Fröling Lambdatronic S 3100 User manual

INSTRUCTIONS CUSTOMER
V24.12 and up
ZURÜCK ZURÜCK
HZG 0 / ÖL
HEIZUNG 1
HEIZUNG 2
HEIZUNG 3
HEIZUNG 4
PUMPE 1
PUMPE 2
PUMPE 3
GEBLÄSE
EINGABE
0
A
HEIZU NG
1
PUMPE HZG 0 / ÖL GEBLÄSE
234123
23456789
1
(1) Two-line display
(2) Menu buttons
(3) Button: Start/Stop
(4) Status LED
(5) Operating display for
pumps
(6) Fan
(7) Switch heater 0 / oil
(8) Switch pump 1...3
(9) Switch heater 1...4
Lambdatronic®
S 3100

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 2 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
1 Contents
1Contents 2
2Hazard information 2
3Operation 3
3.2 Switching on the system 3
3.3 Operating elements 3
3.4 Important control steps 4
3.5 Changing the target boiler temperature 4
3.6 Changing the user code 5
4Status displays 5
5Menu overview 6
6User menu 7
6.2 SET 7
6.3 ERROR DISPLAY 9
7Troubleshooting 9
7.2 Error message list 10
8Remote control 11
9Table of heating programs 11
10 List of parameter changes 12
2 Hazard information
Please read these operating instructions carefully!
Failure to follow the instructions and advice could cause damage to the appliance and personal injury.
Main switch RISK
Never stop the boiler using the main switch!
⇒Do not stop burn-off.
⇒The main switch may only be activated in “Shut down” or “Off”
mode.
Hot surfaces WARNING
Risk of burns from hot parts and poisonous smoke inhalation from
smouldering wood!
Before carrying out work in the boiler:
Wait until the “SHUT DOWN” or “OFF” status has been reached and
the boiler has cooled down.
Then switch off the main switch.
Electrical Hazards RISK
Electric shock may cause injury or death!
Only licensed technicians may perform work on electrical
components!
Observe all applicable standards and regulations!
Keep liquids away from the controller
Unauthorized personnel are forbidden from working on electrical components!
Liquids Note
Damage possible!
Keep liquids away from the insulation and control:
Only use a damp cloth to clean the system

Control System Lambdatronic S 3100
CUSTOMER INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 3 of 12
3 Operation
3.2 Switching on the system
The main switch is on the left hand side of the control casing.
FRÖLING
. . . . . . . . .
After switching on the control unit, the word FRÖLING appears.
The control unit performs a system check.
Off
Boiler temp. 30°←
After the system check, the display menu will appear.
You can read the ACTUAL values in this menu.
DANGER: Never stop the boiler using the main switch!
Do not stop burn-off.
The main switch may only be pressed in “Off” or “Shut down” mode.
Note: burn-off cannot be stopped with the red button 0 on the FHG Turbo 3000.
3.3 Operating elements
The system is operated using a 4-button control unit with a clear menu structure.
All of the parameters necessary for operation are at the customer’s disposal.
ZURÜC
ZURÜCK EINGABE
Feuer-Aus
Kesseltemp. 80°
BETRIEB
STÖRUNG
No. Component Function
1 Two line display Operating modes, operating status, parameters, error messages
2 Start - key I
Stop - key O
Start boiler operation
No function!
3 Status LED
Indicates the system’s operating status:
Long green flashes: System switched on
Short green flashes: System switched off
Short red flashes: System error, not acknowledged
Long red flashes: System error, acknowledged
4
Up-arrow key
Down-arrow key
Enter key
Back - key
Move the arrow up in the menu, increase or activate the parameters
Move the arrow down in the menu, decrease or deactivate the parameters
Switch between menus, call up or confirm entries
Switch between menus, not confirmed
2
3
1
4
BACK ENTER
Shut down
Boiler temp. 80°
OPERATION
ERROR

