Freggia LBF336 User manual
COMBI REFRIGERATOR
FREEZER - FRIDGE
КОМБИ-ХОЛОДИЛЬНИК
КОМБІ-ХОЛОДИЛЬНИК
CHŁODZIARKO-ZAMRAŻARKA
User manual
Руководство пользователя
Інструкція з експлуатації
Instrukcja obsługi
LBF336
EN
Thank you for purchasing Freggia household appliance.
Please carefully read the user manual, as it contains the instructions for the safe installation, operation and maintenance of the
household appliance.
Save it for future use.
RU
Freggia. , -
, , -
.
.
UA
, Freggia. , -
, , .
.
PL
Dziękujemy za zakup sprzętu AGD marki Freggia. Prosimy o zapoznanie się z instrukcją obsługi, gdyż zawiera wskazówki dotyczące
bezpiecznej instalacji, użytkowania i konserwacji zakupionego urządzenia.
Zalecamy zachowanie niniejszej instrukcji do wykorzystania w przyszłości, jak również zapisanie nazwy modelu i numeru seryjnego
Państwa urządzenia.
ATTANTION!
Important safety information.
!
.
!
.
UWAGA!
Ważna informacja dotycząca bezpieczeństwa.
IMPORTANT:
Edditional recommendations regarding usage.
:
.
:
.
PRZYDATNA INFORMACJA:
dodatkowa informacja dotycząca eksploatacji.
NOTE:
Care and maintenance.
:
.
:
.
WSKAZÓWKA:
Wskazówki i porady dotyczące eksploatacji urządzenia.
GB
3
BEFORE USING THE APPLIANCE 3
CONTENTS BEFORE USINGTHE APPLIANCE
BEFORE USING THE APPLIANCE.............................................3
GENERAL WARNINGS.............................................................................3
OLD AND OUTOFORDER FRIDGES..............................................3
SAFETY WARNINGS................................................................................4
INSTALLING AND OPERATING YOUR FRIDGE............................4
BEFORE USING YOUR FRIDGE.......................................................4
THE PARTS OF THE APPLIANCE
AND THE COMPARTMENTS.........................................................4
THE VARIOUS FUNCTION AND POSSIBILITIES............4
THERMOSTAT SETTING................................................................................4
WARNINGS ABOUT TEMPERATURE ADJUSTMENTS.........................5
ACCESSORIES..................................................................................................5
Freezer boxes.............................................................................................5
Chiller shelf.................................................................................................5
Humidity controler..................................................................................5
Adjustable door shelf...........................................................................5
CLEANING AND MAINTENANCE...........................................5
DEFROSTING.................................................................................6
Defrosting the fridge compartment...............................................6
Defrosting the freezer compartment..........................................6
Replacing the light bulb....................................................................6
ARRANGING FOOD IN THE APPLIANCE...........................6
REFRIGERATOR COMPARTMENT...............................................................6
FREEZER COMPARTMENT............................................................................6
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION........................................................................................7
REPOSITIONING THE DOOR.............................................................7
BEFORE CALLING YOUR AFTER SALES SERVICE..........8
TIPS FOR SAVING ENERGY...........................................................8
GENERAL WARNINGS
WARNING: Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING: Donotuse mechanical devicesorother means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
WARNING:
Do not damage the refrigerant circuit.
WARNING: In order to avoid any hazards resulting from the instability
of the appliance, it must be xed in accordance with the following
instructions:
• If your appliance uses R600a as a refrigerant (this information will be provided on
the label of the cooler) you should take care during transportation and installation
to prevent the cooler elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak due to damage of
the cooler elements, move your fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a ammable
propellant in this appliance.
• This appliance is intended to be used in household and domestic applications
such as:
- sta kitchen areas in shops, oces and other working
environments.
- farm houses and by clients in hotels, motels and other residential type
environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be replaced by the
manufacturer, a service agent or similarly qualied persons in order to avoid a
hazard.
• A specially grounded plug has been connected to the power cable of your
refrigerator. This plug should be used with a specially grounded socket of 16
amperes. If there is no such socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer, an
authorised service agent or similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding 2000 m.
OLD AND OUTOFORDER FRIDGES
• If your old fridge has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers may contain isolation material and refrigerant
with CFC or HFC. Therefore, take care not to harm environment when
you are discarding your old fridges.
• Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Please read the instruction manual carefully before installing and using your
appliance. We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in
domestic environments and for the specied purposes. It is not suitable for
commercial or common use. Such use will cause the guarantee of the appliance
to be cancelled and our company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling
• / storing food. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for losses to be
incurred in the contrary case.
The fridge freezer thermostat automatically
regulates the inside temperature of the
compartments. By rotating the knob from
position 1 to 5, colder temperatures can be
obtained.
Important note: Do not try to rotate
knob beyond position 1, it will stop
your appliance from working.
Freezer & fridge thermostat setting;
SAFETY WARNINGS
Do not connect your Fridge Freezer to the mains electricity supply using
an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to play with
the appliance or let them hang o the door.
• Never touch the power cord/plug with wet hands as this could cause a short
circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making compartment
as they can burst as the contents freeze.
• Do not place explosive or ammable material in your fridge. Place drinks with
high alcohol content vertically in the fridge compartment and make sure that
their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it. Ice may
cause frost burns and/or cuts.
Do not touch frozen goods with wet hands. Do not eat ice-cream or ice
cubes immediately after you have taken them out of the ice-making
compartment.
• Do not re-freeze frozen goods after they have melted. This may cause health
issues such as food poisoning.
• Do not cover the body or top of fridge with lace. This aects the performance of
your fridge.
• Secure any accessories in the fridge during transportation to prevent damage to
the accessories.
INSTALLING AND OPERATING YOUR FRIDGE
Before using your fridge, you should pay attention to the following
points:
• The operating voltage for your fridge is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due to ungrounded
usage.
• Place your fridge where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater
cores, and at least 5 cm away from electrical ovens.
• Your fridge should never be used outdoors or exposed to rain.
• When your fridge is placed next to a deep freezer, there should be at least 2 cm
between them to prevent humidity forming on the outer surface.
• Do not place anything on your fridge, and install your fridge in a suitable place
so that at least 15 cm of free space is available above it.
• Use the adjustable front legs to make sure your appliance is level and stable.
You can adjust the legs by turning them in either direction. This should be done
before placing food in the fridge.
• Before using your fridge, wipe all parts with a solution of warm water and a
teaspoon of sodium bicarbonate, then rinse with clean water and dry. Place all
parts in the fridge after cleaning.
• Install the plastic distance guide (the part with black vanes at the rear) by turning
it 90° (as shown in the gure) to prevent the condenser from touching the wall.
• The refrigerator should be placed against a wall with a free space not exceeding
75 mm.
BEFORE USING YOUR FRIDGE
• When using your fridge for the rst time, or after transportation, keep it in an
upright position for at least 3 hours before plugging into the mains. This allows
ecient operation and prevents damage to the compressor.
• Your fridge may have a smell when it is operated for the rst time.This is normal
and the smell will fade away when your fridge starts to cool.
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
A. Fridge compartment
B. Freezer compartment
1. Thermostat knob
2. Lamp cover
3. Turbo fan *
4. Wine rack *
5. Fridge shelves
6. Chiller *
7. Crisper cover
8. Crisper
9. Freezer upper room cover / Upper basket
10. Freezer middle basket
11. Freezer bottom basket
12. Levelling feet
13. Freezer glass shelves
14. Bottle shelf
15. Adjustable door shelf * / door shelf
16. Door shelf
17. Egg holder
18. Ice tray
* In some models
THEVARIOUS FUNCTION AND POSSIBILITIES
THERMOSTAT SETTING
4THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
STARTINGTHE APPLIANCE THE PARTS OFTHE APPLIANCE
ANDTHE COMPARTMENTS
1 – 2 : For short-term storage of food in the freezer compartment, you can set the knob
between the minimum and medium position.
Thermostat knob
• CHILLER SHELF (In some models)
3 – 4 : For long-term storage of food in the freezer compartment, you can set the knob
to the medium position.
5 : For freezing fresh food. The appliance will work for longer. So, after the desired
condition is reached, return the knob to the previous setting.
WARNINGS ABOUT TEMPERATURE ADJUSTMENTS
• We recommend that you do not operate your fridge in environments where the
ambient temperature is below 10°C because this will reduce its eciency.
• Temperature adjustments should be made according to the frequency of door
openings and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient
temperature without interruption after being plugged in to be completely
cooled. Do not open doors of your fridge frequently and do not place much
food inside it in this period.
