Freemotion EPIC GZFW2141.3 User manual

Visit our website at
www.freemotionfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Model No. GZFW2141.3
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guaran-
tee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-201-2109
Mon.–Fri., 8 a.m.–5 p.m. MST
OWNER’S MANUAL

TABLE OF CONTENTS
2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
WARRANTY TERMS AND CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

3
1. Read all instructions in this manual before
using the strength equipment. Use the
strength equipment only as described in this
manual.
2. It is the purchaser’s responsibility to ensure
that there is enough space around the
strength equipment for the intended exer-
cise. Do not crowd the strength equipment.
3. Using the three 9/16” anchor holes to pro-
vide maximum stability, the strength equip-
ment must be anchored to the floor where
required or whenever possible.
4. It is the responsibility of the owner to ensure
that all users of the strength equipment are
adequately informed of all precautions.
5. All users of the strength equipment should
be instructed to report any injury or strength
equipment irregularity to facility staff immedi-
ately.
6. Make sure all parts are properly tightened
before each use of the strength equipment.
Replace any worn parts immediately.
7. Use the strength equipment only on a level
surface. Cover the floor beneath the strength
equipment to protect the floor.
8. Always wear athletic shoes for foot protec-
tion while exercising.
9. Keep hands and feet away from moving
parts. Do not lean on or rest your hands on
the strength equipment when it is in use.
10. Keep children under 12 and pets away from
the strength equipment at all times.
11. The strength equipment is designed to sup-
port a maximum user weight of 350 pounds,
amaximum of 600 pounds of weight, includ-
ing a barbell (not included), and a maximum
total weight of 950 pounds.
12. Always exercise with a partner. Your partner
should be ready to catch the barbell if you
cannot complete a repetition.
13. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool-
ing down.
WARNING:Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the strength equipment.
IMPORTANT PRECAUTIONS

ASSEMBLED DIMENSIONS:
Height: 51 in. / 130 cm
Width: 66 in. / 168 cm
Depth: 63 in. / 160 cm
4
Seat
Anchor Hole Anchor Hole
Storage Bar
Backrest
BEFORE YOU BEGIN
Thank you for selecting the FREEMOTION EPIC™
INCLINE BENCH strength equipment. The strength
equipment is designed to help develop the major mus-
cle groups of the upper body. Whether your goal is to
tone your body, build dramatic muscle size and
strength, or improve your cardiovascular system, the
INCLINE BENCH strength equipment will help you to
achieve the specific results you want.
For your benefit, read this manual carefully before
using the strength equipment. If you have additional
questions, please call our Customer Service
Department toll-free at 1-800-201-2109, Monday
through Friday, 8 a.m. until 5 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note the product model number and serial number
before calling. The model number is GZFW2141.3.
The serial number can be found on a decal attached
to the strength equipment (see the front cover of this
manual).
Before reading further, please review the drawing below
and familiarize yourself with the parts that are labeled.

This section explains how to adjust the strength equipment for exercising. Make sure all parts are properly tight-
ened each time the strength equipment is used. Replace any worn parts immediately.
5
ADJUSTING THE SEAT
To raise the seat, release the seat lock by lifting the
front end of the seat. Slide the seat to the desired
position and lower the end of the seat. Make sure
the seat lock reengages in the new position.
To lower the seat, release the seat lock by lifting the
front end of the seat. Push down on the seat near the
frame to slide it to the desired height. Lower the front
end of the seat. Make sure the seat lock reengages
in the new position.
Rack
Long
Storage
Bar
Short
Storage
Bar
Seat
Frame
Lift this
end
ADJUSTMENTS
STORING WEIGHT
Store unused weights on the storage bars. Note: The
diagram shows the suggested location for storing
weights.
25-lb.
weights
35- and 45-lb.
weights
5- and 10-lb.
weights
WARNING:Each long storage bar
can hold up to 150 pounds. Each short storage
bar can hold up to 225 pounds. Do not place
more than a total of 600 pounds, including the
barbell (not included), on the racks and stor-
age bars. Always place an equal amount of
weight on each side of your barbell.

