Freggia DWI6159 User manual
DISHWASHER
ПОСУДОМОЕЧНАЯ МАШИНА
ПОСУДОМИЙНА МАШИНА
ZMYWARKA
User manual
Руководство пользователя
Інструкція з експлуатації
Instrukcja obsługi
DWI6159
EN
Thank you for purchasing Freggia dishwasher.
Please carefully read the user manual, as it contains the instructions for the safe installation, operation and maintenance of the
dishwasher.
Save it for future use.
RU
Freggia. ,
, ,
.
.
UA
, Freggia. ,
, , .
.
PL
Dziękujemy Państwu za dokonanie zakupu zmywarki Freggia.
Prosimy o uważne zapoznanie się z instrukcją obsługi, gdyż zawiera ona wskazówki dotyczące bezpiecznej instalacji, eksploatacji i
obsługi urządzenia.
Zalecamy zachowanie niniejszej instrukcji do wykorzystania w przyszłości, jak również zapisanie nazwy modelu i numeru seryjnego
Państwa zmywarki.
ATTANTION!
Important safety information.
!
.
!
.
UWAGA!
Ważna informacja dotycząca bezpieczeństwa.
IMPORTANT:
Edditional recommendations regarding usage.
:
.
:
.
PRZYDATNA INFORMACJA:
dodatkowa informacja dotycząca eksploatacji
kuchni.
NOTE:
Care and maintenance.
:
.
:
.
WSKAZÓWKA:
Wskazówki i porady dotyczące eksploatacji urządzenia.
GB
3
Getting familiar with your machine 3
INDEX GETTING FAMILIARWITHYOUR MACHINE
GETTING FAMILIAR WITH YOUR MACHINE....................3
TECHNICAL SPECIFICATIONS.............................................................4
CONFORMITY WITH THE STANDARDS AND TEST DATA.......4
SAFETY INFORMATION AND RECOMMENDATIONS....4
RECYCLING..................................................................................................4
SAFETY INFORMATION..........................................................................4
RECOMMENDATIONS........................................................................5
ITEMS NOT SUITABLE FOR DISHWASHING..................................5
INSTALLING THE MACHINE.................................................5
POSITIONING THE MACHINE........................................................5
WATER CONNECTIONS........................................................................5
WATER INLET HOSE...........................................................................5
WATER OUTLET HOSE.......................................................................5
ELECTRICAL CONNECTION.................................................................5
PRIOR TO USING THE MACHINE...........................................6
PREPARING THE MACHINE FOR USE..................................6
THE IMPORTANCE OF WATER DECALCIFICATION............6
FILLING WITH SALT...............................................................................6
TESTING STRIP.........................................................................................6
ADJUSTING SALT CONSUMPTION................................................6
DETERGENT USAGE...............................................................................6
FILLING THE DETERGENT COMPARTMENT...............................7
COMBINED DETERGENT......................................................................7
FILLING WITH RINSE AID AND MAKING THE SETTING......7
LOADING YOUR DISHWASHER..............................................7
TOP BASKET...............................................................................................7
LOWER BASKET.......................................................................................8
ALTERNATIVE BASKET LOADS.........................................................8
PROGRAMME DESCRIPTIONS..................................................9
PROGRAMME ITEMS............................................................................9
SWITCHING ON THE MACHINE
AND SELECTING A PROGRAMME.............................................9
SWITCHING ON THE MACHINE...................................................9
PROGRAMME FOLLOWUP..................................................................10
CHANGING A PROGRAMME.............................................................10
CHANGING A PROGRAMME WITH RESETTING.........................10
SWITCHING THE MACHINE OFF......................................................10
MAINTENANCE AND CLEANING........................................11
FILTERS........................................................................................................11
SPRAY ARMS.............................................................................................11
HOSE FILTER..............................................................................................11
FAILURE CODES AND WHAT TO DO
IN CASE OF FAILURE ...................................................................12
PRACTICAL AND USEFUL INFORMATION......................12
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control Panel
8. Detergent and rinse-aid dispenser
9. Salt dispenser
10. Upper basket track latch
11. U pper Cutlery Basket
12. Ceiling Spray Arm: It provides better washing for the
dishes at upper basket.
13. Turbo Drying Unit: This system provides better drying
performance for your dishes.