• During power cut, to prevent any compressor problem you should unplug the
refrigerator. You should delay pluging in 5 – 10 minutes after your power supply
returns. If you plug out the refrigerator for a reason you should wait at least 5
min to replug. It is important for avoiding damage to refrigerator’s components.
• Your fridge is designed to operate in the ambient temperature intervals stated
in the standards, according to the climate class stated in the information label.
We do not recommend operating your fridge out of stated temperatures value
limits in terms of cooling eectiveness.
• This appliance is designed for use at an ambient temperature within the 10°C -
43°C range.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
• HUMIDITY CONTROLLER
GB
5
THE VARIOUS FUNCTION AND POSSIBILITIES
THEVARIOUS FUNCTION AND POSSIBILITIES
Climate class Ambient(oC)
T 16 to 43(°C)
ST 16 to 38 (°C)
N 16 to 32 (°C)
ACCESSORIES
• FREEZER BOXES
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
Makethe inverseofthesame operationfor theresettingthe slidingcompartment.
Note:
Always Keep the handle of box while removing the box.
or
Freezer boxes Freezer boxes
Flap cover
Important!
Do not put foods you want to freeze or ice trays in order to make ice.
When the humidity controler in the
closed position, it allows fresh fruit
and vegetables to be stored longer.
In case of the crisper is totally full,
the fresh dial is located in front
of crisper, should be opened. By
means of this the air in the crisper
and humidity rate will be controlled
and endurance life will be increased.
Keeping food in the Chiller compartment
instead of the freezer or refrigerator
compartment allows food retain freshness
and avour longer, while preserving its fresh
appearance. When chiller tray becomes dirty,
remove it and wash it with water.
(Water freezes at 0°C, but foods containing
salt or sugar freeze at temperature lower
than that)
Normally people use the chiller compartment
for raw sh, lightly pickled, rice, etc...
If you see any condensation on glass shelf, humidity control should be taken into the
open positions.
• ADJUSTABLE DOOR SHELF (In some models)
Six dierent height adjustments can be made to provide storage areas that you need
by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the
shelf and pull the buttons
on the side of the door shelf
direction of arrow (Fig.1).
Position door shelf the
height you need by moving
up and down. After you
get the position that you
want the door shelf, release
the buttons on the side of the door shelf (Fig.2) Before
releasing the door shelf, move up down and make sure
the door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the shelf by
supporting the bottom. Otherwise, door shelf could fall o the rails due to the
weight. So damage may occur on the door shelf or rails.
Visual and text descriptions on the accessories section may vary according to the
model of your appliance.
CLEANING AND MAINTENANCE
Important!
Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other electrical
components.
• The refrigerator should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water.
• Clean the accessories separately with soap and water Do not clean them in the
dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse with
clean water and dry carefully. When you have nished cleaning, reconnect the
plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help you to save
on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Fig. 1
Fig. 2
Replacing LED lighting
If your refrigerator has LED lighting contact the help desk as this should
be changed by authorized personnel only.
6CLEANING AND MAINTENANCE
CLEANING AND MAINTENANCE ARRANGING FOOD INTHE APPLIANCE
DEFROSTING
• DEFROSTING THE FRIDGE COMPARTMENT
REFRIGERATOR COMPARTMENT
• To reduce humidity and consequent increase of frost never place liquids in
unsealed containers in the refrigerator. Frost tends to concentrate in the coldest
parts of the evaporator and in time will require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to cool
at room temperature and should be arranged to ensure adequate air circulation
in the refrigerator compartment.
• Nothing should touch on the back wall as it will cause frost and the packages
can stick on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned sh(wrapped in packages or sheets of plastic)
which you will use in 1-2 days,in the bottom section of the refrigerator
compartment(that is above the crisper) as this is the coldest section and will
ensure the best storing conditions.
• You can put the fruits and vegetables into crisper without packing.
Some recommendations have been specied below for the placement and storage
of your food in the cooling compartment.
NOTE:
Potatoes, onions and garlic should not be stored in the refrigerator.
• Defrosting occurs fully automatically in fridge compartment during
operation; the defrosted water collected by the evaporating tray and evaporates
automatically.
• The evaporating tray and water drain hole (back of the refrigerator crisper shelf)
should be cleaned periodically to prevent the water from collecting on the
bottom of the fridge instead of owing out.
• DEFROSTING THE FREEZER COMPARTMENT
• The frost, which covers the shelves of the freezer compartment, should be
removed periodically.
