Application Note
AN3223
Rev. 0, 2/2006
Table of Contents
1 Introduction
This application note describes initialization, general
rules, programming model and performance analysis for
the MPC5200 ATA interface, mainly from a software
perspective. The main focus is to help system architects
understand which mode under what circumstances is
optimalforthefinalproduct.Detailedsoftwareexamples
can be found on the publicly available CD with sample
code for the MPC5200. The MPC5200B microcontroller
is based on an e3001core using the PowerPCTM
instruction set.
The ATA interface is used to connect:
• Hard disks
•CD-ROMs
• DVDs
• Flash storage devices
The MPC5200 ATA interface is fully compatible with
ATA/ATAPI-4 specification (AT Attachment with Packet
InterfaceExtension, ANSI NCITS317-1998)supporting
all three groups of modes:
1. e300, 603e, and G2LE are synonymous.
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 ATA Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 Electrical Characteristics . . . . . . . . . . . . . . . . 3
2.2 Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 IO Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4 Byte Ordering. . . . . . . . . . . . . . . . . . . . . . . . . 5
2.5 Register Addressing . . . . . . . . . . . . . . . . . . . 5
2.6 Sector Addressing . . . . . . . . . . . . . . . . . . . . . 6
2.7 ATA Programming Model . . . . . . . . . . . . . . . 6
2.8 Host Initialization . . . . . . . . . . . . . . . . . . . . . . 9
2.9 Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Performance Analysis . . . . . . . . . . . . . . . . . . . . . 14
4 Literature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix A MPC5200 ATA Register Summary
MPC5200 ATA Interface
by: Martin Nykodym
Transportation Standard Products Group

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor2
• PIO (from PIO-0 to PIO-4) – up to 16.7 MBytes/sec
• Multiword DMA (from MDMA-0 to MDMA-2) – up to 16.7 MBytes/sec
• Ultra DMA (from UDMA-0 to UDMA-2) – up to 33 MBytes/sec
MPC5200 supports 27-bit and 48-bit LBA addressing on every device.
2ATAInterface
The MPC5200 ATA interface includes three groups of registers:
• ATA host registers – host configuration, timing values for all modes (from PIO, MDMA, UDMA)
• ATA FIFO registers – control ATA FIFO for DMA modes (MDMA, UDMA)
• ATA drive registers – access to the registers physically located on the ATA drive
Figure 1 illustrates basic components of the MPC5200 ATA interface internal to the MPC5200. Data
transfer is driven either by MPC5200 core (PIO) or by the BestComm DMA engine (MDMA, UDMA).
BestComm is designed to offload the MPC5200 core and can transfer data to/from different peripherals
simultaneously. The MPC5200 ATA interface is clocked by the IPBI clock of the MPC5200 processor
(66/132 MHz). MPC5200 acts as an ATA host and can control up to two ATA devices as defined in
ATA/ATAPI-4 specification. Pin ATA_ISOLATION of the MPC5200 (not defined as a signal by
ATA/ATAPI-4 spec) connects to the transceiver’s OE pin to control the direction (high = write to drive,
low = read from drive) of the transfer.
Figure 1. ATA Architecture
BestComm
(higher priority)
IPBI
(lower priority)
Arbiter
ATA Rx/Tx FIFO
Interface
(MDMA/UDMA)
IPBI Interface
(PIO)
ATA Host Interface
MPC5200
ATA_ISOLATION
IPBI clock (66/132 MHz)
ATA 40-pin cable
ATA
Line
Drivers
3.3 V – 5 V
ATA device 0
(e.g. DVD drive)
ATA device 1
(e.g. CompactFlash)

