8. The site must allow for the easy
removal of the connector pipe and
drain hose.
9. The unit must be installed at a site
protected from direct sunlight.
Precautions for Installation
Installation at the following sites may cause problems. If you must inevitably install
2. Sites with a high concentration of salinity, such as coastal areas.
3. Sites with sulfuric gas, such as hot water springs.
4. Sites with high frequency equipment, such as wireless equipment, welding
machines and medical installations.
5. Sites with flammable gases or volatile material.
6. Sites with special environmental conditions.
7. Laundry rooms.
Indoor Unit
1. The unit must be installed at a site
that does not obstruct the flow of
air.
2. The site must support the weight of
the indoor unit.
3. The site must be easily accessible
for maintenance and replacement
of the air filter.
4. The site must allow for the
necessary space around the indoor
figure.
that the unit be installed at the
flammable gases.
Choosing the installation site
More
More
More
More
Choosing the installation site
the unit at one of these sites, please consult your local distributor beforehand:
1. Sites with machine oil.
unit, as shown in the sideward
meter) between the unit and radio
5. There should be at least 3 feet (1
7. The indoor unit must be at least 8.2
ft(2.5meters) from the ground.
6. It must be far from fire, smoke or
center.
or television devices. It is ideal
than 6"
than
6"
than 8 .2'
than 6"
06
Installation warnings:
Installation
1. Carefully read the installation manual before beginning.
2. Follow each step as shown.
3. Observe all local, state, and national electrical codes and by qualified,
licensed, authorized personnel only.
4. Pay attention to danger and safety notices

Outdoor Unit
1. The outdoor unit must be
installed at a convenient site
that is not exposed to strong
winds. The site should be dry
and well ventilated.
2. The site must support the weight
of the outdoor unit and allow
for vertical installation.
3. There must not be the possibility
of increased noise and vibration
at the site.
4. The unit must be installed at a
site where the noise produced
by its operation and air
discharge does not disturb the
neighbors or animals.
5. The site cannot have any
leakage of flammable gases.
space around the unit, as shown
access the installation site.
More
More
More
More
More
Choosing the installation site
in the figure.
6. The site must provide enough
7. Children must not be able to
07
than 1'than 1.65' than 1'
than 1.65'
than 6.6'

Parts list
3
1
4
Indoor unit
Outdoor unit
Parts list
PART NAME
Installation plate
Drain Joint
QTY.
1
2
3
41
1
1
Remote controller
Connecting
pipe
assembly
Liquid side
Gas side
NUMBER
(capacity < 18000 Btu's)
(capacity < 12000 Btu's)
(capacity > 24000 Btu’s)
Ø1/4"
Ø1/2"
Ø3/8"
Ø5/8"
Self-tapping scr
ew A #7X1"
5
08
Drainage
Plug
6
capacity = 18000 Btu's
capacity = 21500 Btu s
3
2
capacity < 18000 Btu's
capacity > 24000 Btu’s
5
10
6
8
7
'
7
8
Remote Controller holder 1
2
Self-tapping screw B #4X3/8"
2
1

Attention
1. This illustration is for explanation purposes only.
4
3
1
Indoor unit
Outdoor
unit
5
6
Air filter
More
A
BC
Parts list
2. Copper tubes must be insulated independently
More than 6.6'
More than 1'
More than 1.65'
than 1.65'
More than 6"
More than 6"
More than 6"
09
2
6
8
7

Indoor unit installation 10
1.58''
7.91'' 5.31''
1.58''
A
B
(A:33.31" B:10.83")
=18000 Btu's (A:36.97" B:11.73")
Indoor unit outline
Installation plate
the ceiling
from the wall from the wall
Refrigerant pipe
6" or more from
6" or more
hole (right) Ø 2.56"
6" or more
3.39"
4.21"
12000 Btu's
<
Indoor unit installation
Installation plates and dimensions
3.39"
4.21"
Refrigerant pipe
hole (right) Ø 2.56"
Refrigerant pipe
hole (right) Ø 2.56"
from the wall
6" or more
Installation plate
the ceiling
6" or more from
Refrigerant pipe
hole (right) Ø 2.56"
Indoor unit outline
from the wall
6" or more
A
B

