FRENETIK Core 1 User manual

PoE+ injector
V1.1 - 03/2020
User’s manual
Core 1

User’s manual - Core 1 V1.1 03/2020 2/4
CORE 1 - USER MANUAL Page
1. Carton Contents 2
2. Commissioning steps 2
3. Technical specifications 3
4. Overview 3
1. Carton Contents
- 1 PoE+ Core 1 injector
- 1 power cord
- 1 user manual
2. Commissioning steps
1 Connect the power cord to the PoE+ power injector and then a power outlet.
The Power LED will light up.
2. Connect the network cable from the switch to the Data/In port.
3. Connect the cable to the P+D/OUT port to supply data and power to the device
(direct connection or via a possible splitter).
Power
Power +Data
Data In
Input 100-240V AC
Power
Power +Data
Power Out
Data In
Data Out
Input 100-240V AC

User’s manual - Core 1 V1.1 03/2020 3/4
3. Technical specifications
Ref. PS110DP
Standards PoE 4, 5, 7, 8
Network Cables 100BaseTx Cat. 5 UTP/STP
10BaseT Cat. 3, 4, 5 UTP/STP
Power PoE input 30W
Dimensions 42 × 64 × 145 mm (H x W x D)
Weight 0,18 kg
Operating temperature range 0 to 40°C
Humidity 10 to 90% (non-condensing)
Certifications FCC Class A, CE
4. Overview
1 2 3 4
5
1. Mains power indicator diode
2. PoE power supply indication diode
3. Data output connector + PoE
4. Data input connector
5. Mains power connector