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 3
2.1 Electrical Characteristics
ATA is a voltage level interface and the table below defines the voltage levels for logical ones and zeroes
or input and output values.
2.2 Signals
Table 1. ATA DC Characteristics
Description Min Max
IoL Driver sink current1
NOTES:
1IoL for DASP shall be 12 mA minimum to meet legacy timing and signal integrity.
4mA —
IoH Driver source current2
2IoH value at 400 mA is insufficient in the case of DMARQ that is typically pulled low by a 5.6 kW
resistor.
400 µA—
ViH Voltage input high (logical one) 2.0 Vdc —
ViL Voltage input low (logical zero) — 0.8 Vdc
VoH Voltage output high (IoH=-400 µA, logical one) 2.4 Vdc —
VoL Voltage output low (IoL= 12 mA, logical zero) — 0.5 Vdc
Table 2. ATA Signals
ATA Signal ATA Acronym MPC5200 Pin Direction 40-Pin
ATA Cable
Cable select CSEL — > 28
Chip select 0 CS0- ATA_CSB0 > 37
Chip select 1 CS1- ATA_CSB1 > 38
Data bus bit 0 DD0 ATA_DATA_0 <> 17
Data bus bit 1 DD1 ATA_DATA_1 <> 15
Data bus bit 2 DD2 ATA_DATA_2 <> 13
Data bus bit 3 DD3 ATA_DATA_3 <> 11
Data bus bit 4 DD4 ATA_DATA_4 <> 9
Data bus bit 5 DD5 ATA_DATA_5 <> 7
Data bus bit 6 DD6 ATA_DATA_6 <> 4
Data bus bit 7 DD7 ATA_DATA_7 <> 3
Data bus bit 8 DD8 ATA_DATA_8 <> 4
Data bus bit 9 DD9 ATA_DATA_9 <> 6
Data bus bit 10 DD10 ATA_DATA_10 <> 8
Data bus bit 11 DD11 ATA_DATA_11 <> 10
Data bus bit 12 DD12 ATA_DATA_12 <> 12
Data bus bit 13 DD13 ATA_DATA_13 <> 14

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor4
2.3 IO Cable
The cable specification impacts system integrity and the maximum length that shall be supported in any
application. Cable total length shall not exceed 0.46 m (18 in.). Cable capacitance shall not exceed 35 pF.
80-pin grounded cable helps to avoid problems with noise and inductance although 40-pin cable is
sufficient for modes up to UDMA-2 as in the ATA/ATAPI-4 spec. Also ATA/ATAPI-4 compliant
termination is a must; otherwise, CRC checksum error may randomly occur.
Data bus bit 14 DD13 ATA_DATA_14 <> 16
Data bus bit 15 DD14 ATA_DATA_15 <> 18
Device active or slave (Device 1)
present
DASP- — > 39
Device address bit 0 DA0 ATA_SA_0 > 35
Device address bit 1 DA1 ATA_SA_1 > 33
Device address bit 2 DA2 ATA_SA_2 > 36
DMA acknowledge DMACK- ATA_DACK_B > 29
DMA request DMARQ ATA_DRQ < 21
Interrupt request INTRQ ATA_INTRQ < 31
I/O read
DMA ready during Ultra DMA data in
bursts
Data strobe during Ultra DMA data
out bursts
DIOR-
HDMARDY-
HSTROBE
ATA _ I O R _ B >
>
>
25
I/O ready
DMA ready during Ultra DMA data
out bursts
Data strobe during Ultra DMA data in
bursts
IORDY-
DDMARDY-
DSTROBE
ATA_IOCHRDY <
<
<
27
I/O write
Stop during Ultra DMA data bursts
DIOW-
STOP
ATA _ I O W _ B >
>
23
Passed diagnostics
Cable assembly type identifier
PDIAG-
CBLID-
-<>34
Reset RESET- HRESET_B > 1
Ground GND 2,19,22,24,
26,
30,40
Table 2. ATA Signals (continued)
ATA Signal ATA Acronym MPC5200 Pin Direction 40-Pin
ATA Cable

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 5
2.4 Byte Ordering
Assuming a block of data contains "n" bytes of information, the bytes are labeled Byte(0) through
Byte(n-1), where Byte(0) is the first byte of the block, and Byte(n-1) is the last byte of the block. Table 3
shows the order of the bytes on the ATA interface.
2.5 Register Addressing
This section describes the generation of the actual address (CSn-, DAn) that is present on the physical ATA
interface to address an ATA drive register by means of operations on internal registers of the MPC5200.
Table 4 shows how internal registers are decoded to ATA bus operations.
.
Table 3. ATA Byte Ordering
DD
15
DD
14
DD
13
DD
12
DD
11
DD
10
DD
9
DD
8
DD
7
DD
6
DD
5
DD
4
DD
3
DD
2
DD
1
DD
0
First transfer Byte (1) Byte (0)
Second transfer Byte (3) Byte (2)
...
Last transfer Byte (n-1) Byte (n-2)
Table 4. ATA Register Address/Chip Select Decoding
Addresses Functions
MPC5200
register
address
CS0- CS1- DA2 DA1 DA0
READ (DIOR-) WRITE (DIOW-)
Control Block Registers
— 1 1 x x x Data bus high impedance Not used
— 1 0 0 x x Data bus high impedance Not used
— 1 0 1 0 x Data bus high impedance Not used
0x3A5C 1 0 1 1 0 Drive alternate status Drive device control
— 1 0 1 1 1 Obsolete Not used
0x3A60 0 1 0 0 0 Drive data Drive data
0x3A64 0 1 0 0 1 Drive error Drive features
0x3A68 0 1 0 1 0 Drive sector count Drive sector count
0x3A6c 0 1 0 1 1 Drive sector number Drive sector number
Drive LBA bits 0-7* Drive LBA bits 0-7*
0x3A70 0 1 1 0 0 Drive cylinder low Drive cylinder low
Drive LBA bits 8-15* Drive LBA bits 8-15*
0x3A74 0 1 1 0 1 Drive cylinder high Drive cylinder high
Drive LBA bits 16-23* Drive LBA bits 16-23*