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 4 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
3.4 Important control steps
Push-button Notes
Start system Press green button (I)
or open the insulating
door
The main switch must be switched on
Shut down the system Burn-off must not be stopped. After burn-off
the boiler automatically goes into shut down
mode.
CAUTION DANGER:
Never stop the boiler using the main
switch!
1. Select menu
ZURÜC
ZURÜCK EINGABE You will find an overview of the menu
structure in chapter 5 Menu overview
2. Select
parameters
3. Press the “Enter”
key
EINGABE
A question mark appears next to the
parameter value. The value can now be
changed.
4. Change the value
The “up-arrow” key increases the value.
The “down-arrow” key decreases the
value.
Changing parameters
and values
5. Confirm with the
“Enter” key
EINGABE
Value is saved.
If the “Back” key is pressed instead of the
“Enter” key, the change is not applied.
3.5 Changing the target boiler temperature
Set boiler temp.
80°←
3x
EINGABE
To switch from the display menu to the parameter display, press
the ENTER key three times.
Set boiler temp.
80°?
EINGABE
If you press the ENTER key once more, a question mark will
appear beside the parameter value.
Set boiler temp.
75°?
You can now change the target boiler temperature using the
“arrow up” and “arrow down” keys.
Set boiler temp.
75°←
EINGABE
Confirm the desired value by pressing ENTER.
Heating
Boiler temp. 73°←3x
ZURÜC
ZURÜCK
To return to the display menu, press the Back button three times.
BACK ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
BACK

Control System Lambdatronic S 3100
CUSTOMER INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 5 of 12
3.6 Changing the user code
There is a special code called “child lock” to prevent children or untrained persons from adjusting the settings. In the
“child lock” code you will only be able to see the display menu and the error display. It is not possible to change the
parameters.
Code Designation Display
0 Child lock -------
1 Customer CUSTOMER
Switched off
Off ←The user code must be changed in the display menu.
User name
CUSTOMER←
Hold down the “arrow down” button until you reach the end of the display menu. You will be
able to see the current user level here.
User Code: 0 ?
Press the “Enter” button. A question mark will appear. You can now enter the code (0 for
“child lock” or 1 for “customer”) – confirm by pressing “Enter”. If you enter the wrong code,
the code for “child lock” will automatically be used.
User code: -----. The name of the set user level (-------) will appear briefly.
Off
Boiler temp. 30°←The display will then go back to the top of the display menu.
4 Status displays
There are seven boiler statuses:
Boiler Status Functions
Heating up boiler status during the heating process up to a certain minimum smoke gas
temperature.
Heating The boiler regulates combustion according to the target boiler values.
Maintain constant burn the boiler goes into “maintain glow” mode with very low power consumption.
ID fan at standstill, air dampers closed to minimum opening. If the output requirement
increases again, the boiler automatically switches to “Heating” mode.
Door open The insulating door is open, the fan runs at maximum speed.
Shut down The boiler has burnt out to minimum glow!
Error ATTENTION error! Troubleshooting: see chapter 7 Troubleshooting!
Off The system only regulates the connected heating components.

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 6 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
5 Menu overview
NOTE: The number of parameters depends on the system settings – not all of them are visible in the display!
Boiler status:
e.g.: heating
Boiler temp.
Flue gas temp.
Primary air
Residual O2
Sec.air
Storage.up
DHW temp.
Ex. temp.
Day:
Storage.mi
Storage.low
Time:
Version:
Runtime:
Boardtemp:
Operator
Name customer
Set
Enter
Back

Error display
Enter
Back
Boiler temp.
Enter
Back
Set boiler temp.

