Franklin BW-7000D User manual

1
1. Unpacking
You will nd the following items in the package:
User’s Guide
www.franklin.com
www.franklin.com/eu
Bluetooth Bracelet
Bluetooth Bracelet USB Charger User’s Guide
2. Charging
Connect the USB plug of the USB charger into
the USB port of your computer or an AC adapter
(not provided) and clip the other end of the USB
charger onto the Bluetooth bracelet.
OR
• TheprotrudingchargingcontactsoftheUSB
charger must be placed in the two grooves of
the bracelet for charging.
BW-7000D
Charging contacts
AC adapter not provided
(output 5V)

2
• Thebatteryicon( ) on the display is
animated during charging. It disappears from
the display when charging is complete.
• Thebraceletmustbeturnedoduring
charging.
• Thebatteryrequires3hourstobefully
charged when using for the rst time.
• Thebraceletcanalsobechargedbya5VAC
adapter (not provided).
3. General Controls
Display
Speaker
Microphone
Button A
Button B
4. Power On/O
Press and hold button Bforabout3secondsto
poweronorothebracelet.
5. Display
10:25
Phone is paired with the bracelet
Battery level
New SMS message*
Missed
call*
Time, phone number, message, caller’s name*
*Availability of caller’s name and notication for
missed calls and new SMS messages are phone
dependent. Download the FREE Android app
from Google Play Store to keep current with
Devin’s developments (See Section 10).

3
6. Bluetooth Pairing
1. Press and hold button Bfor 5 seconds.
• Makesurethebraceletisswitched o before
pairing.
• Thedisplayshows“PowerOn”andthen
“Pairing”.
2. Turn on the Bluetooth feature of the phone
you want to connect with the bracelet.
• Select“FRANKLINBRACELET”onyourphone
for pairing.
• Ifapairingcodeisrequired,use“0000”.
• Whenpairingissuccessful,thebracelet
beepsonce,showsthemessage“Paired”on
thedisplay,andvibratesoncetoindicate
successful pairing.
• Thedisplayshowsthepairedicon( ) when
your phone is connected with the bracelet.
• Thebraceletvibratesandshowsthemessage
“Disconnected”whenyourphoneismore
than33feet(10m) away. It will automatically
reconnect when your phone is within the
Bluetooth range again.
7. Setting Time
1. Press any button to show the time.
2. Press and hold button Auntil you see
“Time Format” on the screen.
3. Press button Bto select between 12-hour
and 24-hour time displays.
4. Press button A.
• Thehourtimeashes.
5. Press button Bto adjust the hour time.
6. Press button A.
• Theminutetimeashes.
7. Press button Bto adjust the minute time.
6. Press button Awhen done.
• For12-hourtimedisplay,the“AM”and“PM”
indications only show during time setting.

4
8. Receiving Calls
1. Press button Aor Bonce to receive a
call.
•Thebraceletvibrateswhenthereisacall.
• Thecaller’snumbershowsonthedisplay
(dependent on your phone model).
• Torejectacall,pressandholdbutton Aor
B.
2. Press button Aor Bduring a call to
increase or decrease the volume.
3. Press and hold button Aor Bto end a
call.
9. Redialing Calls
Toredialthelastdialednumber:
1. Make sure the screen of the bracelet is on.
• Ifnot,presseitherbutton Aor Bonce.
2. Press button Atwice in rapid sequence to
dial the last dialed number.
10. Free Android App
ThefreeAndroidappassists:
• Pairingyourphone;
• NotifyingyouofnewSMSmessages( )
and missed calls ( ) with alert sounds and
displayicons;
• Showingcaller’sname(fromthephonebook).
Please go to Google Play Store and search for
“FranklinBracelet”todownloadandinstall
the app. It supports Android phones running
Androidversion3.0orabove.
11. Listening to Music
Thebraceletcanplaymusicfromyourphone.
Afteryourphoneispairedwiththebracelet,start
playback on your phone and the music will play
from the speaker of the bracelet. Press button A

