Sounds
of Gas Appliances.............................................24
Copy of Lighting Instruction Plate............................24
MAINTENANCE
Maintenance............................................................25
Gold Plated Trim...............................................25
Log Replacement..............................................25
Glass Gasket ....................................................25
Door Glass Replacement..................................26
Bay Glass Removal ..........................................26
Flush Glass Replacement.................................26
Fan Maintenance..............................................26
Parts List .............................................................27
WARRANTY
Warranty .............................................................35
Unit Dimensions ........................................................2
Safety Label...............................................................4
MA Code - CO Detector
(for the state of Massachuettes only) ........................5
INSTALLATION
For Your Safety..........................................................6
Specifications ............................................................6
Installation into a Solid Fuel Fireplace.......................6
General Safety Information........................................6
Installation Checklist..................................................7
Materials Required ...................................................7
Minimum Fireplace Clearances.................................7
Clearances to Combustibles......................................7
Conversion to Propane Kit.........................................8
Gas Connection.........................................................8
High Elevation ...........................................................8
Draft Hood Connection..............................................8
Venting ...............................................................9
Combustion & Ventilation....................................9
Gas Pressure Test.....................................................9
Gas Insert Aeration System.......................................9
Test for Flue Spillage.................................................9
Optional Brick Panel ...............................................10
Log Installation ........................................................11
Faceplate & Trim .....................................................14
Glass Front Installation
Standard Flush Door (1 panel)..........................14
Flush Louvers ...................................................15
Optional Bay Front (3 panel).............................15
Bay Louvers......................................................15
Double Door Screen................................................15
Wiring Diagram........................................................16
Full Screen Front.....................................................17
Hampton Cast Faceplate Installation.......................19
Hampton Cast Faceplate Grill .................................20
Excalibur Surround..................................................21
Optional Wall Thermostat........................................23
Optional Remote Control ........................................23
Final Check .............................................................23