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor6
2.6 Sector Addressing
The addressing of data sectors recorded on the device's media is performed by a logical sector address.
Two modes are supported:
• Cylinder/head/sector addressing (CHS)
• Logical block addressing (LBA)
The MPC5200 host system may select either CHS translation addressing or LBA addressing on a
command-by-command basis by using the LBA bit in the ATA drive device/head register. The LBA bit
must be set if the host uses LBA addressing mode. The MPC5200 allows 27-bit LBA addressing per
device.
2.7 ATA Programming Model
Figure 2 describes the typical structure and sequence of steps needed to initialize and issue ATA
commands for MPC5200.
0x3A78 0 1 1 1 0 Drive device/head Drive device/head
Drive LBA bits 24-27* Drive LBA bits 24-27*
0x3A7C 0 1 1 1 1 Drive device status Drive command
— 0 0 x x x Invalid address Invalid address
*Mapping of registers in LBA mode
Table 4. ATA Register Address/Chip Select Decoding (continued)

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 7
Figure 2. MPC5200 ATA Programming Model
A BestComm task loader is needed if there is some peripheral requiring DMA transfer over the FIFOs
to/from a peripheral (ATA MDMA/UDMA, Ethernet, LocalPlus, PCI, etc.). The BestComm image is
downloaded and initialized only once, right after booting, due to the static content of the BestComm image
(image means BestComm binary firmware). The BestComm image acts as a server that serves clients
(peripheral software drivers).
It is recommended to start with the software examples published on the sample code CD. These software
examples include a set of already “pre-cooked” BestComm tasks that handle all required peripherals via
the BestComm C-API (BAPI). The system integrator needs to recompile all drivers in the case of any
change in the image. This guarantees compatible versions for both BestComm firmware and software
drivers.
Figure 3 documents the structure for the MDMA/UDMA data transfer.
BestComm task loader
Download BestComm image
Set task priorities
Initialize BestComm variables
can be restarted at any time
ATA driver
Set cached ATA memory regions
Initialize ATA host (MPC5200)
Initialize ATA device
(e.g. hard disk, CD-ROM, DVD)
Execute ATA command
according specified protocol

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor8
Figure 3. MDMA/UDMA BestComm Driven Data Transfer
The BestComm C-API is not resident software. It is a piece of software statically linked to the driver that
includes a set of standardized function calls.
ATA device
(e.g., DVD drive)
ATA cable
MDMA/UDMA data
ATA data
buffers ATA software driver
ATA level shifters
ATA host interface
MPC5200
Embedded computer
Peripheral FIFOs
Set of “pre-cooked”
tasks
Data transfer driven
by BestComm
ATA Rx/Tx FIFO
BestComm
BestComm image in
MPC5200 SRAM
ATA task
BestComm C-API
Set of peripheral
drivers and their
data buffers
Application 1
(e.g., DVD player)
Application 2
(e.g., MP3 player)
SDR/DDR memory

