Franklin DRP-4000 AnyBook Reader User manual

DRP-4000
AnyBook Reader
User’s Guide
www.franklin.com
License Agreement
READ THIS LICENSE AGREEMENT BEFORE USING THE
PRODUCT. YOUR USE OF THE PRODUCT DEEMS THAT YOU
ACCEPT THE TERMS OF THIS LICENSE. IF YOU DO NOT AGREE
WITH THESE TERMS, YOU MAY RETURN THIS PACKAGE WITH
PURCHASE RECEIPT TO THE DEALER FROM WHICH YOU
PURCHASED THE PRODUCT AND YOUR PURCHASE PRICE WILL
BE REFUNDED. PRODUCT means the software product and
documentation found in this package and FRANKLIN means
Franklin Electronic Publishers, Inc.
Limited Use License
All rights in the PRODUCT remain the property of FRANKLIN.
Through your purchase, FRANKLIN grants you a personal and
nonexclusive license to use this PRODUCT. You may not make
any copies of the PRODUCT or of the data stored therein at
the time of purchase, whether in electronic or print format.
Such copying would be in violation of applicable copyright
laws. Further, you may not modify, adapt, disassemble,
decompile, translate, create derivative works of, or in any
way reverse engineer the PRODUCT. You may not export
or reexport, directly or indirectly, the PRODUCT without
compliance with appropriate governmental regulations. The
PRODUCT contains Franklin’s condential and proprietary
information which you agree to take adequate steps to
protect from unauthorized disclosure or use. This license is
eective until terminated by Franklin. This license terminates
immediately without notice from FRANKLIN if you fail to
comply with any provision of this license.
Please read the following safety
warnings and precautions before
using your device. Note: If this device
is to be used by young children, this
User’s Guide should be read to them
by an adult and their use of the device
should be monitored. Failure to do so
may cause injury.
Introduction
Thank you for purchasing AnyBook
Reader – an electronic recording and
playback device with optical reader.
With this device, you can record readings
and associate them with the provided
stickers. To play back the recordings,
simply touch the stickers with the optical
reader of the device.
Important Safety Information
This user’s guide contains important
information. PLEASE KEEP FOR
FUTURE REFERENCE.
Not suitable for children
under 36 months. Contains
small parts.
WARNING
CHOKING HAZARD – Small parts
Not for children under 3 years
This product conforms to safety requirements
of ASTM F963 and EN 71 and the Canadian
Hazardous Products (Toys) Regulations. Ce
produit est conforme aux normes de sécurité
ASTM F963, EN 71 et aux règlements canadiens
sur les produits dangereux (jouets).
This Class B digital apparatus complies with
Canadian ICES-003. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 du
Canada.
About the Stickers
The product includes special stickers
with pre-recorded sounds and dozens of
blank stickers for your recordings. When
additional stickers are required, you can
purchase them at www.franklin.com/
anybook.
In general, the stickers can be easily
removed from and re-adhered on most
kinds of papers except when the paper
is too thin, made of special materials or
with special coatings. When in doubt,
please try to adhere and remove a sticker
to test its adhesiveness before using the
stickers extensively on a publication.
Battery Precautions
Your device is powered by 2 AAA
batteries (not included).
• Non-rechargeablebatteriesarenot
to be recharged. Never recharge
batteries that come with the device.
• Rechargeablebatteriesaretobe
removed from the device before
being charged.
• Rechargeablebatteriesareonlytobe
charged under adult supervision.
• Dierenttypesofbatteriesornewand
used batteries are not to be mixed.
• Donotmixalkaline,standard
(carbon-zinc), or rechargeable (nickle-
cadmium) batteries.
• Thesupplyterminalsarenottobe
short-circuited.
• Donotexposebatteriestodirect
heat or try to take batteries apart.
Follow the battery manufacturer’s
instructions for battery use.
• Alwaysremoveaweakordead
battery from the device.
• Toavoiddamagecausedbyleakage
of the battery uid, replace the
battery or batteries once every two
years regardless of how much the
device has been used during that
time.
• Shouldabatteryleak,thedevicemay
become damaged. Clean the battery
compartment immediately, avoiding
contact with your skin.
• Batteriesaresmallobjects.Keep
batteries out of reach of small
children. If swallowed, consult a
physician immediately.
• Batteriesshouldbeinstalledor
replaced by an adult only.
• Childrenshouldnothaveaccessto
the product when the battery cover is
removed.
Replacing the Batteries
Your product is powered by 2 AAA
batteries (not included). Replace the
batteries when:
• theLEDlightashes(shortblinks
followed by long pauses);
• playbackcanonlybeatminimum
volume level, and;
• recordingcannotbemade.
To replace batteries:
1. Use a screwdriver to unscrew the
battery cover at the back of the
device.
2. Lift the battery cover gently to
remove it.
3. Remove the old batteries.
4. Install 2 new AAA batteries
following the polarity indicated in
the battery compartment.
Important: Be sure the battery is
installed correctly. Wrong polarity may
damage the unit.
Note: For best performance, alkaline
batteries are recommended.
5. Replace the battery cover and
secure it with the screw.
Product Care
Your device is designed to be light,
compact, and durable. However, it is an
electronic device and must be treated
carefully. Putting unnecessary pressure
on it or striking the device against other
objects can cause damage.
In order to avoid damage to your device,
please:
• Donotdrop,crush,bend,orapply
excessive force to the device.
• Donotexposeyourdeviceto
moisture, extreme or prolonged
heat, cold, humidity, or other adverse
conditions. Avoid storing it in damp,
humid, or wet places. The device is not
waterproof.
• Cleanthedevicebysprayingamild
glass cleaner onto a cloth and wiping
its surface. Do not spray liquids
directly on your device.
• Pleasekeepplasticbagsawayfrom
babies and children to avoid danger
of suocation.
• Checkthedevicefromtimetotime
for proper and safe condition. If there
is any damage or broken parts, do not
use the device.
Hearing Protection
Protect your child from long exposure
of loud sounds at high volume. Set
the volume to an appropriate level
in dierent environments. Limit the
listening time to 90 minutes. Stop using
the device when the user experiences
ringing in the ears or hears mued
speech. Do not hold or place the device
near the ears.
Product Registration
Visit www.franklin.com for product
registration.
Specications
Model DRP-4000 AnyBook Reader
Batteries: 2 x AAA
Size: 6.5 x 1.6 x 1.1 in (165 x 41 x 28 mm)
Weight: 3.88 ounce (110 g)
ISBN: 978-1-59074-592-2
Franklin Electronic Publishers, Inc.
Burlington, N.J. 08016-4907 U.S.A.
Franklin Electronic Publishers, Ltd.
220 Bayview Drive, Units 3 & 4,
Barrie, Ontario L4N 4Y8, Canada.
All rights reserved. Patent Pending.
Imported to the European Community by:
Franklin Electronic Publishers GmbH
Kapellenstr. 13, 85622 Feldkirchen,
Germany
Recycling and Disposal
✓Device Disposal
This device should be disposed
through your local electronic product
recycling system - do not throw in the
trash bin.
✓Packaging Disposal
Please save this User’s Guide and all
packing materials, as they contain
important information. In case of
disposal, please refer to your local
recycling system.
✓Battery Disposal
Do not dispose of batteries with
normal household waste. Please obey
your local regulations when disposing
of used batteries.
This unit may change operating modes,
lose information stored in memory,
or fail to respond due to electrostatic
discharge or electrical fast transients.
Normal operation of this unit may be
re-established by pressing the reset
key, by pressing or by removing and
replacing the battery.