6
MAINTENANCE
It is important for safe and trouble-free operation of your FREEMOTION EPIC strength equipment to perform
routine preventive maintenance on a regular basis. Instruct all personnel to perform equipment inspection and
maintenance requirements. Personnel must record and report any accident. To maintain the strength equip-
ment’s warranty, use only FREEMOTION EPIC parts for repair or replacement. Contact FreeMotion Fitness
Customer Service at 1-800-201-2109 with any questions or concerns.
SCHEDULED MAINTENANCE
DAILY
1. Upholstery—General cleaning:
•Wipe using a soft cloth dampened with a light
solution of mild soap and warm water.
•If necessary, use a soft bristle brush with the
cleaning solution.
•Rinse thoroughly using a soft cloth dampened
with clean water and dry thoroughly.
2. Upholstery—Difficult stains:
•Spray the stain with a non-abrasive household
cleaner such as FORMULA 409®cleaner,
SIMPLE GREEN®,or a similar product.
•Rub the area gently and let it sit for a few min-
utes.
•Rinse thoroughly using a soft cloth dampened
with clean water and dry thoroughly.
•Repeat if necessary using a soft bristle brush.
Optional method for difficult stains:
•Rub the area gently using a soft cloth damp-
ened with rubbing alcohol.
•Rinse thoroughly using a soft cloth dampened
with clean water and dry thoroughly.
CAUTION: When using any cleaning product, try
it first in an inconspicuous place to ensure that
there is no damage to the material. Follow the
directions and adhere to the safety precautions of
the manufacturer of each cleaning product used.
FreeMotion Fitness and its vendors cannot be
held liable for damage or injuries resulting from
the use or misuse of cleaning products.
3. Frames:
•Wipe using a soft cloth dampened with a light
solution of mild soap and warm water. Rinse
thoroughly using a soft cloth dampened with
clean water and dry thoroughly.
Important: Do not use abrasive cleaners
because they may scratch the equipment. Strong
cleaners and abrasives will damage decals. Use
caution around decals. Do not use solvents such
as lacquer thinner, kerosene, gasoline, or similar
liquids.
WEEKLY
1. Hardware:
•Check all nuts and bolts. Tighten them as
required. Important: All FREEMOTION EPIC
cushions are fabricated using dense plywood
with tee-nuts installed for bolting to the machine
framework. Because these tee-nuts are held by
the plywood, they will not withstand the torque
that standard nuts and bolts will. Therefore,
when tightening the cushion bolts, turn them
only until they are snug and the cushion does
not move or feel loose. Overtightening may strip
the tee-nuts from the plywood and make it
impossible to remove the cushion in the future.
2. Grips:
•Check and replace as needed.
3. Wheels:
•Wheels should roll easily. Tighten or replace as
needed.

7
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the owner’s manual for information about ordering replacement parts.
Key No. Qty. Description Key No. Qty. Description
1 1 Base
2 1 Left Upright
3 1 Right Upright
41 Backrest
5 1 Seat
6 2 Long Weight Tube
7 2 Short Weight Tube
8 10 Bumper Ring
9 2 3/8” x 4” Non-patch Bolt
10 4 3/8” x 1” Non-patch Bolt
11 4 1/2” x 1” Bolt
12 2 1/2” x 3” Bolt
13 2 1/2” x 1 1/4” Bolt
14 4 1/2” Washer
15 1 Bungee Cord
16 4 3/8” x 1” Flat Head Screw
17 1 Seat Frame
18 1 Seat Stop
19 2 Wire Tie
20 2 3/8” x 1/2” Flat Head Bolt
21 8 1/2” x 3 1/2” Bolt
22 1 Left Frame
23 1 Right Frame
# 1 Owner’s Manual
PART LIST—Model No. GZFW2141.3 R0106A

8
10
1
23 4
57
77
8
8
9
9
11
11
11 15
17
18
14
14
16 16
19
20
14
14
12
13
21
21
32
12
13
22
8
6
8
8
6
8
21
EXPLODED DRAWING—Model No. GZFW2141.3 R0106A