DHW Enter
Back
Set DHW temperature
Set DHW temp. 2
Reload when DHW below
Start of the first loading
End of the first loading
Start of the second loading
End of the second loading
Heat only once / day
Legionella heating 65°
Legionella heating day

Heating times
Enter
Back
Heating prog. 1...
Enter
Back
Heating phase1 start
Heating phase1 end
Heating phase2 start
Heating phase2 end
Heating prog. 2...
Heating prog. 14...
....
same as heating
prog. 1

Heating circuit 1

Enter
Back
Heating curve
Enter
Back
Flow temp. at outer -10°C
Weekly program
Flow temp. at outer +10°C
Enter
Back
MoTuWeThFrSaSu
1 1 1 1 4 12 3

Flow temp. Reduction
Ex. temp. heating limit
Ex. temp. heating limit
Frost. prot. temp. (inside)

Heating circuit 2
same as heating
Heating circuit 4
Heating circuit 3

RBG 3100
Alloc. 11

Set day
Set time
90
80
70
60
50
40
30
20
... Flow temperature
-15 -10 -5 0 5 10 15 20
Outside temperature
Example: radiator
heatin
g
curve
Example:
underfloor heating
heating curve
Allocation of heating
times 1...14
DHW temp.2
Hot water temp.
Coll. temp.
Boiler ret.
Oil boiler
Flow temp.1
Flow temp.2
Flow temp.3
Flow temp.4
Solar
Enter
Close
d

Set hot water temp.
Room temp. set value
Room temp.TV reduced
Process for changing parameters:
Open memory Change value Save value
Enter ? 
Enter
ID fan
Storage tank
Enter
Back

Storage temp. heat. circ. launch
Storage up. min. temp.
Coll. pump

Control System Lambdatronic S 3100
CUSTOMER INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 7 of 12
6 User menu
Here you will find an overview of the user menu:
The menu parameters are described afterwards.
Menu Function
SET Changing parameters and values
ERROR DISPLAY View the current error
6.2 SET
The “SET” user menu allows you to modify parameters and values.
The display will only show the parameters belonging to the selected system.
Boiler temp. ... ←Set boiler temp. 80°←The boiler temperature will be adjusted to this value.
Storage tank ... ←Storage temp. heat
circ. launch 35°←
This is the minimum value for launching the heating circuit in
combination with a storage tank.
(applies to sensor 1 in conjunction with storage tank)
Storage up. min. temp. 65°←If the top store temperature falls below this value, the “Storage
temp. too low – RELOAD” warning will appear.
DHW ... ←Set DHW temperature 55°←When the set temperature is reached in the DHW, the DHW
loading pump switches off.
Set DHW temp 2 55°←When the set temperature is reached in the DHW, the DHW
loading pump 2 switches off.
Reload if boiler under 45°←Recharging of the boiler is authorized when the DHW temperature
is below this value.
Start of the first loading
session 03:00←Start of the authorization for the first DHW loading session
End of the first loading
session 05:00←End of the authorization for the first DHW loading session
Start of the second loading
session 14:00←Start of the authorization for the second DHW loading session
End of the second loading
session 16:00←End of the authorization for the second DHW loading session
Heat only once / day N←“Yes” stops repeated heating in one day.
Legionella heating65° Y←The DHW is heated to at least 65° once a week.
Legionella heating day Sa←Day of the week for Legionella heating.
Solar ... ←Set hot water temp 55°←Set hot water temp when using a domestic hot water heat
exchanger.
Heating times ... ← Heating prog. 1... ←
Heating phase 1 start 06:00 Lowered outside of heating phases.
Heating phase 1 end 22:00
Heating phase 2 start 23:00
Heating phase 2 end 23:00

