Franklin RA700 User manual

RA700 AI Speaker
User Guide

TOC i
Table of Contents
Introduction....................................................................................................................................................1
Before You Begin..................................................................................................................................1
Before using your Device......................................................................................................................1
Package Contents.................................................................................................................................1
Get Started....................................................................................................................................................2
Parts and Functions..............................................................................................................................2
Device Layout .......................................................................................................................................2
Data transfer Volume and Transfer Speed...........................................................................................3
Insert or remove a SIM Card, SD Card, and Ear Jack..........................................................................3
Data Transfer Volume and Transfer Speed..........................................................................................3
Battery Use ...........................................................................................................................................4
Battery Cautions ............................................................................................................................4
Charging the Battery.............................................................................................................................5
Battery Charging Cautions.............................................................................................................5
Charging using the Micro USB Cable............................................................................................5
Mobile Broadband Device Specifications..............................................................................................6
AC Charger Specifications....................................................................................................................6
Material Specifications..........................................................................................................................8
Warranty and Service............................................................................................................................8
Warranty ........................................................................................................................................8
Services.........................................................................................................................................8
Customer Service ..........................................................................................................................8
Trademarks and Copyright Information ................................................................................................9
Tethering & Portable Hotspot ..............................................................................................................9
Wireless Speaker Mode Selection......................................................................................................10
Safety and Notices......................................................................................................................................11
Safety Precautions..............................................................................................................................11
Important Notice...........................................................................................................................11
Safety and Hazard.......................................................................................................................11
Proper Battery Use and Disposal ................................................................................................12
FCC Compliance..........................................................................................................................12
RF Exposure Information and Specific Absorption Rate (SAR) Information ..............................................13

1
Introduction
The following topics describe the basics of using this guide and your new mobile broadband device.
Before You Begin
Thank you for purchasing your new RA700 AI speaker!
The following topics explain how best to use this guide to get the most out of your mobile broadband
device.
Before Using Your Device
Read Safety and Notices thoroughly for proper usage.
Accessible services may be limited by subscription contract conditions.
Package Contents
See below for details on everything you will find in the box for your RA700.
●RA700 AI speaker
●Battery Cover
●Rechargeable Battery
●Micro USB Cable
●Get Started Guide

2
Get Started
The following topics give you all the information you need to set up your device and wireless service for
the first time.
Parts and Functions
Learn your device's primary parts and functions.
Device Layout
The following illustration outlines your device's primary external features and buttons.

3
Part
Description
Display
View device status and information
SIM card slot
Install the SIM card.
Charging micro USB port
Connect the micro USB cable for charging.
Battery cover
Remove the battery cover to remove or insert the battery or SIM
card.
Power button
Press and hold to power on or off
Data Transfer Volume and Transfer Speed
Wireless Mode
Maximum Downlink Speed
Typical Downlink Speed
4G LTE
150 Mbps
50 Mbps
Note: Actual speeds depend on several factors, including network conditions.
Insert or Remove a SIM Card, SD Card, and Ear Jack
Follow these instructions to insert or remove a SIM card and SD Card. Remember to power off your
device before inserting or removing a SIM card.
1. Lift up the rubber cover in the bottom case and insert SIM Card, SD Card, and Ear Jack.
2. Place the SIM card gently with gold IC chip facing downward. Use the SIM picture engraved on
device to make sure it is placed properly.

4
Battery Use
The following topics explain how to insert and remove your device's battery.
Battery Cautions
Storage: Avoid storing or leaving the battery with no charge remaining. Saved information and
settings may become lost or changed, or battery may become unusable. Charge once every six
months before storing or leaving unused for a long period.
Bulges: Depending on use, bulges may appear near end of battery life. This does not affect safety.
Replacing the Battery: The battery is a consumable item. It needs to be replaced if operating time
shortens noticeably. Battery purchasing and Replacement is available at service center.
Cleaning: Clean soiled terminals between battery and device with a clean, dry cotton swab. Soiled
terminals can result in a poor connection and prevent charging, etc.
SD
CARD
SIM
CARD
Ear
Jack

5
Inserting / Removing the Battery
Follow these instructions to insert your device's battery safely and properly.
1. Press and hold the Power key to turn off the device before inserting or removing the battery.
2. Remove the battery cover.
3. Insert the battery
4. Put the battery cover on.
Charge the Battery
Follow these instructions to charge your device's battery using the included Micro USB
cable

6
Battery Charging Cautions
Charging Conditions: Under low temperatures charging performance decreases. Charge your
device in temperatures between 0°C –45°C. Do not charge in places where there is high
humidity.USB charging may be unavailable depending on Wi-Fi router temperature.
Charge Using the Micro USB Cable
Use the supplied Micro USB Cable.
After charging, disconnect the device from the cable.
☞ Note : Micro USB Cable is only for Battery Charging.

7
Mobile Broadband Device Specifications
Item
Description
Model name
RA700 AI speaker
Dimensions1
67mm (W) x 67mm (L) x 160(H) mm
Weight (g)
500g est.
Display
TFT 2.8 inch (320x240) with Touch screen
External Interface
MIC 2ea, Earphone jack,
Micro-USB Power (Micro-USB B Type)
Operating system
Android 7.0 Nougat
WLAN Connectivity
WCN3610 b/g/n (1x1)
Charging time2
4.5 hours
Continuous communication time3
8.5 hours
Communication speed
LTE category 4
DL : 150Mbps
UP : 50Mbps
Network Band
LTE B13
AC Charger Specifications
Item
Description
Rated input voltage
100-240Vac
Operating range
90-264Vac
Rated input frequency
50/60Hz +/- 3Hz
Nominal dc output voltage
+5.0V (±5%)
Rating load current
2.0A