• 1 POWER ON/OFF BUTTON
When the Power On/O button is pressed, end of program indicator starts lighting.
• 2 PROGRAM DISPLAY
Program display indicates the times of the programs and the remaining time during
the program ow. You can also follow-up the selected programs by this display.
• 3 PROGRAM SELECTION BUTTON
With the program selector button, you can select a suitable program for your dishes.
• 4 DELAY TIMER BUTTON
You can delay the start time of a selected program for 1-2 ….19 hours by pressing
the delay timer button of your machine. When you press the delay timer button,
delay “1h” appears on the program display. If you continue pressing the delay timer
button, 1-2… 19 will be displayed respectively. You can activate the delayed start
by selecting the delay time and the desired washing program with the program
selection button. It is also possible to select the program rst and the delayed start
afterwards. If you want to change or cancel the delayed start time, you can adjust it
with the delay timer button; it will be activated according to the last value entered.
• 5 TABLET DETERGENT BUTTON 3 IN 1 BUTTON
Press tablet detergent button when you use combined detergents that include salt
and rinse aid.
• 6 PREWASH BUTON
If you select an extra pre-washing program, you improve washing performance.
When you select pre-washing, since it improves washing performance, it changes
the temperature and washing time of some programs.
Note: When a program which is not compatible with the pre-wash program is
selected, a buzzer sound is heard indicating that the selected program is not
compatible with the pre-wash option.
4Getting familiar with your machine
GETTING FAMILIARWITH YOUR MACHINE SAFETY INFORMATION AND
RECOMMENDATIONS
Note : If you will only make pre-washing, select prewash program with
program selection button.
• 7. ½ HALF LOAD BUTTON
Using the function ½ , three sorts of washing up can be done those being lower
basket, upper basket and both baskets.
If you have little amount of dishes in your machine and if you have
to wash them, you can also activate the semi-lling function in some
of the programs additionally. If you have dishes in both baskets, press
the key ½ and select the position in which both lamps are highlighted.
If you have dishes only in the upper basket, pres the key ½ and select
the position in which the upper lamp is illuminated. Thus, washing up
shall be done only on the upper basket of your machine. No dishes
should certainly be available in the lower basket while using this
feature.
If you have dishes only in the lower basket, press the key ½ and select
the position in which the lower lamp is illuminated. Thus, washing up
shall be done only on the lower basket of your machine. In using this
feature, make sure that there are no dishes in the upper basket.
Note : If you have used an extra feature on the latest washing program, this
feature will remain active also on the next washing program. If you do not
want to use this feature on the newly selected washing program, press the
selected feature button again, and check that the lamp on the button goes o.
Note: When you select an incompatible program with the half load button,
a buzzer sound is heard which indicates that the selected option is not
compatible.
• 8. SALT LACK WARNING INDICATOR
In order to see whether softening salt in your machine is sucient or not, check salt
lack warning light on the display.When salt light warning light starts coming on, you
need to ll in the salt chamber.
• RINSE AID LACK WARNING INDICATOR
In order to check that there is sucient rinse aid in your machine check rinse aid lack
warning light on the display.When rinse aid warning light starts coming on , ll in
rinse aid chamber.
• END OF PROGRAM INDICATOR
End of program indicator on the control panel turns on when the selected washing
program is completed .Your machine also gives a buzzer sound for “5 times” when
the program is completed.
RECYCLING
• Certain components and the packaging of your machine have been
produced from recyclable materials.
• Plastic parts are marked with international abbreviations: (>PE< , >PS< ,
>POM<, >PP<...)
• Cardboard parts have been produced from recycled paper and they
should be disposed of into waste paper collection containers for recycling.
• Such materials are not suitable for being disposed of into garbage bins.
They should be delivered to recycling centres instead.
• Contact relevant centres in order to obtain information on methods and
points of disposal.
SAFETY INFORMATION
• WHEN YOU TAKE DELIVERY OF YOUR MACHINE
• Check for any damage to your machine or to its packaging. Never start a
machine damaged in any way, make sure to contact an authorised service.
• Unwrap the packaging materials as indicated and dispose of them in
accordance with the rules.
• THE POINTS TO PAY ATTENTION DURING MACHINE INSTALLATION
• Choose a suitable, safe and level place to install your machine.