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 8 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
Heating prog. 2 ... ←
Heating prog. 3 ... ←
Heating prog. 4 ... ←
Heating prog. 5 ... ←
Heating prog. 6 ... ←
Heating prog. 7 ... ←
Heating prog. 8 ... ←
Heating prog. 9 ... ←
Heating prog. 10... ←
Heating prog. 11... ←
Heating prog. 12... ←
Heating prog. 13... ←
Heating prog. 14... ←
...two heating phases each,
like heating prog. 1
You can program up to 14 heating times each with
two heating phases.
These are assigned to the individual days of the
week in the “Heating circuit 1-4 / weekly program”
parameter .
Heating circuit 1... ←Heating curve ... ←Flow temp. at
outer -10°C 60°←
Flow temp. at
outer +10°C 40°←
Only in conjunction with heating circuit control.
You can adjust the heating curve to the respective
system in these two work points.
Weekly program MoTuWeThFrSaSu
1 1 3 1 1 2 5
Heating time programs 1-14 are assigned to the
days of the week for heating circuit 1.
Room temp. set value 20°←Set room temperature value during the heating phase
Æis only visible with remote control.
Room temp. TV reduced
amount 16°←
Set room temperature value during the drawdown phase
Æis only visible with remote control.
Flow temperature reduction 15°←The flow temp. is reduced by this value in the drawdown phase.
Ex. temp. heating limit 18°←If the outside temperature exceeds this heating limit during the heating
phase, the heating circuit pump and mixer are switched off.
Ex. temp. heating limit
Drawdown mode 7°←
If the outside temperature exceeds this heating limit during the
drawdown phase, the heating circuit pump and mixer are switched off.
Frost prot.temp. (inside) 10°←If the room temperature or the flow temperature is lower than the
set value, the heating circuit pump will be switched on.
Heating circuit 2... ←Programming as in heating circuit 1
Heating circuit 3... ←Programming as in heating circuit 1
Heating circuit 4... ←Programming as in heating circuit 1
RBG 3100
Alloc. 14
RBG 3100: possible allocation combinations
Normal: allocation and control of this heating circuit
only
Master: allocation to respective heating circuit,
control of other heating circuits also possible
Other combinations have no function
Normal Master
HC1 1 11
HC2 2 12
HC3 3 13
HC4 4 14
No allocation 0
Set day Set the current date.
Set time Set the current time.
90
80
70
60
50
40
30
Flow temperature
-15 -10 -5 0 5 10 15 20 .. -15 -10 -5 0 5 10
Example: radiator heating curve
Exam
p
le: underfloor heatin
g
heatin
g
curve

Control System Lambdatronic S 3100
CUSTOMER INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 9 of 12
6.3 ERROR DISPLAY
Displays the current errors and warnings.
The red status LED flashes simultaneously.
Acknowledge faults and warnings by pressing the “ENTER” key.
Short red flashes: Warning or fault persists: not acknowledged
Long red flashes: Warning or fault persists: but acknowledged
Warning: The status LED automatically changes to green, as soon as the warning is no longer valid.
Fault: The boiler is only authorized to operate after elimination of the error has been acknowledged by pressing
the “ENTER” key – the status LED returns to green.
Chapter 7.2 Error message list contains a list of possible error messages.
7 Troubleshooting
What to do when a fault occurs:
1. Find and eliminate the fault.
2. Acknowledge the fault by pressing Enter.
3. If the system does not start up again automatically after you have acknowledged the fault,
press start button I.
General fault in power supply area:
Error Cause Elimination of error
No display, no power on
control
FI protective circuit breaker or line
protection is switched off Switch back on
Main switch is off Switch on
Glass tube fusing for control blown Replace fuse – note current: 10 A
NOTE for heating up: if the ID fan does not continue running when you close the insulating door, press the
green start button.