Indoor unit installation
11
Attention
Fixing the Installation Plate
Drilling the Hole
1. Install the installation plate
horizontally over the structural
parts on the wall using the spaces
indicated on the plate, as shown
2. In the case of tiled, concrete or
diameter holes. Place anchorage
supports for the appropriate
assembly screws.
3. Fix the installation plate to the
1. Determine the position of the
installation plate and drill the
downward.
2. Always use a pipe cover with an
Installation plate
Fit the Installation Plate and drill holes
in the wall according to the wall
structure and corresponding mounting
points on the installation plate
(Dimensions are in “mm” unless
otherwise stated).
Wall
Indoor unit Outdoor unit
in the figures above.
A type screws.wall with eight
hole for the pipes using the
pipe hole so that it is tilted slightly
opening when drilling.
similar walls, create 0.2"
0.2"-0.28"
4. At all times securing to the wall
studs is recommended.
1.97'' 1.97''
3.94'' 4.88''
=21500 Btu's (A:39.69" B:12.40")
Refrigerant pipe
hole (right) Ø 2.56"
from the wall
6" or more
Installation plate
the ceiling
6" or more from
Refrigerant pipe
hole (right) Ø 2.56"
Indoor unit outline
from the wall
6" or more
A
B

Connective pipe and drainage installation
Drainage
1. Run the drain hose sloping
downward. Do not install the drain
2. When connecting extension drain
hose, insulate the connecting part
of extension drain hose with a
shield pipe, do not let the drain
hose slack.
Connective pipe
1. For the left-hand and right-hand
piping, remove the pipe cover from
2. For the rear-right-hand and rear-left-
hand piping, install the piping as
connective pipe.
Indoor unit installation
1. Pass the piping through the hole in
the wall.
2. Put the upper claw at the back of
the indoor unit on the upper hook of
the installation plate, move the
indoor unit from side to side to see
that it is securely hooked.
Upper hook
Lower hook
Fastening the Indoor Unit
Do not put the end
of drain hose into water.
Do not block
water flow
by a rise.
Do not block
water flow
by a rise.
piping
Pipe cover
(left)
Pipe
holder
Pipe cover
(right)
Right piping
Connective
pipe
Indoor unit
outline
Rear right
piping
Rear left
Left piping
hose as illustrated sideward.
the side panel. The pipe cover
must be kept as it may
conditioner
to any other place.
be used
the air
shown in the sideward figure. Bend
the connective pipe to be laid at
the wall. Fix the end of the
when relocating
1.69"
a height of 1.69" or less from
12

Attention
Piping and wrapping
1. Bundle the tubing, connecting
cable, and drain hose with tape
2. Because the condensed water
from rear of the indoor unit is
gathered in ponding box and is
anything else in the box.
1. Connect the indoor unit first, then the outdoor unit.
2. Do not allow the piping to let out from the back of the indoor unit.
3. Be careful not to let the drain hose slack.
5. Be sure that the drain hose is located at the lowest side of the bundle. Locating
6. Never intercross nor intertwist the power wire with any other wiring.
7. Run the drain hose sloped downward to drain out the condensed water
smoothly.
Cushioning
material
3. Piping can easily be made by
lifting the indoor unit with a
cushioning material between the
indoor unit and the wall. Get it
out after finish piping.
4. Push the lower part of the indoor
unit up on the wall, Then move
the indoor unit from side to side,
up and down to check if it is
hooked securely.
Indoor unit installation
Indoor unit
Cable
Ponding
box
Pipe room
Wrapping
belt
Drain hose
Connective
pipe
securely and evenly as shown
in the sideward figure.
piped out of room, do not put
connection
at the upper side may cause drain pan to overflow inside the unit.
4. Both of the auxiliary piping should be heat insulation.
13

1. Install the outdoor part of the unit
on a rigid surface to avoid excess
noise and vibration.
2. Direct the air vent toward an area
without obstacles.
especially in areas where it is
frequently windy.
4. If the installation site is exposed to
heavy winds, such as in coastal
areas, place the unit along the
widest part of the wall or use
protective plates.
requirement in the installation
bracket diagram. The installation
wall should be solid brick, concrete
or the same intensity construction,
supporting should be taken.
The connection between bracket
and wall, bracket and the air
conditioner should be firm,
stable and reliable.
6. Be sure there is no obstacle which
Outdoor unit installation
Strong wind
Outdoor unit installation
3. Install the unit at the site where it is
exposed to as little wind as possible,
or action to reinforce, damping
schrubs or bushes.
blocks radiating air, including
14
5. If suspended installation is needed,
local or servicer. The installation
purchase kit No.EA140S from your
bracket should accord with technique

