Franklin 58319 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58319
Specifications
Length 27-1/2″ – 38-1/4″
Towing Capacity 660 lb.
IMPORTANT SAFETY INFORMATION
Assembly Precautions
1. Assemble only according to these instructions.
Improper assembly can create hazards.
2. Wear ANSI-approved safety goggles and
heavy-duty work gloves during assembly.
3. Keep assembly area clean and well lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or when under the
influence of alcohol, drugs or medication.
6. Weight capacity and other product capabilities apply
to properly and completely assembled product only.
7. Make sure the Handle is securly connected to the
wooden dolly before attempting to use dolly.
Use Precautions
1. This product is not a toy. Do not allow
children to play with or near this item.
2. Use as intended only.
3. Inspect before every use; do not use
if parts are loose or damaged.
4. Do not exceed listed weight capacity.
Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
5. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.

Page 3For technical questions, please call 1-888-866-5797.Item 58319
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
1. Position the Handle in the middle of the wooden
dolly (not included), as shown in Figure A.
2. Use a small diameter drill bit (smaller than
the screws) to drill four pilot holes.
3. Use a Philips Head screwdriver to thread
the screw through the Handle and into
the wooden dolly (not included).
4. Using the installed handle, mark the
spot for the Holding Bracket.
5. Drill pilot holes and screw the Bracket into the
wooden dolly to secure it.
Figure A
Adjusting Handle Length
1. Remove the Adjusting Bolts, as shown in Figure
B, and move handle to desired length.
2. Insert the same bolts back into the handle.
3. Tighten bolts using a wrench.
Figure B
Parts List and Diagram
Part Description Qty
1Wood Screws, 1″ 4
2 Swivel Handle 1
3 Holding Bracket 1
4Screws for Holding Bracket 2
Record Serial Number Here:
Note: If product has no serial number, record
month and year of purchase instead.
Note: Some parts are listed and shown
for illustration purposes only, and are not
available individually as replacement parts.
Specify UPC 193175437303 when ordering parts.
wooden dolly to secure it.
Mounting
Screws (1)
Adjusting Bolts
Holding
Bracket (3)