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 10 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
7.2 Error message list
A warning or fault is always displayed in plain text as soon as it occurs.
The red signal light will also flash.
Warning (W): Boiler remains operational.
Fault (F): Boiler switches off immediately, heating circuit control and pumps remain on.
Error text
Type Cause of error Elimination of error
Ex. temp. error W Sensor signal faulty Check sensor and sensor cable
DHW temp. error W Sensor signal faulty Check sensor and sensor cable
DHW temp2. error W Sensor signal faulty Check sensor and sensor cable
Remote control 1 error W Sensor signal faulty Check sensor and sensor cable
Remote control 2 faulty W Sensor signal faulty Check sensor and sensor cable
Remote control 3 error W Sensor signal faulty Check sensor and sensor cable
Remote control 4 error W Sensor signal faulty Check sensor and sensor cable
Boiler return temp. error W Sensor signal faulty Check sensor and sensor cable
Boiler temp. error W Sensor signal faulty Check sensor and sensor cable
Solar return temp. error W Sensor signal faulty Check sensor and sensor cable
Oil boiler temp. error W Sensor signal faulty Check sensor and sensor cable
Check primary air damper W Feedback signal varies from control
signal by more than 5% for 5 minutes
Actuator not turning.
Actuator incorrectly fitted
Incorrect direction of rotation
Damper movement impeded
Connection line damaged
Check actuator and cable
Correct fitting:
0% = damper closed
On actuator: swap connection for left
with right
Check dampers can turn
Check cable and connection
Storage temp low RELOAD W “Top storage tank” temperature
insufficient for heat supply
Info only – no error
Æautomatic acknowledgment
Store temp. mid error W Sensor signal faulty Check sensor and sensor cable
Store temp. up error W Sensor signal faulty Check sensor and sensor cable
Store temp. low error W Sensor signal faulty Check sensor and sensor cable
Return feed temp. too LOW
too long
W Return feed temperature too cold Check return feed lift, check sensor
Check sec. air damper W Feedback signal varies from control
signal by more than 5% for 5 minutes
Actuator not turning.
Actuator incorrectly fitted
Incorrect direction of rotation
Damper movement impeded
Connection line damaged
Check actuator and cable
Correct fitting:
0% = damper closed
On actuator: swap connection for left
with right
Check dampers can turn
Check cable and connection
Secondary flow temp. error W Sensor signal faulty Check sensor and sensor cable
Safety temp. limiter released F Boiler has overheated, substantial
reduction in heat consumption:
Heating and pump switches have
gone off.
Pump suddenly stops
Slide valves/cut-offs closed.
Release safety temperature limiter
(only possible once boiler has cooled
down)
Set switch back to “AUTO”
Check pump
Reopen slide valves/cut-offs
Flow temp.1 error W Sensor signal faulty Check sensor and sensor cable
Flow temp.2 error W Sensor signal faulty Check sensor and sensor cable
Flow temp.3 error W Sensor signal faulty Check sensor and sensor cable
Flow temp.4 error W Sensor signal faulty Check sensor and sensor cable
Safety time wrong air W Filling doors, soot doors or blanking
plate not tightly sealed
Check seal on doors. Readjust,
tighten screws if necessary

Control System Lambdatronic S 3100
CUSTOMER INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 11 of 12
8 Remote control
The remote control also contains a room sensor which sends the current room temperature to the control.
Switch settings:
Ä... Override circuit: ignores the reduction
... Automatic: heating phases as per heating time program
e... Drawdown mode: ignores the heating phases
Hand wheel ... allows you to adjust the temperature by ± 3°C
9 Table of heating programs
You can enter your personal heating times here:
Heating phase 1 Heating phase 2 Heating phase 1 Heating phase 2
Start End Start End Start End Start End
Heating prog. 1 Heating prog. 8
Heating prog. 2 Heating prog. 9
Heating prog. 3 Heating prog. 10
Heating prog. 4 Heating prog. 11
Heating prog. 5 Heating prog. 12
Heating prog. 6 Heating prog. 13
Heating prog. 7 Heating prog. 14
You can make a note of your weekly program settings for the individual heating circuits here:
One of the 14 heating programs can be allocated to each heating circuit for each day of the week.
Weekly program
for:
Monday Tuesday Wednesday Thursday Friday Saturday Sunday
Heating circuit 1
Heating circuit 2
Heating circuit 3
Heating circuit 4
Sample allocation of heating times for heating circuit 1:
Heating circuit 1 1 1 2 1 4 3 3

