FrightProps HB-1ABV User manual

JUMPER PAIRING
BUTTON
NOTE: Signal Interlock is not usable with these units
HOW TO PROGRAM THE 1-RELAY WIRELESS TRIGGER
With power connected to the relay board hold the small
white button on the board down until the led turns on
and turns o. Keep holding it down until it ashes. 1
ash will put it in momentary mode. 2 ashes will put
it in latching mode, 3 ashes will put it in Inter-lock /
latched mode (this mode requires a remote with 2 but-
tons. One turns it on and two turns it o) and 4 ashes
will put it in the delay mode
PAIRING THE REMOTE
Now you must pair the remote with the base. Hold the white button
until the led comes on and release the button. Than press the remote
.button. The led will ash twice and is now paired with the base

PAIRING
BUTTON
+ DC
GND
NO COM NO COM

SETTING THE RELAY FUNCTION USING THE JUMPERS
You can set the functions of the relays by adjusting the jumper on the circuit board. e following are the
settings for each jumper position.
NO JUMPER - Toggle 1-12 - Turning on any relay turns o all other relays.
A L - All Relays Momentary - Relay coresposning to remote button will stay on only as long as remote
button is held down
B L - All Relays Latching - Relay coresposning to remote button will stay on once button is pressed and
turn o once button is pressed again.
C L - Relays 1-6 Momentary, Relays 7-12 Latching
AL and BL - Relays 1-6 Latching, Relays 7-12 Toggle
AL, BL, and CL - Relays 1-4 Momentary, Relays 5-8 Latching and Relays 9-12 Toggle
BL and CL - Relays 1-6 Momentary, Relays 7-12 Latching
AL and CL - Relays 1-2 Momentary, Relays 3-6 Latching, Relays 7-12 Toggle in Pairs (7/8, 9/10, 11/12).
Pairing the Remote
To pair the remote, press the button on the relay board and then press any button on the remote.