• Do not use sharp metal objects for this operation. They could puncture the
refrigerant circuit and cause irreparable damage to the unit. Use the plastic
scraper provided.
• When there is more than 5 mm of frost on the shelves, defrosting must be
carried out.
• Before defrosting, place the frozen food in a cool place after wrapping it in
sheets of newspaper (this will help the food to maintain it’s tempertaure for
longer).
• To accelerate the defrosting
process, place one or more bowls
of warm water in the freezer
compartment.
• Dry the inside of the compartment
with a sponge or a clean cloth.
• Once the unit has been defrosted,
place the food into freezer and
remember to consume it in a
short period of time.
REPLACING THE LIGHT BULB
To replace the bulb in the fridge compartments;
1. Unplug your fridge freezer.
2. Using a screwdriver, carefully remove the light cover from the top panel. (a)
3. Replace with a 15 watt bulb. (b)
4. Reinstall the light cover. (c)
5. Wait for 5 minutes before re-plugging the fridge in and restore the thermostat
to its original position.
Food Maximum Storing time Where to place in the
fridge compartment
Vegetables and fruits 1 week Vegetable bin
Meat and sh 2 - 3 Days
Wrapped in plastic foil or
bags or in a meat contai-
ner (on the glass shelf)
Fresh cheese 3 - 4 Days In special door shelf
Butter and margarine 1 week In special door shelf
Bottled products milk
and yoghurt
Until the expiry date recom-
mended by the producer In special door shelf
Eggs 1 month In the egg shelf
Cooked food All shelves
FREEZER COMPARTMENT
• Please use the deep freeze compartment of your refrigerator for storing the
frozen food for a long time and for producing ice.
• To get maximum capacity for freezer compartment, please just use glass shelves
for upper and middle section. For bottom section, please use lower basket.
• For optimum appliance performance to reach maximum freezing capacity, Set
the refrigerator at 4 for 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, change the setting to 5 for 24 hours is
generally sucient. After 24 hours, you can reduce the setting if required.
• Please do not place the food you shall newly freeze nearby the already frozen
food.
• You should freeze the food to be frozen (meat, minced meat, sh, etc.) by
dividing them into portions in such a way that they can be consumed once.
• Please do not refreeze the frozen food once they are thawed. It may pose a
danger for your health since it might cause problems such as food poisoning.
• Do not place the hot meals in your deep freeze before they become cold. You
would cause the other food frozen beforehand in the deep freeze to become
putreed.
• When you buy frozen food, makes sure that they were frozen under appropriate
conditions and the package is not torn.
• While storing the frozen food, the storage conditions on the package should
certainly be observed. If there is not any explanation, the food must be
consumed within the shortest time possible.
• If there had been humidication in the frozen food package and it has a foul
smell, the food might have been stored under unsuitable conditions previously
and gone rotten. Do not purchase this type of foods!
• The storage durations of frozen food change depending on the ambient
temperature, the frequent opening and closing of the doors, thermostat
settings, food type and the time elapsed from the purchase time of the food
to the time it is placed into the freezer. Always abide by the instructions on the
package and never exceed the indicated storage duration.
7
ARRANGING FOOD IN THE APPLIANCE 7
ARRANGING FOOD INTHE APPLIANCE
Note that; if you want to open again immediately after closing the freezer
door, it will not be opened easily. It’s quite normal! After reaching equilibrium
condition, the door will be opened easily.
Important note:
• Frozen foods, when thawed, should be cooked just like fresh foods. If they are
not cooked after being thawed they must NEVER be re-frozen.
• The taste of some spices found in cooked dishes (anise, basilica, watercress,
vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black
pepper, etc.) changes and they assume a strong taste when they are stored for a
long period. Therefore, the frozen food should be added little amount of spices
or the desired spice should be added after the food has been thawed.
• The storage period of food is dependent on the oil used. The suitable oils are
margarine, calf fat, olive oil and butter and the unsuitable oils are peanut oil and
pig fat.
• The food in liquid form should be frozen in plastic cups and the other food
should be frozen in plastic folios or bags.
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a
strong rope. The instructions written on the corrugated box must be followed
while transporting.
• Before transporting or changing the installation position, allthemovingobjects
(ie,shelves,crisper…) should be taken out or xed with bands in order to prevent
them from getting damaged.
Important!
Carry your fridge in the upright position.