Settlement of outdoor unit
Anchor the outdoor unit tightly and
horizontally on a concrete or rigid
Air inlet
Air
inlet
Air outlet
$
%
mount with a bolt and nut 0.39" or 
Aft) B( ft)
Outdoor unit dimension ft(WxHxD)
[[
[[




'
[[
1'
0.32" diameter (Purchased separately).
Chassis
Drain
connection
Drainage
Plug
Condensate drainage of outdoor unit
(no for cooling only)
The condensate and defrosting water formd during heating
in the outdoor unit can be properly discharged by drainage
pipe .
Installation method:Insert the drain connection into one of the
25 holes of the chassis and then connect drainage pipe with
drain nozzle. Insert drainage plugs into the other holes
(Only for 12000Btu's).
Chassis
Drain
connection
12000 Btu's
<%WXV
Ø

15Outdoor unit installation

Flaring work
Main cause for refrigerant leakage is
due to defect in the flaring work.
Carry out correct flaring work using the
following procedure:
1. Cut the pipes and the cable.
A) Use the piping kit accessory or
pipes purchased locally.
B) Measure the distance between the
indoor and the outdoor unit.
C) Cut the pipes a little longer than the
measured distance.
D) Cut the cable 4.9ft longer than the
pipe length.
2. Burr removal
A) Completely remove all burrs from
the cut cross section of pipe/tube.
tube/pipe in a downward direction
as you remove burrs in order to
avoid dropping burrs into the
tubing.
indoor and outdoor unit, then put
them on pipe/tube having
possible to put them on after flaring
work)
Refrigerant piping connection
Refrigerant piping connection
Pipe
Correct Wrong
Oblique Roughness Burr
Pipe
Reamer
Point
down
Flare nut
Cooper tube
Remove flare nuts attached to
B) Put the end of the copper
3. Put nut on.
completed burr removal.(It is not
loop for excess.
Note: Keep original bend so not kinking of the tube occurs.
Unit comes with 16.4' tubing bundle. It is not recommended to cut. If too long,
16

4. Flaring work.
die in the dimension shown in
the table below.
OUTER
Connection Adjustment
1. Align the pipes to be connected.
OUTER TIGHTENING
Caution: Excessive twisting may
break the nut, depending on the
installation conditions.
Refrigerant piping connection
Bar
pipe
Handle
Clamp
handle
Yoke
Red arrow mark
Flare
nut
Pipings
Indoor unit
tubing
Copper
A (inch)
Max. Min.
DIAMETER (inch)
0.051
0.063
0.071
0.095
0.028
0.039
0.039
0.087
2. Screw the flare nut with your
fingers, and then tighten it with
a spanner and torque wrench,
as shown in the following figure.
ADDITIONAL TIGHTENING
DIAMETER (inch)
Firmly hold copper pipe in a
1/4
3/8
1/2
5/8
1/4
3/8
1/2
5/8
TORQUETORQUE (lbf.in)
139 174
260 304
434 477
651 694
(lbf.in)
17

Note: The supply voltage must be consistent with the rate voltage of the air conditioner.
Electrical work
1. If there is serious safety problem
about the power supply, the
technicians should refuse to install
the air conditioner and explain to the
client until the problem is solved.
2. Power voltage should be in the
range of 90%~110%of rated
voltage.
3. The circuit protector and main
power switch with a 1.5 times
capacity of Max. Current of the unit
should be installed in power circuit.
4. Ensure the air conditioner is
grounded well.
5. According to the attached
Electrical Connection Diagram
located on the panel of the
outdoor unit to connect the wire.
6. All wiring must comply with local
and national electrical codes and
be installed by qualified and
skilled electricians.
7. An individual branch circuit
used only for this air conditioner
must be available. See the
following table for suggested wire
sizes and fuse specifications:
Electric safety regulations for the initial Installation
Electrical work
INPUT RATED AMP
Switch / Fuse
POWER SUPPLY SIZE
CAPACITY
<9000 Btu's
9000 Btu's <capacity <12000 Btu’s
> 12000 Btu's
115V~/ 60Hz
115V~/ 60Hz
208/230V~/ 60Hz
25A/25A
25A/25A
25A/25A
AWG WIRE
1
12
18
2
12