5
or Bto increase or decrease the volume during
playback.
12. Wearing the Bracelet
1. Position the bracelet so that its opening is
facing the side of your hand.
• Toavoiddamages,DONOTwidenthe
opening of the bracelet by force.
2. Keep your ngers together, slide the
opening of the bracelet over your hand.
10:25
10:25
3. Rotate the bracelet so that the display can
be properly seen.
10:25
10:25
13. Key Controls Reference
Functions Operations
Turnsonoro Press and hold button B
Goes to pairing
mode
Whenthebraceletiso,pressandhold
button B until“Pairing”isdisplayed
Receives a call Press button Aor Bonce
Ends a call Press and hold button Aor B
Rejectsacall Press and hold button Aor B
Redials the last
dailed number
Press button Atwice when the screen
is on
Controls the
volume for call or
music
Press button Aor Bonce
Goes to time
setting mode
Press and hold button Awhen the time
is displayed

6
14. Troubleshooting Tips
1. I cannot connect the bracelet with my
phone via Bluetooth connection.
• MakesureyouhaveturnedontheBluetooth
feature on your phone.
• MakesureyouhaveturnedontheBluetooth
feature (or pairing mode) on your phone (See
Section 6).
• Makesurethebatterylevelofthebraceletis
not too low.
2. There is no sound or distorted sound when
using the Bluetooth connection.
• Makesurethatthebraceletisnottoofar
(within33feetor10meters)fromyour
pairedphone,orthebraceletisnothaving
interferencefromwirelessLAN,other2.4GHz
wirelessdevice,ormicrowaveoven.
3. There are no alert icons for new SMS
messages and missed calls.
• AlerticonsfornewSMSmessagesandmissed
calls on your phone depend on the phone
model you are using. Android phone users
can download and install the free Android
app“FranklinBracelet”forthesealerticons.
• Onlythecaller’sname(fromthephonebook)
or phone number is displayed for iPhone
users.
4. How does the bracelet behave according to
my phone settings?
• RefertothetablebelowforAndriodphone
andiPhone,respectively.
Android Phone settings Bracelet
Phone call vibration & ringtone vibration only
vibration vibration only
ringtone vibration only
SMS vibration & alert sound alert sound*
vibration no alert sound*
alert sound alert sound*

7
Others(e.g.
Whatsapps)
vibration & alert sound alert sound
vibration no alert sound
alert sound alert sound
*WiththefreeAndroidappinstalled,youalsoseeanewmessageicon
displayed when an SMS message is received.
iPhone Phone settings Bracelet
Phone call vibration & ringtone onealertsound,then
vibration
vibration onealertsound,then
vibration
ringtone onealertsound,then
vibration
silent onealertsound,then
vibration
SMS vibration & alert sound alert sound
vibration no alert sound
alert sound alert sound
Others(e.g.
Whatsapps)
vibration & alert sound alert sound
vibration no alert sound
alert sound alert sound
15. Specications
Model/Name: BW-7000D Bluetooth Bracelet
• Size:80x68x38.5mm(3.15x2.7x1.5inch)
• Weight:80 g (2.8 ounce)
• Bluetoothversion:2.1
• Frequency:2.4GHz
• Operatingtemperatures:-20to60˚C(-4to
140˚F)
• Chargingvoltage:5V
• Display:128x32OLED
• Battery:LithiumPolymer,150mA
• Chargingtime:2-3hours
• Operatingtime:Talk:2-3hours,Standby:up
to 72 hours
• Compatibility:iPhone3G/3GS,4/4S,5and
Android phones