4FPI U31-2 Gas Fireplace Insert
SAFETY LABEL
Thisisacopyofthelabelsthataccompanyeach
U31-2GasInsert.Wehaveprintedacopyofthe
contents here for your review. The safety label
is located on a plate inside the base of the unit
visible when the bottom louver is opened.
NOTE: FPI units are constantly being im-
proved. Check the label on the unit
and if there is a difference, the label
on the unit is the correct one.
DO NOT REMOVE THIS LABEL /
NE PAS ENLEVER CETTE ETIQUETTE
Serial No. / No de serie
218
218
Min. supply pressure 5" WC (1.25kPa)
Low Setting Man. pressure 1.1" WC (0.27kPa)
Max. Manifold pressure 3.8" WC (0.95kPa)
Orifice size 37 DMS (2.64mm)
Minimum input 14,500 Btu/h (4.25kW)
Altitude 0-2000ft (0-610m)
Maximum input 30,000 Btu/h (8.79kW)
Use Conversion Kit (Part #400-970)
Min. supply pressure 5" WC (1.25 kPa)
Low Setting Man. pressure 1.1" WC (0.27 kPa)
Max. Manifold pressure 3.8" WC (0.95 kPa)
Orifice size 40 DMS (2.49 mm)
Minimum input 13,000 Btu/h (3.81kW)
Altitude 2000-4500ft (610-1370m)
Maximum input 27,200 Btu/h (7.97kW)
908-786e
Mantel Clearances in Masonry
Fireplace Installation
NATURAL GAS FIREPLACE INSERT:
MODEL U31-NG2
PROPANE FIREPLACE INSERT:
MODEL U31-LP2
1
12" WC (2.99 kPa)
2.9" WC (0.72 kPa)
11" WC (2.74 kPa)
52 DMS (1.6mm)
13,700 Btu/h (4.01kW)
0-2000ft (0-610m)
27,500 Btu/h (8.057kW)
2" WC (2.99 kPa)
2.9" WC (0.72 kPa)
11" WC (2.74 kPa)
53 DMS (1.5mm)
12,400 Btu/h (3.63 kW)
2000-4500ft (610-1370m)
25,000 Btu/h (7.33 kW)
Use Conversion Kit (Part #400-971)
FPI Fireplace Products International Ltd.
Delta BC, CANADA
MADE IN CANADA / FABRIQUE AU CANADA
Model: U31-NG2 Model: U31-LP2
Factory Equipped For Altitude 0-2000ft. (0-610m)
Field Convertible For Altitude 2000-4500ft.(610-1370m)
Duplicate Serial number
K
L
A
B
O
N
P
Q
M
R
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or
Natural Gas and Propane Installation Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the United States, or when such a standard is not applicable,
ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard or ANSI A119.2 ou NFPA 501C Standard for Recreational
Vehicles
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located,
manufactured (mobile) home where not prohibited by local codes. See owner's manual for details.
WARNING.This fireplace has been converted for use with a gas fireplace insert only and cannot be used for burning wood or solid fuels unless
all original parts have been replaced, and the fireplace re-approved by the authority having jurisdiction.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation ANSI Z223.1,
National Fuel Gas Code ou CSA-B149.1 en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24
CFR Part 3280, Manufactured Home Construction and Safety Standard. Si ces normes ne sont pas pertinentes, utilisez la norme
ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard, ou ANSI A119.2 ou NFPA 501C Standard for Recreational
Vehicles.
AVERTISSEMENT : Ce foyer a été converti pour utilisation avec un foyer au gaz encastrable et ne peut être utiliser pour brûler du bois ou
d'autres combustibles solides à moins que toutes les pièces d'origine aient été remplacées et que le foyer ait été approuvé de nouveau par
l'autorité compétente.
For use with glass doors certified with the appliance only
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison
préfabriquée ou mobile (É.-U. seulement) installée à demeure si les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de
renseignements. Cet appareil ne peut pas être utilisé avec d'autres gaz sauf si une trousse de conversion certifiée est fournie.
Pour utilisation uniquement avec les portes en verre certifiées avec l'appareil
Minimum Clearances to Combustibles from Insert
Side wall A 10"(255mm)
Ceiling B 47-1/2"(1205mm)
Alcove Width K 48"(1220mm)
Max. Alcove Depth L 36"(915mm)
NOTE: for Zero Clearance Kit clearances to
Combustibles. See manual for details.
Max. Mantel depth M 12"(305mm)
Mantel height N 17"(432mm)
Mantel depth O 3-1/2"(89mm)
Mantel height P 13"(330mm)
Floor Q 19-1/2"(495mm)
Mantel Clearances in Zero Clearance
Kit Installations
Max. Mantel depth M 12"(305mm)
Mantel height N 22"(432mm)
Listed:
Certified for/Certifi e pour:
Tested to:
WN# 16455
CANADA and U.S.A.
CGA-2-17-M91, ANSI Z21.88a-2007 / CSA 2.33a-2007
VENTED GAS FIREPLACE HEATER
/ FOYER AU GAZ À ÉVACUATION
é
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS. /
NE PAS UTILISER AVEC DUCOMBUSTIBLE SOLIDE.
FOYER AU
GAZ À ÉVACUATION -
For the State of Massachusetts, installation and repair must be done by a plumber or gasfitter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, flexible connectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve.
The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm
with battery back up in the same room where the gas appliance is installed.

