Fractal design DEFINE S2 VISION User manual

User Guide
DEFINE S2
Anwenderleitfaden / Guide de l’utilisateur / Guía del usuario / Användarguide /

Builder’s Guide
Optional Steps
Additional Info
Support and Service
Weitere Informationen / Informations supplémentaires / Información adicional / Övrig information /
Support und Kundendienst / Assistance technique et maintenance / Soporte y servicio técnico / Support och
Builder’s Guide Optional Steps Additional Info Support
Without question, computers are more than essential technology
– they have become integral to our lives. Computers do more than
The products we choose represent how we want to describe the
world around us, and how we want others to describe us. Many of
us are drawn to designs from Scandinavia, which are organized,
clean and functional while remaining stylish, sleek and elegant.
We like these designs because they harmonize with their surround-
ings and become nearly transparent. Brands like Georg Jensen,
Bang Olufsen, Skagen Watches and Ikea are just a few that repre-
In the world of computers components there is only one name you
should know, Fractal Design.
www.fractal-design.com
V1.4

Accessory Box Contents
x4
x1
x2
x20
x1
Power Supply Screw
Netzteilschraube
Vis de l’alimentation
Tornillos para la fuente de alimentación
Nätaggregatskruv
SATA Power Extension Cable
SATA-Stromverlängerungskabel
Câble allonge d’alimentation SATA
Alargador del cable de alimentación SATA
Förlängningskabel för SATA-ström
Reservoir Bracket
Reservoirhalterung
Support du réservoir
Soporte del receptáculo
Fästplatta för reservoar
2.5-Zoll-Laufwerk-Schraube
Vis du disque dur 2.5
Tornillo para la unidad 2,5”
Zusätzliche Hauptplatinenaufnahme
Entretoise pour carte-mère supplémentaire
Separador de la placa base adicional
Extra moderkortsdistans
x13
x12
x1x12
Motherboard and Reservoir Bracket Screw
Motherboard- und Reservoir-Montageschraube
Vis du support de la carte-mêre et du réservoir
Tornillo del soporte del receptáculo y placa madre
Skruv för moderkort och reservoarfästplatta
3,5-Zoll-Laufwerk-Schraube
Vis du disque dur 3.5
Tornillo para la unidad 3,5”
Outil pour les entretoises
Ajustador manual para separadores
Hylsnyckel för distanser
x6
Cable Tie
Kabelbinder
Serre-câbles
Sujetacables
Buntband
x4
Optional side panel screws
Optionale Seitenblechschrauben
Vis pour panneau latéral en option
Tornillos del panel lateral opcional
Extra skruvar till sidopaneler

Builder’s Guide
Builder’s Guide

2
Builder’s Guide
Remove Side Panels

3
Install the Power Supply
Builder’s Guide
1x PH24x
1. 2.

4
Prepare the Motherboard Install the I/O Shield
Builder’s Guide
Vorbereitung Hauptplatine / Préparer la carte mère / Prepare la placa base / Förbered moder- Installieren Sie die I/O Schild / installer le plaque d’E/S / Instale la protección de E/S / Instal-
1x
2.
1.

5
Install the Motherboard Assembly
A MM-ATX:
Builder’s Guide
1x PH2
8x
1. 2.

6
Builder’s Guide
Connect Cables for Front I/O
POWER SW
POWER LED
HDD LED
USB 3.1 Gen 2RESETHD Audio USB 3.0
USB 2.0

7
Connect PWM Fan Hub
Builder’s Guide
3-pin Fans
Main 4 pin PWM CPU fan
RPM value reported to Motherboard
Additional 4-pin PWM fans
Connect to:
CPU_FAN
Connect to power supply

8
Install the Graphics Card
Builder’s Guide
Install a 2.5” Drive
- Installation 2,5-Zoll-Laufwerke / Installer des disques 2.5 / Instale las unidades de 2,5” / Installera
PH2 PH2
2.5”
1x 4x
1x
2.
1.

9
Builder’s Guide
Install a 2.5” or 3.5” Drive
PH2
3.5”
1x 4x 4x
PH2
2.5”
1x
1x
4x
2A. 3.
2B.1.

10
Alternative Placement of 2.5” Drives
Optional Steps
Alternative Anordnung von 2,5“-Laufwerkseinschüben / Emplacement alternatif pour les plateaux de disques durs de 2,5” / Ubicación alternativa de las bandejas de unidades de 2,5” / Alternativ placering

Optional Steps
Optional Steps

12
Remove ModuVent™ for Additional Fan Slots
ModuVent™ für weitere Lüftereinbauplätze entfernen / Enlevez les ModuVent™ pour avoir plus de rainures de ventilateur / Retirar ModuVents™ para ranuras de ventilador adicionales / Montera bort
Optional Steps
1. 2.

13
Securing Side Panels for Transportation
Optional Steps
4x

14
Alternative Placement of Graphics Card
Optional Steps
PH2PH2 1x1x 2x2x
Not included / Nicht im Lieferumfang enthalten / Non inclus / No incluido
1. 2.

15
Removing the Top Panel Inset for Easier Access
Optional Steps
1. 2.
PH2

16
Adding a Water Cooling Fillport
Optional Steps
Zusätzlicher Wasserkühlung-Einfüllstutzen / Ajout d’un port de remplissage pour l’eau de refroidissement / Añadiendo un puerto de llenado de agua refrigerante / Montera fyllnadsport för vattenkylning /
1x
25,4 mm
2 mm