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 9
The following steps should be used to set up the cache for ATA memory buffer regions:
• Set DBAT registers and enable data cache.2(See Programming Environments Manual for 32-Bit
Implementations of the PowerPC Architecture for details.)
• Set XLB priorities in the XLB arbiter master priority register and enable XLB priorities in the
arbiter master priority enable register.3(See the XLB Arbiter chapter in the MPC5200 User’s
Manual for details.)
• Set window address, size and snooping policy in the XLB arbiter snoop window register and
enable snooping in the XLB arbiter configuration register.4(See the XLB Arbiter chapter in the
MPC5200 User’s Manual for details.)
2.8 Host Initialization
The MPC5200 ATA host initialization covers three different groups of steps:
1. ATA common initialization
— Set ATA chip select in GPS port configuration register
— Read IPBI clock speed in CDM configuration register (66 or 132 MHz) needed for timing
registers)5
— Enable ATA clock in CDM clock enable register
— Install ATA interrupt handler and BestComm interrupt handler for MDMA/UDMA modes
— Enable ATA/BestComm interrupt
2. PIO initialization (BestComm not needed for PIO modes)
— Set PIO timing registers
— Enable drive interrupt (to pass to CPU in PIO modes) in ATA host configuration register
(IE bit)
— Enable IORDY in ATA host configuration register (for PIO-3 and above)
3. MDMA/UDMA initialization
— Set either MDMA or UDMA timing registers
2.9 Protocols
ATA commands written into the ATA drive device command register are grouped into different classes
according to the protocols. The protocols define the command execution flow. The command classes with
their associated protocols are defined in Table 5.
The following sections directly document the commands instead of providing a detailed general
description for each protocol. The addressing scheme and the handling of some of the commands are
usually provided in linkable libraries by operating system vendors; therefore, the following description is
2. Usually entire memory cached, initialized by bootloader
3. Initialized by bootloader
4. Set up by driver
5. Bootloader sets up IPBI clock speed, peripheral drivers should read status only

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor10
intended to help software engineers understand how to initialize the MPC5200 ATA interface and how to
execute standard commands.
NOTE
Flash storage media require a different set of commands that are not
described in this application note. It is recommended to first read the
identify table for each ATA device found on the ATA bus. It contains
specific information needed to handle the device properly. For protocol and
identification information details, see Attachment with Packet Interface
Extension, ANSI NCITS 317-1998.
.
2.9.1 Drive Initialization
2.9.1.1 PIO Initialization Protocol Steps
1. Select drive according to device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY6=0 and DRQ7= 0 in ATA drive alternate status register
Table 5. ATA Protocols
Protocol Commands
Device reset protocol —
Execute device diagnostic
protocol
—
Device selection protocol —
PIO data-in command protocol CFA TRANSLATE SECTOR, IDENTIFY DEVICE, IDENTIFY PACKET DEVICE, READ BUFFER,
READ MULTIPLE, READ SECTOR(S), SMART READ DATA
PIO data-out command protocol CFA WRITE MULTIPLE WITHOUT ERASE, CFA WRITE SECTORS WITHOUT ERASE,
DOWNLOAD MICROCODE, SECURITY DISABLE PASSWORD, SECURITY ERASE UNIT,
SECURITY SET PASSWORD, SECURITY UNLOCK, WRITE BUFFER, WRITE MULTIPLE,
WRITE SECTOR(S)
Non-data command protocol CFA ERASE SECTORS, CFA REQUEST EXTENDED ERROR CODE, CHECK POWER MODE,
FLUSH CACHE, GET MEDIA STATUS IDLE, IDLE IMMEDIATE, INITIALIZE DEVICE
PARAMETERS, MEDIA EJECT, MEDIA LOCK, MEDIA UNLOCK, NOP, READ NATIVE MAX
ADDRESS, READ VERIFY SECTOR(S, SECURITY ERASE PREPARE, SECURITY FREEZE
LOCK SEEK, SET FEATURES, SET MAX ADDRESS, SET MULTIPLE MODE SLEEP, SMART
DISABLE OPERATION, SMART ENABLE/DISABLE AUTOSAVE, SMART ENABLE
OPERATION, SMART EXECUTE OFFLINE IMMEDIATE, SMART RETURN STATUS,
STANDBY, STANDBY IMMEDIATE
DMA command protocol READ DMA, WRITE DMA
Packet non-data and PIO data
command protocol
PACKET, SERVICE
Packet DMA command protocol PACKET, SERVICE
Read/write DMA queued
command protocol
READ DMA QUEUED, SERVICE, WRITE DMA QUEUED
6. BSY - The Drive Busy bit indicates that the device is busy.
7. DRQ - The Data Request bit indicates that the device is ready to transfer a word of data between the host and the device.