5
FPI U31-2 Gas Fireplace Insert
REQUIREMENTS
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

6FPI U31-2 Gas Fireplace Insert
INSTALLATION
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The FPI Gas Insert must be installed in ac-
cordancewiththeseinstructions.Carefullyread
all the instructions in this manual first. Consult
the building authority having jurisdiction to de-
termine the need for a permit prior to starting
the installation.
NOTE: Failure to follow the instructions
could cause a malfunction of the
heater which could result in death,
serious bodily injury, and/or prop-
erty damage. Failure to follow
these instructions may also void
your fire insurance and/or warranty.
This appliance can be used with a
thermostat.
FOR YOUR SAFETY
This appliance requires air for proper combus-
tion. Always provide adequate combustion
and ventilation air. Follow instructions and
information in CAN/CGA B149 (in Canada) or
theNationalFuelGasCodeANSIZ223.1(inthe
USA), regarding requirements for combustion
and ventilation air.
SPECIFICATIONS
At pressures over 1/2 psig, the pipe to the unit
must be disconnected.
Gas Input Capacity:
Natural Gas 30,000 Btu/h
Propane 27,500 Btu/h
Min. Output (Fan Off)
Natural Gas 21,000 Btu/h
Propane 19,400 Btu/h
Max. Output (Fan On)
Natural Gas 22,000 Btu/h
Propane 20,500 Btu/h
Fuels: Approved for use with both natural
gas, and propane. Approved as is for use at
0' to 2,000'. With a field installed conversion
kit 0' - 4,500'.
Electrical: 120V A.C. system.
Circulation Fan: Variable speed, 127 CFM.
Log Set: Ceramic fibre, 7 per set.
Vent System: Minimum 4" B-Vent or listed
gas fuel vent liner.
GAS PRESSURE TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa).Disconnect pipingfrom valveat testpres-
sures over 1/2 psig (3.45 kPa).
POLICY FOR SOLID
FUEL BURNING AND
FACTORY BUILT
FIREPLACES
TheFPIU31-2maybeinstalledandventedinto
any solid fuel fireplace that has been installed
in accordance with the National, Provincial and
local building codes and is constructed of non-
combustible materials.
1) Installer must mechanically attach the sup-
plied label to the inside of the firebox of the
fireplace into which the gas fireplace insert
is installed.
WARNING: This fireplace has been con-
verted for use with a gas fireplace insert
only and cannot be used for burning wood
or solid fuels unless all original parts have
beenreplaced,andthefireplacere-approved
by the authority having jurisdiction.
2) Do not cut any sheet-metal parts of the
fireplace, in which the gas fireplace insert
is to be installed.
3) Ifthefactory-builtfireplacehasnogasaccess
hole(s) provided, an access hole of 1-1/2"
(37.5mm) or less may be drilled though
the lower sides or bottom of the firebox in
a proper workmanship like manner. This
access hole must be plugged with a non-
combustible insulation after the gas supply
line has been installed.
4) The fireplace flue damper can be fully
blocked open or removed for installation of
the gas fireplace insert.
5) The fireplace and fireplace chimney must
be clean and in good working order and
constructed of non-combustible materials.
6) The chimney cleanouts must fit properly.
7) Refractory (firebricks), glass doors, screen
rails, screen mesh and log grates can be
removedfromthefireplacebeforeinstalling
the gas fireplace insert.
8) Smokeshelves, shieldsand bafflesmay be
removed if attached by mechanical fasten-
ers.Ifanypartisremoveditmustnotweaken
the structural integrity of the factory built.
9) Trim panels or surrounds shall not seal
ventilation openings in the fireplace.
BEFORE YOU START
Safeinstallationandoperationofthisappliance
requires common sense, however, we are
required by the Canadian Safety Standards
and ANSI Standards to make you aware of
the following:
General Safety Information
1) The appliance installation must conform
withlocalcodesorintheabsenceoflocal
codes, with CAN/CGA B149 (in Canada)
or the National Fuel Gas Code ANSI
Z223.1.Thisapplianceshouldbeinstalled
by a qualified gas fitter technician only.
2) Installation and repair should be done
by a qualified service person.
3) The appliance should be inspected before
use and at least annually by a professional
service person. More frequent cleaning
may be required due to excessive lint from
carpeting,beddingmaterial,animalhair,etc.
It is imperative that control compartments,
burners and circulating air passageways of
the appliance be kept clean.
4) See general construction and assembly
instructions. This appliance may only be
installed in a vented, noncombustible fire-
place.
5) This appliance is Listed for bedroom instal-
lations. In Canada room heaters must be
installed with a Listed Millivolt Thermostat.
Someareasmayhavefurtherrequirements,
check local codes before installation.
6) Thisunit isnotapproved forinstallation into
a mobile home.
7) Always connect this insert to a vent sys-
tem venting to the outside of the building
envelope. Never vent to another room or
inside a building. Make sure that the vent
is properly sized and is of adequate height
to provide the proper draft.
8) Inspect the venting system annually for
blockage and any signs of deterioration.
9) Any glass removed for servicing must be
replaced prior to operating the appliance.
10) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.