8
Materials Specifications
Parts
Materials/Finishing
A cover
PC(Black),SF coating
B cover
PC(Black)
Battery cover
PC(Black)
Power key
PC(Milky White),Spray(Black),UV(Gloss 80%)
LCD Bracket
PC(Black)
Warranty and Service
The following topics outline your device's warranty and service information.
Warranty
Your device purchase includes Warranty.
●Confirm shop name and purchase date.
●Read contents of Warranty and keep it in a safe place.
●Check warranty period in the Warranty.
Services
Before submitting your device for repairs, contact Service Provider’s Customer Service or General
Information; be prepared to describe the problem in detail.
●During the warranty period, repairs will be made under the terms and conditions described in the
Warranty.
●After the warranty period, repairs will be upon request; if said repairs can be made, you will be
charged for them.
Customer Service
For mobile broadband device or service information, call general information. For repairs, call your
Service Provider’s customer assistance.
Trademarks and Copyright Information
The names of companies, products, and services used in this guide are registered trademarks or
trademarks of the respective companies.
Franklin Wireless logo is trademarks or registered trademarks of Franklin Wireless Corporation in
US. Copyright © 2017 Franklin Wireless Corporation. All rights reserved.

9
How to Activate Portable Hotspot
1. Go to the Tethering & Portable hotspot menu thru Settings => More => Tethering & Portable hotspot.
2. Press Portable Wi-Fi hotspot button to turn it On, then RA700 acts on as hotspot and other peer device
can access the RA700 AP.
3. Can set up WI-FI hotspot thru Setup Wi-Fi hotspot option(Network name/PW/AP band) also.
☞ Note: This product does not support the USB tethering function.

10
Wireless Speaker Mode Selection
1. Press and hold on the home screen, Press the widget icon.
2. Drag and drop the BT Speaker Setting Icon on the home screen.
3. User can turn it On or Off by selecting the Button after selecting create widget.

11
Safety and Notices
The following topics address important safety precautions, general notes, and required RF exposure
information for your mobile broadband device.
Safety Precautions
The following topics outline important safety precautions that must be observed when using your device.
Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be
guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant
delays or losses of data are rare when wireless devices are used in a normal manner with a well-
constructed network, your device should not be used in situations where failure to transmit or receive data
could result in damage of any kind to the user or any other party, including but not limited to personal
injury, death, or loss of property. Franklin Wireless accepts no responsibility for damages of any kind
resulting from delays or errors in data transmitted or received using your device, or for failure of your
device to transmit or receive such data.
Safety and Hazards
Do not operate your device under the following conditions.
●In areas where blasting is in progress
●Where explosive atmospheres may be present
●Near medical equipment
●Near life support equipment, or any equipment that may be susceptible to any form of radio
interference.
In such areas, your device MUST BE POWERED OFF. Your device can transmit signals that could
interfere with this equipment.
Do not operate your device in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, your
device MUST BE POWERED OFF. When operating, your device can transmit signals that could interfere
with various onboard systems.
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground. Your device
may be used at this time if allowed by airlines.
The driver or operator of any vehicle should not operate the device while in control of a vehicle. Doing so
will detract from the driver or operator’s control and operation of that vehicle. In some jurisdictions,
operating such communications devices while in control of a vehicle is an offense.

12
Proper Battery Use and Disposal
Follow these guidelines to ensure safe and responsible battery use.
●Do not open, disassemble, puncture, crush, bend, or shred.
●Do not expose to water or other liquids, fire, explosion, or other hazards.
●Use the original RA700 battery supplied with your device.
●If using with a charger, use only the AC charger supplied with your device.
●Do not short circuit the battery.
●When replacing a battery, use the same model of battery that was supplied with your device.
●Follow local regulations when disposing of a used battery.
●Avoid dropping your device or the battery. If dropped and you suspect damage, take it to a
service center for inspection.
●Battery usage by children should be supervised.
Note: Improper battery use may result in a fire, explosion, or other hazard.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.

13
RF Exposure Information and Specific Absorption Rate (SAR) Information
The following topics detail the specific absorption rate (SAR) information, electromagnetic safety
information, and radiofrequency (RF) exposure information for this device.
This device is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the United States.
During SAR testing, this device is set to transmit at its highest certified power level in all tested frequency
bands, and placed in positions that simulate RF exposure in usage near the body with the separation of
10 mm. Although the SAR is determined at the highest certified power level, the actual SAR level of the
while operating can be well below the maximum value. This is because the device is designed to operate
at multiple power levels so as to use only the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power output.Safety and Notices 90
The exposure standard for wireless employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
Tests for SAR are conducted using standard operating positions accepted by the FCC with the
device transmitting at its highest certified power level in all tested frequency bands.
The FCC has granted an Equipment Authorization for this model device with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model device
is on file with the FCC and can be found under the Display Grant section of http://fcc.gov/oet/ea/fccidafter
searching on FCC ID: XHG-RA700
More information on the device's SAR can be found from the following FCC website:
http://fcc.gov/oet/ea/fccid.
While there may be differences between the SAR levels of various devices and at various positions, they
all meet the government requirement.
SAR compliance for body operation is based on a separation distance of 10 mm between the unit and the
human body. Carry this device, at least 10 mm away from your body to ensure RF exposure level
compliant or lower to the reported level. To support body operation, choose the belt clips or holsters,
which do not contain metallic components, to maintain a separation of 10 mm between this and your body.
Body-Worn Operation
Please note this important safety information regarding radio frequency (RF) radiation exposure and near-
body operation. To ensure compliance with RF exposure guidelines, the device must be used at least 10
mm from your body. Failure to observe this warning could result in RF exposure exceeding the applicable
guideline limits.
