Fresco Allure Connect-12 User manual

Outside Zone
2.25m
60cm
Outside Zone - Area outside of Zone 2
Safety & Care
Wear suitable eye protection when drilling. Take care when using power tools near water - the use of a RCD
(Residual Current Device) is advised. Beware of hidden cables or pipes when drilling. It is recommended that a
piece of masking tape is applied to the wall before marking out the xing holes to help prevent the drill slipping
when drilling the xing holes.
Allure Mirrors are manufactured in 5mm glass, do not strike glass surfaces with hard or sharp items. Do not place
very hot or very cold items against the glass. Do not cover the glass when the mirror is in use.
Ensure that the wall surface is of suitable strength to hold the weight of the mirror.
Installation Areas
All Allure Connect Mirrors are
CE approved & IP44 rated and
are suitable for installation in a
bathroom within “Zone 2” or the
“Outside Zone”. See diagram -
Allure Connect-12 Mirror Instructions
Features -
Bluetooth Speakers
LED Light Frame
Infra Red Dimmer Switch
De Mist Function
Shaver Socket
Size -
Allure Connect-12 (S429)
1200 x 800mm wide Landscape

Installation
All mirrors should be installed by a qualied electrician
e mirrors are hung on the wall using a z-prole with the additin of 2 keyholes cut in the aluminium frame for
secure xing mirror to the wall.
e measurements for these are given in the diagrams below -
1100mm
A
B
93.5mm
677.5mm
C
Determine the position and height at which you want to
install the mirror.
Place the z-prole on the wall 93.5mm below the height
you want for the top of the mirror, orientated as diagram
A, and central on the wall.
Check the z-prole is level and mark the holes and drill
and push in raw plugs and screw the z-prole to the wall
Mark up and drill hole positions for the botton hanging
screws as shown on diagram C. Push in raw plugs and x
screws leaving 2-3mm of screw thread protruding from
the wall.
Ensure the electricty supply to the cable in the wall is
switched o and connect the wire from the back of the
mirror to the power cable using a suitable terminal block.
Hang the mirror on the z-prole & the 2 bottom xing
points.
Operating the Mirror & Speakers
To connect your mobile device to the speakers, open the
bluetooth settings on your device and select “mirror BT”.
When you have nished listening to your music you need
to diconnect your mobile device from the mirror so that
others can connect.
To operate the mirror light and demist
function wave your hand over 70-
80mm in front of the infra red sensor.
To adjust the brightness hold you hand
70-80mm from the sensor and then
remove hand at the desired brightness.
e
brightness will cycle from 10% to
100% and back to 10% until you re-
move your hand.
To turn the lights o wave your hand
in front of the sensor.
Allure
Connect-12