Lambdatronic S 3100 Control System
CUSTOMER INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 12 of 12 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
10 List of parameter changes
Parameter Changed to, date
Boiler temp. ... ←Set boiler temp. 80°←
DHW ... ←Set DHW temp. 55°←
Set DHW temp 2 55°←
Reload if boiler under 45°←
Start of the first loading
session 03:00←
End of the first loading
session 05:00←
Start of the second loading
session 14:00←
End of the second loading
session 16:00←
Heat only once / day N←
Legionella heating65° Y←
Legionella heating day Sat←
Solar ... ←Set hot water temp 55°←
Heating circuit 1... ←Flow temp. at outer -10°C 60°←
Flow temp. at outer +10°C 40°←
Heating circuit 2... ←Flow temp. at outer -10°C 60°←
Flow temp. at outer +10°C 40°←
Heating circuit 3... ←Flow temp.at outer -10°C 60°←
Flow temp. at outer +10°C 40°←
Heating circuit 4... ←Flow temp. at outer -10°C 60°←
Flow temp. at outer +10°C 40°←
Room temp. set value 20°←
Room temp.TV reduced
amount 16°←
Flow temperature reduction 15°←
Ex. temp. heating limit 18°←
Ex. temp. heating limit
Drawdown mode 7°←
Frost prot.temp. (inside) 10°←
RBG 3100 alloc.: 0
Notes:

Lambdatronic S 3100 Control System
SERVICE INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 24 of 24 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
Notes:

Control System Lambdatronic S 3100
SERVICE INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 23 of 24
10 List of parameter changes
Parameter Changed to, date

Lambdatronic S 3100 Control System
SERVICE INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 22 of 24 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
9.11 Heating circuit pump 0 / Oil - oil boiler contact
The HCP 0 / oil connection can be used either for heating circuit pump 0 or as an oil boiler contact depending on the
system settings.
Connecting a HCP 0 up to 2 Ampere:
Connecting a HCP 0 up to 5 Ampere:
External feed:
Connection as an oil boiler contact:
NOTE:
⇒for pumps with speed control: always set pumps to maximum power level.
⇒Only operate power switch for pumps when the system is switched off!
LV
N
Lambdatronic 3100
HCP
0
LV
N
to oil boiler control:
floating contact for
boiler release
Lambdatronic 3100
LV
N
Lambdatronic 3100
HCP
0
L
PE
N

Control System Lambdatronic S 3100
SERVICE INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 21 of 24
9.9 Console RBG 3100
A shielded cable is required for the console. The cable must not be longer than 20 m. Console RBG 3100 also
includes a room sensor which sends the current room temperature to the control.
Note: RXD and TXD must be “crossed over": RXD on TXD, TXD on RXD.
9.10 PC Visualisation
The system is connected to the PC via a serial interface.
Maximum cable length: 15 m
+US
TXD
RXD
GND
Lambdatronic
3100
1
2
3
4
5
PC visualisation 6
7
8
9
User extension
9 pin
D-sub connector
GND
RXD
TXD
+
US
Lambdatronic
3100
GND
RXD
TXD
+US
RBG 3100
back view

Lambdatronic S 3100 Control System
SERVICE INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 20 of 24 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
blue
red
green yellow
9.6 Air damper actuator
Connection is via a 5-pin, numbered cable
Type LM24-SR-T-C2 (3-pin)
Type LM24-5P0-T-C2 (6-pin)
9.7 Flue gas sensor
9.8 Remote control
The remote control also contains a room sensor which sends the current room temperature to the control.
Switch settings:
Ä... Override circuit: ignores the reduction
... Automatic: heating phases as per reduction program
e... Drawdown mode: ignores the heating phases
Hand wheel ... allows you to adjust the temperature by ± 3°C
Lambdatronic 3100
-
+
RC
Lambdatronic 3100
12345
Y/P3
P2
GND
+R
+L
Lambdatronic
3100
4
5
1/6
3
2
6-pin cable
Y/P3
P2
GND
+R
+L
Lambdatronic
3100
3
2
1
5
3
2
5
2
3