8
Bluetooth:NoiseBlackoutExtreme,operating
range up to 10 meters. Maximum operating
range may vary depending on obstacles (such
asperson,metal,wall,etc.)orelectromagnetic
environment(suchaswirelessLAN).
©2013FranklinElectronicPublishers,Inc.
Burlington,N.J.08016-4907U.S.A.Allrights
reserved.
Imported to the European Community by:
FranklinElectronicPublishersGmbH,Kapellenstr.
13,85622Feldkirchen,Germany.
FCC ID: CK2-BW7000D
Bluetooth
The word mark and logos are owned
byBluetoothSIG,Inc.andanyuseofsuchmarks
by Franklin Electronic Publishers Inc. is under
license.Othertrademarksandtradenamesare
those of their respective owners.
Compatibility
ThisdeviceiscompliantwithBluetooth
Specication2.1supportingA2DP1.0,
GAVDP1.0,HFP1.5,HSP1.1.Pleasecheckwiththe
manufacturers of other devices to check for their
compatibility with this device.
16. Product Care
Yourdeviceisdesignedtobelight,compactand
durable.However,itisanelectronicdeviceandmust
be treated carefully. Putting unnecessary pressure
onitorstrikingthedeviceagainstotherobjects
cancausedamage.Toavoiddamagetoyourdevice,
please:
• Donotdrop,crush,bend,orapplyexcessive
force to the device.
• Donotexposeyourdevicetomoisture,extreme
orprolongedheat,cold,humidity,orother
adverseconditions.Avoidstoringitindamp,

9
humid or wet places. It is not waterproof.
• Donotoperateorstoreunitinplaceswith
frequentstaticelectricityorelectricalnoise(e.g.
speaker,TVset).
• Cleantheunitwithasoftclothoradamp
chamoisleather.Neverusesolvents.
• Theunitmustnotbeopened.
• Pleasekeepplasticbagsawayfrombabiesand
childrentoavoiddangerofsuocation.
17. Recycling and Disposal
Device Disposal
Thisdeviceshouldbedisposedthroughyourlocal
electronicproductrecyclingsystem-donotthrowin
trash bin.
Packaging Disposal
PleasesavethisUser’sGuideandallpackingmaterials,asthey
containimportantinformation.Incaseofdisposal,pleasereferto
your local recycling system.
Battery Disposal
Do not dispose of batteries with normal household
waste. Please obey your local regulations when
disposing of used batteries. Please visit www.franklin.
com/eu to contact Franklin or its distributors to get
informationforbatterydisposaland/orreplacement.However,
shipping and handling expenses might apply.
18. Battery Precautions
• Ifthedeviceisnotusedforalongperiodoftime,thebattery
may lose its charge. Please recharge the battery following the
steps described above in order to use your device.
• Rechargeablebatteriesareonlytobechargedunderadult
supervision.
• Useonlythesuppliedchargerstorechargethebattery.
Improperly charging a battery may damage it or the device.
• Neveropenthedevice.Openingthedevicebyyourselfwill
invalidate the warranty.
• Donotattempttoopentherechargeablebatteryorbattery
pack.Therearenouserserviceablepartsinside.
• Keepbatteriesoutofreachofsmallchildren.Ifswallowed,
consult a physician immediately.
• Leavingthebatteryinhotorcoldplaces,suchasinaclosed
carinsummerorwinterconditions,willreducethecapacity
and lifetime of the battery. Always try to keep the battery
between15°Cand25°C(59°Fand77°F).Adevicewithahot

10
orcoldbatterymaynotworktemporarily,evenwhenthe
battery is fully charged.
• Donotdisposeofbatteriesinareastheymayexplode.
Batteries may also explode if damaged. Dispose of batteries
according to local regulations. Do not dispose as household
waste.
19. FCC Notice (U.S. only)
ThisdevicecomplieswithPart15oftheFCCRules.Operation
issubjecttothefollowingtwoconditions:(1)Thisdevicemay
notcauseharmfulinterference,and(2)Thisdevicemustaccept
anyinterferencereceived,includinginterferencethatmaycause
undesired operation.
Warning:Changesormodicationstothisunitnotexpressly
approved by the party responsible for compliance could void the
user’sauthoritytooperatetheequipment.
Note:Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforaClassBdigitaldevice,pursuanttoPart15ofthe
FCCRules.Undertheinuenceofelectrostaticphenomenon,
theproductmaymalfunctionandrequireusertoreset.These
limits are designed to provide reasonable protection against
harmfulinterferenceinaresidentialinstallation.Thisequipment
generates,usesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,there
is no guarantee that interference will not occur in a particular
installation.Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevisionreception,whichcanbedeterminedbyturning
theequipmentoandon,theuserisencouragedtotrytocorrect
the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna. 2) Increase the
separationbetweentheequipmentandreceiver.3)Connectthe
equipmentintoanoutletonacircuitdierentfromthattowhich
the receiver is connected. 4) Consult the dealer or an experienced
radio/TVtechnicianforhelp.
Note:Themanufacturerisnotresponsibleforanyradioor
TVinterferencecausedbyunauthorizedmodicationstothis
equipment.Suchmodicationscouldvoidtheuser’sauthorityto
operatetheequipment.
FCC Radiation Exposure Statement :
ThisequipmentcomplieswithFCCRFradiationexposurelimits
setforthforanuncontrolledenvironment.Thistransmittermust
notbeco-locatedoroperatinginconjunctionwithanyother
antenna or transmitter.