7
FPI U31-2 Gas Fireplace Insert
INSTALLATION
NOTE:MantelclearancesforInstallationinto
a Zero Clearance Kit are different. Please
refer to the Zero Clearance Kit Manual for
details.
MINIMUM FIREPLACE
DIMENSIONS
The minimum fireplace dimensions for the FPI
gas fireplace insert are shown in the following
diagrams:
Combustible Mantel Clearances
with Bay & Flush Louvers in
Masonry Installation
Note: A non-combustible mantel may be
installed
at a lower
heightifthe
framing is
made of
metalstuds
covered
with a non-
combusti-
ble board.
11) Failure to position the parts in accordance
with the diagrams in this manual or failure
to use only parts specifically approved with
thisappliancemayresultinpropertydamage
or personal injury.
12) Due to high temperatures, the appliance
should be located out of high traffic areas
and away from furniture and draperies.
Children and adults should be alerted to
the hazards of high surface temperatures,
especially the fireplace glass and gold
trims, and should stay away to avoid burns
or clothing ignition. Young children should
be carefully supervised when they are in
the same room as the appliance. Clothing
or other flammable material should not be
placed on or near the appliance.
INSTALLATION
CHECKLIST
The FPI Gas Insert is installed as listed be-
low.
1) Unit Location - check Clearances to Com-
bustibles on page 6.
2) Make the gas connections (see page 7).
Convertto PropaneGas if necessary, page
7.
3) Install the flue or liner to the sliding draft
hood. See page 8.
4) InstallVenting,page8.Slidetheunitintothe
fireplace. Attach draft hood to the insert.
5) Testgaspressure, page 8. Check aeration,
page 8.
6) Test for flue spillage, page 8.
7) Install the optional brick panels. See page
9.
8) Install the log set. See page 9.
9) Assembleandinstallthefaceplateandtrim.
See page 11.
10) InstalltheglassfrontandoptionalBayFront.
See pages 11 & 12.
11) Install both louvers. See page 12.
12) Install Optional Double Screen Door. See
page 12
13) InstallOptionalRemoteControlandOptional
Wall Thermostat, page 20.
14) Finalcheck:Beforeleavingthisunitwiththe
customer, the installer must ensure that the
appliance is firing correctly. This includes:
a) Clockingtheappliance toensurethe
correct firing rate.
b) Adjusting the primary air, if required,
to ensure that the flame does not
carbon. See page 10.
c) Ensuringthattheapplianceisventing
correctly. See page 9.
MATERIALS REQUIRED
Noelectricalpowersupplyisrequiredforthegas
control to operate. A120 VoltAC power cord is
hooked up to the fan. Plug the 3 wire cord into
a suitable receptacle. Do not cut the ground
terminaloffunderanycircumstances. When
connectedwith120volts,theappliancemustbe
electrically grounded in accordance with local
codes,orintheabsence oflocalcodes,withthe
current CanadianElectricalCodeCSAC22.1(in
Canada) or with the current National Electrical
Code ANSI/NFPA 70-1987 (in U.S.A.).
NOTE:This unit isequipped with aheat sen-
sor thermodiscwhichwillpreventthe
blower from operating until the unit
reaches the correct temperature.
CLEARANCES TO
COMBUSTIBLES
From Unit
Sides A10" / 255 mm
Ceiling B47.5" / 1205 mm
Mantle C See mantle
clearances
From Standard Surround (26" x 40")
Sides D4" / 100 mm
Ceiling E41.5" / 1055 mm
Max. Mantel Depth G 12" / 305 mm
Min. Alcove Width K48" / 1220 mm
Max. Alcove Depth L 36" / 915 mm
* No Hearth Required
Note:IfyouareinstallingtheMoldedFaceplate
or Excalibur Surround, the minimum fireplace
dimensions are as follows:
Width (at front): 29" (737mm)
Depth: 16" (406mm)
Emissions from burning wood or gas could
contain chemicals known to the State of Cali-
fornia to cause cancer, birth defects or other
reproductive harm.

8FPI U31-2 Gas Fireplace Insert
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS
FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !!
Conversion Kit from Natural Gas to Propane
Model #402-969 for: U31-NG2 Units
1) Turn the unit off and allow it to cool to room
temperature.
2) Unplug or disconnect power source to
stove.
3) Remove glass front (see manual).
4) Remove logs and brick panels (if in-
stalled).
5) Remove the Grate by removing the screws
on each side of the grate.
Remove the 2 screws holding
the grate in position.
Remove the 2 screws,
push Burner Tray to the left, and lift off.
6) Remove the Burner Tray by removing the
screws on each side of the tray. Push the
tray to the left and lift up.
7) Removeburnerorificewith1/2"wrenchand
replace with the #52 orifice in the Kit.
Diagram 1
8) Remove regulator from valve and replace
with Propane regulator. See diagram 1.
Burner
Orifice
9) Pull off the pilot cap to expose the pilot
orifice.
10) Unscrew the pilot orifice with the allen key
and replace with the LP pilot orifice in the
kit.
11) Replace Burner Tray and reverse steps 5)
to 1).
12) Adjust the burner aeration setting to 1/8"
to 3/16" as required for the best flame pic-
ture.
INSTALLATION
GAS CONNECTION
3) Locate the center point where the vent will
pass through the chimney above the appli-
ance. Move the appliance into the exact
location where it is to be installed. Ensure
that the Insert is level.
4) The installer must provide a valve with a
pluggedtapping,accessiblefor test gauge
connection, immediately upstream of the
gas supply connection to the appliance.
HIGH ELEVATION
Thisunit is approved in Canadafor altitude 0 to
2000 ft. with the orifice supplied. For 0' - 4500'
usethe optional fieldconversion kit (Part#400-
970forNaturalGasunitsandPart#400-971for
Propane units). In USA refer to ANSI Z223.1-
1988, Appendix F, for re-sizing orifice.
DRAFT HOOD
CONNECTION
1) Attach the vent to the flue collar on the
detachable draft hood. The flue collar of
the appliance will fit inside a standard vent
and may be fastened directly to the vent by
sheet metal screw. Diagram 1.
2) Before pushing the appliance into position
inside the fireplace, align the draft hood
with the guides on the insert top and push
forward. While pushing the unit back into
place keep pulling the draft hood forward
until the screw hole in the spill tube aligns
GAS CONNECTION WARNING:
Only persons licensed to work
with gas piping may make the
necessarygasconnectionstothis
appliance.
1) If the appliance is to be installed into an
existing chimney system, thoroughly clean
the masonry or factory built fireplace.
2) The appliance is provided with an opening
on the left hand side of the control com-
partment. A 1/2" gas supply pipe must be
brought near this inlet hole. (See Diagram
3 on page 11).

