FREE Drum Filter IoT Box Manual

!!!!!
Version 2.0 www.freedrumfilter.com
Copyright © 2022 by Real Link Company Ltd.
1
SET UP INSTRUCTIONS for IoT BOX
1. INTRODUCTION
The IoT Box is the smart device using our proprietary cloud-base App developed by
FREE Drum Filter
, can
be downloaded from the
Apple Store
or the
Google Play Store
, allows users to monitor, control the RDFs
and receive notification on their smartphone (
iOS
or
Android
). Below are the list of features/Indicators:
FUNCTION
INDICATIOR
DESCRIPTION
INDICATION
METHOD
Connection status
or
Blue: Power on and connected to WIFI.
Red: Disconnected from WIFI!or Power outage.
Indicatior and
Push notification
Operation status
GOOD / FAIL
Failure alert when the safety sensor is activated
which indicates issues with filter system or water
level that need to be checked immediately.
Indicatior and
Push notification
Water level status
GOOD /
WARNING
Filter system continues running, but the water
level should be inspected.
Indicatior and
Push notification
Rinse status
CLEANING /
STOP
Indicates whether the machine is currently
cleaning or stop.
Indicatior only
Counter
1234
Counting the total number of rinses from the last
reset.
Indicatior only
Reset Counter
Reset Button
Reset the counter to zero. Reset time will display.
Indicatior and
Control
Manual Rinse (*)
Push Button
Push and hold to start a cleaning cycle.
Control
Rinses Per Day
123
Total number of rinses within the last 24 hours.
Shown in Log
Excessive rinse
Alert
123
Excessive cleaning alert when the total rinses
exceed 300 times within last 24 hours.
Indicator and
Push notification
Last rinse time
Time
Indicate the last rinse time.
Shown in Log
Logs panel
Time & Events
Record important events with real time.
Shown in Log
Save for 7 days
Manage Multiple
devices
“Pond A”
“Pond B”
Monitor and control multiple RDFs using the
same App.
Full functions
for each device
Languague
Interface
English or Vietnamese.
Optioned
(*) Function only available on Control Box shipped beginning 2022. For older Control Box, contact dealers.

!!!!!
Version 2.0 www.freedrumfilter.com
Copyright © 2022 by Real Link Company Ltd.
2
!
!
!
!
!
FREE Drum Filter
App is available on App Store
and Google Play Store: In the Search field, search
for the app name “FREE Drum Filter” or scan the
QR Code or click the link below to download the
Application.
2. DOWNLOAD APPLICATION
App Store Link: https://apps.apple.com/us/app/free-drum-filter/id1597472915
Google Play Link: https://play.google.com/store/apps/details?id=com.freedrumfilterandroid.iot
3. REGISTRATION ACCOUNT
• Provide your dealer with your email address for account registration.
• An Activation email will be sent to you. Follow the instructions in the email to activate your account.
• Login the Application with your email address and password you have just created.
4. IoT BOX CONFIGURATION
• Plug the IoT BOX cable into the connector label “IoT BOX” on the Contro Box and push the Power button
on the IoT BOX to turn it on. The green light will be lit.
• Go to your smartphone WIFI settings, you should see a WIFI named “
FREE Drum IoT
” in the WIFI list,
select and connect to this “
FREE Drum IoT
” WIFI. If the “FREE Drum IoT” is not found,
reset
IoT Box (**).
• Open the Application that you had just logged in, choose + (add device) at the top right corner.
• A WIFI setup window appears to allow you to connect your IoT box to your home network (Figure 1).
Enter your home WIFI Name (SSID) and Password then click SAVE.
• After about 10 seconds processing (Figure 2) the device indicator will show “Online” (Figure 3).
• The default Name of device will be
FREE Drum IoT
. Wipe to the left on the name to display options to
rename or to delete the device.
Figure 1
Figure 3 Figure 2
(**)
Reset
: If you don’t see the WIFI name “FREE Drum IoT”, reset your IoT Box by push and hold the Reset
button (a small hole on the right side of the IoT Box, using a small stick) for about 10 seconds.