WARRANTY TERMS AND CONDITIONS
9
Limited Warranty on Commercial Equipment
FreeMotion Fitness, Inc. warrants that all new equipment will be free of manufacturing defects in workman-
ship and materials, becoming effective at the date of original installation. Parts repaired or replaced under
the terms of this warranty will be warranted for the remainder of the original warranty period only. Labor
must be performed at a FreeMotion Fitness commercial service facility or by a FreeMotion Fitness author-
ized commercial service provider.
Terms and Conditions of Coverage
1. Warranty applies only while:
(A) it remains in the possession of the original purchaser and proof of purchase is demonstrated,
(B) it has not been subject to accident, misuse, abuse, improper service, or modification, and
(C) claims are made within the warranty period.
2. All coverage is provided by specific Product according to the guidelines listed below.
3. If the Product or any covered part must be returned to a service facility for repairs, We, FreeMotion
Fitness, Inc., will pay all transportation and insurance charges for the first year. We must approve trans-
portation and insurance previous to shipping. You are responsible for transportation and insurance
charges during the remaining years.
4. We will ship to you any new or rebuilt replacement part or component, or, at our option, replace the
Product. Such replacement parts are warranted for the remaining portion of the original warranty period.
5. This warranty does not cover damage or equipment failure caused by failure to provide reasonable and
necessary maintenance as outlined in the owner’s manual. Any failures or damage caused by unautho-
rized service, misuse, accident, negligence, improper assembly or installation, debris resulting from any
destruction activities in the Product’s environment, rust or corrosion as a result of the Product’s location,
alterations or modifications without written authorization, or by failure on your part to use, operate, and
maintain the Product as set in your owner’smanual will void this warranty. All terms of this warranty
are void if this Product is moved beyond the continental borders of the United States of America
(excluding Alaska, Hawaii, and Canada) and are then subject to the terms provided by that coun-
try’slocal authorized FreeMotion Fitness representative.
6. During the labor period, FreeMotion Fitness, Inc. compensates Servicers for warranty trips within their
normal service area to repair Product at the consumer’slocation. You may be charged a trip charge out-
side the service area.
7. FreeMotion Fitness, Inc. Limited Warranty service may be obtained by contacting Customer Care at
1-800-201-2109.
8. Product limited warranty is void when Product is installed in a country other than where sold.
Limited warranty does not apply to:
1. Repairs performed on Product with missing, altered, or defaced serial numbers.
2. Service calls to correct installation of the Product or instruct owners on how to use the Product.
3. Repair pick-up, delivery, or freight charges other than specified above.
4. Any labor costs incurred beyond the applicable labor warranty period.
Limited Warranty
Parts are warranted to be free from defects in materials and workmanship for the duration of the warranty
period as described below. Labor is warranted for one year except for upholstery and grips.
• 10 years: Structural frame
•3years: Bearings, guide rods, pulleys, cams, weight stacks
• 1 year: Cables
• 120 days: Upholstery, grips, selector pins, knobs, decals

10
Your Responsibility
Retain proof of purchase; use, operate, and maintain the Product as specified in the Owner’s Manual; noti-
fy Customer Care of any defect within 10 days after discovery of the defect; if instructed, return any defec-
tive part for replacement, or, if necessary, the entire Product for repair.
Owner’s Manual
It is very important that you read the Manual before operating the Product. Remember to perform the peri-
odic maintenance requirements specified in the Manual to assure proper operation and your continued sat-
isfaction.
Receipt of Parts and Service
Simply call Customer Care toll-free at 1-800-201-2109, Monday through Friday from 8 a.m. to 5 p.m.
Mountain Time, and give your name, address, and the serial number of your Product. A representative will
tell you how to get a replacement part, or, if necessary, arrange for service where your Product is located
or advise you on how and where to ship the Product for service.
Before Shipping:
1. Obtain a Return Authorization Number (RA#) from Customer Care.
2. Securely pack your Product.
3. Write the RA# on the outside of the carton.
4. Insure the Product.
5. Include a letter explaining the defect or problem and a copy of your proof of purchase if you believe the
service is covered by warranty.
Exclusive Warranty
FreeMotion Fitness, Inc. is not responsible or liable for indirect, special, or consequential damages arising
out of, or in connection with, the use or performance of the Product or damages with respect to any eco-
nomic loss, loss of property, loss of revenues or profits, loss of enjoyment or use, costs of removal or
installation, or other consequential damages of whatsoever nature. Some states do not allow the exclusion
or limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly,the above
limitation may not apply to you.
Unauthorized Changes to Warranty
No one is authorized to change, modify, or extend the terms of this limited warranty.
State Laws
This warranty gives you specific legal rights and you may have other rights which vary from state to state.

NOTES
11

Part No. GZ7359 R0106A Printed in USA © 2006 ICON IP, Inc.
To order replacement parts, simply call our Customer Service Department toll-free at 1-800-201-2109, Monday
through Friday, 8 a.m. until 5 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre-
pared to give the following information:
• The MODEL NUMBER of the product (GZFW2141.3)
• The NAME of the product (FREEMOTION EPIC INCLINE BENCH strength equipment)
• The SERIAL NUMBER of the product (see the front cover of this manual)
• The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING on
pages 7 and 8 of this manual)
ORDERING REPLACEMENT PARTS