REPOSITIONING THE DOOR
• It is not possible to change the opening direction of your refrigerator door, if the
door handle on your refrigerator is installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any
handles.
• If the door opening direction of your refrigerator may be changed, you should
contact the nearest Authorised Service Agent to have the opening direction
changed.
GB
Meat and sh Preparation
Maximum
Storing time
(month)
Steak Wrapping in a foil 6 - 8
Lamb meat Wrapping in a foil 6 - 8
Veal roast Wrapping in a foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packages without using
spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be packaged even if it
has membrane
Chicken and turkey Wrapping in a foil 4 - 6
Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar In 2.5 kg portions and as llets 6 - 8
Fresshwater shes (Salmon,
Carp, Crane, Siluroidea) After cleaning the bowels and
scales of the sh, wash and dry
it; and if necessary, cut o the
tail and head.
2
Lean sh; bass, turbot,
ounder 4
Fatty shes (Tunny, Mackarel,
bluesh, anchovy) 2 - 4
Shellsh Cleaned and in bags 4 - 6
Caviar In its package, aluminium or
plastic container 2 - 3
Snails In salty water, aluminum or
plastic container 3
Vegetables and
Fruits Preparation
Maximum
Storing time
(month)
String beans and
beans
Wash and cut into small pieces and boil
in water 10 - 13
Beans Hull and wash and boil in water 12
Cabbage Cleaned and boil in water 6 - 8
Carrot Clean and cut to slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove
the core and boil in water 8 - 10
Spinach Washed and boil in water 6 - 9
Cauliower
Take the leaves apart, cut the heart into
pieces, and leave it in water with a little
lemon juice for a while
10 - 12
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet
corn 12
Note: Frozen meat should be cooked as fresh meat after being thawed. If the
meat is not cooked after being thawed, it must not be re-frozen.
Vegetables and
Fruits Preparation
Maximum
Storing time
(month)
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Adding 10 % of sugar in the container 12
Plum, cherry,
sourberry Wash and hull the stems 8 - 12
Dairy
Products Preparation
Maximum
Storing
time
(months)
Storing Conditions
Packet
(Homogenize)
Milk
In its own
packet 2 - 3 Pure Milk – In its own packet
Cheese-
excluding
white cheese
In slices 6 - 8
Original package may be used
for short storing period. It
should be wrapped in foil for
longer periods.
Butter,
margarine
In its
package 6
Dairy
Products
Maximum
Storing time
(months)
Thawing
time in room
temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
8BEFORE CALLING YOUR AFTER SALES SERVICE
If your fridge freezer is not working properly, it may be a minor problem, therefore to
save time and money, check the following, before calling an electrician.
What to do if your appliance does not operate Check that:
• There is no power,
• The general switch in your home is disconnected,
• The thermostat setting is on the «•» position,
• The socket is not faulty. To check this, plug the appliance in to another socket
which you know is working.
What to do if your appliance performs poorly Check that:
• You have overloaded the appliance,
• The thermostat setting is on position “1” (if so set the thermostat dial to a
suitable value).
• The doors are closed properly,
• There is no dust on the condenser,
• There is enough space at the rear and side walls.
If your fridge is operating too loudly Normal Noises
Compressor noise
• Normal motor noise: This noise means that the compressor operates normally
• Compressor may cause more noise for a short time when it starts.
Bubbling noise and splash:
• This noise is caused by the ow of the fridge freezer in the tubes of the system.
• If you hear any other noises check that:
- The appliance is level
- Nothing is touching the rear of the appliance
- The objects on the appliance are vibrating.
If there is water in the lower part of the fridge freezer, Check that:
The drain hole for the water is not clogged (use the defrost drain plug to clean the
drain hole).
Recommendations
• If you do not intend to use the appliance for long time (for example during the
summer holidays) unplug and clean the appliance and leave the door open to
prevent the formation of mildew and smells.
• To stop the appliance completely, unplug it from the main socket (for cleaning
and when the doors are left open).
• If a problem persists after you have followed all the instructions above, please
consult the nearest Authorised Service Centre.
TIPS FOR SAVING ENERGY
• Install the appliance in a cool, well ventilated room , but not in direct sunlight
and not near a heat source (radiator, cooker.. etc). Otherwise use an insulating
plate.
• Allow warm food and drinks to cool down outside the appliance.
