Frap Tools 333 User manual

!
333
PRO AUDIO SUM & DISTRIBUTION
333

1. SAFETY & WARRANTY!2"
2. WHAT IS 333!3"
3. CONNECT THE POWER!3"
3.1. Warm-up and working temperature 3
4. MOUNTING THE MODULE!3"
5. FEATURES!4"
6. FLOW CHART!5"
7. TECHNICAL DETAILS!6"
8. QUALITY CONTROLS!6"
9. WHAT’S IN THE BOX!6

1. SAFETY & WARRANTY
This product is covered by the Frap Tools srls (hereinafter “Frap Tools”) warranty, for two (2) years following the date of purchase.
This warranty covers any defect in the manufacturing of this product. This warranty does not cover any damage or malfunction
caused by incorrect use as described in the following instructions.
The warranty covers replacement or repair, as decided by Frap Tools. Please contact customer service at [email protected] for a
return authorization.
Frap Tools warrants that your new Frap Tools product, when purchased at an authorized Frap Tools dealer, shall be free of defects in
materials and workmanship for a period of two (2) years from the original date of purchase. Please contact Frap Tools for warranty
and service outside of Europe. During the warranty period, Frap Tools shall, at its sole option, either repair or replace any product
that proves to be defective upon inspection by Frap Tools. Frap Tools reserves the right to update any unit returned for repair and to
change or improve the design of the product at any time without notice. This warranty can be transferred to anyone who may
subsequently purchase the product provided that such transfer is made within the applicable warranty period and Frap Tools is
provided with all of the following items:
•all warranty registration information for the new owner;
•proof of the transfer within thirty (30) days of the transfer purchase, and a photocopy of the original sales receipt.
Warranty coverage shall be determined by Frap Tools in its sole discretion. This is your sole warranty. Service and repair of Frap
Tools products are to be performed only by Frap Tools or an authorized service company. Unauthorized service, repair or
modification will void this warranty.
Please follow the given instructions for use of the device because this will guarantee correct device operation. Due to the fact that
these instructions also include indications concerning Product Liability, it is absolutely imperative that they be read carefully. Any
claim for defect will be rejected if one or more of the following points is not observed. Disregard of the instructions can void the
warranty.
The device may only be used for the purpose described in this operating manual. Due to safety reasons, the device must never be
used for purposes not described in this manual. If you are not sure about the intended purpose of the device please contact an
expert or Frap Tools at the email address above.
Do not use or store the device in humid places. Avoid contact with any kind of liquid.
Do not touch any component of the device when it is power or connected to any power source.
Do not place the device on unstable carts, stands, tripods, tables, or other surfaces, or on surfaces which are not perfectly plane.
This may cause the device to fall which could result in human injury, property damage and/or improper functioning of the device
itself.
The device is designed for use only when safely and tightly mounted in a proper eurorack case, made of non flammable materials. If
you are not sure about the intended purpose of the device please contact an expert or Frap Tools at the email address above.
Do not ever leave the device switched on when not in use.
To prevent fire, never place any type of candle, or fire, or other source of heat on or near the device.
Transport the device only in the original box with original packaging or when safely and tightly mounted in a proper eurorack case,
and handled with care. Never let the device fall or topple. Make sure that during transport and while in use the device and its case,
have a proper stand and does not fall, slip or turn over because of potential human injury to persons and/or property damage. Any
damage from physical abuse such as dropping the unit, impact from hard objects or damage to external components as a result of
negligence will void this warranty.
Never subject the device to temperatures above +40°C or below 0°C. Before operation, also verify operating temperature ranges of
all the modules and the power boards in use. Do not keep or leave the case that hosts the device, or the device itself near heat
sources.
Any modification must be carried out only by Frap Tools or an authorized service company. The device may not be modified in any
way by any parties not expressly authorized by Frap Tools. Any repair, modification, tampering, or attempted repair made by
unauthorized personnel will void this warranty.
Frap Tools can not be held responsible in any way for problems to persons or property or to the device itself, if the device is installed
improperly, or if it is improperly used, maintained, or stored.
Any device shipped to Frap Tools for return, exchange, warranty repair, update, or examination must be sent in its original
packaging! Any other deliveries will be rejected. Therefore, you should keep the original packaging, and any technical
documentation or manual provided. The device must be shipped only with the original packaging. As specified on the product box,
this box is not intended for shipment: if you bought the device directly at a physical reseller's shop, you should put the device in the
original packaging and put the packaging in a proper larger box with proper packaging destined for shipping. If you received the
device via carrier or any post service, it should have come with a proper double box packaging.
All non-warranty services are subject to a minimum fee of €50.00+VAT (within the European Union). The customer must pay for
shipping to Frap Tools, Frap Tools will cover return shipping costs.
It is important to note that the front panel of the 333 module may get warm, and may warm up the case where it is mounted. Please
do not be alarmed, as this is normal and is part of its standard operation.
Shut down your equipment immediately if it produces smoke, a strange odor, or unusual noise. Continued use may lead to fire.
Immediately unplug the equipment and contact your dealer or Frap Tools at the address above for advice.
user manual rev 2 November 2017
Page !of !2 6