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 11
b) Write ATA drive device/head register with appropriate DEV8bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
2. Enable INTRQ in ATA drive device control register (nIEN bit)
3. Set PIO mode in ATA drive features register according to non-data command protocol in
ATA/ATAPI-4 spec:
a) Set PIO mode in ATA drive sector count register
b) Write SET TRANSFER mode into ATA drive features register
c) Write SET FEATURES command into ATA drive device command register
d) Wait for ATA interrupt – indicates that the device has accepted the SET FEATURES command
2.9.1.2 MDMA/UDMA Initialization Protocol Steps
1. Select drive according to device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
b) Write ATA drive device/head register with appropriate DEV bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
2. Enable INTRQ in ATA drive device control register (nIEN bit)
3. Set MDMA/UDMA mode in ATA drive features register according to non-data command
protocol in ATA/ATAPI-4 spec:
a) Set MDMA/UDMA mode in ATA drive sector count register
b) Write SET TRANSFER MODE into ATA drive features register
c) Write SET FEATURES command into ATA drive device command register
d) Wait for ATA interrupt – indicates that the device has accepted the SET FEATURES command
8. DEV - The Device Selection bit in ATA drive device/head register specifies which device is selected, 0 or 1.

MPC5200 ATA Interface, Rev. 0
ATA Interface
Freescale Semiconductor12
2.9.2 PIO Data Read
2.9.2.1 PIO Data in Command Protocol Steps
1. Select drive according to device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
b) Write ATA drive device/head register with appropriate DEV bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
2. Write ATA drive cylinder low register, ATA drive cylinder high register, ATA drive sector number
register, ATA drive sector count register
3. Write READ SECTOR(S) command into ATA drive device command register
4. Wait 400 ns
5. Wait for ATA interrupt – indicates that the data is ready for reading by host
6. Read (sector_count × sector_size) 16-bit ATA data words from ATA drive data register driven
either by core or Bestcomm. In the case of Bestcomm when snooping is not used, cache needs to
be invalidated first
2.9.3 PIO Data Write
2.9.3.1 PIO Data Out Command Protocol Steps
1. Select drive according to device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
b) Write ATA drive device/head register with appropriate DEV bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
2. Write ATA drive cylinder low register, ATA drive cylinder high register, ATA drive sector number
register, ATA drive sector count register
3. Write WRITE SECTOR(S) command into ATA drive device command register
4. Wait 400 ns
5. Wait for BSY=0 and DRQ = 1 in ATA drive alternate status register
6. Write (sector_count × sector_size) 16-bit ATA data words to ATA drive data register, driven either
by core or Bestcomm. In the case of Bestcomm when snooping is not used, cache needs to be
flushed first (entire write buffer)
7. Wait for ATA interrupt – indicates that the data has been written by the device

ATA Interface
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 13
2.9.4 DMA Data Read
2.9.4.1 DMA Command Protocol Steps
1. Select drive according to the device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
b) Write ATA drive device/head register with appropriate DEV bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
2. If snooping is not used, cache needs to be invalidated
3. Initialize and start BestComm ATA task
4. Set ATA FIFO alarm and granularity in ATA Rx/Tx FIFO alarm register, ATA Rx/Tx FIFO
control register
5. Set FIFO Reset bit (FR) in ATA drive device command register when the direction is switched
from Tx to Rx
6. Clear FIFO Reset bit (FR) in ATA drive device command register*
7. Set FIFO Flush in Rx Mode bit (FE) and Read bit (READ) in ATA drive device command
register*
8. If UDMA, set UDMA bit (UDAMA) in ATA drive device command register. Clear it for
MDMA*
9. Set Drive Interrupt bit (IE) in ATA drive device command register*
NOTE
This could be done just by one command.
10. Wait 400 ns
11. Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
12. Write ATA drive cylinder low register, ATA drive cylinder high register, ATA drive sector number
register, ATA drive sector count register
13. Wait 400 ns
14. Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
15. Write READ DMA command into ATA drive device command register
16. Wait for BestComm interrupt – indicates all data moved from ATA Rx FIFO to the RAM
2.9.5 DMA Data Write
2.9.5.1 DMA Command Protocol Steps
1. Select drive according to device selection protocol in ATA/ATAPI-4 spec:
a) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
b) Write ATA drive device/head register with appropriate DEV bit and LBA bit
c) Wait 400 ns
d) Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register