1. The inside and outside connecting
cable can be connected without
removing the front grille.
2. Connecting cable between indoor
unit and outdoor unit shall be
approved polychloroprene
sheathed flexible cord, type
cord.
3. Lift the indoor unit panel up,
remove the electrical box cover by
loosening the screw.
4. Ensure the colour of wires of
outdoor unit and the terminal Nos.
are the same to the indoors
respectively.
5. Wrap those cables not connected
with terminals with insulation
tapes, so that they will not touch
any electrical components. Secure
the cable onto the control board
with the cord clamp.
Connect the cable to the indoor unit
Electrical work
cover
Electrical box
designation 16AWG or heavier
Code wire
1.57"
0.39"
19
Terminal block of indoor unit
N(1) 2 3
To Outdoor Unit
C
Cable

Remove the electrical control
board cover from the outdoor unit
by loosening the screw.
2. Connect the connective cables to
the terminals as identified with
their respective matched numbers
on the terminal block of indoor
and outdoor units. The connective
cable to power supply shall be
approved polychloroprene
sheathed flexible cord, type
designation
or heavier cord.
3. Secure the cable onto the control
board with the cord clamp.
4. To prevent the ingress of water,
cable as illustrated in the
installation diagram of indoor and
outdoor units.
5. Insulate unused cords (conductors)
Connect the cable to the outdoor unit
6FUHZ
&RYHU
form a loop of the connective
with PVC -tape. P rocess them so
they could not touch any electrical
or metal parts.
Terminal block of outdoor unit
N(1) 2 3 L N

To indoor unit To power supply
Electrical work 20
Cable
1.57"
0.39"
Code wire
12AWG

1. Never fail to have an individual power circuit specifically for the air
conditioner. As for the method of wiring, be guided by the circuit diagram
posted on the inside of control cover.
liable to come loose from vibrations to which the unit is subjected during
the course of transportation. Check them and make sure that they are all
tightly fastened. (If they are loose, it could cause burn-out of the wires.)
3. Specification of power source.
4. Confirm that electrical capacity is sufficient.
5. See to that the starting voltage is maintained at more than 90 percent of
the rated voltage marked on the name plate.
6. Confirm that the cable thickness is as specified in the power source
specification.
7. Always install an earth leakage circuit breaker in a wet or moist area.
switch, which will damage the contact point, fuse breaking, disturbance of
9. The means for disconnection from a power supply shall be incorporated
in each active (phase) conductors.
Caution
After the confirmation of the above conditions, prepare the wiring as follows:
Air purging
below:
1. Pressure in the system rises.
2. Operating current rises.
4. Moisture in the refrigerant circuit
may freeze and block capillary
tubing.
5. Water may lead to corrosion of
parts in the refrigeration system.
between the indoor and outdoor unit
moisture from the system.
Electrical work and air purging
2. The screws which fasten the wiring in the casing of electrical fittings are
8. The following would be caused by voltage drop: vibration of a magnetic
the normal function of the overload protector.
Air and moisture in the refrigeration system have undesirable effects as indicated
Therefore, the indoor unit and tubing
in the fixed wiring and have an air gap contact separation of at least 1/8 inch
must apply leakage test and be evacuated
to remove any noncondensables and
3. Cooling or heating(only for
models with heating function)
efficiency drops.
21