9
FPI U31-2 Gas Fireplace Insert
INSTALLATION
TEST FOR FLUE
SPILLAGE
A " spillage" test must be made before the
installedunitisleftwiththecustomer.Follow
the procedure below:
1) Start all exhaust fans in the home and then
close all external doors and windows in the
house.
2) Light the unit and set controls to maximum.
Turn fan off.
Themanifoldpressureiscontrolledbyaregulator
builtintothegascontrol,andshouldbechecked
at the pressure test point. The pressure check
shouldbecarriedoutwiththeunitburningandthe
setting should be within the limits specified.
GAS INSERT AERATION
SYSTEM
The aeration adjustment rod is attached to the
airshutterwhichislocatedjustabovetheorifice
bracket. The rod is used to adjust the aeration
on the main burner without having to take the
appliance apart.
Theburner aerationis factory setbut mayneed
adjusting due to either the local gas supply, air
supply or altitude.
Natural Gas: 1/8" (3.2mm) open
Propane: 3/16" (4.8mm) open
Note: Anydamageduetocarboningresult-
ingfrom improperly settingtheaera-
tion controls is NOT covered under
warranty.
Note: Aeration Adjustment should only
be performed by an authorized FPI
Installer at the time of installation or
service.
with the screw hole in the top of the firebox.
Thescrew issecured throughthe insidetop
ofthefireboxintothebottomofthespilltube.
(Ifscrewholesdonotlineupthendrafthood
is not positioned correctly.)
NOTE: final gas connection should be
afterunit isin place to avoid damage
to line when pushing the unit into
position.
VENTING
Diagram 1
Diagram 2
THE APPLIANCE MUST NOT BE
CONNECTEDTOACHIMNEYFLUE
SERVING A SEPARATE SOLID
FUEL BURNING APPLIANCE.
Thisapplianceisdesignedtoattachtoa4"diam-
etertypeB-Ventorlistedgasfueltypeventliner
runningthefulllengthofthechimney.Aminimum
flue height of 12 feet is recommended. B-Vent
must be supported by a vent support - supplied
by vent manufacturer. See chart on this page
for minimum distances from roof.
TheFPI Insert incorporates its own internal
draft hood, so no additional external draft hood
is required.
Periodically check that the vent is unrestricted
and an adequate draft is present when the unit
is in operation. (See page 8 for spillage test.)
Before installing vent system ensure that the
damper plate is open and secure to prevent
the damper plate from falling down and crush-
ing the liner.
WARNING: Operation of this ap-
pliance when not connected to a
properly installed and maintained
venting system or tampering with
the blocked vent shutoff system
canresultincarbonmonoxide(CO)
poisoning and possible death.
Combustion and Ventilation Air
WARNING: This appliance needs
freshairforsafeoperationandmust
be installed with provisions for ad-
equate combustion and ventilation
air available to the room in which it
is to be operating.
Follow CAN/CGA B149 (in Canada) or ANSI
Z223.1 (in the USA) requirements, and any
local codes or regulations of the enforcing
authority.
Air for combustion is drawn in through the front
of the unit, therefore, the front of the unit must
be kept clear of any obstructions.
GAS PRESSURE TEST
The unit is preset to give the correct gas input
at the specified manifold pressures shown on
thelabel.The maximum gas manifold pressure
is:
Natural Gas 3.8" w.c.
Propane 11.0" w.c.

