Frigidaire FAC064L7A1 User manual

ROOM AIR CONDITIONER
Model No.
FAC064L7A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309341601
OWNER’S GUIDE - # 309000825
ENERGY GUIDE - # 309367454
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
PRODUCT NO. BASE MODEL NO. VOLTS BTU-COOLING
FAC064L7A1 FAC064L7A 115 6100 BTU
MARKET
North America
Publication No.
5995370953
020425
-EN/SERVICE /BLT
345

04/02 2
Publication No. FAC064L7A1
5995370953
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 04/02
* = Non-Illustrated Parts
FAC064L7A Publication No.
5995370953
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309643602 Cabinet
* 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
8 309640204 Louver Assy,Includes8&9
8 309639302 Louver,horizontal
9 309647201 Louver,vertical ,with link
12 309343501 Filter-air,7.12 x 17.31 ,no frame
17 309640104 Front-cabinet,4 way ,complete assy
19 309340803 Overlay
25 309328603 Door,fresh air vent
26 309638201 Handle,vent door
26A 309330201 Detent,vent
38 309646301 Panel,cabinet front
43 309646401 Frame,cabinet front
70 309342201 Enclosure,elec control mt
78 309342604 Remote Control,transmitter ,with batteries

04/02 4
Publication No. FAC064L7A1
5995370953
CONTROLS

# = Fast-moving Parts 5 04/02
* = Non-Illustrated Parts
FAC064L7A1 Publication No.
5995370953
CONTROLS
POS. NO PART NO DESCRIPTION
7 # 309643801 Control Box
10 309643702 Bulkhead
10* 309111201 Grommet,wire protector
12 5304413782 Holder,thermistor ,w/seal
13 # 5304426449 Capacitor,250 V ,35+5 mfd
14 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,grounding
15 309351901 Strap,capacitor mtg.
17 # 309343101 Cord-electric power,18 AWG ,115 V
70 309342201 Enclosure,elec control mt
71 # 309350401 PC Board,power ,w/temp sensor
72 # 309350402 PC Board,input
72* 5304417643 Ribbon Protector
74 5303301590 Screw,6-20AB x 0.38
75 5304413781 Support,PC board
76 309111601 Transformer,120/12 Volt

04/02 6
Publication No. FAC064L7A1
5995370953
AIR HANDLING PARTS

# = Fast-moving Parts 7 04/02
* = Non-Illustrated Parts
FAC064L7A Publication No.
5995370953
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 309646202 Fan Blade,with clamp
2 3202975 Screw,10-16AB x 0.72 ,square drive
3 309643901 Housing,fan shroud
4 5303303759 Seal,bottom
5 5304421913 Seal,top
6 08007481 Nut,Keps ,motor mtg ,(4)
8 # 309645002 Motor,fan
10 309643702 Bulkhead
11 # 309643302 Blower Wheel,8mm hub
12 327161302 Clamp,blower wheel mt ,compression
15 309642901 Housing,blower scroll ,Extended
16 309100201 Clip,evap/bulkhead
20 309643004 Plate,housing/scroll

04/02 8
Publication No. FAC064L7A
5995370953
COMPRESSOR PARTS

04/02 9
FAC064L7A Publication No.
5995370953
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 309616921 Compressor
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 3201668 Gasket,terminal cover
7 5304405245 Cover,compr terminal
8 # 5303317553 Overload Protector
9 3201670 Nut,terminal cover
10 # 5303317601 Start Assist Kit,compressor
11 # 309637507 Evaporator
12 # 309645303 Condenser
13 # 309642801 Tray,evap drip
14 309644003 Base,compressor mt. ,with studs
16 # 5308017120 Capillary Tube,45 inch long ,cut to length
17 # 5300265301 Drier-filter,service kit
17* 5303290357 Strainer
19 5303002664 Washer,compressor mtg
19* 309112501 Washer,metallic

04/02 10
Publication No. FAC064L7A1
5995370953
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 04/02
* = Non-Illustrated Parts
FAC064L7A Publication No.
5995370953
POS. NO PART NO DESCRIPTION
1 5304407729 Seal,window stuffer
2 5303211056 Bracket,sash lock
4 309644901 Frame Extension Kit,accordian ,LH & RH ,Includes4&14
4 5304414120 Frame,cab extension ,LH
5 08016226 Seal,top rail/cab
14 5304414121 Frame,cab extension ,RH
15 309626504 Closure,accordian type ,window mount
16 5304417362 Rail,retainer ,top
17 3002803 Screw,wood, type 17 ,10-12 x 0.750
18 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
20 5304411997 Screw,8-18 x 0.750
22 5304403252 Rail,retainer ,bottom
23 3001806 Screw,23(T) ,10-32 x 0.310
24 5308002974 Screw,wood,type 17 ,8-15 x 0.500
WINDOW MOUNTING PARTS

04/02 12
Publication No. FAC064L7A1
5995370953 WIRING DIAGRAM