MPC5200 ATA Interface, Rev. 0
Performance Analysis
Freescale Semiconductor14
2. If snooping is not used, cache needs to be flushed (entire write buffer)
3. Initialize and start BestComm ATA task
4. Set ATA FIFO alarm and granularity in ATA Rx/Tx FIFO alarm register, ATA Rx/Tx FIFO
control register
5. Set Write bit (WRITE) in ATA drive device command register*
6. If UDMA, set UDMA bit (UDAMA) in ATA drive device command register. Clear it for
MDMA*
7. Set Drive Interrupt (IE) bit in ATA drive device command register*
NOTE
This could be done just by one command.
8. Wait 400ns
9. Wait for BSY=0 and DRQ = 0 in ATA drive alternate status register
10. Write ATA drive cylinder low register, ATA drive cylinder high register, ATA drive sector number
register, ATA drive sector count register
11. Write WRITE DMA command into ATA drive device command register
12. Wait for ATA interrupt – indicates that the data has been written by the device
2.9.6 Interrupt Handler
In the interrupt service routine, the first action is to clear the lower part of the ATA drive device command
register by writing a logical zero (bits HUT, FR, FE, IE, UDAMA, READ, WRITE). The pending ATA
drive interrupt is cleared by reading of the ATA drive device sstatus register as it is specified in the
ATA/ATAPI-4 specification.
3 Performance Analysis
Table 6 documents the maximum data throughput for all possible ATA modes. Of course, it is a theoretical
maximum throughput that, in reality, is never achieved. The real final result depends on the following:
•Device response delay – Average seek time for hard disks is a few milliseconds; therefore, some
host-based cache would be essential for applications like video players where large and
continuous streams of data need to be read from the device. This kind of host-based cache is
usually implemented as filesystem cache
•Sustained data rate – Devices like hard disks have limited speed at which physical data is read.
This number can be found in the device data sheet.
• Mode dependent delay
— Standby mode – The ATA device goes to the standby mode when the standby timer expires.
The interface is capable of accepting commands while waiting for the spindle to reach
operating speed. Delay is roughly hundreds of milliseconds
— Idle mode – See technical documentation for the ATA device.

Performance Analysis
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 15
•Device fragmentation delay – If the device is highly defragmented, using the look-ahead feature9
does not help. This is a typical problem of hard disks or Flash storage devices. DVDs and CDs
always have contiguous blocks of data.
•MPC5200 timing granularity – The MPC5200 ATA interface is clocked by the IPBI clock
(66/132 MHz). The ATA/ATAPI-4 specification defines minimum values for cycle time, setup
time, and hold time. Minimum values for timing registers are specified in IPBI clock cycles and
need to be rounded up; therefore, the best result are achieved with finer granularity. (For example,
the IPBI clock 132 MHz is measured on the logic analyzer, 31.5 MBytes/sec, for UDMA-2.)
Compare this with the maximum theoretical throughput in Table 6.
ATA performance can be optimized by:
• Reading/writing of the maximum number of sectors per single ATA command (see Figure 410).
Regular hard disk defragmentation is essential
• Enabling of special features in the ATA device—look-ahead, write cache, etc. First, they need to
be checked in the identify table to see if supported and then enabled by the SET FEATURES
command
• Using IPBI 132 MHz as described above
• Utilizing Bestcomm which can drive read/write in PIO mode to offload the core
9. Look-ahead read allows reading consequent sectors into the device cache. ATA host reads data from device cache. The size
of cache is vendor/type dependent, which can be found in the device documentation
Table 6. ATA Maximum Data Throughput
Mode Max.Rate
[MBytes/Sec]
MPC5200 ATA
Initialization
Driven By
MPC5200 ATA
Data Transfer
Driven By
PIO-0 3.3 core core/Bestcomm
PIO-1 5.2 core core/Bestcomm
PIO-2 8.3 core core/Bestcomm
PIO-3 11.1 core core/Bestcomm
PIO-4 16.7 core core/Bestcomm
MDMA-0 4.2 core BestComm
MDMA-1 13.3 core BestComm
MDMA-2 16.7 core BestComm
UDMA-0 16.7 core BestComm
UDMA-1 25 core BestComm
UDMA-2 33 core BestComm
10.Normalized results are measured by writing/reading 1 MB data to/from the same LBA address for IBM DBCA-203240 hard
disk with disabled drive cache. It could be different for other ATA devices. Check maximum number of sectors per single command
in the device identify table (usually up to 16 sectors per single command supported).