10 FPI U31-2 Gas Fireplace Insert
Diagram 1
3) Afterfiveminutes,testthatthereisa“pull”on
thefluebyplacingasmokematch,cigarette
or similar device which gives off smoke,
in front of the spill tube. To ensure a valid
test, place a scrap piece of sheet metal (or
other noncombustible material) between
the spill tube and the upper louver, this will
prevent the natural convection of the unit
from interfering with the test. See diagram
1.
Diagram 1
Diagram 2
Diagram 3
The smoke should be drawn into the spill tube.
If the smoke is still not drawn into the spill tube,
turn the unit off and check for the cause of the
lack of draft. If necessary, seek expert advice.
Forwindturbulentsites,awindcapmayremedy
the problem.
Note: The thermally activated safety switch
willsensethechangeintemperatureandshut
down the gas valve in the event of a severe
downdraft or a blocked or disconnected
vent. The switch acts as a safety shut-off to
preventabuild-upofcarbonmonoxide. Ifthe
flue is blocked or has no "draw", the switch
will automatically shut off the supply of gas
within 5 - 10 minutes. Tampering with the
switch can result in carbon monoxide (CO)
poisoning and possible death.
Iftheheaterturnsoffbecauseoflackofdraft
during the spillage test, check for the cause
and if necessary, seek expert advice.
The thermally actuated safety switch will
automatically reset after it has cooled off.
The switch will continue to cycle until the
draftproblemiscorrected.DONOTBYPASS
OR DISCONNECT THIS SWITCH.
OPTIONAL
BRICK PANEL
1) Unwrap the brick pattern panels from the
protective wrapping.
2) Remove the glass front if it is already in-
stalled.
3) Puttherearbrickpanelflatagainsttheback
of the unit.
4) Beforeinstallingthesidebrickpanels,loosen
the screws for the brick tabs enough so that
youcanslide thebricktabsonto thescrews
easily but that the tabs are secure. For the
location of the side brick tab screws see
diagram 1.
5) Remove the brick tabs and slide the side
brick panels into position. See diagram 3.
Install the brick tabs. See diagram 2.
INSTALLATION

11
FPI U31-2 Gas Fireplace Insert
LOG SET INSTALLATION
INSTALLATION
Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until
they are replaced. Broken logs can interfere with the pilot operation.
The gas log kit contains the following:
a) 02-43 Rear Log
b) 02-45 Front Right Log
c) 02-56 Middle Left Log
d) 02-46 Left Top Log
e) 02-47 Center Log
f) 02-48 Middle Right Log
g) 02-44 Front Left Log
h) 902-154 Embers
i) 902-153 Rockwool
j) 902-179/P Vermiculite
k) 946-669 Platinum Embers
(supplied with packaged manual)
Note: Install Optional Brick Panels prior to installing logs.
1) Carefully remove the logs from the box and unwrap
them. The logs are fragile, handle with care - do not
force into position.
2) Sprinkle the vermiculite around the firebox base. Take
some of the embers (approx. 1/3 of the bag) and
sprinkle over the vermiculite.
3) Place Rear Log A)02-43 on the two pins on the rear
log support.
Vermiculite
and embers Vermiculite
and embers
Vermiculite
and embers
Pins on Rear Log Support
4) Place Front Right Log B)02-45 on the two pins as
shown.
A)02-43
B)02-45
The "02" refer numbers (i.e. 02-43) are
molded into the rear of each log.

12 FPI U31-2 Gas Fireplace Insert
Logs D)02-46 and E)02-47 in position.
6) Place the Left Top Log D)02-46 on the pin on Log
C)02-56 and on top of the cutout on Log A)02-43.
7) Place the notch in Center Log E)02-47 over Log B)02-
45 and across the cutout on Log A)02-43.
Cutout
Pin
Cutout
Notch
8) Position notch in Front Right Log F)02-48 on Log
E)02-47 and push the bottom right edge against the
bracket on the burner tray and the front edge of the
rear burner.
Notch
Bracket
D)02-46
E)02-47
F)02-48
C)02-56
A)02-43
B)02-45
A)02-43
B)02-45
E)02-47
Logs A)02-43, C)02-56, and B)02-45 in position
C)02-56
5) Place the Middle Left Log C)02-56 on the two pins as
shown.
INSTALLATION

13
FPI U31-2 Gas Fireplace Insert
10) Place the embers and Rockwool on the exposed front
burner tray.
9) Place Front Left Log G)02-44 onto the 2 front pins as
shown.
G)02-44
F)02-48
B)02-45
Bracket
A)02-43
Front edge of
rear burner
The bottom right edge of Log F)02-48 must sit snugly against
the bracket and the front edge of the rear burner.
Side View
11) Separate platinum embers and place on and around
the embers and rockwool on the burner tray. Avoid
stacking platinum embers.
12) Test fire to ensure proper light off (make sure flame
flows smoothly from one end of burner to the other. If
there is any flame hesitation, check that area for any
blockage of the burner port.
The "02" refer numbers (i.e. 02-43) are
molded into the rear of each log.
A) 02-43 D) 02-46 G) 02-48
C) 02-44 B) 02-56 F) 02-47 E) 02-45
INSTALLATION