• When thawing frozen food, place it in the refrigerator compartment. The low
temperature of the frozen food will help to cool the refrigerator compartment
when it is thawing. This will help to save energy. If the frozen food is put out, it
results in a waste of energy.
• Cover drinks or other liquids when placing them in the appliance Otherwise
humidity increases in the appliance. Therefore, the working time gets longer.
Also covering drinks and other liquids helps to preserve smell and taste.
• Try to avoid keeping the doors open for long periods or opening the doors too
frequently as warm air will enter the cabinet and cause the compressor to switch
on unnecessarily often.
• Keep the covers of the dierent temperature compartments (crisper, chiller
...etc ) closed
• Door gasket must be clean and pliable. Replace gaskets if worn.
• Energy consumption is declared with maximum load and using only bottom
freezer drawer and bottom glass shelf.
BEFORE CALLINGYOUR AFTER SALES SERVICE
: ,
.
:
,
.
: -
, ,
.
:: -
.
: ,
, -
.
• R600a, -
, .
,
. R600a – ,
,
, ,
, , -
.
• -
.
• , -
.
• .
• -
, -
. ,
.
• (
) , -
,
,
. ,
.
• -
.
16 . -
, -
.
• , -
. , -
8 ,
,
, .
8
. .
•
. -
. -
.
• 2000
.
• , ,
,
, .
• -
CFC HFC
. , -
, ..
• , , -
.
:
• ,
. -
, -
.
9
RU
СОДЕРЖАНИЕ ПЕРЕД ИСПОЛЬЗОВАНИЕМ УСТРОЙСТВА
.....................9
......................................9
.............9
...............................................................................................10
...........10
...................10
...........................10
.................................11
....................................................................11
.........................................................................................................11
.................................................................................................11
...........................................................11
..............................................11
..........................................................................11
.......................................................11
.......................................12
............................................................................12
...........................12
........................12
..........................................................12
.............................................12
..........................................................................12
..........................................................................13
....................................................................................14
..............................................................14
, .......................14
..................15
• , -
, .
•
.
. -
,
- .
• -
/ .
-
- , . -
- .
-
.
• , .
• , .
• ,
, .
• ,
.
• , .
.
• , -
. -
,
.
• , , -
, / .
!
-
!
• , .
, -
.
• . -
.
• -
.
:
• 220-240 50 .
• - , -
.
• , -
.
• 50 , -
, 5
.
•
.
• -
, 2
.
• . ,
, , 15 .
• -
, -
. ,
( ). -
, .
• -
,
. .
• (
), 90°, -
.
• -
, 75 .
• -
-
3 , .
, .
• ;
.
ДЕТАЛИ И КАМЕРЫ ХОЛОДИЛЬНИКА
10
ПЕРЕД ИСПОЛЬЗОВАНИЕМ УСТРОЙСТВА
-
.
A.
B.
1.
2.
3. *
4. *
5.
6. O *
7.
8.
9.
10.
11.
12.
13. C
14.
15. P * /
16.
17.
18.
*
(. 2). , ,
.
. -
. - .
.
-
.
-
.
1 -
5 .
:
,
1, -
.
1 – 2 :
.
3 – 4 :
.
5 : . .
, -
.
•
10 °C.
•
.
• , -
.
• ,
24 ( -
).
.
• 5- -
, ,
, . -
5 .
• -
, ,
.
.
• -
10°C 43°C.
Термостат
RU
11
ДИСПЛЕЙ И ПАНЕЛЬ УПРАВЛЕНИЯ
oC
T 16 43 (°C)
ST 16 38 (°C)
N 16 32 (°C)
SN 10 32 (°C)
•
-
.
• .
• .
, ,
.
• , -
.
• , .
•
-
,
.
,
, , -
, .
-
-
-
,
.
.
( 0 °C, , -
,
.) -
-
, , . .
.
.
• ( )
, -
.
.
, ,
-
-
,
(. 1).
-
, -
.
, -
Рис. 1
Рис. 2
или
Ящики морозильной
камеры
Дверца мо-
розильного
отсека
Ящики морозильной
камеры
-
.
.
, .
• ( )
, -
, .. -
.
РАСПРЕДЕЛЕНИЕ ПРОДУКТОВ
• , ,
. -
;
.
• . -
-
, .
• ,
. .
• ( ), -
1–2 ,
( ),
.
• -
.
-
.
12
ОЧИСТКА И ОБСЛУЖИВАНИЕ
, -
.
• .
• -
.
• , .
.