Control System Lambdatronic S 3100
SERVICE INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 19 of 24
9 Connection instructions
Please follow the connection instructions below.
9.2 Mains connection
L, N, PE... feed for the whole control, cable width 1.5 mm²
L1... remains free
9.3 Heating circuit pumps for underfloor or wall heating
In addition to the temperature limit by the control, the following is required for safety reasons:
A flow contact thermostat must also be connected upstream of the respective heating circuit pump.
9.4 Jumper setting for actuators
The jumpers on the motherboard 3100 must be adjusted to the type of actuator in the air dampers:
Actuator Jumpers on motherboard 3100
without feedback 3 terminals on motor Do not set JP1, JP2
with feedback 6 terminals on motor Set JP1, JP2
⇒Both actuators must be the same type.
⇒Note “Actuator with feedback" parameter in “System selection"!
9.5 Jumper setting for solar control
With the solar control the mixer 3 and mixer 4 outputs are used as pump outputs.
The jumpers on expansion board 2 must be set as shown in the table:
Jumpers on expansion board 2 System
Set JP1 12,13,14
Set JP2 12,14
⇒JP1 and JP2 on expansion board 2 must not be set without a solar control (for mixer drive).
Feed cable
L1
PE
N
L
Lambdatronic
3100
remains free

Lambdatronic S 3100 Control System
SERVICE INSTRUCTIONS
B 018 10 04 FRÖLING Heizkessel und Behälterbau GmbH
Page 18 of 24 A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone]
HCP 3
Heating circuit pump 3
HCP 4
Heating circuit pump 4
HCP 2
Heating circuit pump 2
HCP 1
Heating circuit pump 1
Sensor 9
Sensor 7
Sensor 8
Sensor 6
FS 4
Flow sensor 4
RC 3
Remote control 3
RC 4
Remote control 4
FS 3
Flow sensor 3
FS 1
Flow sensor 1
ES 1
External sensor 1
FS 2
Flow sensor 2
RC 1
1Remote control
RC 2
Remote control 2
Mixer
3
Mixer
1
Mixer
4
Mixer
2
Flat ribbon cable
from motherboard
Flat ribbon cable
from motherboard
Heater 4
Heater 2
Heater 3
Heater 1
PE2
PE1
N2
N1
L2
L1
Motherboard power supply
Motherboard power supply
Expansion board 2 3100
Expansion board 1 3100
L
N
L
N
L
N
L
N
OPEN
OPEN
OPEN
OPEN
CLOSED
CLOSED
CLOSED
CLOSED
N
N
N
N
View of top level
W
H
A
W
H
A
W
H
A
W
H
A
JP2 JP2
JP1 JP1

Control System Lambdatronic S 3100
SERVICE INSTRUCTIONS
FRÖLING Heizkessel und Behälterbau GmbH B 018 10 04
A-4710 Grieskirchen, Industriestraße 12, Tel.: [phone] Page 17 of 24
8 Connection diagram for control
A
W
W
W
H
H
H
PEL
L
L1
L1
+L
+L
+R
+R
P2
P2
Y/P3
Y/P3
+US
+US
GND
GND
RXD
RXD
TXD
TXD
N
Mains
ID fan
Pump 2
Pump 1
Pump 3
Burner /
Secondary
air
Primary air
TSS
Door sensor switch
Sensor 3
Sensor 2
Sensor 1
Sensor 4
Sensor 5
HCP 0
N
PE1 PE2
A
W
H
A
A
HCP / oil
Lambda
board
3100
optional
View of bottom level
Control
element
3100
Flat ribbon cable to
expansion board 1
Flat ribbon cable to
expansion board 2
L
N
L
N
L
N
L
N
wh 12VAC
wh 12VAC
gr
-
bl +
PEL
Motherboard power supply
NL LL
D
I
S
P
L
A
Y
E
P
R
O
M
Trans-
former
Pump 1
Pump 3
NLLL NE1
LE1 NE2LE2
Pump 2
Fan
NL, LL, PEL ....Lambda board power
supply
NE1, LE1, PE1 ....Expansion board 1
power supply
NE2, LE2, PE2 ....Expansion board 2
power supply
Mother-
board
3100
W
H
A
JP2
JP1
Follow connection instructions!
Supply
L1... do not connect