14 FPI U31-2 Gas Fireplace Insert
Diagram 4
Diagram 5
Rear View: Trim Assembly
Diagram 2
Diagram 3
Rear View: Faceplate Assembly
Diagram 1
FACEPLATE & TRIM
INSTALLATION
1) Laythe faceplate panelsflat, face downon
something soft so they don't scratch.
2) Takethetopfaceplateandaligntheholesin
itwiththeholesinthesidepanels. Usingthe
screwsprovided,attach from the top of the
panel(theholesinthetoppanelareslightly
larger than the holes in the side panel to
facilitate easier installation). Diagram 1.
Hint: Don't tighten the screws down com-
pletely at this point, continue on with steps
3 and 4 and do a trial fit to the unit. Make
anynecessaryadjustmentsandwhenitfits
properly then tighten down the screws.
Hearth Trim Option: Hearth Trim is an
option that can be used to finish off the
installationwhenthebottomofthefireplace
ishigher than thehearth or toraise the fire-
place.Attach the HearthTrimtothe bottom
ofthefaceplatesidepanelswiththescrews
provided. See Diagram 1.
3) Usingtheconnectors provided, join the left
side trim (with the ON/OFF switch) to the
top trim. Diagram 2. Connect the right side
trim to the top trim.
4) Place the trim on the assembled faceplate
panels, aligning the wire connections from
the switches with the notch on the left side
panel.
5) Connect the fan switch wires by taking the
black and red wires with the male ends (in
INSTALLATION
the grey harness) and connect them with
the wire connectors from the fan speed
control.
6) ConnecttheON/OFFswitchwiresbytaking
theblackandredwireswiththefemaleends
and connect them to the ON/OFF switch.
7) Tuck the wires into the faceplate to keep
them away from the insert using the clip
provided. Attach the clip to the rear of the
faceplate to ensure that the wires do not
touch the side of the unit. Diagram 3.
8) The power cord should be run behind the
faceplate panel.
9) Attach the brass trim to the faceplate by
drillinga1/8"holethroughintothefaceplate
usingthe holein thetrimas aguide. Fasten
the trim to the faceplate panels using the
plated screws. Diagram 4.
10) Attach the faceplate panels to the insert
body using the 4 remaining black screws.
Diagram 5.
11) Push the Regency logo plate into the two
holes in the bottom left corner of the face-
plate.
FLUSH FRONT
INSTALLATION
1) Install Logs before going on to the next
step. See the Log Installation instruction
sheet or page 9.
2) Install the bottom glass trim by hooking the
triminto thelip on thefirebox base.Thetrim
will not fit into place if the glass is installed
first.

15
FPI U31-2 Gas Fireplace Insert
BAY FRONT
INSTALLATION
1) Place the bay door onto the 2 pins on the
top of the unit.
2) Install bottom louver by sliding the two
bracket clips into the brackets located
underneath the bay door and secure with
2 screws into the bracket on the bottom of
the Bay Front as per diagram above.
3) Slide the valve extension knobs onto the
valve knobs. match the correct ext. knob
with the valve knob.
BAY LOUVERS
1) Install top louver by sliding the two bracket
clips into the brackets located on top of the
baydoor.Seebelow.Thefittedlouverleaves
a small gap between faceplate bottom and
louver top.
INSTALLATION
FLUSH LOUVERS
3) Place the bottom of the flush glass behind
the bottom glass trim.
4) Securethe glass with thetwoglass clips at
the top corners of the glass. Secure glass
clipswith the screwsprovided. Do notover
tighten as this could break the glass.
5) Slide in the top glass trim under the spring
clips.
2) Position2magnetsonthebackofeachtrim
piece close to the ends. Place the top and
bottom trim pieces on the bay front.
3) Install top and bottom louvers.
Note: The top and bottom trim pieces are
different, check diagrams above and
below.
DOUBLE DOOR
SCREEN
1) Pull out the
top louver
and the top
glass trim.
2) Loosen the
screws so
the glass
clips can
be turned
aside and
the flush
glass re-
moved.
1) The Top Louver is held in place by friction
fit, if the Louver needs to be adjusted; bend
the bracket out as shown in the diagram.
2) InstalltheSpringHingesontheleftandright
side of the bottom of the Firebox using 2
screws per hinge.
Bottom Louver
Hinge
Location
3) PlacetheBottomLouvernearthehinge.Flip
hinge over the Bottom Louver and secure
using 3 screws.