MPC5200 ATA Interface, Rev. 0
Performance Analysis
Freescale Semiconductor16
Figure 4. ATA Relative Throughput Improvement
System throughput is a result of the speed of the peripheral and the final integration—typically in OSs. For
a properly defragmented ATA device, it is considered bad programming style if the MPC5200 ATA host
reads or writes only a small number of sectors per single ATA command. In this case, the ATA software
driver and its interrupt handler could consume significant amounts of core time. The ATA software driver
can block anything running with lower priority in the system (see Table 7).11 In some cases in OSs, such
bad application implementation can degrade final ATA throughput by ~50% .
.
Looking at Table 7,the question arises as to why the throughput improvement indicated in Figure 4 is not
as expected. The answer is simple; it is writing/reading the same LBA address with the look-ahead/write
cache feature disabled. The time needed to read data from the interface is much smaller (microseconds)
than the average seek time (milliseconds).
Static memory allocation for the ATA software driver is recommended.
Although not described in the MPC5200 User’s Manual, the MPC5200 ATA interface is capable of
UDMA-4 66 MBytes/sec mode. The programming model is the same as for UDMA-2. The impact of all
the above possible performance considerations is more visible because of higher speed.
11.Reading subsequent sectors from hard disk with enabled look-ahead feature, the worst scenario for MPC5200 core load
Table 7. System Throughput
ATA Mode Sectors Per Single
Command
Time Between Two ATA
Interrupts
UDMA-2
115
µs
460
µs
16 240 µs
3.0
2.5
2.0
1.5
1.0
0.5
0.0
1.000 1.000
1.455 1.833 1.923
normalized throughput
2.535
16 sectors per single command
8
4
UDMA-2 write
UDMA-2 read

Literature
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 17
4 Literature
• MPC5200UM, MPC5200 User’s Manual (www.freescale.com)
• MPCFPE32B, Programming Environments Manual for 32-Bit Implementations of the PowerPC
Architecture) (www.freescale.com)
• G2CORERM, G2 Core Reference Manual (www.freescale.com)
• ATA/ATAPI-4, AT Attachment with Packet Interface Extension, ANSI NCITS 317–1998
(www.t13.org/technical/d98121r0.pdf)
• G2CORERM, G2 PowerPC Core Reference Manual (www.freescale.com)

MPC5200 ATA Interface, Rev. 0
MPC5200 ATA Register Summary
Freescale Semiconductor18
Appendix A MPC5200 ATA Register Summary
Table A1. MPC5200 ATA Host Registers
Register Acronym1
NOTES:
1Acronyms use terminology such as ata.h in freely distributed software
examples.
Offset Size [Bits]
ATA host configuration ata_config MBAR+0x3A00 8
ATA host status ata_status MBAR+0x3A04 8
Table A2. MPC5200 ATA Timing Registers
Register Acronym1
NOTES:
1Acronyms use terminology such as ata.h in freely distributed software
examples.
Offset Size [Bits]
ATA PIO timing 1 ata_pio1 MBAR+0x3A08 32
ATA PIO timing 2 ata_pio2 MBAR+0x3A0C 32
ATA multiword DMA timing 1 ata_dma1 MBAR+0x3A10 32
ATA multiword DMA timing 2 ata_dma2 MBAR+0x3A14 32
ATA ultra DMA timing 1 ata_udma1 MBAR+0x3A18 32
ATA ultra DMA timing 2 ata_udma2 MBAR+0x3A1C 32
ATA ultra DMA timing 3 ata_udma3 MBAR+0x3A20 32
ATA ultra DMA timing 4 ata_udma4 MBAR+0x3A24 32
ATA ultra DMA timing 5 ata_udma5 MBAR+0x3A28 32
ATA share count ata_invalid MBAR+0x3A2C 32
Table A3. MPC5200 ATA FIFO Registers
Register Acronym1
NOTES:
1Acronyms use terminology such as ata.h in freely distributed software examples.
Offset Size [Bits]
ATA Rx/Tx FIFO data word ata_fifo_data MBAR+0x3A3C 32
ATA Rx/Tx FIFO status ata_fifo_status MBAR+0x3A41 8
ATA Rx/Tx FIFO control ata_fifo_control MBAR+0x3A44 8
ATA Rx/Tx FIFO alarm ata_fifo_alarm MBAR+0x3A4A 16
ATA Rx/Tx FIFO read pointer ata_fifo_rdp MBAR+0x3A4E 16
ATA Rx/Tx FIFO write pointer ata_fifo_wrp MBAR+0x3A52 16