• Carry out the installation and connection of your machine by following
the instructions.
• This machine should be installed and repaired by an authorised service
only.
• Only original spare parts should be used with the machine.
• Before installing, be sure that the machine is unplugged.
• Check whether the indoor electrical fuse system is connected according
to the regulations.
• All electrical connections must match the values indicated on the rating
plate.
• Pay special attention and be sure that the machine does not stand on the
electricity supply cable.
• Never use an extension cord or a multiple socket for making a connection.
The plug should be comfortably accessible after the machine has been
installed.
• Please assemble the dishwasher, which is inserted under or in the kitchen
platform, according to the instruction. Be sure that the product is xed
properly.
• After installing the machine to a suitable place, run it unloaded for the
rst time.
• IN DAILY USE
• This machine is for household use; do not use it for any other purpose.
Commercial usage of the dishwasher will void the guarantee.
• Do not get up, sit or place a load on the open door of the dishwasher, it
may fall over.
• Never put into the detergent and rinse aid dispensers of your machine
anything other than those detergents and rinse aids which are produced
specically for dishwashers. Our company will not be responsible for any
damage that might occur in your machine otherwise.
• The water in the machine’s washing section is no drinking water, do not
drink it.
• Due to danger of explosion, do not put into the machine’s washing
section any chemical dissolving agents such as solvents.
• Check whether plastic items are heat-resistant before washing them in
the machine.
• Do not put into your machine those items which are not suitable for
dishwashing. Also, do not ll any basket above its capacity. Our company
will not be responsible for any scratch or rust to form on the inner frame
of your machine due to basket movements otherwise.
• Especially because hot water may ow out, the machine door should not
be opened under any circumstances while the machine is in operation.
In any case, a safety devices ensures that the machine stops if the door
is opened.
• Do not leave your dishwasher’s door open. Failure to do so may lead to
accidents.
• Place knives and other sharp-ended objects in the cutlery basket in
blade-down position.
Capacity 15 place settings
Height 820 mm – 870 mm
Width 596 mm
Depth 550 mm
Net Weight 38 kg
Electricity input 220-240 V, 50 Hz
Total Power 2200 W
Heating Power 2000 W
Pump Power 100 W
Drain Pump Power 30 W
Water supply pressure 0.03 MPa (0,3 bar) - 1 MPa (10 bar)
Current 10 A
• Producer company has its right to amend design and technical
specications reserved.
• The machine’s service life is 10 years (the duration required to keep spare
parts for the machine to full its usage functions).
CONFORMITY WITH THE STANDARDS AND TEST DATA / EC
DECLARATION OF CONFORMITY
All stages related to the machine are executed in accordance with the safety rules
provided in all relevant directives of the European Community.
2004/108/EC, 2006/95/EC,IEC 436/DIN 44990, EN 50242
GB
5
INSTALLING THE MACHINE
Make sure that the water inlet and outlet hoses do not get squeezed while positioning
the machine. Also, make sure that the machine does not stand on the electrical cable.
Adjust the machine’s adjustable feet so that it can stand level and balanced. Proper
positioning of the machine ensures problem-free opening and closing of its door.
If the door of you machine does not close properly, check if the machine is stable
on the oor it stands; if not, adjust the adjustable feet and ensure its stable position.
WATER CONNECTION
Be sure that the indoor plumbing is suitable for installing a dishwasher. Also, we
recommend that you t a lter at the entrance of your place or apartment so as to
avoid any damage to your machine because of any contamination (sand, clay, rust
etc.) that might be occasionally carried in through the mains water supply or the
indoor plumbing, and to forestall such complaints as yellowing and formation of
deposits after washing.
WATER INLET HOSE
Do not use the water inlet hose of your old machine, if any. Use
the new water inlet hose supplied with your machine instead. If
you are going to connect a new or long-unused water inlet hose
to your machine, run water through it for a while before making
the connection. Connect the water inlet hose directly to the water
inlet tap.The pressure supplied by the tap should be at a minimum
of 0.03 Mpa and and at a maximum of 1 Mpa.
If the water pressure is above 1 Mpa, a pressure-relief valve should
be tted inbetween. After the connections are made, the tap
should be turned on fully and checked for water tightness. For
the safety of your machine, make sure to always turn o the water
inlet tap after each wash programme is nished.