16 FPI U31-2 Gas Fireplace Insert
INSTALLATION
WIRING DIAGRAM
CAUTION: Label all wires prior
to disconnection when servicing
controls. Wiring errors can cause
improper and dangerous opera-
WARNING: Electrical Grounding Instructions
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should
be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from
this plug.
This heater does not require a 120V A.C. sup-
ply for operation. In case of a power failure, the
burner switch and the optional remote control/
thermostat will continue to operate. However,
a 120V A.C. power supply is needed for the
fan/blower operation.
Caution: Ensure that the wires do
not touch any hot surfaces and are
away from sharp edges.
Slots
Push Screen
Door down
firmly
to lock into
place.
3) Open Bottom Louvers.
4) Remove the bottom glass trim.
Discard both top & bottom glass trim.
5) Replace the glass and secure with the two
glassclips. Donotovertightenasthiscould
break the glass.
Make sure the glass is centered.
6) Insert side hooks on the double screen
door into the 4 slots between the faceplate
and the glass and lower assembly into the
lockingposition.Pushdownfirmlywithboth
hands to lock into place.
Side Hook
Insert Screen Door
hooks into the 4
slots between the
faceplate and the
flush door.

17
FPI U31-2 Gas Fireplace Insert
FULL SCREEN FRONT
INSTALLATION
1) Hold the full screen door up against the unit in order to make the
following wire connections.
Pull the ON/OFF connector wires from the firebox and connect them
to the switch.
Connect the fan switch wires with the wire connectors from the fan
speed control. Place clips over wires and tuck into side trim.
2) Lift unit up slightly and push down on the corners of the Bottom Trim
Bracket and slide under unit. Unit should touch tabs on Bottom Trim
Bracket.
Bottom Trim Bracket
Push in Corners
3) Completely secure the full screen door to the unit by securing 4
screws to the Left and Right Side Trims.
.
NOTE: When mounting the full screen door to the unit, the inside
flange of the side trims are to fit over the inner side of the unit flange
and NOT next to the outer side of the unit flange.
Inside flange of Side Trim goes over
the inner side of the unit flange.

18 FPI U31-2 Gas Fireplace Insert
INSTALLATION
5) Place Bottom Frame near hinge. Flip hinge over Bottom Frame and
secure with 3 screws.
4) Install Spring Hinges on the Left and Right Side of the bottom of the
firebox using 2 screws per hinge.
6) The Top Frame is held in place by friction fit, if the frame needs to
be adjusted; bend the bracket accordingly.
Top Frame
Hinge
Screen Door
7) InstalltheLeftandRightSideScreen Doorsinthe fullyopenposition
by placing over top of the hinges on the full screen door.
8) Close screen doors.
NOTE: If you find that the doors do not align properly, adjust the
hinges on the door(s) by loosening them and adjust accordingly.
Bottom Frame
Hinge Location

19
FPI U31-2 Gas Fireplace Insert
HAMPTON CAST
FACEPLATE INSTALLATION
1) Lay the faceplate panels flat, face down on something soft so they
don't scratch.
2) Attachthesidefillerbracketsto theleftandrightsidesusing3screws
and washer per side.
3) Attach the right and left cast sides to the top using 2 screws per
side.
5) ConnecttheON/OFFswitchwires
by taking the black and red wires
with the blue female ends thru
theholeprovidedandconnecting
them to the ON/OFF switch.
6) Connect the fan switch wires by
taking the black and red wires
with the male ends (in the grey
harness) thru the hole provided
and connect them with the wire
connectors from the fan speed
control.
7) Insert wires into the strain relief
and install into switch box as-
sembly.
8) Place the switch box assembly
over the boss on the rear left
side piece and secure with one
screw.
Ensure that the
top and sides are
aligned.
4) Use a measuring tape to ensure that the distance between the left
and right side pieces is 28" (711mm).
Switch Box Assembly
Boss on rear left side
piece.
9) Tuck the wires into the faceplate to keep them away from the insert
using the clip provided. Attach the clip to the rear of the faceplate
to ensure that the wires do not touch the side of the unit.
NOTE: Do not install Cast Faceplate when unit is installed
into a Zero Clearance Unit.
28"
10) The power cord should be run behind the
faceplate panel.
NOTE: There are filler brackets specifically for each side. The way
to differentiate this is that on the side of the brackets there are 2
mounting holes. The side where there is a 7/16" gap from the top
of the bracket to the mounting hole, must face the top.
INSTALLATION