Never attempt to repair this product yourself. Improper repair work can be dangerous. Never disassemble or modify this product.
Tampering with this product may result in injury or fire and will void your warranty.
Do not allow foreign matter to fall into the equipment. Penetration by foreign objects may lead to fire.
If water or other liquid spills into this equipment, do not continue to use it. Continued use may lead to fire. Unplug the power cord
immediately and contact your dealer or Frap Tools at the address above for advice.
WARNING: The internal components of the 333 module can get very hot. Do not touch the internal components while it is
connected and/or powered and after they completely cool down after use for at least 30 minutes.
2. WHAT IS 333
The 333 is an analog summing and distribution module for eurorack modular systems. It is composed of three identical sections,
each of those comprising an high quality summing amplifier with 3 inputs, and three independently buffered outputs.
The summing amplifier circuitry and the system optimization are derived directly from the CGM creative mixer series, with the
additional ability to handle signals starting from DC.
3. CONNECT THE POWER!
Before to connect the power cable, pay attention to:
•the power connector on the module is the keyed one in the top;
•the red line on the cable should be placed matching the -12V side on your power board:
please double check with your power boar supplier that the marked side is the -12V.
WARNING: Frap Tools can not be held responsible in any way for problems or damage to
persons or property or to the device itself, if the device is not connected as indicated above.
3.1. Warm-up and working temperature
For best performances, we suggest to let the 333 warm up around 15 minutes prior
to use it [tested at 25°C]. It is absolutely normal that it feels warm when using it!
4. MOUNTING THE MODULE
After connecting the power as explained in the previous section, install the 18HP modules in your case using the 4 screws provided
you prefer, being sure the module is safely and tightly connected to your eurorack case.
The 333 module use the standard eurorack orientation, red line is -12V. Please double check with the power system you want to
use that both uses the same powering system.
WARNING: Frap Tools can not be held responsible in any way for problems or damage to persons or property or to the device itself,
if the device is not connected as indicated above.
!
user manual rev 2 November 2017
Page !of !3 6

5. FEATURES
The 333 is based on a very simple approach: it is composed of three identical section, red, yellow and green. Each of those section
sums up to three signals, the one plugged to any of its three inputs, and distribute this sum to three independently buffered outputs.
The first input of yellow and green sections (the one in the top) is semi-normalled to the after switch sum result of the previous
section (so the yellow to the red, and the green to the yellow).
All the inputs are DC coupled, so you can use each section to sum audio signals, control voltages as well as merging clocks.
Using the -6dB (-50%) attenuation switch you can attenuate all these signals, independently on each section. !
user manual rev 2 November 2017
Page !of !4 6
input
output
6dB / 50%
attenuator
semi
normalled
input

6. FLOW CHART
user manual rev 2 November 2017
Page !of !5 6
IN
IN
IN
SUM
ATT
BUFFER
BUFFER
BUFFER
OUT
OUT
OUT
IN
IN
IN
SUM
ATT
BUFFER
BUFFER
BUFFER
OUT
OUT
OUT
IN
IN
IN
SUM
ATT
BUFFER
BUFFER
BUFFER
OUT
OUT
OUT

7. TECHNICAL DETAILS
333 size is 6HP.
Input impedance 100 KΩ±10%.
Output impedance <50Ω.
Tolerance of <0.5%, with global offset less than ±20 mV per section.
Frequency response: each section is guaranteed from DC to 30KHz bandwidth within 1dB, measured at +10dBu onto a 1KΩload.
Harmonic Distortion (THD+N): less than 0.01%, measured at 1KHz with output signal of +10dBu onto 1KΩload with a 10Hz to
80KHz bandwidth measurement system.
8. QUALITY CONTROLS
100% of 333 modules are tested in the following aspects:
•correct behavior, power consumption and avoid any failed components with a 1 hour burn-in
•correct LEDs behavior
•switches, jack sockets and any mechanical part stress test
•visual quality inspection
100% of 333 cable is testes in the following aspects:
•mechanical behavior
•shorts
•open pins
9. WHAT’S IN THE BOX
Current Draw
idle
+12V
48 mA
-12V
48 mA
code
description
composed by
Q.ty
F-3330-SM
333
333 Module
1
16 to 10 poles IDC Power Cable
1
M3x6 black and Zinc with plastic washer for mounting
4
user manual rev 2 November 2017
Page !of !6 6