NOTE:
Aquastop water spout is used in some models.
In case of using Aquastop, a dangerous tension
exists. Do not cut Aquastop water spout. Do not
let it get folded or twisted.
WATER OUTLET HOSE
The water drain hose can be connected either
directly to the water drain hole or to the sink
outlet spigot. Using a special bent pipe (if
available), the water can be drained directly
into the sink via hooking the bent pipe over the
edge of the sink.
This connection should be at a minimum of 50
cm and and at a maximum of 110 cm from the
oor plane.
WARNING!
When a drain hose longer than 4 m is used, the dishes might remain dirty. In
that case, our company will not accept responsibility.
ELECTRICAL CONNECTION
The earthed plug of your machine should be connected to an earthed outlet
supplied by suitable voltage and current. If there is no earthing installation, have
a competent electrician carry out an earthing installation. In case of usage without
earthing installed, our company will not be responsible for any loss of usage that
might occur.
The indoor fuse current value should be 10-16 A.
Your machine is set according to 220-240 V. If the mains voltage in your location
is 110 V, connect a transformer of 110/220 V and 3000 W inbetween. The machine
should not be plugged in during positioning.
Always use the coated plug supplied with your machine.
The machine’s electrical cable should be replaced by an authorised service or an
authorised electrician only. Failure to do so may lead to accidents.
In order not to cause an electric shock, do not unplug when your hands are wet.
For safety purposes, always make sure to disconnect the plug when a wash
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• FOR YOUR CHILDREN’S SAFETY
• After removing the machine’s packaging, make sure that the packaging
material is out of reach of children.
• Do not allow children to play with or start the machine.
• Keep your children away from detergents and rinse aids.
• Keep children away from the machine while it is open because there may
still be residues of cleaning substances inside the machine.
• Be sure that your old machine does not pose any threat to your children.
Children are known to have gotten themselves locked in old machines.To
forestall such a situation, break your machine’s door lock and tear o the
electrical cables.
• IN CASE OF MALFUNCTIONING
• Any malfunction in the machine should be repaired denitely by qualied
persons. Any repair work performed by anyone other than the authorised
service personnel will cause your machine to be left outside the scope of
warranty.
• Prior to any repair work on the machine, be sure that the machine is cut
o from the mains. Switch o the fuse or unplug the machine. Do not pull
by the cable when unplugging. Make sure to turn o the water tap.
RECOMMENDATIONS
• For energy and water saving, remove coarse residues on your dishes
before placing the dishes into the machine. Start your machine after
having fully loaded it
• Use the pre-wash programme only whenever necessary.
• Place such hollow items as bowls, glasses and pots into the machine in
such a way that they will face down.
• You are recommended not to load into your machine any dishes dierent
or more than indicated.
ITEMS NOT SUITABLE FOR DISHWASHING:
• Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-
alloy materials;
• Forks, spoons and knives with wooden or bone, or ivory or nacre-coated
handles; glued items, items soiled with abrasive, acidic or base chemicals.
• Plastic items that are not heat-resistant, copper or tin-coated containers;
• Aluminium and silver objects (they may discolour, become dull)
• Certain delicate glass types, porcelains with ornamental printed patterns
as they fade even after the rst wash; certain crystal items as they lose
their transparency over time, adhered cutlery that is not heat-resistant,
lead crystal glasses, cutting boards, items manufactured with synthetic
bre;
• Absorbent items as sponges or kitchen rags are not suitable for
dishwashing.
WARNING!
Take care to buy dishwasher-proof sets in your future purchases.
INSTALLING THE MACHINE
POSITIONING THE MACHINE
When determining the place to put your machine on, take care to choose a place
where you can easily load and unload your dishes.
Do not put your machine in any location where there is the probability for the room
temperature to fall below 0°C.
Before positioning, take the machine out of its packaging by following the warnings
located on the package.
Position the machine close to a water tap or drain. You need to site your machine,
taking into consideration that its connections will not be altered once they are made.
Do not grip the machine by its door or panel in order to move it.
SAFETY INFORMATION AND
RECOMMENDATIONS
Table of contents
Languages:
Other Freggia Dishwasher manuals