11
20. EU notice
ThisproductisCEmarkedaccordingtotheprovisionsoftheR&
TTEDirective(1999/5/EC).Hereby,FranklinElectronicPublishers
Inc.,declaresthatthisproductisincompliancewiththeessential
requirementsandotherrelevantprovisionsofDirective1999/5/
EC. A copy of the Declaration of Conformity is attached on the last
page of the manual.
21. Disclaimer of Warranties
Exceptasspecicallyprovidedherein,Franklinmakesnowarranty
ofanykind,expressorimplied,withrespecttothisproduct.
21.1 Limited Warranty (U.S.)
WarrantyService:Ifyouthinkyourproductisdefective,call
Franklin’sCustomerServiceDeskat1-800-266-5626.Ifyou
returnyourFranklinproduct(transportationchargespre-paid)
pleaseincludeyourname,address,telephonenumber,abrief
description of the defect and a copy of your sales receipt as proof
of your original date of purchase. Franklin strongly recommends
using a trackable form of delivery for your return.
Franklin Electronic Publishers
Attn: Service Department
Burlington,NJ08016-4907
Thisisnotawaterresistantproduct.LimitedWarrantydoesnot
cover water damage.
21.2 Limited Warranty (EU and
Switzerland)
Notwithstandingthedisclaimerofwarrantiesabove,thisproduct,
excludingbatteriesandliquidcrystaldisplay(LCD),isguaranteed
by Franklin to be free of defects in materials or workmanship for a
period of two years from the date of purchase. It will be repaired
orreplacedwithanequivalentproduct(atFranklin’soption)free
of charge for any defect in workmanship or materials during that
time.
Thiswarrantyexplicitlyexcludesdefectsduetomisuse,accidental
damage,orwearandtear.Thiswarrantydoesnotaectthe
consumer’s statutory rights.
Thisisnotawaterresistantproduct.LimitedWarrantydoesnot
cover water damage.

12
BTB-28000-00A  PrintedinChina
FranklinElectronicPublishers,Inc.
8TerriLane,Burlington,NJ08016-4907,USA
TEL:1-800-266-5626URL:http://www.franklin.com
DECLARATION OF CONFORMITY
We,FranklinElectronicPublishers,Inc.,8TerriLane,Burlington,
NJ08016-4907,U.S.A.declareunderoursoleresponsibility
that the product:
Model: BW-7000D
to which this declaration refers conforms with the following
standards:
EMC:
?
SAFETY:
?
SPECTRUM:
?
RF EXPOSURE:
?
AccordingtotheDirectivein1999/5/EC(R&TTE):Article3.1a,
3.1b,3.2
TheconformityassessmentprocedurereferredtoinArticle
10anddetailedinAnnexIVofDirective1999/5/EChasbeen
followedwiththeinvolvementofthefollowingNotiedBody:
PHOENIX TESTLAB GmbH, Köningswinkel 10, 32825,
Blomberg, Germany
TheproductismarkedwiththeCEmarkandNotiedBody
numberaccordingtotheDirective1999/5/EC:
CE
PlaceOfIssue:HongKong  
DateOfIssue:April??,2013
ProductDevelopmentAuthorization:
Signature: _____________________
Name: FrancisChan
Position: Director
Global Quality