• ,
, , -
.
•
. -
, .
!
, .
•
• -
. -
.
•
( -
), .
•
• , , -
.
• .
, ,
. .
• 5 , -
.
•
, ,
.
• -
-
.
•
.
• -
-
-
.
3. (b) 15 .
4. (c) .
1
2 - 3
(
)
3 - 4
1
,
1 -
:
1. ;
2. (a) ,
. : ,
.
-
()
,
10 - 13
, 12
6 - 8
, , -
12
, -
,
8 - 10
6 - 9
-
,
.
10 - 12
2 . 10 - 12
12
8 - 10
4 - 6
-
8 - 12
-
10% 12
, ,
8 - 12
13
13
РАСПРЕДЕЛЕНИЕ ПРОДУКТОВ
•
.
•
. -
.
• , , -
.
• , (, , . .), -
, ,
.
• . -
, .
• . -
, .
• , -
, .
• ,
. -
.
• ,
, , -
. !
• -
, ,
, ,
.
.
•
. , , -
.
.
: ,
,
. .
, .
• ,
. ,
.
• (, ,
, , , , , , , ,
, .) :
.
-
.
• .
,
, , -
.
• -
, — .
-
()
6 - 8
6 - 8
6 - 8
6 - 8
4 - 8
1 - 3
( ) 1 - 3
/
4 - 6
4 - 6
-
()
, ,
2,5 6 - 8
(, , ) -
; -
.
2
, ,
, 4
(, -
, , ) 2 - 4
4 - 6
,
2 - 3
,
3
:
.
, .
RU
14
ДОСТАВКА И ИЗМЕНЕНИЕ МЕСТА УСТАНОВКИ
•
( ).
• ,
,
.
• (, , -
..) -
.
!
.
• -
, -
.
• -
.
• -
, , .
РАСПРЕДЕЛЕНИЕ ПРОДУКТОВ ПЕРЕД ТЕМ, КАК ОБРАТИТЬСЯ В СЕРВИС
-
()
-
()
()
4 - 6 2 - 3 4-5 (220-225 °C)
3 - 6 1 - 1,5 5-8 (190-200 °C)
1 - 3 2 - 3 5-10 (200-225 °C)
1 - 1,5 3 - 4 5-8 (190-200 °C)
2 - 3 1 - 1,5 5-8 (190-200 °C)
2 - 3 2 - 4 15-20 (200 °C)
-
-
-
()
(-
)
-
2 - 3 -
, -
-
6 - 8
-
,
-
6
, -
. ,
.
-
.
.
, . -
:
• ? -
?
• ?
• ?
• ? , -
, .
, -
( ). :
• ?
• ?
• ?
• ?
• -
?
• , -
.
• -
.
, -
. :
• ?
• ?
, -
,
.
, :
• -
, , -
, .
-
.
, -
:
• ?
• ?
• , ?
• ? , -
.
• ?
( )
•
• (- -
)
: .
( ):
,
.
: -
.
ПЕРЕД ТЕМ, КАК ОБРАТИТЬСЯ В СЕРВИС
15
,
RU
: ,
. -
( ):
• .
• ?
?
• ? -
.
•
.
-
:
• ?
• , , ?
• ?
:
-
, .
-
. -
4-5 .
, « »
.
, , -
. . .
.
• ( -
), .
• , -
.
, .
•
.
.
1. , ,
, (-
, ..). , -
.
2. , -
, .
3. -
.
. , -
. -
, .
4.
.
. , .
-
.
5.
.
6. , (
, ..) .
7. . -
.
8. -
.
16
: ,
.
:
, -
.
:
, -
.
:
.
: -
, .
• R600a ( -
),
, -
, . R600a
, , -
’
, ,
.
•
, .
• ,
.
• .
• ,
.
• ( )
, ,
, , ,
, -
.
• , .
.
, -
16 .
• ,
.
8 ,
, -
-
. .
.
• , , -
, ,
.
• 2000 -
.
• ,
,
, ,
.
•
, CFC HFC . , -
, , .
• -
( WEEE) ,
, ,
.
:
•
. ,
.
• , , -
,
.
ЗМIСТ ПЕРЕД ВИКОРИСТАННЯМ
.....................................................16
...................................................................16
........................................16
..........................17
...........17
.............................17
................................17
.................................17
..............................................18
........18
.................................................................................................18
..................................................18
.........................................................18
...........................................................................18
...................................................18
..................................19
............................................................................19
......................19
........................19
..........................................................19
...........19
..........................................................................19
..........................................................................20
...........................................................................21
......................21
.....................................................................21
...................................22
•
-
3 . . -
.