MPC5200 ATA Register Summary
MPC5200 ATA Interface, Rev. 0
Freescale Semiconductor 19
Table A4. MPC5200 ATA Drive Registers
Register Acronym1Offset Size [Bits] Mode
ATA drive device control ata_drive_ctrl MBAR+0x3A5C 8 write-only
ATA drive alternate status 8 read-only
ATA drive data ata_drive_data MBAR+0x3A60 16 R/W
ATA drive features ata_drive_ftr MBAR+0x3A64 8 write-only
ATA drive error 8 read-only
ATA drive sector count ata_drive_sc MBAR+0x3A68 8 R/W
ATA drive sector number ata_drive_sn MBAR+0x3A6C 8 R/W
ATA drive cylinder low ata_drive_cl MBAR+0x3A70 8 R/W
ATA drive cylinder high ata_drive_ch MBAR+0x3A74 8 R/W
ATA drive device/head ata_drive_dh MBAR+0x3A78 8 R/W
ATA drive device command ata_drive_cmd MBAR+0x3A7C 8 write-only
ATA drive device status 8 read-only
NOTES:
1Acronyms use terminology such as ata.h in freely distributed software examples.

AN3223
Rev. 0, 2/2006
How to Reach Us:
Home Page:
www.freescale.com
E-mail:
suppor[email protected]
USA/Europe or Locations Not Listed:
Freescale Semiconductor
Technical Information Center, CH370
1300 N. Alma School Road
Chandler, Arizona 85224
[phone] or [phone]
suppor[email protected]
Europe, Middle East, and Africa:
Freescale Halbleiter Deutschland GmbH
Technical Information Center
Schatzbogen 7
81829 Muenchen, Germany
[phone] (English)
[phone] (English)
[phone] (German)
[phone] (French)
suppor[email protected]
Japan:
Freescale Semiconductor Japan Ltd.
Headquarters
ARCO Tower 15F
1-8-1, Shimo-Meguro, Meguro-ku,
Tokyo 153-0064
Japan
0120 191014 or [phone]
suppor[email protected]
Asia/Pacific:
Freescale Semiconductor Hong Kong Ltd.
Technical Information Center
2 Dai King Street
Tai Po Industrial Estate
Tai Po, N.T., Hong Kong
[phone]
suppor[email protected]
For Literature Requests Only:
Freescale Semiconductor Literature Distribution Center
P.O. Box 5405
Denver, Colorado 80217
1-800-441-2447 or 303-675-2140
Fax: [phone]
[e-mail]
Information in this document is provided solely to enable system and software
implementers to use Freescale Semiconductor products. There are no express or
implied copyright licenses granted hereunder to design or fabricate any integrated
circuits or integrated circuits based on the information in this document.
Freescale Semiconductor reserves the right to make changes without further notice to
any products herein. Freescale Semiconductor makes no warranty, representation or
guarantee regarding the suitability of its products for any particular purpose, nor does
Freescale Semiconductor assume any liability arising out of the application or use of any
product or circuit, and specifically disclaims any and all liability, including without
limitation consequential or incidental damages. “Typical” parameters that may be
provided in Freescale Semiconductor data sheets and/or specifications can and do vary
in different applications and actual performance may vary over time. All operating
parameters, including “Typicals”, must be validated for each customer application by
customer’s technical experts. Freescale Semiconductor does not convey any license
under its patent rights nor the rights of others. Freescale Semiconductor products are
not designed, intended, or authorized for use as components in systems intended for
surgical implant into the body, or other applications intended to support or sustain life,
or for any other application in which the failure of the Freescale Semiconductor product
could create a situation where personal injury or death may occur. Should Buyer
purchase or use Freescale Semiconductor products for any such unintended or
unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor and
its officers, employees, subsidiaries, affiliates, and distributors harmless against all
claims, costs, damages, and expenses, and reasonable attorney fees arising out of,
directly or indirectly, any claim of personal injury or death associated with such
unintended or unauthorized use, even if such claim alleges that Freescale
Semiconductor was negligent regarding the design or manufacture of the part.
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
The described product is a PowerPC microprocessor core. The PowerPC name is a
trademark of IBM Corp. and is used under license. All other product or service names
are the property of their respective owners.
© Freescale Semiconductor, Inc. 2006. All rights reserved.