Air purging with vacuum pump
1. Check that each tube(both liquid and gas side tubes) between the indoor and
outdoor units have been properly connected and all wiring for the test run has
been completed. Remove the service valve caps from both the gas and the
liquid side on the outdoor unit. Note that both the liquid and the gas side
service valves on the outdoor unit are kept closed at this stage.
2. When relocating the unit to another place, perform evacuation using vacuum
pump.
3. Pipe length and refrigerant amount:
the stopper. Do not try to open it further.
Air purging
Half union
Refrigerant
AC
D
B
Packed valve
Gas
Indoor unitOutdoor unit
1. Operation of opening packed valve: Open the valve stem until it hits against
2. Operation of closing packed valve: Securely tighten the valve stem with a special
tool. Then securely tighten the valve stem cap with a spanner or the like. Refer to
2
2
Flare nut
Stopper
Cap
Valve stem
Charge port
Valve body
Caution in handling the packed valve integrated in the outlets of
outdoor unit.
for valve stem cap tightening torquetightening torque table in page 17
high side outlet. The low side outlet is shown in the sketch map below.
Note: There is a charging port integrated in the low side outlet, but not in the
Air
purging
Additional amount of
refrigerant to be charged
Connective
pipe length
Use vacuum pump.
Use vacuum pump.
25'~98.4'
Less than 25'
R410a: 0.705ozs (Pipe length-25')
(=18000Btu's)
Use vacuum pump.25'~65.6 R410a: 1.058ozs (Pipe length-25')
( 12000Btu's)
<
'
R410a: 1.058ozs (Pipe length-25')
(=21500Btu's)

Air purging
23
Vacuum pump
Charge hose
Manifold valve
-76cm/Hg
Charge
hose
Handle Lo Handle Hi
Outdoor unit
Indoor unit
When using the vacuum pump
For method of using a manifold valve, refer to its operation manual.
manifold valve.
evacuate. After starting evacuation,
slightly loose the flare nut of the
Lo valve on the gas pipe side and
check if the air is entering (Operation
noise of the vacuum pump changes
and a compound meter indicates
0 instead of minus), then tighten
the flare nut. The procedure verifies
if there are blocks inside the tubes.
valve B about 45
counterclockwise for 6~7
out, then tighten the flare nut
again. Make sure the pressure
display in the pressure indicator is
a little higher than the atmosphere
pressure. This procedure verifies if
the refrigerant goes through the
tubes correctly.
o
manifold valve to the vacuum pump.
seconds after the gas comes
5. Make evacuation for 15 minutes
or more and check that the
compound meter indicates
-7.6 x 10 μmHg (-1x10 Pa).
55
1. Completely tighten the flare nuts at
connection point A, B, C and D.
Connect valve core removal tool to
the charging port, then connect
vacuum hose to valve core tool.
Open the schrader valve.
Note: The schrader valve is inside
the charging port.
2. Connect the other charge hose of
3. Fully open the handle Lo of the
4. Operate the vacuum pump to
packed valve.
9. Securely tighten the cap of the
stems B and A.
8. Fully open the packed valve
fully close the handle Lo of the
manifold valve and stop the
operation of the vacuum pump.
After the evacuation is completed,
6. Turn the stem of the packed
7. Close the schrader valve, then
remove the valve core tool.
Replace the charging port cap.

Electrical safety
Perform the electric safety check after completing installation:
Gas leak check
Soap water method
Apply a soap water or a liquid neutral
detergent on the indoor unit
connection or outdoor unit connections
by a soft brush to check for leakage of
the connecting points of thepiping. If
bubbles come out, the pipes have
Leak detector
Use the leak detector to check for
leakage.
Caution
A: Lo packed valve, B: Hi packed valve
C and D are ends of indoor unit
connection.
Outdoor unit
check point
Cover
indoor unit
check point
1. Insulated resistance: The insulated resistance must be more than 2M .
2. Grounding work: After finishing grounding work, measure the grounding
resistance by visual detection and grounding resistance tester. Make sure the
grounding resistance is less than 4 .
3. Electrical leakage check (performing during test running): During test operation
after finishing installation, the serviceman can use the electric probe and
multimeter to perform the electrical leakage check. Turn off the unit
immediately if electrical leakage happens. Check and find out the solution
ways till the unit operatesproperly.
Electrical safety and gas leak check
leakage point.
2
4

Test running
Perform test operation after completing gas leak check at the flare nut
connections and electrical safety check.
1. Connect the power, press the ON/OFF button on the remote controller to
turn the unit on.
cannot be controlled by the remote controller to run in cooling mode,
manual operation can be taken. Manual operation is used only when the
remote controller is disable or maintenance necessary.
Test running
Manual control button
Auto/OFF
o
F), the unit3. When the ambient temperature is too low(lower than 63
function), AUTO and FAN to check if all the functions work well.
2. Use the MODE button to select COOL, HEAT(Only for models with heating
25