• ’ .
, .
ЧАСТИНИ ТА ВІДСІКИ ПРИСТРОЮ
17
UA
ПЕРЕД ВИКОРИСТАННЯМ
• . -
.
. -
, --
.
•
.
/ -
, . - -
, .
-
.
• , .
• , .
• ,
, .
• —
!
• .
.
• -
. -
.
• , —
/ .
! -
,
!
• .
’, , .
• .
.
• , -
.
-
.
• 220–240 50 .
•
.
• , -
.
• 50
, 5 -
.
• -
.
•
, 2 ,
.
• - .
, 15 -
.
• ,
. -
( ).
, .
•
,
. .
• ( ) -
, , 90°, -
.
• 75
.
. -
.
A)
B)
1.
2.
3. *
4. *
5.
6. *
7.
8.
9.
10.
11.
12.
13.
14.
15. * /
16.
17.
18.
*
: , -
. , -
.
.
.
Терморегулятор
oC
T 16 43 (°C)
ST 16 38 (°C)
N 16 32 (°C)
, ,
.
• , .
• ,
•
-
.
,
.
-
-
, -
,
. -
,
.
( 0 °C, , -
,
.)
, -
, , .
, .
’
.
• ( )
-
.
. (.1)
-
, -
. -
-
(.
2). -
, -
,
.
Мал.1
Мал.2
або
Контейнер
для заморожування
Відкидна
кришка
i i -
i i. 1 5, -
.
, 1,
.
• ( )
18
ДИСПЛЕЙ ТА ПАНЕЛЬ КЕРУВАННЯ
i i i .
1-2: -
-
-
.
3-4: i
iii -
.
5: i i.
i -
.
.
• -
10 °C .
•
.
• -
24
.
.
• ,
5- , -
, .
5 .
• -
, , , -
. -
, ,
.
• -
10 - 43 °C.
•
.
:
•
• .
-
.
:
.
Контейнер
для заморожування
UA
19
ЧИЩЕННЯ ТА ОБСЛУГОВУВАННЯ
LED
! LED-, -
,
.
РОЗТАШУВАННЯ ПРОДУКТІВ У ПРИСТРОЇ
• ’ ,
.
,
.
• .
. -
, -
.
• :
, . -
.
• ’ ( ),
1-2 , (
) — ,
.
• .
-
.
:
, .
!
’ .
• .
• ,
.
• ,
.
• , .
.
• .
.
, -
.
•
.
.
!
.
•
•
; -
.
• (
) ,
.
•
• , , -
.
• . -
-
.
• . -
5 , .
• -
, -
.
• -
-
-
.
• -
.
• ,
’, -
.
1
( )
' 2 3 .
,
( )
3 4
1
,
,
1
:
1. ’ ,
2. (A), ,
.
3. () , 15 .
4. .(C)
•
.
• ,
-
. -
.
•
, ,
i 4 24 .
• , ,
.
• , (’, , ) ,
, .
• . -
’ .
• ,
. ,
.
• , , -
, .
•
, . -
, .
•
,
. !
•
, , ,
. -
, ;
.
•
. -
18 , 32°C,
13 . -
.
— .
,
. ! -
.
!!! -
, . -
, .
• (, , , , , ,
, , , , , , )
.
, ,
, .
• , .
, , ,
; -
.
-
()
-
, -
’ 10 - 13
, ’ 12
’ 6 - 8
, -
’ 12
, , -
’ 8 - 10
’ 6 - 9
,
-
10 - 12
2 10 - 12
12
8 - 10
4 - 6
8 - 12
10%
12
, ,
8 - 12
'
-
()
6 - 8
6 - 8
6 - 8
6 - 8
'
1 - 3
() 1 - 3
/ ,
'
-
()
4 - 6
4 - 6
, ,
2,5 ,
6 - 8
(-
, , , )
-
; -
2
(-
, ,
)
4
(,
, , ) 2 - 4
,
4 - 6
, -
2 - 3
3
: ’
, ’. ’ ,
.
20
РОЗТАШУВАННЯ ПРОДУКТІВ У ПРИСТРОЇ
Table of contents
Languages:
Other Freggia Refrigerator manuals
