Frigidaire FAA085P7A User manual

M40L0002.eps M40C0002.eps M40M0001.eps 2202049158.eps
Product No. FAA085P7A1 FAA085P7A2 FAA085P7A3 FAA085P7A4 FAA085P7A5 FAA085P7A6
Series MS II MS II MS II MS II MS II MS II
Color N/A N/A N/A N/A N/A N/A
Volts 115 115 115 115 115 115
BTU-Cooling 8000 8000 8000 8000 8000 8000
Owner's Guide 220201d011 220201d011 220201d011 220201d011 220201d011 220201d011
Installation Instructions msinstalleng msinstalleng msinstalleng msinstalleng msinstalleng msinstalleng
Market North America North America North America North America North America North America
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995438701
05/06/07
(EN/SERVICE/WC)
099
ROOM AIR
CONDITIONER
Model No.
FAA085P7A
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995438701 FAA085P7A
06/05 2
CABINET, FRONT, CONTROLS

FAA085P7A Publication No: 5995438701
# Functional Parts 3 06/05
* Non-Illustrated Parts
CABINET, FRONT, CONTROLS
Model Index: AFAA085P7A (FAA085P7A1)
BFAA085P7A (FAA085P7A2)
CFAA085P7A (FAA085P7A3)
DFAA085P7A (FAA085P7A4)
EFAA085P7A (FAA085P7A5)
FFAA085P7A (FAA085P7A6)
POS. NO PART NO. DESCRIPTION
1 5304446386 A B C D E F Base, unitchassis
2 5304437068 A B C D E F Rail, shutter track, bottom
3 5304437055 A B C D E F Frame, shutter panel, LH
4 5304437052 A B C D E F Retainer, shutter lock
5 5304437053 A B C D E F Shutter, accordion panel
6 5304437057 A B C D E F Retainer, shutter mount, cabinet sides
7 5304446348 A B C D E F Cabinet, wrapper/sleeve
8 5304437069 A B C D E F Rail, shutter track, top
9 5304437054 A B C D E F Frame, shutter panel, RH
10 5304437063 A B C D E F Front Assembly, complete panel, includes
11 5304437059 A B C D E F Panel, front grille, tilt-out
12 5304437062 A B C D E F Filter, air, plastic frame
13 5304437058 A B C D E F Frame, front assembly
14 5304437061 A B C D E F Louver, horizontal
15 5304437060 A B C D E F Louver, vertical
17 5304436536 A B C D E F Enclosure, control, pcb display
17* 5304436541 A B C D E F Control Panel, display, electronic
18 # 5304437074 A B C D E F PC Board, display/input
19 5304446346 A B C D E F Panel, control mounting board
20 # 5304436532 A B C D E F PC Board, control/power
21 # 5304436543 A B C D E F Sensor, ambient temp
22 # 5304436542 A B C D E F Sensor, evap temp, defrost
23 5304436530 A B C D E F Strap, capacitor mtg.
24 # 5304436528 A - - D - - Capacitor
24 # 5304436527 - B C - E F Capacitor
25 5304437070 A B C D E F Control Box
26 # 5304436595 A B C D E F Remote Control, transmitter
27 # 5304436529 A B C D E F Ionizer
* 5304458022 A B C D E F Hardware Kit, installation

Publication No: 5995438701 FAA085P7A
06/05 4
COOLING & AIR FLOW SYSTEMS

FAA085P7A Publication No: 5995438701
# Functional Parts 5 06/05
* Non-Illustrated Parts
COOLING & AIR FLOW SYSTEMS
Model Index: AFAA085P7A (FAA085P7A1)
BFAA085P7A (FAA085P7A2)
CFAA085P7A (FAA085P7A3)
DFAA085P7A (FAA085P7A4)
EFAA085P7A (FAA085P7A5)
FFAA085P7A (FAA085P7A6)
POS. NO PART NO. DESCRIPTION
1 5304446349 A B C D E F Scroll, blower housing, bottom
2 # 5304446350 A B C D E F Blower Wheel, centrifugal fan
3 5304446351 A B C D E F Scroll, blower housing, top
6 5304446355 A B C D E F Cover, blower scroll, top
7 # 5304437049 A B C D E F Fan Blade, propeller, axial flow
8 # 5304447863 A B C D E F Shroud, fan housing
9 # 5304446392 A - C - - F Motor, fan
9 # 5304446393 - B - D E - Motor, fan
11 # 5304446373 A B C D E F Evaporator
12 # 5304446378 A - - D - - Capillary Tube
12 # 5304446385 - B C - E F Capillary Tube
13 # 5304446388 A - - D - - Discharge Tube
13 # 5304446391 - B C - E F Discharge Tube
14 # 5304437077 A - - D - - Compressor Assy
14 # 5304446390 - B C - E F Compressor Assy
15 # 5304446387 A - - D - - Condenser
15 # 5304446375 - B C - E F Condenser
16 # 5304446381 A - - D - - Suction Tube
16 # 5304446389 - B C - E F Suction Tube
* # 5304446361 A B C D E F Power Cord, electric, 115 V

Publication No: 5995438701 FAA085P7A
06/05 6
WIRING DIAGRAM
2202019158
